Ridder RB50EPLUS User manual

Ridder Drive Systems
Lorentzstraat 36-38 3846 AX Harderwijk
P.O. Box 360 3840 AJ Harderwijk
the Netherlands
T+31 (0)341 416 854 F+31 (0)341 416 611
Iwww.ridder.com [e-mail]
Product Manual
Ridder RB50Eᵖˡᵘˢ Tube motor
265041EN - 2017.06 - V01
Original Product Manual

TABLE OF CONTENTS
1. GUIDELINES, STANDARDS AND CONDITIONS
1.1 Applicable guidelines and standards 3
1.2 Approved personnel 3
1.3 Warning about discouraged use 3
1.4 Warranty provisions 3
2. SYMBOLS, WARNINGS AND SAFETY INSTRUCTIONS
2.1 Explanaon of warnings (ISO 3864-2) 3
2.2 Precauons and safety instrucons 4
2.3 Residual risks 5
2.4 Symbols and abbreviaons 5
3. PRODUCT DETAILS
3.1 Descripon 6
3.2 Applicaon 7
3.3 Dimensions 8
3.4 Technical specicaons 8
3.5 Idencaon 9
4. INSTALL INSTRUCTIONS
4.1 Special tools and equipment 9
4.2 Installaon - Condions and starng points 10
4.3 Installaon guiding prole and guiding unit 12
4.4 Aach the tube motor to the guiding unit 16
4.5 Aach the cable carrier 17
4.6 Aach the coupling piece to the tube motor 19
4.7 Aach the screen cloth and winding tube 20
5. CONNECT INSTRUCTIONS
5.1 Electrical material 22
5.2 Protecon - Condions and starng points 22
5.3 Wiring diagram: Single 24
5.4 Wiring diagram: Parallel 25
6. USER INSTRUCTIONS
6.1 Usage - Condions and starng points 26
6.2 Operaon 27
7. COMMISSIONING INSTRUCTIONS
7.1 Commissioning - Condions and starng points 27
7.2 Special tools and equipment 28
7.3 RB50Eᵖˡᵘˢ limit-switch system 28
7.4 Seng the end posions 29
7.5 Erasing one end posion 30
7.6 Erasing two end posions at the same me 31
8. MAINTENANCE INSTRUCTIONS
8.1 Maintenance general 32
8.2 Maintenance and cleaning RB50Eᵖˡᵘˢ tube motor and accessories 32
8.3 Maintenance and cleaning roller-screen system 32
9. SERVICE
9.1 Troubleshoong 33
9.2 Technical support 34
10. ENVIRONMENT
10.1 Waste disposal 35
10.2 Decommissioning and removal 35
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
2

1. GUIDELINES, STANDARDS AND CONDITIONS
1.1 Applicable guidelines and standards
The Ridder RB50Eᵖˡᵘˢ tube motor complies with the provisions of the European guidelines that
follow:
Machinery Direcve 2006/42/EC | Low Voltage Direcve 2006/95/EC | EMC Direcve 2004/108/EC
The harmonized standards (or parts of these standards) that follow are applicable:
NEN-EN-ISO 12100:2010 | NEN-EN-IEC 60204-1 |
NEN 82079-1 (62079: 2001) | NEN5509 | ISO 3864-2
Make sure that this product is only put into operaon if the system (in which it will be installed)
complies with the requirements of the applicable standards and guidelines.
1.2 Approved personnel
This product manual contains important informaon for installers about the installaon and
commissioning of a RB50Eᵖˡᵘˢ tube motor. Read this product manual and instrucons rst before the
work starts. Approved mechanical and/or electrical installers, with professional competence, must
do all work safe and responsible.
1.3 Warning about discouraged use
The condions that follow are applicable when the RB50Eᵖˡᵘˢ tube motor is used:
• Do not change the construcon of the RB50Eᵖˡᵘˢ
• It is not permied to use the RB50Eᵖˡᵘˢ to li or move people
• Do not let the torque of the RB50Eᵖˡᵘˢ be more than its maximum
• Do not let the duty cycle of the RB50Eᵖˡᵘˢ be more than its maximum.
Refer to §3.2 for a descripon of the intended use of the RB50Eᵖˡᵘˢ tube motor.
1.4 Warranty provisions
For the warranty period and condions refer to the ‘Condions’ secon on our website at www.
ridder.com, or in the Ridder catalogue.
2. SYMBOLS, WARNINGS AND SAFETY INSTRUCTIONS
2.1 Explanaon of warnings (ISO 3864-2)
This product manual contains ps, notes and warnings of dierent degrees of importance. The list
that follows tells what they mean.
Suggeson to perform an operaon more eecve.
May result in damage or problems if an acon is performed
incorrectly.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
3

2.2 Precauons and safety instrucons
Precauons
A roller-screen system can be dangerous. The correct safety precauons are important (safety
barriers, persons cannot touch the winding tube).
• If these precauons cannot be obeyed, then use warnings.
• The responsibility for precauons and warnings lies with the installer of the roller-screen system.
Refer to the, local or naonal, laws and regulaons of the country if a CE cercaon (to show
the safety is made sure) is necessary.
• Parts of the electrical or electronic installaons are connected to dangerous electrical voltages.
Work without professional competence or not obeyed warning instrucons could cause injury
and/or material damage.
• Ridder is not responsible for injury, material damage or consequenal damage if accessories that
Ridder did not make are used.
Safety instrucons
• Do not let persons and not approved personnel be near controls and roller-screen systems which
are in operaon.
• Damaged systems must be stopped immediately unl they are repaired.
• Do not operate roller-screen systems when persons are in the danger zone and can touch the
roller screen.
• Monitor the danger zone when you work with or near the roller screen.
• Stop and de-energize roller-screen systems during maintenance and cleaning work to or near the
system.
• Make sure that there is sucient space between parts that move and adjacent objects.
• Stay away from or safety areas where there is a risk to become caught in the system (tube-motor
guiding, roller screen).
• The torque and the duty cycle of the system must be in the range of the tube motor parameters.
Refer to §3.4/§3.5.
• Use safety barriers, for system parts that move, to a height of 2.5 m from the ground.
• Safety distances must agree with ISO 13857:2008.
May result in minor injury if the hazard is not avoided.
Signicant injury, possible death, if the hazard is not avoided.
Severe injury and possible death if the hazard is not avoided.
If you do not obey the safety instrucons that follow it can be
dangerous and cause injury.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
4

2.3 Residual risks
Automated controls
The Ridder RB50Eᵖˡᵘˢ tube motors are generally used in automac controlled roller-screen systems.
Persons who do work or stay near the roller-screen system must know about that. If persons or their
cloths touch the roller-screen system when it winds up, it could have serious consequences.
Torque guard
The RB50Eᵖˡᵘˢ tube motor has a torque guard. The funcon is to minimize the risk of injury to
persons, damage to the system or damage to the tube motor. Because of the forces in the systems
(in which the tube motor is installed), Ridder cannot be sure that there will be no injury to persons
or damage to the system.
2.4 Symbols and abbreviaons
This secon tells about used symbols and abbreviaons in this manual. The table that follows gives
the descripons.
Symbol Description Symbol Description
ACS Automac control system NNeutral wire
CB Control box with switch components P20 Journal with 2 at sides at a
distance of 20 mm (parallel)
EM, M Electric motor, Motor P71, P72 Automac control contacts (ACS)
FCP Female connecon PE Protecve earth
F11 Fuse RB Tube Motor
ICurrent charging rate at full load in
Amperes (A) SS System switch (put near the tube
motor)
kb Maximal cycle in minutes (min) (kb =
KurzBetrieb/ Short operaon) S21 System switch (to stop the tube
motor)
L1 Voltage source, Phase-1 S111 Manual switch (MC)
MDrive torque in Newton metres (Nm) UNominal mains voltage / supply
voltage in Volts (V)
MCP Male connecon
MPCB Motor Protecon Circuit Breaker U1, V1, W1 Motor connecon
nSpeed of revoluons in revoluons
per minute (/min) VK10 Journal square 10x10 mm
Persons can be in danger of life if they touch a roller-screen system
that turns.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
5

3. PRODUCT DETAILS
3.1 Descripon
The Ridder RB50Eᵖˡᵘˢ tube motor is built-in to a 50 mm aluminium tube (wall thickness 1.5 mm) and
suitable for use with 50 mm winding tubes. Because it is built-in it is possible to wind around the full
width of the tube motor.
The RB50Eᵖˡᵘˢ tube motor is supplied with a 1-phase 2 core asynchronous electric motor for a mains
voltage of 230 V at 50 Hz, an integrated brake and a lubricated gear system. When the tube motor
operates with undervoltage the braking funcon stays good unl a minimum of 190 V. The tube
motor has a thermal protecon system. This prevents the burn-out of the drive if the electric motor
becomes too hot.
The RB50Eᵖˡᵘˢ tube motor is almost enrely water resistant. The protecon classicaon of IP55
makes sure that a damp environment has no eect on the tube motor.
The RB50Eᵖˡᵘˢ tube motor has an electronic limit-switch system, with a range of 38 revoluons, that
counts pulses. These counted pulses are used to stop the tube motor at the end posions and in
case of an overload. It is possible to set end posions with an adjusng set. The electronic limit-
switch system also makes parallel connecon of tube motors possible.
Together with the Ridder guiding unit and a guiding prole, the tube motor can be installed on the
two sides of a roller screen.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
6

3.2 Applicaon
The Ridder RB50Eᵖˡᵘˢ tube motors are designed to be used with roller-screen systems in
greenhouses and livestock houses. For other (dierent) applicaons approval from Ridder Drive
Systems is necessary.
Components RB50Eᵖˡᵘˢ tube motors
To operate the roller-screen system more components are necessary to complete the drive
system. The illustraon and table that follow show an overview of the Ridder components that are
applicable to the RB50Eᵖˡᵘˢ tube motor.
Posion Descripon
1RB50Eᵖˡᵘˢ tube motor
2Guiding unit
3Guiding prole
4Guiding-prole mounng-bracket
5Cable-carrier mounng-set
6Cable carrier
7Cable-carrier mounng-bracket
8 (5) Cable-carrier bracket
9Adjusng switch
10 RMC50 Motor control unit
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
7

3.3 Dimensions
Note: The dimensions and illustraons are approximate. In this product manual shown illustraons
can be dierent than the components and/or systems.
3.4 Technical specicaons
Mechanical
Torque 50 Nm (50 Hz)
Speed (revoluons per minute) 3.5 rpm (50 Hz)
Limit-switch range 38 revoluons (drive sha)
Dimensions (WxHxD) 550032, 550037: 802 x 50 x 50 mm (approximately)
550039: 876 x 50 x 50 mm (approximately)
Tube 50 x 1.5 mm
Weight 4.2 kg
Electrical
Supply voltage 230 V AC, 1-phase (50 Hz)
Maximum current 0.56 A (50 Hz)
Power 126 W
Thermal protecon < 120 °C (248 °F)
Duty Cycle (kb) Applicable for intermient duty, duty class S2, a maximum of 10
minutes
Environment
Protecon rang IP55
802/876*
Ø4
16
772 (l)/846 (l)*
139/213*
167/241*
1.5
Ø50
12
3030
20
10
10
35
A
A(2)
20 30
32
24
11
6
32
9
A(1) 550037 (P20)550037 (P20)
*= 550039
5000
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
8

3.5 Idencaon
This product manual is only applicable to:
• Ridder RB50Eᵖˡᵘˢ tube motors (2016)
• Serial numbers from 200.900.000
• Item numbers: 550032
550037
550039.
Idencaon is possible from the scker on the locaon shown. Refer
to the explanaon that follows on how to read the informaon. For
more informaon on item numbers and models refer to the Ridder
catalogue or website www.ridder.com.
4. INSTALL INSTRUCTIONS
4.1 Special tools and equipment
Ê
EXAMPLE
B50: Diameter of the tube motor in mm
VK10: Journal dimensions in mm (10x10)
Alternaves: P20 - width in mm
50: Mains frequency 50 Hz
230: Mains voltage 230 V
3.5: Number of revoluons drive sha at 50 Hz
E+: Tube motor with electronic limit-switch
50: Torque RB tube motor in Nm
RB: General designaon Ridder tube motors
L772: Length (l) of the tube motor in mm
Alternaves: 846 mm
Make sure that the correct equipment and tools are used.
During mechanical installaon an adjusng switch can be used, if
necessary, to operate the tube motor.
§7.2 gives more informaon about the adjusng switch.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
9

4.2 Installaon - Condions and starng points
Ridder components
• The starng point is that only Ridder components are used.
Roller-screen system
• The starng point is a side-wall roller-screen in a greenhouse. The roller screen is installed on
a side wall between the purlins. For dierent installaons, systems, greenhouses and building
structures this product manual does not give full informaon.
Standard installaon (tube motor 550032/550039)
• The starng point is the standard installaon of a tube motor 550032 or 550039.
For dierent installaons refer to “ALTERNATIVES”.
• The guiding unit (550500) is for the standard VK10 journal.
• The tube of the 550039 tube motor has an extension of 74 mm. This makes the RB50Eᵖˡᵘˢ tube
motor interchangeable with the RB50 tube motor.
Installaon side of the roller screen
• The installaon is possible on the two sides of the roller screen (20).
If installaon on the other side of the roller screen (20) is necessary:
• Turn the assembly 180° around the longitudinal axis of the post (B).
Note: In §4.3 thru §4.7 each me the same installaon side is shown.
550032
550039
4.2.1VK10 (standard installaon)
4.2.2
Put the cable-carrier bracket (8) and tube motor (1) in the correct
posion for the related installaon side of the roller screen.
REFER TO §4.4/4.5. This prevents more subsequent work.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
10

Sloped building-structure
• If the building structure is sloped Ridder recommends to put the tube motor and guiding system
at the highest posion. This makes sure that water can ow away from the tube motor along the
roller screen when it is winded up.
Assembly order
• In the manual an assembly order is given. A dierent order can be used, but you must obey the
guidelines in this manual.
ALTERNATIVES
Replacement - Guiding unit: P20 to VK10 (tube motor 550032/550039)
• The replacement (VK10) for the P20 guiding unit.
• There is a special guiding unit for the two installaon sides of the roller screen.
Tube motor 550037: Adapter VK10 to P20
• The 550037 is a tube motor (VK10) with an adapter set 550411. The head of the tube motor is
changed to P20.
• The tube motor is aached to the guiding unit (P20) with hex socket-screws M4 and a locking
plate.
• There is a special guiding unit for the two installaon sides of the roller screen.
550032
550039
P20 4.2.3 VK10
4.2.4
P20
550037
550411
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
11

4.3 Installaon guiding prole and guiding unit
Prepare the guiding prole.
1. Cut the guiding prole (3) to the correct length l1. Refer to illustraon 4.3.1. The guiding prole
(3) is supplied in standard lengths. The necessary length l1 is usually equal to the distance
between the purlins or between the purlin and foundaon. Refer to illustraon 4.3.3. A small
number of millimeters shorter than l1 is also permied.
2. Drill the holes of ø 6.5mm (4x). Refer to illustraon 4.3.1.
3. Put the guiding unit (2) onto the guiding prole (3). Refer to illustraon 4.3.2.
Put the guiding prole and guiding unit in posion.
4. Put the guiding prole (3) with guiding unit (2) between:
- The purlins (A) and (D)
OR
- The purlin (A) and the foundaon (C).
Use 4 bolts M6 (11) and self-locking nuts (12) to aach the mounng brackets (4) to the guiding
prole (3).
Note: It is recommended to ghten the nuts (temporarily) with your hand.
Refer to illustraon 4.3.3.
5. Put the guiding prole (3) with guiding unit (2) and mounng brackets (4):
- Aligned with the purlin (A)
- At the distance of 41 mm between the guiding prole (3) and post (B).
Refer to illustraon 4.3.3.
6. Find (in the width of the purlin) the posion of the guiding prole (3) where the guiding unit (2)
can move to the highest point. The highest point possible of the guiding unit (2) is related to the
width of the purlin (A).
Refer to illustraon 4.3.4.
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
12

.
l1
4.3.1
6.5mm (4x)
2550
A A
5025
A-A
10.5
6.5 (4x) 19.5
48
27.5
4.3.2
l1
4.3.3
41
4.3.4
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
13

Drill the holes
1. - Drill the holes of Ø9 mm for the bolts M8 (14) (2x or 3x) in the purlin (D).
Refer to illustraons 4.3.5/4.3.8.
OR
- Drill the holes of the necessary diameter (ø) for the anchor bolts M8 (13) (2x or 3x) in the
foundaon (C). Refer to illustraons 4.3.6/4.3.9.
2. Drill the holes of Ø9 mm for the bolts M8 (14) (2x or 3x) in the purlin (A).
Refer to illustraons 4.3.7/4.3.10.
Drill the holes at the correct posions for the related installaon side
of the roller screen.
This prevents more subsequent work. REFER TO §4.4/4.5.
4.3.5 4.3.6
4.3.7
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
14

Install the guiding prole (3) with guiding unit (2)
1. - Aach the mounng bracket (4) with bolts M8 (14) (2x or 3x) and self-locking nuts (15) to the
purlin (D). Refer to illustraon 4.3.8
OR
- Aach the mounng bracket (4) with anchor bolts M8 (13) (2x or 3x) to the foundaon (C).
Refer to illustraon 4.3.9.
2. Aach the mounng bracket (4) with bolts M8 (14) (2x or 3x) and self-locking nuts (15) to the
purlin (A). Refer to illustraon 4.3.10.
3. Fully ghten the 4 bolts M6 (11) and self-locking nuts (12) of the mounng brackets (4).
Refer to illustraons 4.3.8/4.3.9/4.3.10.
Make sure that the guiding unit (2) is put onto the guiding prole (3)
before installaon. REFER TO ILLUSTRATION 4.3.2.
This prevents more subsequent work.
4.3.8 4.3.9
4.3.10
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
15

4.4 Aach the tube motor to the guiding unit
Aach the cable-carrier bracket (8) to the guiding unit (2) at the same time as the tube motor (1).
Refer to view B-B. Refer to view C-C if the installaon is on the other side of the roller screen.
Do the procedure that follows.
1. Align the hole of ø 4 mm (for the split pin 19) with the opening 2.2.
2. Put the cable-carrier bracket (8) in posion with the long side pointed to the guiding unit (2).
3. Put the power cable of the tube motor (1) along the long side of the cable-carrier bracket (8).
4. Move the head (10x10) of the tube motor (1) through the boom hole (8.1) of the cable-carrier
bracket (8).
5. Put the head of the tube motor (1) fully into the hole (10x10) of the aachment bracket (2.1) of
the guiding unit (2). At this me the cable-carrier bracket (8) is also put in the correct posion.
6. Put the split pin (19) in the hole of ø 4mm.
7. Use the split pin (19) and safety the assembly.
(C-C)
(C-C)
4.4.1
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
16

4.5 Aach the cable carrier
The cable carrier prevents that the roller-screen system causes damage to the power cable during
movement of the tube motor.
Do the procedure that follows.
1. Use the pop-rivets (5) to aach the end connector (MCP) to the cable-carrier bracket (8).
2. Make marks of the position of the cable-carrier mounng-bracket (7) on the post (B). This
posion is equal to the length l1 multiplied by 0.5 to 0.6. Drill the holes for the applicable
screws (7.1) or bolts (7.1), into the post (B).
3. Use the screws (7.1) or bolts (7.1) to install the cable-carrier mounng-bracket (7).
4. Use the pop-rivets (5) to aach the end connector (FCP) to the cable-carrier mounng-bracket
(7).
4.5.1
MCP
0.5-0.6 x l1
l1
4.5.2
FCP
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
17

5. Adapt the cable carrier (6) to the correct length. The minimum is length l1 multiplied by 0.5 to
0.6, plus 200 mm.
6. Put the power cable through the cable carrier (6). Start at the FCP end (female connecon) of
the cable carrier (6). Aach this end (6) to the end connector (MCP) at the cable-carrier bracket
(8).
7. Aach the other end of the cable carrier (6) to the end connector (FCP) at the cable-carrier
mounng-bracket (7).
(0.5-0.6 x l1) + 200
4.5.3
MCP
FCP
FCP
MCP
FCP
MCP
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
18

4.6 Aach the coupling piece to the tube motor
The condions and starng points that follow are applicable.
• Use pop-rivets to aach the coupling piece (16) (for a winding tube ø50 mm) to the tube (1.1).
Use a minimum of 4 pop-rivets (18) with a minimum diameter of 5 mm.
Do the procedure that follows.
1. Put the coupling piece (16) into the tube (1.1) of the tube motor (1). Make sure that the distance
into the tube is sucient to drill the holes (d) correctly in the coupling piece (16) and the tubes
(1.1/17). For the four recommended drilling posions (d) refer to illustraons 4.6.1/D-D. Drill
only in the permied part from the open end of the tube (1.1). Note: Drill the holes for the
winding tube (17) in §4.7.
2. Drill one of the holes for the pop-rivets (18) into the tube (1.1) and coupling piece (16)
(minimum of ø5.2 mm if pop-rivets of ø5 mm are used).
3. Use a pop-rivet pliers to aach the pop-rivet (18).
4. Drill the holes for the other three pop-rivets (18).
5. Use the pop-rivet pliers to aach the other three pop-rivets (18).
6. Put the winding tube (17) on the coupling piece (16) at a small distance from the tube motor.
This distance is temporarily necessary when the cord (20.1) is pulled through the winding tube
(17). Refer to step 2 of §4.7.
Do not drill into the tube motor more than 120 mm* from the open
end. *For the tube motor 550039 this is 194 mm.
Make sure that the connecons between the winding tube and the
tube motor are strong enough for the supplied drive torque.
Make sure that the connecons between the winding tube and the
tube motor are aached as smooth as possible.
This is important for the screen cloth.
D-D
d (4x)
50
1.5
25
75
<120*
4.6.1
B
B
550037 (P20)
*550039:
<194 mm
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
19

4.7 Aach the screen cloth and winding tube
The condions and starng points that follow are applicable.
• The overview in illustraon 4.7.1 is the starng point in §4.7.
• In this product manual the starng point is a side-wall roller-screen. The roller screen is installed
on a side wall between the purlins. In a roof roller-screen system an angle of inclinaon of less
than 20° from the horizontal baseline is not recommended. Refer to illustraon 4.7.2.
• The RB50Eᵖˡᵘˢ tube motor is built-in to a smooth circular aluminium tube (50 x 1.5 mm).
Compared to the winding tube (17), this tube does not have a groove for the screen cloth (20).
• First aach the screen cloth (20) to the building structure. Make sure that it does not fold!
4.7.1
Refer to F-F(1) Refer to E-E (2)
40 mm
4.7.2
Ridder Drive Systems
T+31 (0)341 416 854 F+31 (0)341 416 611 Iwww.ridder.com
20
