Fluke SPOT Light User manual

PN 4151274
February 2012 | Rev. 2, 1/22
© 2012-2022 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
SPOT Light
SpO2 Functional Tester

Warranty and Product Support
Fluke Biomedical warrants this instrument against defects in materials and workmanship for two years from the date of
original purchase. You will be charged our customary fee for such calibration. During the warranty period, we will repair or at
our option replace, at no charge, a product that proves to be defective, provided you return the product, shipping prepaid, to
Fluke Biomedical. This warranty covers the original purchaser only and is not transferable. The warranty does not apply if
the product has been damaged by accident or misuse or has been serviced or modified by anyone other than an authorized
Fluke Biomedical service facility. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR PURPOSE, ARE
EXPRESSED OR IMPLIED. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
This warranty covers only serialized products and their accessory items that bear a distinct serial number tag. Recalibration
of instruments is not covered under the warranty.
This warranty gives you specific legal rights and you may also have other rights that vary in different jurisdictions. Since
some jurisdictions do not allow the exclusion or limitation of an implied warranty or of incidental or consequential damages,
this limitation of liability may not apply to you. If any provision of this warranty is held invalid or unenforceable by a court or
other decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability of any other provision.
7/07

Notices
All Rights Reserved
Copyright 2012-2022, Fluke Biomedical. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language without the written permission of Fluke Biomedical.
Copyright Release
Fluke Biomedical agrees to a limited copyright release that allows you to reproduce manuals and other printed materials for use in service
training programs and other technical publications. If you would like other reproductions or distributions, submit a written request to Fluke
Biomedical.
Unpacking and Inspection
Follow standard receiving practices upon receipt of the instrument. Check the shipping carton for damage. If damage is found, stop unpacking
the instrument. Notify the carrier and ask for an agent to be present while the instrument is unpacked. There are no special unpacking
instructions, but be careful not to damage the instrument when unpacking it. Inspect the instrument for physical damage such as bent or
broken parts, dents, or scratches.
Technical Support
For application support or answers to technical questions, either email [email protected] or call 1-800- 850-4608 or 1-440-
248-9300. In Europe, call [phone].
Claims
Our routine method of shipment is via common carrier, FOB origin. Upon delivery, if physical damage is found, retain all packing materials in
their original condition and contact the carrier immediately to file a claim. If the instrument is delivered in good physical condition but does not
operate within specifications, or if there are any other problems not caused by shipping damage, please contact Fluke Biomedical or your local
sales representative.

Returns and Repairs
Return Procedure
All items being returned (including all warranty-claim shipments) must be sent freight-prepaid to our factory location. When you return an
instrument to Fluke Biomedical, we recommend using United Parcel Service, Federal Express, or Air Parcel Post. We also recommend that
you insure your shipment for its actual replacement cost. Fluke Biomedical will not be responsible for lost shipments or instruments that are
received in damaged condition due to improper packaging or handling.
Use the original carton and packaging material for shipment. If they are not available, we recommend the following guide for repackaging:
Use a double–walled carton of sufficient strength for the weight being shipped.
Use heavy paper or cardboard to protect all instrument surfaces. Use nonabrasive material around all projecting parts.
Use at least four inches of tightly packed, industry-approved, shock-absorbent material around the instrument.
Returns for partial refund/credit:
Every product returned for refund/credit must be accompanied by a Return Material Authorization (RMA) number, obtained from our Order
Entry Group at 1-440-498-2560.
Repair and Calibration:
For customers based in the U.S.A., please contact Fluke Electronics at [e-mail], or call 1-833-296-9420.
All other customers, please go to www.flukebiomedical.com/service to find the nearest service center.

Certification
This instrument was thoroughly tested and inspected. It was found to meet Fluke Biomedical’s manufacturing specifications when it was
shipped from the factory. Calibration measurements are traceable to the National Institute of Standards and Technology (NIST). Devices for
which there are no NIST calibration standards are measured against in-house performance standards using accepted test procedures.
WARNING
Unauthorized user modifications or application beyond the published specifications may result in electrical shock hazards or improper
operation. Fluke Biomedical will not be responsible for any injuries sustained due to unauthorized equipment modifications.
Restrictions and Liabilities
Information in this document is subject to change and does not represent a commitment by Fluke Biomedical. Changes made to the
information in this document will be incorporated in new editions of the publication. No responsibility is assumed by Fluke Biomedical
for the use or reliability of software or equipment that is not supplied by Fluke Biomedical, or by its affiliated dealers.
Manufacturing Location
The SPOT Light SpO2 Functional Tester is manufactured at Fluke Biomedical, 6920 Seaway Blvd., Everett, WA, U.S.A.

i
Table of Contents
Title Page
Introduction .................................................................................................................... 1
Intended Use .................................................................................................................. 2
Safety Information .......................................................................................................... 2
Unpack the Product........................................................................................................ 3
Instrument Familiarization .............................................................................................. 4
Accessories.................................................................................................................... 5
How to Turn On the Product........................................................................................... 6
How to Use the Product ................................................................................................. 6
SpO2 Sensor Placement ........................................................................................... 6
How to Set Test Parameters ..................................................................................... 8
How to Set Custom Tests............................................................................................... 9
Maintenance................................................................................................................... 10
How to Clean the Product.......................................................................................... 11
Battery Maintenance.................................................................................................. 11
How to Charge the Battery ................................................................................... 11

SPOT Light
Users Manual
ii
Battery Removal................................................................................................... 13
General Specifications................................................................................................... 14
Detailed Specifications .................................................................................................. 14
Oximeter SpO2Optical Emitter and Detector ............................................................ 14

iii
List of Tables
Table Title Page
1. Symbols................................................................................................................................. 2
2. Product Controls and Connections........................................................................................ 4
3. Standard Accessories ........................................................................................................... 5
4. Optional Accessories............................................................................................................. 5
5. Test Parameters.................................................................................................................... 8

SPOT Light
Users Manual
iv

v
List of Figures
Figure Title Page
1. Product Controls and Connections ........................................................................................ 4
2. Power-Up Screen .................................................................................................................. 6
3. Main Screen .......................................................................................................................... 6
4. Oximeter Sensor Placement.................................................................................................. 7
5. SpO2 Parameter Change ...................................................................................................... 9
6. External Battery Charging Connections ................................................................................ 12
7. Battery Removal.................................................................................................................... 13

SPOT Light
Users Manual
vi

1
SpO2 Functional Tester
Introduction
 Warning
To prevent possible electrical shock, fire, or
personal injury, read all “safety information”
before you use the Product.
The Fluke Biomedical SPOT Light SpO2 Functional
Tester (the Product) is a compact, portable, functional
tester used to measure the performance of SpO2
monitors (pulse oximeters).
The Product uses light detection and emission to do tests.
The tests examine the electronics of the pulse oximeter
and the sensor.
Table 1 is a list of the symbols used on the Product and in
this manual.

SPOT Light
Users Manual
2
Table 1. Symbols
Symbol Description

Important information. Refer to manual.

Hazardous voltage.
Conforms to relevant Canadian and US
standards.
Conforms to relevant Australian EMC
requirements.
 Conforms to European Union directives.
Do not dispose of this product as
unsorted municipal waste. Go to Fluke’s
website for recycling information.
Intended Use
The Product is intended to be used to test and verify the
basic operation of patient monitoring devices or systems
used to monitor SpO2. Additionally, the Product provides
an optical signal to verify the electronics inside the pulse
oximeter sensor are functional.
The intended user is a trained biomedical equipment
technician who performs periodic preventative
maintenance checks on patient monitors in service. Users
can be associated with hospitals, clinics, original
equipment manufacturers and independent service
companies that repair and service medical equipment.
The end user is an individual, trained in medical
instrumentation technology.
This Product is not intended for use on patients, or to test
devices while connected to patients. This Product is not
intended to be used to calibrate medical equipment.
Safety Information
A Warning identifies conditions and procedures that are
dangerous to the user. A Caution identifies conditions
and procedures that can cause damage to the Product or
the equipment under test.
 Warning
To prevent possible electrical shock, fire, or
personal injury, follow these guidelines:
•Do not connect the Product to a patient
or equipment connected to a patient. The
Product is intended for equipment
evaluation only and should never be
used in diagnostics, treatment, or any
other capacity where the Product would
come in contact with a patient.
•Use the Product only as specified, or the
protection supplied by the Product can
be compromised.

SpO2 Functional Tester
Unpack the Product
3
•Replace the batteries when the low
battery indicator shows to prevent
incorrect measurements.
•Carefully read all instructions.
•Do not use the Product around explosive
gas, vapor, or in damp or wet
environments.
•Do not use, and disable the Product if it
is damaged.
•Do not use the Product if it operates
incorrectly.
•Use only current probes, test leads, and
adapters supplied with the Product.
Caution
The pulse oximeter component of the device
is not intended to validate the SpO2 accuracy
of pulse oximeter equipment.
This device is not intended to confirm the
SpO2 accuracy of the calibration curve of the
pulse oximeter monitor or to assess the
optical characteristics of representative
pulse oximeter sensors to determine their
proper calibration.
Not all functional testers and pulse oximeter
equipment are compatible. Functional testers
can vary in pulse methods, pulse contours,
and amplitude. A functional tester might not
accurately reproduce the calibration of the
pulse oximeter equipment and can yield
different results between pulse oximeter
equipment.
Unpack the Product
Carefully unpack all items from the box and check that
you have these items:
•SPOT Light
•Users Manual
•Carrying Case
•Power Cord
•AC/DC Power Supply

SPOT Light
Users Manual
4
Instrument Familiarization
Table 2 is a list of Product controls and connections
shown in Figure 1.
Figure 1. Product Controls and Connections
Table 2. Product Controls and Connections
Item Description
1 SpO2 Artificial Finger
2 Scroll Up and Down Buttons
3 Select Button
4 LCD Display
5 Mini B USB Device Port (Service use only)

SpO2 Functional Tester
Accessories
5
Accessories
Available Product accessories are shown in Table 3 and 4.
Table 3. Standard Accessories
Item Fluke Biomedical Part Number
SPOT Light Users Manual 4151274
AC/DC Power Supply 4766589
AC Power Cord
US 284174
Schuko 769422
UK 769455
Japan 284174
Australia/China 658641
Brazil [1] 3841347
Carrying Case 4026799
[1] Product shipped to Brazil also includes a US power cord.
Table 4. Optional Accessories
Item Fluke Biomedical Part Number
Battery Pack 4026823

SPOT Light
Users Manual
6
How to Turn On the Product
Push for one second to turn on the Product. The
screen shown in Figure 2 is the power-up screen. Push
and hold for 3 seconds to turn off the Product.
Figure 2. Power-Up Screen
Note
Firmware version shown is for illustration only.
The version shown on your Product could be
different.
When the self test is complete and no errors are sensed,
the screen shown in Figure 3 shows in the display.
Figure 3. Main Screen
How to Use the Product
All Product tests are set through the controls on the main
screen. As each parameter is set, the test value changes
immediately.
SpO2 Sensor Placement
Put the SpO2 sensor on the artificial finger as shown in
Figure 4.

SpO2 Functional Tester
How to Use the Product
7
Figure 4. Oximeter Sensor Placement

SPOT Light
Users Manual
8
Put the sensor with the LEDs on the bottom of the
artificial finger. While you put the sensor on the artifact
finger, monitor the signal indicator along the bottom of the
Product display. Adjust the sensor on the finger for
maximum signal strength.
Note
Cable position changes with sensor
manufacturer
How to Set Test Parameters
When you turn on the Product, all parameters are set to
their default values. To change a parameter value, push
or to move the highlight to a parameter that
you need to change. Push to move the highlight to
the value of the parameter. Push or to
scroll through the values. With the correct parameter
value shown in the display, push to set the
parameter. Table 5 is a list of all parameters and their
values.
Table 5. Test Parameters
Parameter Values*
SpO2 70%, 75%, 80%, 85%, 90%,
95%, 97%, 98%, 99%, 100%
HR (Heart Rate) 30, 40, 60, 65, 80, 100, 120,
140, 150, 180, and 240 BPM
PA (Pulse Amplitude) 0.2%, 2.0%, and 10%
Transmission LG (Large), Med (Medium),
and Sm (Small) finger
Artifact None, Respiration: 2.5%,
Ambient light: 50 or 60 Hz
Type Nonin, Masimo, Nellcor, Nihon
Kohden, Mindray, GE-Ohmeda,
Philips/HP, and BCI
Test Manual, Custom 1, Custom 2,
and Custom 3
* Default values are in bold type.
