Riello KV 130 - 28 Manual

cod. 20105199 rev. 0 09/15
RESIDENCE COLONNA CONDENS KV 130 - 28
EN INSTALLATION AND MAINTENANCE MANUAL

2
CONFORMITY
RESIDENCE COLONNA CONDENS rboilers conform to the following directives:
• Directive92/42/EEConefficiencyrequirements
•GasAppliancesDirective2009/142/CE
•LowVoltageDirective2006/95/CE
•ElectromagneticCompatibilityDirective2004/108/CE
•EcodesignDirective2009/125/CEforenergy-relatedproducts
•EnergyLabellingDirective2010/30/EU
•DelegatedRegulation(UE)N.811/2013
•DelegatedRegulation(UE)N.813/2013
•DelegatedRegulation(UE)N.814/2013
MODEL CODE
RESIDENCECOLONNACONDENSKV/13028 20105844
RANGE

GENERAL
3
Dear heating engineer,
Congratulations on having chosen a rRESIDENCE COLONNA CONDENS boiler. You have
selected a modern, quality product that is designed to give dependable, efficient and safe service
and to provide comfort in the home for many years to come. This manual provides information that
is essential to the installation of the appliance. Used in conjunction with your own knowledge and
expertise it will enable you to install the appliance quickly, easily, and correctly.
Once again, please accept our thanks and our congratulations on your choice of product.
Riello S.p.A.

4CONTENTS
This manual, Code 20105199 - Rev. 0 (09/15) is made
upof52pages.
Thefollowingsymbolsareusedinthismanual:
b = Identifiesactionsthatrequirecautionandade-
quatepreparation.
a = IdentifiesactionsthatyouMUSTNOTdo.
GENERAL
Generalsafetyinformation  page 5
Precautions  “ 5
Productdescription  “ 6
Safetydevices  “ 6
Identification  “ 7
Layout  “ 8
Technicalspecifications  “ 9
Accessories  “ 10
Watercircuit  “ 11
Locationofsensors  “ 12
Pump  “ 13
Wiringdiagram  “ 16
Controlpanel  “ 17
INSTALLER
Unpackingtheproduct  page 18
Dimensionsandweight  “ 18
Handling  “ 19
Placeofinstallation  “ 20
Installationinoldersystemsand
systemsrequiringmodernisation  “ 21
Waterconnections  “ 22
Electricalconnections  “ 24
Outdoortemperaturesensor  “ 26
Fuelconnections  “ 27
Fluegasoutletandcomburentairintake  “ 27
Fillinganddrainingthesystem  “ 31
TECHNICAL ASSISTANCE SERVICE
Preparingforinitialstart-up  page 33
Initialstart-up  “ 33
Shutdown  “ 36
WarningLEDsanderrors  “ 37
Automatictemperaturecontrol  “ 38
Settings  “ 41
Conversionfromonegastypetoanother  “ 42
Maintenance  “ 43
Troubleshooting  “ 45
Usefulinformation  “ 48
CONTENTS

GENERAL
5
GENERAL SAFETY INFORMATION
b Assoonasyouopenthepackaging,checkimme-
diatelythatthecontents areallpresentandunda-
maged. Contact the r reseller from whom you
purchasedtheproductifyounoticeanyproblems.
b Thissystemmustbeinstalledbyalegallyqualified
heatingengineer.Oncompletionoftheinstallation,
theinstallermustissuetheownerwithadeclaration
of conformity confirming that the installation has
been completed to the highest standards in com-
pliance with the instructions provided by rin
this instruction manual, and that it conforms to all
applicablelawsandstandards.
b This RESIDENCE COLONNA CONDENS boiler
must be used only for the proper purpose for
whichit is designed and made. The manufacturer
declines all responsibility, contractual or other, for
damagetopropertyorinjurytopersonsoranimals
causedbyimproperinstallation,adjustment,main-
tenanceoruse.
b If you notice any water leaking from the boiler,
disconnectitimmediatelyfromthemainselectricity
supply, shut off the water supply, and notify your
local rTechnicalAssistanceCentreoraquali-
fiedheatingengineerimmediately.
PRECAUTIONS
Observethefollowingprecautionstoensuresafeopera-
tionoftheboiler.
a Do not allow children or infirm persons to operate
theboilerunsupervised.
a Donotoperateanyelectricaldevicesorequipment,
including switches or domestic appliances, etc.,
if you can smell fuel or fumes. If you detect any
suspicioussmells:
- Ventilatetheroombyopeningalldoorsandwin-
dows.
- Closethefuelshut-offcock.
- Report the fault immediately to r’s Technical
AssistanceServiceortoaprofessionallyqualified
heatingengineer.
a Donottouchtheboilerwhenbarefootorwet.
a Never clean or service the boiler without first
disconnectingitfromthemainselectricitysupplyby
turningthemainsswitchOFF.
aDo not tamper with or adjust the safety or control
devices without prior authorisation and instructions
fromtheboiler’smanufacturer.
b Periodically, and when the system is cold, check
that operating pressure in the heating circuit is
between 1 and 1.2 bar. If water pressure is con-
sistently low, contact r’s Technical Assistance
Service or a professionally qualified heating engi-
neer.
b Iftheboilerisnotgoingtobeusedforanextended
periodoftime,proceedasfollowstoprepareitfor
shutdown:
- TurnthemainspowerswitchOFF.
- Closetheboiler’sfuelcockandwatercock.
- Drainthecentralheatingcircuitifthereisanyrisk
offreezing.
b Theboilermustbeservicedatleastonceayear.
b If the boiler is destined to heat low temperature
(under-floor)heatingsystems,itmustbefittedwith
anaccessorymixervalvekit.
b This instruction manual is an integral part of the
boiler. It must be kept safe and must ALWAYS
accompany the boiler, even if it is sold to another
owner or transferred to another user or to another
installation. If you damage or lose this manual,
order a replacement immediately from your local
TechnicalAssistanceCentre.
a Neverpull,disconnect,ortwisttheelectricalcables
coming from the boiler even if it is disconnected
fromthemainselectricitysupplyatthetime.
a Do no obstruct or restrict the vents in the room
wheretheboilerisinstalled.Adequateventilationis
essentialforcorrectcombustion.
a Donot expose the boilerto the elements. It isnot
designedforuseoutdoors.
a Do not switch the boiler off if outside temperature
dropsbelowZERO(riskoffreezing).
a Donotstorecontainersofflammablesubstancesin
theroomwheretheboilerisinstalled.
a Donotdisposeofpackagingmaterialintotheenvi-
ronment, or leave it within the reach of children,
sinceitcanbecomeapotentialhazard.Disposeof
packaging material in compliance with applicable
legislation.

GENERAL
6
RESIDENCE COLONNA CONDENS boilers are high
efficiency, low temperature boilers for the production
of hot water for central heating and domestic hot water
systems.Theyincorporatea130litrestoragecylinder.
RESIDENCE COLONNA CONDENS boilers incorporate
alowwatercontent,lowpressuredrop,compact,mono-
bloc,aluminiumheatexchanger,andapremixedmicro-
flame burner controlled by an electronic control panel,
all enclosed within a robust free-standing casing. They
featuresealedcombustionchambersand,dependingon
whatflueaccessoriesarefitted,canbeclassedasB23P,
B53P,C13,C23,C33,C43,C53,C63orC83appliances.
The fan extracts flue gases and aspirates comburent
airfrom outdoors, and is continuously controlled by the
electroniccontrolcard.
The characteristics of the heat exchanger and burner
ensureanexcellentlevelofperformance.
-Ionisation flame control device for shutting off gas
supplyincaseofflamefailure.
-Water pressure switch to prevent ignition in case of
lowwaterpressure(witherrordisplay).
-Maximum temperature thermostat to detect overhe-
ating and ensure the safety of the entire system (with
errordisplayrequiringresetbyOFF-RESETbutton).
-Flue gas temperature sensortoshutdowntheburner
iffluegastemperatureexceedsthesafetythreshold.
-Flue gas venting safety system incorporated in the
pneumaticfunctioningsystemofthegasvalve.
-Overtemperature diagnosis with double sensor on
centralheatingflow andreturn(temperaturethreshold
85°C).
-3 barcentralheatingcircuitsafety valve.
-8 bardomestichotwatercircuitsafety valve.
-Circulation diagnosis by comparison of readings of
centralheatingflowandreturntemperaturesensors.
The combustion chamber and the heat exchange area
are designed to keep temperature low over the bur-
ner surface, thus minimising emissions, maximising
combustion efficiency and improving ignition reliability.
RESIDENCE COLONNA CONDENS boilers come com-
pletewithsafetyvalves,ventandbleedvalve,expansion
vessels,draincocks,systemfillcockandpumpsforthe
centralheatingcircuit,storagecylinder.
Morethanonehighorlowtemperaturezonecanbehea-
ted,withtheadditionoftherelevantmulti-zoneaccesso-
ries.Seethercataloguefordetails.
b The intervention of a safety device indicates a
potentially dangerous malfunction in the system,
andmeansthatyoumustcontactr’s Technical
AssistanceServiceimmediately.
a Neverstart the boilerupevenfora shortperiod if
the safety devices are not functioning correctly or
havebeentamperedwith.
b Safety devices must only be replaced by r’s
Technical Assistance Service using original spare
parts.
Alwayscheckthattheboilerisfunctioningcorrectlyafter
anyrepairs.
RESIDENCE COLONNA CONDENS boilersareequippedwiththefollowingmainsafetydevices:
PRODUCT DESCRIPTION
SAFETY DEVICES

GENERAL
7
European Directive
92/42/EEC:
η =
N°
230 V ~ 50Hz W
Pms= bar T = °C
Pmw= bar T = °C
D = l/min
Qn(min)=
Pn(min)=
NOx:
/
IP P.nom.G20= mbar
Qn(max=
Pn(max)=
Cod.
kW
kW
kW
kW
kW
kW
kW
kW
RIELLO S.p.A.
Via Ing.Pilade Riello 7
37045 Legnago (VR) - ITALY
Categoria:
Categorie:
Kategorie:
Combustible:
Brennstoff:
Combustibile:
Brandstof:
KESSEL GEREGELT FÜR:
CALDAIA REGOLATA PER: CHAUDIERE REGLEE POUR:
VERWARMINGSKETEL INGESTELD OP:
T067745GE
T067745GE
Caldaia a condensazione - Chaudière à condensation
Brennwertkessel - Condenserende verwarmingsketel
European Directive
92/42/EEC:
η =
N°
230 V ~ 50Hz W
Pms= bar T = °C
Pmw= bar T = °C
D = l/min
Qn(min)=
Pn(min)=
NOx:
/
IP P.nom.G20= mbar
Qn(max=
Pn(max)=
Cod.
kW kW kW kW
kW kW kW kW
RIELLO S.p.A. Via Ing.Pilade Riello 7 37045 Legnago (VR) - ITALY
Categoria: Categorie: Kategorie:
Combustible:
Brennstoff: Combustibile:
Brandstof:
KESSEL GEREGELT FÜR:
CALDAIA REGOLATA PER: CHAUDIERE REGLEE POUR:
VERWARMINGSKETEL INGESTELD OP:
T067745GE
T067745GE
Caldaia a condensazione - Chaudière à condensation Brennwertkessel - Condenserende verwarmingsketel
European Directive
92/42/EEC:
η =
N°
230 V ~ 50Hz W
Pms= bar T = °C
Pmw= bar T = °C
D = l/min
Qn(min)=
Pn(min)=
NOx:
/
IP P.nom.G20= mbar
Qn(max=
Pn(max)=
Cod.
kW
kW
kW
kW
kW
kW
kW
kW
RIELLO S.p.A.
Via Ing.Pilade Riello 7
37045 Legnago (VR) - ITALY
Categoria:
Categorie:
Kategorie:
Combustible:
Brennstoff:
Combustibile:
Brandstof:
KESSEL GEREGELT FÜR:
CALDAIA REGOLATA PER: CHAUDIERE REGLEE POUR:
VERWARMINGSKETEL INGESTELD OP:
T067745GE
T067745GE
Caldaia a condensazione - Chaudière à condensation
Brennwertkessel - Condenserende verwarmingsketel
rRESIDENCE COLONNA CONDENSboilersareidentifiedbytwoplates:
b Iftheseplatesoranyothermeansofclearlyidentifyingtheproductaredefaced,removedorlost,properinstal-
lationandservicingmayberendereddifficult.
- Data plate
This lists the appliance’s technical specifications
 andperformancedata.
- Gas plate
This is applied near the data plate and specifies the
type of gas used by the boiler, and the country in
whichtheboilerisdestinedforuse.
Data plate
Domestichotwatersection
Centralheatingsection
Qn Ratedheatinput
Pn Ratedusefulheatoutput
IP Indexofprotection
P.min Minimumpressure
Pmw Maximumoperatingpressure,
 DHWsystem
Pms Maximumoperatingpressure,
 CHsystem
T Temperature
η Efficiency
D Specificflowrate
NOx
NOxclass
IDENTIFICATION

GENERAL
8
°C
0120
20 100
40 80
60
3
20
22
23
25
26
27
28
30
21
31
24
4
3
3
4
5
6
7
9
13
12
10
11
8
1
2
15
14 13
12
9
33
10
32
3
33
6
5
19
15
24
29
17
20
21 21
29
19
18
16
1 Coverpanel
2 Top front panel
3 Automaticventvalve
4 Bleedmanifold
5 Waterpressureswitch
6 Draincockfordeliverygroup
7 Deliverygroup
8 Bottomfrontpanel
9 CH/storagecylinderpump
10 Deviatorvalveandby-pass
11 Storagecylindertemperaturesensorsocket
12 CHcircuitfillcock
13 Storagecylinderdraincock
14 DHWcircuitsafetyvalve(8bar)
15 DHWcircuitexpansionvessel(6litres)
16 Bypasspipe
17 Draincollectorpipe
18 Electricalcableguides
19 CHcircuitsafetyvalve(3bar)
20 Combustiongroup
21 Vent/airintakefitting(concentric60/100)
22 Controlpanel
23 Gas diaphragm
24 Gas valve
25 DHWcapillarytemperaturegauge
fitting
26 Magnesiumanode
27 Storagecylinderflange
28 LH side panel
29 CHcircuitexpansionvessel(12litres)
30 Comburentairintakepipe(twinpipe)
31 Fluegasanalysissocket
32 RHsidepanel
33 Boilerdraincock
LAYOUT

GENERAL
9
Description RESIDENCE COLONNA CONDENS
KV/130 28 ISCN
Devicetype
condensingboilerformixedheating
B23P-B53P-C13-C23-C33-C43-C53-
C63-C83
Fuel G20/G31
Devicecategory II2H3P
RatedheatinputatfurnacereferredtoHVC(LCV) 22,2(20) kW
MinimumratedheatinputatfurnacereferredtoHVC(LCV) 6,7(6) kW
Useful(rated)heatoutput 20 kW
Maximumusefulheatoutput(80-60°C)P4 19,6 kW
Maximumusefulheatoutput(50-30°) 21,0 kW
30%heatoutputwithreturnat30°C(P1)  6,5 kW
Reducedheatoutputat(80-60°) 5,9 kW
Reducedheatoutputat(50-30°) 6,4 kW
Efficiencyclassincentralheatingmode B
EfficiencyclassinDHWmode A
Seasonalenergyefficiencyincentral
heating mode hs91 %
Efficiencyatratedheatinputinhigh
temperaturemode(HCV) h4UsefulPn (60-80°C) 88,2 %
Efficiencyat30%ratedheatinputinlow
temperaturemode(HCV) h1Useful 30%ofPn 96,9 %
EnergyefficiencyinDHWmode hwh 75 %
Storagecylinderchargingprofile L
Heatlossinstandbymode Pstby 196 W
Combustionefficiency 95,6 %
Annualenergyconsumption QHE 62 GJ
Dailyelectricalenergyconsumption Qelec 0,209 kWh
Annualelectricalenergyconsumption AEC 46 kWh
Dailyfuelconsumption Qfuel 15,9 kWh
Annualfuelconsumption AFC 12 GJ
Noise(soundpower) LWA 51 dB(A)
Emissionsatmaximumheatinput
Nox (referred
toHCV) 38 mg/kWh
CO2 9 %
COw.a.< 170 ppm
∆Tfluegas 55 °C
Emissionsatminimumheatinput
Nox (referred
toHCV) 22 mg/kWh
CO2 9 %
CO 35 ppm
∆Tfluegas 37 °C
Residualhead,concentricpipes,0.85m 100 Pa
Airflowrate(G20) 24,98 Nm3/h
Fluegasflowrate(G20) 26,99 Nm3/h
Fluegasmassflowrate 0,009 Kg/s
Maximumoperatingpressure 3 bar
Safetythermostattriptemperature 110 °C
Maximumoperatingtemperature 90 °C
Boilerwatertemperatureselectionrange 40-80 °C
Boilerwatercapacity 5 l
VolumeofCHcircuitexpansionvessel 12 l
PrechargeofCHcircuitexpansionvessel 1,5 bar
Powersupply 230~50 V-Hz
TECHNICAL SPECIFICATIONS

GENERAL
10
Electricdegreeofprotection categoryB X4D IP
categoryC X5D IP
Absorbedpowersupply(max) 118 W
Consumptionatfullload Elmax 65 W
Consumptionatpartload Elmin 19 W
ConsumptioninstandbymodePSB P sb 4W
Specifieddatamustnotbeusedtocertifythesystem.Certificatesmuststatethevalueslistedinthe“SystemService
Booklet”asmeasuredoninitialstart-up..
Description RESIDENCE COLONNA CONDENS
KV/130 28
Typeofstoragecylinder Vitrified
Storagecylinderlayout Vertical
Heatexchangerlayout Vertical
Maximumpowerabsorbedbyheatexchanger 28 kW
DHWtemperaturesettingrange 35÷60 °C
Storagecylindercapacity 137 l
Coilwatercapacity 5,5 l
Coilheatexchangesurfacearea 0,91 m2
DHWproduction ∆T25°C 13,6 l/min
∆T35°C 8,8 l/min
Specificflowrate(EN625) 23,3 l/min
Maximumoperatingpressureofstoragecylinder 8 bar
Volumeofexpansionvessel(DHW) 6 l
Prechargeofexpansionvessel(DHW) 2,5 bar
Foracompletelistofaccessoriesanddetailsoftheircompatibility,refertotheCatalogue.
Description RESIDENCE COLONNA CONDENS
KV/130 28 ISCN
Function parameters for G20
LowerWobbeindex(at15°C-1013mbar) 45,67 MJ/m3S
Ratedsupplypressure 20 mbar
Minimumsupplypressure 10 mbar
Gas diaphragm 6,7 mm
Maximumgasflowrate,DHW/CH 2,96-2,12 Sm3/h
Minimumgasflowrate,DHW/CH 0,63-0,63 Sm3/h
Maximumfanspeed,DHW/CH 6100-4400 giri/min
Minimumfanspeed 1700 giri/min
Burnerignitionslowfanspeed 3700 giri/min
Function parameters for G31
LowerWobbeindex(at15°C-1013mbar) 70,69 MJ/m3S
Ratedsupplypressure 37 mbar
Minimumsupplypressure 35 mbar
Gas diaphragm 4,7 mm
Maximumgasflowrate,DHW/CH 2,17-1,55 Sm3/h
Minimumgasflowrate,DHW/CH 0,47-0,47 Sm3/h
Maximumfanspeed,DHW/CH 6100-4300 giri/min
Minimumfanspeed 1700 giri/min
Burnerignitionslowfanspeed 3700 giri/min
ACCESSORIES

GENERAL
11
CH flow
CH return
GAS
1
DHW outlet
Cold water inlet
19
20
22
23
31
21
20
17
16
27
6
2 3 11
10
10
7
9
8
30
24
29
28
18
25
14
12
12
4
5
26
15
13
32
1 Primaryheatexchanger
2 CHflowtemperaturesensor
3 Safetythermostat
4 Fan
5 Gas valve
6 CHreturntemperaturesensor
7 Condensatedrainsiphon
8 Gas diaphragm
9 Sealedchamber
10 Drain
11 Bleedmanifold
12 Automaticventvalve
13 CHcircuitexpansionvessel(12litres)
14 CH/storagecylinderpump
15 Boilerdraincock
16 Deliverygroup
17 Waterpressureswitch
18 Draincockfordeliverygroup
19 Systemsafetyvalve(3bar)
20 Non-returnvalve
21 Non-returnvalveandby-pass
22 Automaticbypass
23 Deviatorvalve
24 130litrestoragecylinder
25 DHWcircuitexpansionvessel(6litres)
26 DHWcircuitsafetyvalve(8bar)
27 CHcircuitfillcock
28 Magnesiumanode
29 Flangia bollitore
30 Storagecylinderflange
31 Bypasspipe
DHWrecirculation
WATER CIRCUIT

GENERAL
12
°C
0 120
20 100
40 80
60
°C
0120
20 100
40 80
60
NTC CH FLOW
TEMPERATURE
SENSOR
(located on CH circuit flow
pipe inside sealed chamber)
CENTRAL HEATING
TEMPERATURE
GAUGE SENSOR
NTC CH RETURN
TEMPERATURE
SENSOR
(located on CH circuit return
pipe inside sealed chamber)
SAFETY THERMOSTAT
(located on CH circuit flow
pipe inside sealed chamber)
NTC FLUE GAS
TEMPERATURE
SENSOR
CONDENSATE SENSOR
(located inside sealed chamber)
NTC STORAGE
CYLINDER
TEMPERATURE
SENSOR
STORAGE
CYLINDER
TEMPERATURE
GAUGE SENSOR
LOCATION OF SENSORS

GENERAL
13
0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,0 2,2 2,4 2,6 2,8 3,0 3,2 3,4 Q [m³/h]
0,0 0,1 0,2 0,3 0,4 0,5 0,60,7 0,80,9 1,0 Q [l/s]
0
10
20
30
40
50
[W]
P1
Flow rate
0
1
2
3
4
5
Q [m³/h]
0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,02,2 2,42,6 2,83,0 3,23,4
6
7
[m]
H
0
10
20
30
40
50
60
[kPa]
p
Residual head
Curvesarereferredtoawaterdensity of983.2Kg/m3,a temperatureof+20°C,andakinematic
viscosityof0.474mm2/s(0.474cSt).
PUMP CURVE
TECHNICAL SPECIFICATIONS
DESCRIPTION ERP ready 2015
Electricalconsumption 53 W
EEIPart3(*) ≤0,20
PL,Avg(**) ≤24 W
Minimumpressureatpumpsuctioninlet 0,5 bar
(*) EnergyefficiencyindexaccordingtoERP2015(Commissionregulations641/2009and622/2012)
(**) AverageannualelectricityconsumptionaccordingtoERP2015(Commissionregulations641/2009and622/2012)
PUMP

GENERAL
14
The boiler's pump is ErP 2015 Ready, and suitable for
usein central heating only/domestic hot water applica-
tions.ThepumpcanbecontrolledbyanexternalPWM
signal and has 4 different pressure curves for central
heatingapplications.
When controlled by a PWM signal, pump speed varies
accordingtothefrequencyoftheincomingPWMsignal,
modulating head/flow rate on the basis of the selected
curve.
In the absence of a PWM signal, the pump runs at full
speedanddeliversthehead/flowratedeterminedbythe
selectedcurve.Eachcurveischaracterisedbyamaxi-
mumheadexpressedinmetres.
User interface
Theuserinterfacefeaturesonebutton(1),onered/green
LED(2)andfouryellowLEDs.
LED (2)
BUTTON (1)
Viathisinterface,userscanaccess::
- Functioning (performance display) mode. Pump per-
formanceisdisplayedduringfunctioningasa%ofcur-
rentdrawwithrespecttoratedload.Alarmconditions
canbeseenfromthecolourofLED(2).
- Setting mode. Setting mode is accessed by pressing
thebutton(1),andisusedtoselectthepumpcurve.
ADJUSTING THE PUMP Display Meaning % power
LED1flashinggreen Stand-by
(onlywith
PWMcontrol)
0
LED1greenandLED2
yellow,bothlit
Low load 0-25
LED1greenandLEDs
2,3yellow,alllit
Low-medium
load
25-50
LED 1 green, LEDs 2,
3,4yellow,alllit
Medium-high
load
50-75
LED 1 green, LEDs 2,
3,4,5yellow,alllit
High load 75-100
PUMP LOAD CURVE
100 %
75 %
50 %
25 %
Functioning mode
A)Performancedisplay
Whenthepumpisfunctioning,LED1isgreen.Thefour
yellow LEDs indicate the instantaneous power draw as
showninthetableabove.
Infunctioningmode,allactiveLEDsarelit(notflashing)
to differentiate this condition from setting mode. If the
pump is stopped by the external control signal, LED 1
flashesgreen.
B)Alarmdisplay
Ifthepumpdetectsoneormorealarmconditions,LED1
changesfromgreentored.Whenanalarmisactive,the
LEDsindicatethetypeofalarmasshowninthefollowing
table.Ifmorethanonealarmisactiveatthesametime,
theLEDsonlyshowthealarmconditionwiththehighest
priority.Alarmpriorityfollowstheorderofthetable.
Whennoalarmisactive,theuserinterfaceautomatically
displayspumpperformance.

GENERAL
15
Display Meaning Function Action
LED1redandLED5yellow,
both lit
Thepumprotorisblocked. The pump automatically
attempts to start every 1.5
seconds.
Waitorcheckthatthepump
rotorisfreetorotate.
LED1redandLED4yellow,
both lit Supply voltage too low. Indication only. The pump continuestofunction.
Check the voltage of the
powersupply
LED1redandLED3yellow,
both lit
Electroniccontrollererror The pump has stopped
because supply voltage is
tooloworbecauseanerror
has occurred in the internal
electronic controller
Check the voltage of the
powersupplyorreplacethe
pump
SETTING MODE
A) Setting display
To switch from performance display to setting display,
pressbutton(1).TheLEDsshowsthecurrentsetting.See
thefollowingtableforthemeaningoftheLEDdisplay.
Settingdisplaymodeshowsthetypeofpumpcontrolor
the currently selected pump curve. Settings cannot be
changedinperformancedisplaymode.After2seconds,
thedisplayreturnstoperformancedisplaymode.
IfLED1isred,itindicatesthatanalarmisactiveorthat
the the pump is being controlled by an external (PWM)
signal.
LEDs2and3showthetypeofinternalcontrolwhileLEDs
4and5showthecurrentlyselectedcurve(1,2,3or4).
AlltheseLEDsareyellowincolour..
LED 1 LED 2 LED 3 LED 4 LED 5
PWMA Red ON - - -
Curve1(4m) - - -
Curve2(5m) - ON -
Curve3(6m) - ON ON
Curve4(7m) - - ON
B) Button lock function
Thebuttonlockfunctionservestopreventimproperuse
oraccidentalchangestopumpsettings.
Whenthebuttonlockisactive,pressingthebuttonhasno
effect. This prevents users from accidentally accessing
settingmode while allowingthem to usesetting display
mode.
Pressandholdthebuttonformorethan10seconds,to
activate/deactivatethebuttonlock.
When the button is held down for 10 seconds, all the
LEDs except the red LED flash for one second to indi-
cate that the button lock function has been activated/
deactivated..
C) Setting mode
To access setting mode, press and hold the button (1)
for between 2 and 10 seconds. The button lock must
be deactivated in order to change settings. Available
settings are displayed in a pre-defined sequence that
isrepeatedeverytimethebuttonisbrieflypressedand
released.Ifthebuttonisnotpressedforover10seconds,
the pump exits setting mode and returns to performan-
ce display mode. The last settings made are saved in
memory. See the table above for the meanings of the
LEDsequences.
> 10s.
SETTING MENUPERFORMANCE
> 2 s.
X
10 s.
2 s.
SELECTED SETTING

GENERAL
16
12345
1234
12 34
5
black
blue
orange
yellow/green
blue brown
white
white
yellow/green
brown CH
N
DHW
brown
blue
blue
brown
pink
CN5 CN2
X4 X9 X2
JP4
CN3CN1
P1
P3
P2
OPE OPE
FA2
CONTROL CARD
FA1
SC ER
EA
TAC
TLS TLA
TBT APC
SM
PA
CI
M5 M3
F1 F2 M3a
M4
TA
N
N L
L
F
VD
VG
brown
brown
black
blue brown black
blue
blue
VHv
1234 1
4 3 2 1 8 7 6 5 4 3 2 1 9 8 7 6 5 4 3 2 1
1 2 3 4 5 6 7
2312345 6
X16
Power supply
230 VAC
red
pink red
black
white
white
orange orange
black
bianco
VLv
blue
blue
blue
black
black
grey
red
red
SR
CR
SE
SB
SF
PO
white
purple
brown
WIRING DIAGRAM
APC Condensatepumpalarm
CR Remotecontrol CN1-CN5 Mainsvoltageconnections
EA Ignitionelectrode ER Flamedetectionelectrode
F Fuse3.15AF(fast)
F1-F2 Fuse3.15AT(timed)
JP4 Boilerconfigurationselectionjumper(in
position3)
M3-M5 Roomtimer-thermostatconnection
terminals
M3a-M4 Outdoortemperaturesensor/condensate
pump/lowtemperaturethermostat/ remote control connection terminals
OPE Gasvalveoperator Cl Centralheating/storagecylinderpump
PA Waterpressureswitch P1 DHWtemperaturesettingpotentiometer P2 CHtemperaturesettingpotentiometer P3 Functionselector R9 Maximumfanspeedtrimmer R10 Minimumfanspeedtrimmer R14 Burnerignitionslowfantrimmer
R19 MaximumCHfanspeedtrimmer
R35 Temperaturecontrolcurveselection
trimmer
SC Condensatesensor SE Outdoortemperaturesensor
SM Primarycircuitflowtemperature
sensor
SR Primarycircuitreturn
temperaturesensor
SW1 Chimneysweep TAC Ignitiontransformer TR2 Maintransformer TBT Lowtemperaturethermostat TLA Waterovertemperature
threshold thermostat
TLS Heatexchangerthreshold
thermostat
VHv Fanpowersupply230V VLv Fan control signal
VG Gas valve X2÷X16 Lowvoltageconnections VD 3-wayvalveservomotor SB Storagecylinder
temperaturesensor
SF Fluegastemperature
sensor
PO DHWtimer-programmer
(accessory)

GENERAL
17
0
bar
4
13
2
°C
0 120
20 100
40 80
60
1 82 6 73 54
1 Boiler pressure gauge
Displaysthepressureinthecentralheatingcircuit.
2 .Storage cylinder temperature selector
Allowsyoutosetthetemperatureofthedomestichotwater.
3 Green LED
Whenlit,showsthataflameisbeingdetected.
4 Two figure digital display
Displaysinformationonboilerstatus.
5 Red LED
Whenlit,showsthatanerror(alarm)conditionhasbeendetected.
6 Function selector
0Off/Reset
{Winter mode
}Summermode
7
/Central heating temperature selector
Allowsyoutosetthetemperatureofthecentralheatingwater.
8 Storage cylinder temperature gauge
Displaysdomestichotwatertemperature.
CONTROL PANEL
THE MAIN CONTROL PANEL

INSTALLER
18
CONFORMITÀ
UNPACKING THE PRODUCT
DIMENSIONS AND WEIGHT
Theboilerisdeliveredinasinglepackageonawooden
pallet, covered by a PVC sheet and inside a wooden
crate.Thefollowingitemsaredeliveredinaplasticbag
(A)insidetheboiler:
- UserManual,andInstallationandMaintenanceManual
for the boiler
- Hydraulictestcertificate
- Outdoortemperaturesensor
- LPGconversionkit(diaphragm,label).
b The instruction manuals are integral parts of the
boiler. Once located, read them thoroughly and
keepthemsafe.
Description
L600 mm
P610 mm
H1540 mm
Netweight 130 Kg
Grossweight(withpackaging) 150 Kg
A
RESIDENCE COLONNA CONDENS boilers are desig-
ned and made for installation in combined central heating
anddomestichotwaterproductionsystems.
P
L
H

INSTALLER
19
HANDLING
Onceyouhaveremovedthepackaging,proceedasfol-
lowstohandleandmovetheboiler.
- Unscrewthe4screws(A)showninthefigureandremo-
vetheboilerfromthepallet.
- Remove the front panel (1) to facilitate handling and
movementoftheboiler.
-Grip the boiler at points (B) and tilt it backwards,
thengripitat points(B)and (C)toliftit. Anoptional
handling bracket kit is available to provide a better
gripatpoints(B).
b Do not lift the boiler by its casing but only by
rigid parts such as its base and top frame.
b Do not lift the boiler by its casing but only by
rigid parts such as its base and top frame.
a Donotdisposeofpackagingmaterialintotheenvi-
ronment, or leave it within the reach of children,
sinceitcanbecomeapotentialhazard.Disposeof
packaging material in compliance with applicable
legislation.
TILT
OPEN
1
LIFT
B
C
C
B
A
A

INSTALLER
20
PLACE OF INSTALLATION
RESIDENCE COLONNA CONDENS boilers can be
installed in any indoor location provided the flue gases
areadequatelyremovedandcomburentairdrawninfrom
outdoors. Provided the boiler is properly installed, the
boilerroomitselfdoesnotneedanyventilationassuch,
sincethecombustioncircuitofRESIDENCE COLONNA
CONDENS boilers is sealed with respect to the envi-
ronment. If instead comburent air is drawn from inside
the boiler room itself, the room must have adequately
dimensioned ventilation conforming to the relevant tech-
nicalstandards.
IMPORTANT
Before installing the boiler, thoroughly flush out all the
pipes to remove any dirt and deposits that could com-
promisethecorrectfunctioningoftheboiler.Openexpan-
sion chambers must be fitted with an overflow siphon
connectedtoadrainpoint.
Before lighting the burner for the rst time, make sure
that the boiler is congured for use with the type
of gas supplied. The type of gas is specied on the
packaging label and on the gas identication plate on
the boiler itself.
b When installing the boiler, allow sufficient space
around it to access all safety and control devices
andtopermiteasymaintenance.
b Make sure that the boiler’s index of electrical pro-
tection is adequate for the characteristics of the
roomwhereitistobeinstalled.
b
Ifthespecificweightofthegassupplytotheburner
isgreaterthanthespecificweightofair,allelectrical
partsmustbeinstalledatleast500mmabovefloor
level.
a RESIDENCE COLONNA CONDENS boilers must
be installed indoors. They are not designed for
outdooruse and arenotfitted withautomatic frost
protectiondevices.
≥ 50 cm
≥ 50 cm
≥ 100 cm
≥ 20 cm
60 cm
154 cm
61 cm
