Quick Guide
MSO2000A/DS2000A Series
Digital Oscilloscope
May 2019
RIGOL(SUZHOU) TECHNOLOGIES INC.

RIGOL
MSO2000A/DS2000A Quick Guide
I
Guaranty and Declaration
Copyright
© 2013 RIGOL (SUZHOU) TECHNOLOGIES INC.All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL (SUZHOU) TECHNOLOGIES INC.
Publication Number
QGA18104-1110
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at the company’s sole decision.
Information in this publication replaces all previously released materials.
Information in this publication is subject to change without notice.
RIGOLshall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or performance of this manual, as well as
any information contained.
Any part of this document is forbidden to be copied, photocopied, or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial
standards in China as well as the ISO9001:2015 standard and the ISO14001:2015
standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: servi[email protected]
Website: www.rigol.com

RIGOL
MSO2000A/DS2000A Quick Guide
II
Safety Requirement
General Safety Summary
1. Only the exclusive power cord
designed for the instrument and
authorized for use within the local
country could be used.
2. Ensure that the instrument is safely
grounded.
3. Connect the probe correctly.
4. Observe all terminal ratings.
5. Use proper overvoltage protection.
6. Do not operate without covers.
7. Do not insert objects into the air
outlet.
8. Use the proper fuse.
9. Avoid circuit or wire exposure.
10. Do not operate the instrument with
suspected failures.
11. Provide adequate ventilation.
12. Do not operate in wet conditions.
13. Do not operate in an explosive
atmosphere.
14. Keep instrument surfaces clean and
dry.
15. Prevent electrostatic impact.
16. Handle with caution.
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could
result inpotential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result indamage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

RIGOL
MSO2000A/DS2000A Quick Guide
III
Measurement Category
Measurement Category
MSO2000A/DS2000A series digital oscilloscopes can make measurements in
Measurement Category I.
WARNING
This oscilloscope can only be used for measurements within its specified
measurement categories.
Measurement Category Definitions
Measurement category I is for measurements performed on circuits not directly
connected to MAINS. Examples are measurements on circuits not derived from
MAINS, and specially protected (internal) MAINS derived circuits. In the latter case,
transient stresses are variable; for that reason, the transient withstand capability of
the equipment is made known to the user.
Measurement category II is for measurements performed on circuits directly
connected to the low voltage installation. Examples are measurements on household
appliances, portable tools and similar equipment.
Measurement category III is for measurements performed in the building installation.
Examples are measurements on distribution boards, circuit-breakers, wiring,
including cables, bus-bars, junction boxes, switches, socket-outlets in the fixed
installation, and equipment for industrial use and some other equipment, for
example. Stationary motors with permanent connection to the fixed installation.
Measurement category IV is for measurements performed at the source of the
low-voltage installation. Examples are electricity meters and measurements on
primary overcurrent protection devices and ripple control units.
Ventilation Requirement
This oscilloscope uses fan to force cooling. Please make sure that the air intake and
exhaust areas are free from obstructions and have free air. When using the
oscilloscope in a bench-top or rack setting, provide at least 10 cm clearance beside,
above and behind the instrument for adequate ventilation.
WARNING
Inadequate ventilation may cause temperature increase which would
damage the instrument. So please keep the instrument well ventilated
during operation and inspect the intake and fan regularly.

RIGOL
MSO2000A/DS2000A Quick Guide
IV
Working Environment
Temperature
Operating: 0℃to +50℃
Non-operating: -40℃to +70℃
Humidity
0℃to +30℃: ≤95％relative humidity
+30℃to +40℃: ≤75％relative humidity
+40℃to +50℃: ≤45％relative humility
WARNING
To avoid short circuit inside the instrument or electric shock, please do not
operate in humid environment.
Altitude
Operating: less than 3 km
Non-operating: less than 15 km
Installation (overvoltage) Category
This product is powered by mains conforming to installation (overvoltage) category
II.
WARNING
Make sure that no overvoltage (such as that caused by thunderbolt) can
reach the product, or else the operator might expose to danger of electric
shock.
Installation (overvoltage) Category Definitions
Installation (overvoltage) category I refers to signal level which is applicable to
equipment measurement terminals connected to the source circuit. In these
terminals, precautions are done to limit the transient voltage to the corresponding
low level.
Installation (overvoltage) category II refers to the local power distribution level
which is applicable to equipment connected to the AC line(AC power).
Pollution Degree
Degree 2
Pollution Degree Definitions
Pollution degree 1: No pollution or only dry, non-conductive pollution occurs. The
pollution has no influence. For example: a clean room or air-conditioned office
environment.

RIGOL
MSO2000A/DS2000A Quick Guide
V
Pollution degree 2: Normally only dry, non-conductive pollution occurs. Occasionally
a temporary conductivity caused by condensation may occur. For example: general
indoor environment.
Pollution degree 3: Conductive pollution occurs, or dry, non-conductive pollution
occurs which becomes conductive due to condensation which is expected. For
example: Sheltered outdoor environment.
Pollution degree 4: Pollution that generates persistent conductivity through
conductive dust, rain, or snow. For example: outdoorlocations.
Safety Class
Class 1 –Grounded Product
General Care and Cleaning
Care:
Do not store or leave the instrument in where the instrument will be exposed to
direct sunlight for long periods of time.
Cleaning:
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with
mild detergent or water. Avoid having any water or other objects into the
chassis via the heat dissipation hole. When cleaning the LCD, take care to avoid
scarifying it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries, ensure
that the instrument is completely dry before connecting it to the power
supply.

RIGOL
MSO2000A/DS2000A Quick Guide
VI
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.
Document Overview
This manual is used to guide users to quickly get familiar with the front panel, rear
panel, user interface and basic operation method of MSO2000A/DS2000A series
digital oscilloscope. You can download the newest version of the manual from
RIGOLofficial website (www.rigol.com).
Format Conventions in this Manual:
1. Button
The front panel keys are denoted by the format of "Button Name (Bold) + Text
Box". For example,Utilitydenotes the "Utility"key.
2. Menu
The menu softkeys are denoted by the format of "Menu Word (Bold) +
Character Shading". For example,Systemdenotes the "System"menu under
Utility.
3. Operation Step
The next step of operation is denoted by an arrow "". For
example,UtilitySystemdenotesthat first press Utility on the front panel and
then press System.
4. Knob
Label
Knob
HORIZONTAL SCALE
Horizontal Scale Knob
HORIZONTAL POSITION
Horizontal Position Knob
VERTICAL SCALE
Vertical Scale Knob
VERTICAL POSITION
Vertical Position Knob
TRIGGER LEVEL
Trigger Level Knob

RIGOL
MSO2000A/DS2000A Quick Guide
VII
Content Conventions in this Manual:
MSO2000A/DS2000A series includes the following models. This manual takes
MSO2302A-S as an example to illustrate the functions and operation methods of
MSO2000A/DS2000A series.
Model
Analog
Bandwidth
Number of
Analog
Channels
Number of
Source Channels
MSO2102A/DS2102A
100 MHz
2
--
MSO2102A-S
100 MHz
2
2
MSO2202A/DS2202A
200 MHz
2
--
MSO2202A-S
200 MHz
2
2
MSO2302A/DS2302A
300 MHz
2
--
MSO2302A-S
300 MHz
2
2

RIGOL
MSO2000A/DS2000A Quick Guide
VIII
Contents
Guaranty and Declaration......................................................................... I
Safety Requirement.................................................................................II
General Safety Summary........................................................................... II
Safety Notices and Symbols ...................................................................... II
Measurement Category............................................................................III
Ventilation Requirement...........................................................................III
Working Environment .............................................................................. IV
General Care and Cleaning........................................................................ V
Environmental Considerations................................................................... VI
Document Overview ............................................................................... VI
Quick Start ...............................................................................................1
General Inspection ....................................................................................1
Appearance and Dimensions ......................................................................2
To Prepare for Operation............................................................................3
To Adjust the Supporting Legs .............................................................3
To Connect to AC Power Supply ...........................................................3
Turn-on Checkout ...............................................................................4
To Connect the Probe..........................................................................4
Function Inspection ............................................................................6
Probe Compensation...........................................................................7
Front Panel Overview ................................................................................8
Rear Panel Overview .................................................................................9
Front Panel Function Overview .................................................................11
VERTICAL ........................................................................................11
HORIZONTAL ...................................................................................12
TRIGGER .........................................................................................13
CLEAR .............................................................................................14
RUN/STOP .......................................................................................14
SINGLE............................................................................................14
AUTO ..............................................................................................14
Knob ...............................................................................................15
Navigation Knob ...............................................................................15
MENU..............................................................................................16
Signal Source ...................................................................................16
Record.............................................................................................17
Print................................................................................................17
Logic Analyzer..................................................................................18
User Interface.........................................................................................19
To Use the Security Lock..........................................................................24
To Use the Built-in Help System................................................................25
Troubleshooting .....................................................................................26

RIGOL
MSO2000A/DS2000A Quick Guide
1
Quick Start
General Inspection
1. Inspect the packaging
If the packaging has been damaged, do not dispose the damaged packaging or
cushioning materials until the shipment has been checked for completeness and
has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrumentresulting
from shipment. RIGOL would not be responsible for free maintenance/rework
or replacement of the instrument.
2. Inspect the instrument
In case of any mechanical damage, missing parts, or failure in passing the
electrical and mechanical tests, contact your RIGOL sales representative.
3. Check the accessories
Please check the accessories according to the packing lists. If the accessories
are damaged or incomplete, please contact yourRIGOL sales representative.

RIGOL
MSO2000A/DS2000A Quick Guide
2
Appearance and Dimensions
Figure 1 Front View Unit: mm
Figure 2 TopView Unit: mm
361.6
179.6

RIGOL
MSO2000A/DS2000A Quick Guide
3
To Prepare for Operation
To Adjust the Supporting Legs
Adjust the supporting legs properly to use them as stands to tilt the oscilloscope
upwards for stable placement of the oscilloscope as well as betteroperation and
observation.
Figure 3 To Adjust the Supporting Legs
To Connect to AC Power Supply
This oscilloscope can accept100-240V, 45-440 Hz AC power supply. Please use the
power cord supplied with the accessories to connect the oscilloscope to the power
supplyas shown in the figure below. Whenthe oscilloscope is powered onand the
Power key at the lower-left corner of the front panel is blinking.
Figure 4 To Connect to AC Power Supply
Power Cord Connector

RIGOL
MSO2000A/DS2000A Quick Guide
4
Turn-on Checkout
When the oscilloscope is connected to power, press the Power key at the
lower-left corner of the front panel to start the oscilloscope. During the start-up
process, the oscilloscope performs a series of self-test items and you can hear the
sound of relay switching. After the self-test, the welcome screen is displayed. The
instrument is installed with the trial versions of the options before leaving factory and
the remaining time is about 2,000 minutes. The "Current Options"dialog box will be
displayed if your instrument has currently installedthe trial versions of options. From
this dialog box you can view the types, names, versions and the remaining time of
the options currently installed.
To Connect the Probe
RIGOLprovides passive probes for DS2000A, and provides passive probes and logic
probes for MSO2000A. For the model of the probes, please refer to
MSO2000A&DS2000A Series Datasheet . For detailed technical information of the
probes, please refer to corresponding Probe User’s Guide.
Connect the Passive Probe:
1. Connect the BNC terminal of the probe to an analog channel inputof the
oscilloscope onthe front panel.
2. Connect the ground alligator clip or spring of the probeto the circuit ground
terminal and then connect the probe tip to the circuit point under test.
Figure 5 To Connect the Passive Probe

RIGOL
MSO2000A/DS2000A Quick Guide
5
After you connect the passive probe, check the probe function and probe
compensation adjustment before making measurements. For detailed procedures,
refer to "Function Inspection" and "Probe Compensation" sections in this
manual.
Connect the Logic Probe:
1. Connect the single-wire terminal of the logic probe to the [LOGIC D0-D15]
digital channel terminalonthe front panel of MSO2000A in the correct direction.
2. Connect the other terminal of the logic probe tothe signal under test. RIGOL
provides MSO2000A with the standard RPL2316 logic probe. To cater to different
application scenarios, RPL2316 provides three connection methods for the signal
under test. For details, please refer to the RPL2316 Logic Probe User’s Guide .
Figure 6 To Connect the Logic Probe
Note: The digital channel input terminal does not support hot plugging. Please do
not insert or pull out the logic probe when the instrument is in power-on state.

RIGOL
MSO2000A/DS2000A Quick Guide
6
Function Inspection
1. Press StorageDefault to restore the oscilloscope to its default configuration.
2. Connect the groundalligator clip of the probe to the "GroundTerminal"as shown
in the figure below.
3. Use the probe to connect the input terminal of CH1 and the "Compensation
Signal Output Terminal" of the oscilloscope.
Figure 7 To Use the Compensation Signal
4. Set the attenuationon the probe to 10X. ThenpressAUTO.
5. Observe the waveform on the display. In normal condition, the display should be
a square waveform as shown in the figure below:
Figure 8 Square Waveform
6. Use the same method to test the other channels. If the square waveforms
actually shown do not match that in the figure above, please perform "Probe
Compensation".
WARNING
To avoid electric shock during the use of probe, please make sure that the
insulated wire of the probe is in good condition. Do not touch the metallic
part of the probe when the probe is connected to high voltage source.
Compensation Signal Output Terminal
Ground Terminal

RIGOL
MSO2000A/DS2000A Quick Guide
7
Tip
The signal output from the probe compensation connector can only be used
for probe compensation adjustment and cannot be used for calibration.
Probe Compensation
When the probes are used for the first time, you should compensate the probes to
match the input channels of the oscilloscope. Non-compensated or poorly
compensated probes may cause measurement inaccuracy or errors. The probe
compensation proceduresare as follows:
1. Perform Step 1, 2, 3 and 4 specified in"Function Inspection".
2. Check the displayed waveforms and compare them with the waveforms in the
following figure.
Figure 9 Probe Compensation
3. Use a nonmetallic driver to adjust the low-frequency compensation adjustment
hole on the probe until the displayed waveform is displayed as the
"Perfectlycompensated"in the figure above.
Over compensatedPerfectly compensatedUnder compensated

RIGOL
MSO2000A/DS2000A Quick Guide
8
Front Panel Overview
Figure 10 Front Panel Overview
Table 1 Front Panel Description
No.
Description
No.
Description
1
Measurement Menu Softkeys
13
Power Key
2
LCD
14
USB HOST Interface
3
Logic Analysis Control Key[1]
15
Digital Channel Input Interface[1]
4
Multifunction Knob
16
HORIZONTAL Control Area
5
Function Menu Keys
17
Function Menu Softkeys
6
Signal Source[2]
18
VERTICAL Control Area
7
Navigation Knob
19
Analog Channel Input Area
8
CLEAR
20
Waveform Record/Playback Control Keys
9
AUTO
21
TRIGGER Control Area
10
RUN/STOP
22
EXT TRIG Input Terminal
11
SINGLE
23
Probe Compensation Signal Output
Terminal/ Ground Terminal
12
Help/Print
--
--
Note[1]: Only applicable to MSO2000A and MSO2000A-S models.
Note[2]:Only applicable to the MSO2000A-S model.
3 4 5 6 7 8 9 10 11 12
1 2
(1) (2)
13 14 15 16 17 18 19 20 21 22 23

RIGOL
MSO2000A/DS2000A Quick Guide
9
Rear Panel Overview
Figure 11 Rear Panel Overview
1．Handle
Pull up the handle vertically for easy carrying of the instrument. When you do
not need the handle, press it down.
2．LAN
Connect the instrument to the network via this interface for remote control. This
oscilloscope conforms to the LXI CORE 2011 DEVICE class instrument standards
and can quickly build test system with other instruments.
3．USB DEVICE
PictBridge printer or PC can be connected via this interface to print waveform
data or control the instrument using PC software.
4．Fuse
If a new fuse is required, please use the specified fuse (250V, T2A). The
operationmethod is as follows:
1 2 3
4 5 6 7 8

RIGOL
MSO2000A/DS2000A Quick Guide
10
(1) Turn off the instrument and remove the power cord.
(2) Insert a small straight screwdriverinto the slot at the power cord
connectorand pry out the fuse holder gently.
(3) Take out the fuse and replace it with a specified fuse. Then,install the fuse
holder.
5．AC PowerCord Connector
AC power input terminal. The power requirements of this oscilloscope
are100-240 V, 45-440 Hz. Use the power cord provided with the accessories to
connect the instrument to AC power. Then, you can press the Power key onthe
front panel to start the instrument.
6．Lock Hole
You can lock the instrument to a fixed location by using the security lock (please
purchaseit yourself) via the lock hole.
7．Trigger Out
The oscilloscope can output a signal that can reflect the current capture rate of
the oscilloscope at each trigger via this interface. Connect the signal to
awaveform display device and measure the frequency of the signal. The
measurement result is the same asthe current capture rate. The instrument can
also outputa signalwhen a failed waveform is detected during the pass/fail test.
8．Source Output
When Source1 or Source2 is enabled, thesignal currently set can
beoutputthrough the [Source1]or[Source2]connectoron the rear panel to the
analog input terminal of the oscilloscope or external devices connected to the
connector. This function is only available for the MSO2000A-S model.
