RIGHT ANGLE 415NR User manual

SQUARE
PAGE 1 OF 3
TAPE MEASURE
TOOLS REQUIRED FOR ASSEMBLY:
VERSION DATED: 10/4/11
#2 SQUARE HEAD DRIVER BIT
#2 PHILLIPS HEAD DRIVER BIT OR
CORDLESS DRILL
BY PULLING THE
5
PAPER STRIPS OFF THE TRACK. SEE THE TOP VIEW BELOW. POSITION THE TRACK
SQUARE WITH THE FRONT OF THE WORKSURFACE AND BACK 3/8 . PRESS THE
FROM THE BOTTOM UP AND INTO THE TRACK.
TRACK FIRMLY IN PLACE SO THE GLUE DOTS WILL HOLD THE TRACK ONTO
THE BOTTOM OF THE WORKSURFACE.
IMPORTANT NOTE: THE WORKSURFACE MATERIAL MUST BE COMPATIBLE WITH
THE SCREWS PROVIDED. THE WORKSURFACE MUST BE AT LEAST 1" THICK.
INTO THE FRONT OF THE TRACK. ATTACH IT USING (2) SELF
STEP 3: ATTACH THE TRACK 1
INSTRUCTION # 52359
TO THE WORKSURFACE USING (6) WOOD
SCREWS 3 . DO NOT OVER-TIGHTEN THE SCREWS. USE A LOW TORQUE
SETTING ON THE DRILL.
STEP 4: SLIDE THE ARTICULATING ARM 2
HARD ARE PACK # 52372 & 50531 (TRACK HARD ARE)
BACK INTO THE TRACK
TAPPPING MACHINE SCREWS
1 . INSERT
THE FRONT STOP 4
415/417NR NOTEBOOK TRAY AND ARTICULATING ARM INSTALLATION
INSTRUCTIONS:
STEP 1: SLIDE THE ARTICULATING ARM 2 OUT OF THE TRACK 1 AND SET IT
ASIDE. DETERMINE THE LOCATION TO MOUNT THE TRACK AND ARTICULATING
ARM. LOCATE THE TRACK SO THAT THE ARM AND TRAY CAN ROTATE LEFT
AND RIGHT AS FAR AS YOU WANT IT TO ROTATE.
STEP 2: EXPOSE THE GLUE DOTS ON THE TOP OF THE TRACK 1
ITEM # PART # DESCRIPTION QTY.
1 VARIES TRACK ASSEMBLY 1
2 VARIES ARTICULATING ARM ASSEMBLY 1
3 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW 6
4 50232 FRONT STOP 1
5 50200 10-24 x 1/2 SELF TAPPING MACHINE SCREW 2
6 VARIES 415/417NR NOTEBOOK TRAY 1
7 52679 8-32 x 3/8 PHILLIPS TRUSS HEAD MACHINE SCREW 6
8 50267 8-32 SERRATED FLANGE LOCK NUT 6
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
5
BEFORE BEGINNING
4
1
2
3
READ ALL THE
INSTRUCTIONS
STEPS 1-4
GLUE DOTS
COVERING
PAPER STRIPS
1

PAGE 2 OF 3
VERSION DATED: 10/4/11
STEP 5: PLACE THE NOTEBOOK TRAY 6 ON THE ARTICULATING ARM 2 ALIGNING THE HOLES
IN THE TRAY WITH THE HOLES IN THE ARM. INSERT (6) MACHINE SCREWS 7 THROUGH THE
HOLES IN THE TRAY & THE ARTICULATING ARM.
STEP 6: THREAD (6) FLANGE NUTS 8 ONTO THE MACHINE SCREWS 7 & TIGHTEN.
STEP 7: ADJUST THE TRAY TO THE DESIRED POSITION. SEE PAGE 3 OF 3. 6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
K&A MANUFACTURING
7
6
2
8
STEPS 5-7

PAGE 3 OF 3
OPERATION OF THE 415/417NR NOTEBOOK TRAY AND ARTICULATING ARM SYSTEMS:
NFP23/S ARTICULATING ARM: FOR HEIGHT ADJUSTMENT, GRASP THE FRONT AND BACK EDGES OF THE TRAY. TILT
THE TRAY TOWARD THE BACK AND LIFT UP OR PUSH DOWN. RELEASE THE TRAY TO LOCK IT IN PLACE. TO TILT THE
TRAY, TURN THE KNOB ON THE RIGHT HAND SIDE OF THE ARM. THE ARM WILL SLIDE FORWARD AND BACK IN THE
TRACK. IT WILL ALSO ROTATE LEFT AND RIGHT ON THE SWIVEL WITH A MODERATE PUSH.
NVS23/S ARTICULATING ARM: TO OPERATE THE ARM, LOOSEN THE KNOB ON THE RIGHT HAND SIDE. TILT THE TRAY UP OR DOWN AND SET THE DESIRED
HEIGHT. RE-TIGHTEN THE KNOB. THE ARM WILL SLIDE FORWARD AND BACK IN THE TRACK. IT WILL ALSO ROTATE LEFT AND RIGHT ON THE SWIVEL WITH A
MODERATE PUSH.
NC23/S ARTICULATING ARM; FOR HEIGHT ADJUSTMENT, PUSH DOWN OR PULL UP ON THE BACK OF THE TRAY. TO TILT THE TRAY, LOOSEN THE KNOB ON
THE RIGHT HAND SIDE OF THE ARM. TILT THE TRAY TO THE DESIRED ANGLE AND RE-TIGHTEN THE KNOB. FOR A GREATER RANGE OF TILT (DOWN), REMOVE
THE KNOB AND THE WASHER UNDERNEATH IT. REMOVE THE LOCKOUT TAB WITH A NEEDLE NOSED PLIERS. SEE THE DETAIL BELOW. REPLACE THE WASHER
AND KNOB. THE ARM WILL SLIDE FORWARD AND BACK IN THE TRACK. IT WILL ALSO ROTATE LEFT AND RIGHT ON THE SWIVEL WITH A MODERATE PUSH.
NFSS26/S ARTICULATING ARM: TO RAISE THE TRAY LIFT UP ON THE TRAY. IT WILL LOCK IN PLACE. TO LOWER THE TRAY TILT THE TRAY BACK AND PUSH DOWN.
RELEASE THE TRAY TO LOCK IT IN PLACE. TO TILT THE TRAY TURN THE KNOB ON THE RIGHT HAND SIDE OF THE ARM. THE ARM WILL SLIDE FORWARD AND
BACK IN THE TRACK. IT WILL ALSO ROTATE LEFT AND RIGHT ON THE SWIVEL WITH A MODERATE PUSH.
NDA23/S ARTICULATING ARM: TO RAISE OR LOWER THE TRAY PUSH THE LEVER TO THE RIGHT AND MOVE THE TRAY TO THE DESIRED HEIGHT. PUSH THE LEVER
TO THE LEFT TO LOCK THE TRAY IN PLACE. TO TILT THE TRAY PULL OUT ON THE T-HANDLE AND TILT THE TRAY TO THE DESIRED ANGLE. RELEASE THE HANDLE
TO LOCK THE TRAY IN PLACE. THE ARM WILL SLIDE FORWARD AND BACK IN THE TRACK. IT WILL ALSO ROTATE LEFT AND RIGHT ON THE SWIVEL WITH A
MODERATE PUSH.
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: [phone] FAX: [phone]
.raproducts.com
VERSION DATED: 10/4/11
K&A MANUFACTURING
LOCKOUT TAB
LOCKOUT TAB ON THE NC23/S ARM
