HONTECH HT-A05 User manual

HT-A05
1
2
Specification
Product Spec
Max. Load:40kg
Net Weight:1.4kg
(Front View)
UNIT mm：
(Lateral View)
()Back View ()Top View
Parts Name
Please check out all parts.
TV Bracket x1
Wall Bracket x1
M4x15 Screw x4
Wall Anchor 5/16 x4 & 1/4 4x
4x20 Wood Screw x4
4 Plastic Sleeve x6
Registered design and patent pending All rights reserved.

HT-A05
Registered design and patent pending All rights reserved.
Tighten!!
1
2
3
4
Step 1
Step 2
Step 3
Step 4
The wall must be at
least 5cm thick.
For a wooden wall,please choose
wood screws 6pcs 5x38mm(D)
For a concrete wall,please choose
wall anchors 4pcs 10x56mm(C)
At the time of installation,make
sure that 2 people hold the LCD TV.
Make sure the LCD TV is turn off
before installing.
Make sure the two brackets are
locked and secure.
Tighten the fixed screw to
lock the TV in place.
Use 4 pcs M4x12(F)screws to
assemble the TV bracket to the
LCD TV.
Installation
