Document Overview
This manual is used to guide users to correctly test the performance specifications of
DG2000 series function/arbitrary waveform generator. The performance verification
test mainly verifies whether DG2000 series can work normally and is within
specifications.
Main topics in this Manual:
Chapter 1 Test Overview
This chapter introduces the preparations before the performance verification test,
the recommended test devices, the test result record, the test notices and the
related information of the technical parameters.
Chapter 2 Performance Verification Test
This chapter introduces the test method, procedures and limits of each performance
specification in details.
Appendix
The appendix provides the test results record forms and performance specifications
of DG2000 series function/arbitrary waveform generator.
Format Conventions in this Manual:
1. Keys:
The keys on the front panel are usually denoted by the format of "Key Name
(Bold) + Text Box". For example, Pulse/Utility denotes the Utility key.
2. Menu Labels:
The menu labels are usually denoted by the format of "Menu Word (Bold) +
Character Shading". For example, System Setting.
3. Connectors:
The connectors on the front or rear panel are usually denoted by the format of
"Connector Name (Bold) + Square Brackets (Bold)". For example, [Counter].
4. Operation Procedures:
"" represents the next step of operation. For example, when the backlight of
the Shift key is illuminated, pressing Pulse/Utility System Setting
denotes that first press Pulse/Utility on the front panel, and then tap the
System Setting menu label.

RIGOL
DG2000 Performance Verification Guide
V
Content Conventions in this Manual:
DG2000 series function/arbitrary waveform generator includes the following models.
Unless otherwise noted in this manual, DG2102 is taken as an example to illustrate
the performance verification test methods of DG2000 series.
Model
No. of Channels
Max. Output Frequency
DG2052
2
50 MHz
DG2072
2
70 MHz
DG2102
2
100 MHz

Contents RIGOL
DG2000 Performance Verification Guide
VI
Contents
Guaranty and Declaration......................................................................... I
General Safety Summary.........................................................................II
Document Overview...............................................................................IV
Chapter 1 Test Overview.................................................................... 1-1
Test Preparations ...................................................................................1-1
Recommended Test Devices....................................................................1-1
Test Result Record .................................................................................1-2
Test Notices...........................................................................................1-2
Technical Parameters..............................................................................1-2
Chapter 2 Performance Verification Test ........................................... 2-1
Frequency Accuracy Test.........................................................................2-2
Specification ...................................................................................2-2
Test Procedures...............................................................................2-2
Test Record Form ............................................................................2-3
AC Amplitude Accuracy Test ....................................................................2-4
Specification ...................................................................................2-4
Test Procedures...............................................................................2-4
Test Record Form ............................................................................2-5
DC Offset Accuracy Test..........................................................................2-6
Specification ...................................................................................2-6
Test Procedures...............................................................................2-6
Test Record Form ............................................................................2-7
AC Flatness Test.....................................................................................2-8
Specification ...................................................................................2-8
Test Procedures...............................................................................2-8
Test Record Form ..........................................................................2-11
Harmonic Distortion Test.......................................................................2-12
Specification .................................................................................2-12
Test Procedures.............................................................................2-12
Test Record Form ..........................................................................2-14
Spurious Signal Test.............................................................................2-15
Specification .................................................................................2-15
Test Procedures.............................................................................2-15
Test Record Form ..........................................................................2-17
Rise/Fall Time Test...............................................................................2-18
Specification .................................................................................2-18
Test Procedures.............................................................................2-18
Test Record Form ..........................................................................2-19
Overshoot Test ....................................................................................2-20
Specification .................................................................................2-20
Test Procedures.............................................................................2-20
Test Record Form ..........................................................................2-21

Contents RIGOL
DG2000 Performance Verification Guide
VII
Appendix..................................................................................................1
Appendix A: Test Result Record Form......................................................... 1
Appendix B: Performance Specifications ..................................................... 8

Chapter 1 Test Overview RIGOL
DG2000 Performance Verification Guide
1-1
Chapter 1 Test Overview
Test Preparations
Before performing the test, make sure that the instrument is within the calibration
period (the recommended calibration period is 1 year) and has been warmed up for
at least 30 minutes under the specified operation temperature (18℃to 28℃).
Recommended Test Devices
It is recommended that you use the test devices listed in the table below or other test
devices whose performance specifications satisfy the "Performance Requirement"
listed in the table below to test the performance specifications of the DG2000 series.
Table 1-1 Recommended test devices
Device Performance Requirement
Recommended
Instrument
Frequency Counter
>10MHz
Accuracy: 0.1ppm
Keysight 53131A
Digital Multimeter
61/2digits
RIGOL DM3068
Power Meter
-30dBm to +20dBm
Accuracy: ±0.02dB
Resolution: 0.01dB
Keysight N1913A
Power Sensor
-30dBm to +20dBm
Keysight N8482A
Spectrum Analyzer
Minimum resolution bandwidth is
100Hz
RIGOL DSA815
Oscilloscope
Bandwidth: 500MHz
Rise/Fall time measurement
function
Overshoot measurement
function
RIGOL DS4052/DS4054
Power Sensor
Connecting Cable
Used to connect the power meter
and power sensor
--
Connecting Cable
BNC (m)-BNC (m)
--
Connecting Cable
BNC (m)-Dual banana plug (m)
--
50Ω Load
50Ω/1W
--
Adaptor
N (f)-BNC (m)
--
Adaptor
BNC (f)-N (m)
--

RIGOL Chapter 1 Test Overview
DG2000 Performance Verification Guide
1-2
Test Result Record
Record and keep the test results of each test item. The test result record forms,
which provide all the test items and the corresponding performance specification
limits as well as spaces for users to record the test results, are provided in
“Appendix A: Test Result Record Form” of this manual.
Tip:
It is recommended that you photocopy the test result record form before each test.
During the test process, record the test results on the copies so that the forms can
be used repeatedly.
Test Notices
To achieve optimum test effect, all the test procedures should follow the following
recommendations.
1) Make sure that the environment temperature is between 18℃and 28℃and
every test is performed under the specified operation temperature (18℃to
28℃).
2) Before performing each test, make sure that the instrument has been warmed
up for at least 30 minutes.
3) Before performing each test, restore the instrument to factory setting.
Technical Parameters
Chapter 2 of this manual provides the corresponding specification of each test item.
Besides, "Appendix B: Performance Specifications" provides the detailed
performance specifications of DG2000 series.

Chapter 2 Performance Verification Test RIGOL
DG2000 Performance Verification Guide
2-1
Chapter 2 Performance Verification Test
This chapter introduces the performance verification test methods of DG2000 series
function/arbitrary waveform generator by taking CH1 of DG2102 as an example. The
test methods are also applicable to CH2.
The test items include:
Frequency Accuracy Test
AC Amplitude Accuracy Test
DC Offset Accuracy Test
AC Flatness Test
Harmonic Distortion Test
Spurious Signal Test
Rise/Fall Time Test
Overshoot Test

RIGOL Chapter 2 Performance Verification Test
DG2000 Performance Verification Guide
2-2
Frequency Accuracy Test
Specification
Frequency characteristic
Accuracy
±(1 ppm[1] of the setting value + 10 pHz), 18
℃
to 28
℃
Note[1]:ppm denotes one part per million. For example, if the setting frequency is 1MHz and the actual output
frequency is between 0.999 998 999 999 999 99MHz and 1.000 001 000 000 000 01MHz, the instrument is up
to the specification requirement and the test passes.
Test Procedures
1. Make sure that the environment temperature is between 18℃and 28℃and
DG2000 has been warmed up for at least 30 minutes. Connect the channel
output terminal (take CH1 as an example; the test method is also applicable to
CH2) of DG2000 with the signal input terminal of the frequency counter using a
dual-BNC cable as shown in Figure 2-1.
DG2000 Series Frequency Counter
Figure 2-1 Connect DG2000 and the Frequency Counter
2. Turn on the frequency counter and set its output impedance to 1MΩ.
3. Turn on DG2000. When the Shift key is illuminated, press Sine/Preset and
tap the Def icon, then a dialog box is displayed, tap "Apply"to restore DG2000
to the factory setting.
4. Set DG2000:
a) Set the output waveform of CH1 to a sine waveform with 1MHz frequency
and 1Vpp amplitude.
b) Press Output1or tap the channel output configuration status bar
to turn on the output of CH1 in the channel setting interface.
5. Record the reading of the frequency counter and judge whether the reading is
between 0.999 998 999 999 999 99MHz and 1.000 001 000 000 000 01MHz.
6. Set CH1 of DG2000 to output square, ramp and pulse waveforms (the
frequencies are 1MHz and the amplitudes are 1Vpp) respectively. Record the
◎

Chapter 2 Performance Verification Test RIGOL
DG2000 Performance Verification Guide
2-3
readings of the frequency counter respectively and judge whether the readings
are between 0.999 998 999 999 999 99MHz and 1.000 001 000 000 000 01MHz.
7. Repeat steps 1 to 6 to test the frequency accuracy of CH2 and record the test
results.
Test Record Form
Waveform
Setting
Value
Measurement
Value
Specification Pass/Fail
Sine Frequency:
1MHz
Amplitude:
1Vpp
0.999 998 999 999 999
99MHz to 1.000 001 000 000
000 01MHz
Square
Ramp
Pulse

RIGOL Chapter 2 Performance Verification Test
DG2000 Performance Verification Guide
2-4
AC Amplitude Accuracy Test
Specification
Output Characteristic
Amplitude (into 50Ω)
Accuracy
Typical (1kHz Sine, 0V Offset, >10mVpp, Auto)
±(1% of setting value) ±5mV
Test Procedures
1. Make sure that the environment temperature is between 18℃and 28℃and
DG2000 has been warmed up for at least 30 minutes. Connect the 50Ωload to
the channel output terminal (take CH1 as an example; the test method is also
applicable to CH2) of DG2000; connect the 50Ωload and the voltage input
terminals of the digital multimeter using a BNC-Dual banana plug connecting
cable as shown in Figure 2-2.
DG2000 Series Digital Multimeter
50Ω Load
Figure 2-2 Connect DG2000 and the Digital Multimeter via a 50Ω Load
2. Turn on the multimeter, select the ACV measurement function and set the range
to “Auto”.
3. Turn on DG2000. When the Shift key is illuminated, press Sine/Preset and
tap the Def icon, then a dialog box is displayed, tap "Apply"to restore DG2000
to the factory setting.
4. Set DG2000:
a) Set the output impedance of CH1 to 50Ω. (Tap the channel output
configuration status bar under the user interface to enter the
channel setting interface. Tap the OutputSet HighZ to select "Off". Tap
the Impedance menu label, and set the impedance to 50Ω.)
b) Set the output waveform of CH1 to a sine waveform with 1kHz frequency,
20mVpp amplitude and 0Vdc offset.
◎◎
◎◎
◎

Chapter 2 Performance Verification Test RIGOL
DG2000 Performance Verification Guide
2-5
c) Press Output1or tap the channel output configuration status bar
to turn on the output of CH1 in the channel setting interface.
5. Record the reading of the multimeter and judge whether it is within the
specification ("Amplitude Output Value (Vrms)" in Table 2-1) range.
6. Keep the output impedance of CH1 of DG2000 at 50Ωand the output waveform
of CH1 as a sine waveform with 1kHz frequency and 0Vdc offset. Set the output
amplitude of CH1 to 100mVpp, 500mVpp, 1Vpp, 5Vpp and 10Vpp respectively.
Record the readings of the multimeter respectively and judge whether the
readings are within the specification (“Amplitude Output Value (Vrms)” in Table
2-1) range.
Table 2-1 Amplitude output values (Vrms) of AC amplitude accuracy test
Amplitude
Setting
Value
(Vpp)
Allowed
Error (Vpp)[1] Amplitude Output Value (Vpp) Amplitude Output Value (Vrms)[2]
20mVpp ±5.2mVpp 14.8mVpp to 25.2mVpp 5.2mVrms to 8.9mVrms
100mVpp ±6mVpp 94mVpp to 106mVpp 33.2mVrms to 37.5mVrms
500mVpp ±10mVpp 490mVpp to 510mVpp 173.3mVrms to 180.3mVrms
1Vpp ±15mVpp 0.985Vpp to 1.015Vpp 348.3mVrms to 358.9mVrms
5Vpp ±55mVpp 4.945Vpp to 5.055Vpp 1.75Vrms to 1.7875Vrms
10Vpp ±105mVpp 9.895Vpp to 10.105Vpp 3.5Vrms to 3.5732Vrms
Note[1]:"Allowed Error" is calculated from the specification "±(1% of setting value) ±5mVpp".
Note[2]:"Amplitude Output Value (Vrms)" is calculated from "Amplitude Output Value (Vpp)".
The conversion relation between Vrms and Vpp is
rms22pp VV =
.
7. Repeat Step 1-6 to test the AC amplitude accuracy of CH2 and record the test
results.
Test Record Form
Amplitude
Setting
Value
Setting Measurement
Value Specification Pass/Fail
20mVpp
Frequency:
1kHz
Offset: 0Vdc
Impedance:
50Ω
5.2mVrms to 8.9mVrms
100mVpp 33.2mVrms to 37.5mVrms
500mVpp 173.3mVrms to 180.3mVrms
1Vpp 348.3mVrms to 358.9mVrms
5Vpp 1.75Vrms to 1.7875Vrms
10Vpp 3.5Vrms to 3.5732Vrms

RIGOL Chapter 2 Performance Verification Test
DG2000 Performance Verification Guide
2-6
DC Offset Accuracy Test
Specification
Output Characteristic
Offset (into 50Ω)
Accuracy
±(1% of setting value + 5mV + 1% of amplitude)
Test Procedures
1. Make sure that the environment temperature is between 18℃and 28℃and
DG2000 has been warmed up for at least 30 minutes. Connect the 50Ωload to
the channel output terminal (take CH1 as an example; the test method is also
applicable to CH2) of DG2000; connect the 50Ωload and the voltage input
terminals of the digital multimeter using a BNC-Dual banana plug connecting
cable as shown in Figure 2-2.
2. Turn on the multimeter, select the DCV measurement function and set the range
to "20V".
3. Turn on DG2000. When the Shift key is illuminated, press Sine/Preset and
tap the Def icon, then a dialog box is displayed, tap "Apply"to restore DG2000
to the factory setting.
4. Set DG2000:
a) Set the output impedance of CH1 to 50Ω. (Tap the channel output
configuration status bar under the user interface to enter the
channel setting interface. Tap the OutputSet HighZ to select "Off". Tap
the Impedance menu label, and set the impedance to 50Ω.)
b) Set the output waveform of CH1 to a sine waveform with 1kHz frequency,
5Vpp amplitude and 0Vdc offset.
c) Press Output1or tap the channel output configuration status bar
to turn on the output of CH1 in the channel setting interface.
5. Record the reading of the multimeter and judge whether it is within the
specification ("Offset" in Table 2-2) range.
6. Keep the output impedance of CH1 of DG2000 at 50Ωand the output waveform
of CH1 as a sine waveform with 1kHz frequency and 5Vpp amplitude. Set the
offset of the output waveform of CH1 to -2.5Vdc, -1Vdc, -500mVdc, 500mVdc, 1Vdc
and 2.5Vdc respectively. Record the readings of the multimeter respectively and
judge whether the readings are within the specification ("Offset" in Table 2-2)
range.

Chapter 2 Performance Verification Test RIGOL
DG2000 Performance Verification Guide
2-7
Table 2-2 Offset limits of DC offset accuracy test
Offset Setting
Value
Amplitude
Setting Value
Allowed Error[1] Offset[2]
-2.5Vdc
5Vpp
±0.080Vdc -2.580Vdc to -2.420Vdc
-1Vdc ±0.065Vdc -1.065Vdc to -0.935Vdc
-500mVdc ±0.060Vdc -0.560Vdc to -0.440Vdc
0Vdc ±0.055Vdc -0.055Vdc to 0.055Vdc
500mVdc ±0.060Vdc 0.440Vdc to 0.560Vdc
1Vdc ±0.065Vdc 0.935Vdc to 1.065Vdc
2.5Vdc ±0.080Vdc 2.420Vdc to 2.580Vdc
Note[1]: “Allowed Error” is calculated from the specification “± (1% of setting value + 5 mV + 1% of
amplitude)”.
Note[2]: Offset = offset setting value ± allowed error.
7. Repeat Step1-6 to test the DC offset accuracy of CH2 and record the test results.
Test Record Form
Offset
Setting
Value
Setting Measurement
Value Specification Pass/Fail
-2.5Vdc
Frequency:
1kHz
Amplitude:
5Vpp
Impedance:
50Ω
-2.580Vdc to -2.420Vdc
-1Vdc -1.065Vdc to -0.935Vdc
-500mVdc -0.560Vdc to -0.440Vdc
0Vdc -0.055Vdc to 0.055Vdc
500mVdc 0.440Vdc to 0.560Vdc
1Vdc 0.935Vdc to 1.065Vdc
2.5Vdc 2.420Vdc to 2.580Vdc

RIGOL Chapter 2 Performance Verification Test
DG2000 Performance Verification Guide
2-8
AC Flatness Test
Specification
Output Characteristic
Flatness
Typical (Sine, 1 Vpp)
≤5 MHz: ±0.1 dB
≤15 MHz: ±0.2 dB
≤25 MHz: ±0.3 dB
≤40MHz: ±0.5 dB
>40 MHz: ±1 dB
Test Procedures
1. Make sure that the environment temperature is between 18℃and 28℃and
DG2000 has been warmed up for at least 30 minutes. Connect the 50Ωload to
the channel output terminal (take CH1 as an example; the test method is also
applicable to CH2) of DG2000; connect the 50Ωload and the voltage input
terminals of the digital multimeter using a BNC-Dual banana plug connecting
cable as shown in Figure 2-2.
2. Turn on DG2000. When the Shift key is illuminated, press Sine/Preset and
tap the Def icon, then a dialog box is displayed, tap "Apply"to restore DG2000
to the factory setting.
3. Set DG2000:
a) Set the output impedance of CH1 to 50Ω. (Tap the channel output
configuration status bar under the user interface to enter the
channel setting interface. Tap the OutputSet HighZ to select "Off". Tap
the Impedance menu label, and set the impedance to 50Ω.)
b) Set the output waveform of CH1 to a sine waveform with 1kHz frequency
and 1Vpp amplitude.
c) Press Output1or tap the channel output configuration status bar
to turn on the output of CH1 in the channel setting interface.
4. Turn on the multimeter and select the ACV measurement function. Turn on the
dBm operation function and set the reference resistance to 50Ω. Read the
measurement value and take it as the reference power (Pref).
Tip:
In this step, if the dBm operation function is not turned on, you can also
calculate the reference power using the formula
]1
/)/[(10 ref
2
reading10 mWRVLogdBm ×=
according to the measurement value of
