Rico CNC User manual

15 STEPS TO
MAKE SURE A
SAFE CNC
WOODTURNING
WORK
RICO CNC
x

- RicoCNC
Step 1
Before operating the CNC wood lathe machine , the workpiece
should be firmly fixed . Tighten the tailstock locking bolts and
thimble .
Then adjust the position of the tool holder device , it should be set
near the center of the workpiece by 2 - 3mm . If the distance
between the tool holder and the workpiece is too large , it is easy
to feed too much and cause accidents .

After the workpiece is well clamped ,
use hands to adjust the lathe chuck to
the right position , and check whether
tool holder device and tools is firm ,
then turn on the power to test .
Step 2
RicoCNC

Step 3
For wookpiece which exceeds 100mm , the tailstock
thimble must be used to fix it during processing ;
RicoCNC

Step 4
Select a suitable wood lathe knife, and when
installing wood lathe cutter, the length of the tool
holder bar protruding from the tool holder should be
shorter than 50mm, and the tool holder bar must
have the length of 150mm.
The tool must be steady fixed on the tool holder. And
when processing large workpieces (more than
500mm in diameter), the feed rate should not be too
large.
RicoCNC

Step 5
RicoCNC
The amount of feed rate should be appropriate . During rough turning ,
the
feed rate should be smaller to clean corners of workpiece . When
corners
are cleaned , the speed can be increased .

Step 6
Keep the cutting edge of the turning tool
sharp. Using a blunt wood lathe knife will
affect the quality and cause accidents
easily.
RicoCNC

Small workpieces with wood knots are not allowed
to be cut .
Do not cut fast when the workpieces have wood
knots .
Other hard materials within the workpiece must be
removed before turning .
Step 7
RicoCNC

When cutting workpiece with irregular edges
and corners by CNC woodworking lathe
machine , it is recommend to cut off the
corners with aspecial turning tool firstly , then
use normal turning tools for detailed
processing .
Step 8
RicoCNC

Step 9
Grinding the surface of the workpiece with sandpaper can improve
the surface quality.
The sanding should not be pressed by hands too hard.
The sandpaper should move at a uniform speed along the surface of
the workpiece, to prevent surface damage.
RicoCNC

Step 10
The feed rate at the beginning of work should
be set low.
And when turning glue-bonded wood, make
sure is fully glue together before processing
on a lathe.
RicoCNC

Step 11
RicoCNC
The rotating speed of CNC lathe machine is determined by the dimensions and
materials of the processed parts.
It should not be too fast to prevent workpiece flying out and hurt people;

RicoCNC
Select a right spindle speed. Turn large-scale workpieces at a
slower speed, because large workpieces have large inertia when rotating,
fast turning is easy to cause accidents.
When turning small workpieces, the speed can be appropriately faster, and the
faster turning speed can obtain a smooth and clean workpiece surface. And it is
best to cut the square workpiece near round shape at first.
Step 12

Step 13
Strictly abide by the safe operation
rules of CNC woodworking lathe.
Before starting the machine, check
whether all parts are in normal
condition.
RicoCNC

RicoCNC
Step 14
The operator must oil and clean the movable parts of the equipment once a day.

Step 15
The mechanics perform maintenance
on each transmission part regularly.
RicoCNC

For more information about CNC
woodturning tools, please contect
us !
