Yamaha Clavinova CVP-709 Instruction manual

By connecting your iPhone, iPad or iPod touch to a compatible Yamaha digital instrument and
using the various applications we’ve created, you can manage your music files more easily and
take advantage various functions — expanding the potential of the instrument and make it an even
more integral part of your total music life.
NOTE In this manual, iPhone and iPod touch are hereafter collectively called iPhone.
Yamaha Applications for Piano & Keyboard Instruments
Refer to the following web page for information on Yamaha applications for pianos and keyboard
instruments.
http://www.yamaha.com/kbdapps/
iPhone/iPad compatibility and other related system requirements vary from application to
application. Be sure, therefore, to refer to the compatibility-related information provided on the
above web page.
Certain applications do not need to be connected to an instrument. In such a case, there is no
need to follow the instructions provided in this manual.
Download the applications
You can download the applications from the App Store, accessible by clicking or tapping the App
Store icon in each application’s page of the website above.
EN
iPhone/iPad Connection Manual

Contents
Yamaha Applications for Piano & Keyboard Instruments ........................ 1
NOTICE .......................................................................................................... 3
Information .................................................................................................... 3
Determining the Connection Type .............................................................. 4
Connection .................................................................................................... 8
Troubleshooting Problems with Wireless LAN Connections ................. 14
Glossary of Terms ...................................................................................... 15
About Using BSD-Licensed Software ....................................................... 16
iPhone/iPad Connection Manual 2

iPhone/iPad Connection Manual 3
NOTICE
To prevent the iPhone/iPad from falling, note the following points:
• Before moving the instrument, make sure to remove the iPhone/iPad from the music rest.
• Never put anything else on the music rest together with the iPhone/iPad, such as a song booklet or another iPhone/iPad.
Doing so may make the music rest unstable.
• Never place the instrument with the iPhone/iPad in an unstable position.
• Never slide the iPhone/iPad along the music rest or submit it to strong shock, such as pushing or hitting it when on the music
rest.
• After use, or when you separate from a instrument, make sure to remove the iPhone/iPad from the music rest.
To avoid noise caused by communication, note the following points:
When using your instrument together with an App on your iPhone/iPad, we recommend that you turn on Airplane Mode on your
device. If you need to connect to a Wi-Fi network at this time, we recommend that after turning on Airplane Mode, you also turn
on Wi-Fi.
Information
• The contents of this manual are exclusive copyrights of Yamaha Corporation.
• Copying of the reproduction of this manual in whole or in part by any means is expressly forbidden without the written consent
of the manufacturer.
• Yamaha makes no representations or warranties with regard to the use of the documentation and cannot be held responsible
for the results of the use of this manual.
• The screen displays as illustrated (are based on the CVP-609) in this manual are for instructional purposes, and may appear
somewhat different from the screens which appear on your instrument or device.
• Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is strictly
prohibited except for your personal use.
• iPhone, iPad, iPod touch and Lightning are trademarks of Apple Inc., registered in the U.S. and other countries.
• IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
• The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
Yamaha Corporation is under license.
• The company names and product names in this manual are the trademarks or registered trademarks of their respective
companies.

iPhone/iPad Connection Manual 4
Determining the Connection Type
You can connect your iPhone/iPad to instruments equipped with MIDI terminals or a [USB TO HOST]
terminal, or to instruments compatible with a USB Wireless LAN Adaptor or those equipped with a
wireless LAN function. Since the connection procedures differ depending on the terminal of the
instrument, the particular iPhone/iPad connector and the iOS version, confirm which connection type
applies to your situation, using the following chart.
NOTE Audio signals cannot be transferred between the digital instrument and the iPhone/iPad. This means that audio signals
created via your keyboard performance cannot be recorded to the connected iPad/iPhone.
iPhone/iPad Connection Matrix Chart
Cable connection
Wireless connection
NOTE Some of the cables and adaptors used in connections A-J may not be available depending on your area.
NOTE Please confirm the version of Bluetooth in the product specification chart of iPhone/iPad/iPod touch.
iPhone/iPod touch iPad
Lightning connector 30-pin connector Lightning connector 30-pin connector
iOS 7.0
or later
iOS 4.3 –
6.1.5
iOS 7.0
or later
iOS 4.3 –
6.1.5 iOS 4.3 or later
Yamaha
Instrument
USB TO
HOST A or C C B or D D A or C B or D
MIDI EFEF
iPhone/iPad/iPod touch
Bluetooth 4.0
iOS 4.3 or lateriOS 8.0 or later
Yamaha
Instrument
USB Wireless LAN Adaptor
G or H
Wireless LAN function included
USB TO HOST I–
MIDI J
Connection A For connection instructions, see page 8.
USB
iPhone
iPad
123
USB
(B)
USB
(A)
USB Cable Lightning to USB
Camera Adapter
USB TO HOST

iPhone/iPad Connection Manual 5
* The Camera Connector is included in the Apple iPad Camera Connection Kit.
NOTE MIDI data only; audio signal not supported.
NOTE MIDI data only; audio signal not supported.
Connection B For connection instructions, see page 8.
Connection C For connection instructions, see page 8.
Connection D For connection instructions, see page 8.
iPhone
iPad
USB
123
USB
(B)
USB
(A)
USB Cable
Camera Connector *
USB TO HOST
iPhone
iPad
USB
i-UX1
123
Lightning to 30-pin
Adapter
USB TO HOST
USB
i-UX1
iPhone
iPad
12
USB TO HOST

iPhone/iPad Connection Manual 6
NOTE MIDI data only; audio signal not supported.
Please make sure that i-MX1 MIDI OUT terminal is connected to the MIDI IN terminal of the instrument, and the i-MX1 MIDI IN
terminal to the MIDI OUT terminal of the instrument.
NOTE MIDI data only; audio signal not supported.
Please make sure that i-MX1 MIDI OUT terminal is connected to the MIDI IN terminal of the instrument, and the i-MX1 MIDI IN
terminal to the MIDI OUT terminal of the instrument.
If the wireless LAN function is included on the instrument, the USB Wireless LAN Adaptor is not required.
Connection E For connection instructions, see page 8.
Connection F For connection instructions, see page 8.
Connection G For connection instructions, see page 8.
i-MX1
OUT
MIDI
IN
THRU
MIDI IN
OUT
iPhone
iPad
34
12
Lightning to 30-pin
Adapter
MIDI
OUT
MIDI
IN
MIDI
OUT
MIDI
IN
i-MX1
OUT
MIDI
IN
THRU
MIDI IN
OUT
iPhone
iPad
3
12
MIDI
OUT
MIDI
IN
MIDI
OUT
MIDI
IN
iPad
iPhone
1
Access point
Wireless LAN Wireless LAN
USB Wireless
LAN Adaptor

iPhone/iPad Connection Manual 7
If the wireless LAN function is included on the instrument, the USB Wireless LAN Adaptor is not required.
NOTE MIDI data only; audio signal not supported.
NOTE MIDI data only; audio signal not supported.
Connection H For connection instructions, see page 12.
Connection I For connection instructions, see page 13.
Connection J For connection instructions, see page 13.
iPad
iPhone
1
USB Wireless
LAN Adaptor
iPad
iPhone
USB
312
Bluetooth
UD-BT01
USB TO HOST
USB AC
adaptor
USB
(B)
USB
(A)
USB Cable AC outlet
OUT
MIDI
IN
THRU
iPad
iPhone
1
Bluetooth
MIDI
OUT
MIDI
IN
MD-BT01

iPhone/iPad Connection Manual 8
Connection
Connecting with MIDI terminals or a [USB TO HOST] terminal
1Turn off the power of the instrument.
Quit any open application software on your iPhone/iPad.
2Connect your iPhone/iPad to the instrument.
For the proper order, carefully follow the indicated instruction steps for each connection type.
3Turn on the instrument.
4The connection procedures are completed at step 3. Use the application on your iPhone/iPad
to communicate with your instrument.
NOTE Some applications need the appropriate setting to communicate with the instrument. For details, refer to the
relevant application manuals.
Connecting with Wireless LAN via an Access Point
If the wireless LAN function is included on the instrument, skip steps 1 and 2 below.
1Turn off the power to the instrument.
Quit any open application software on your iPhone/iPad.
2Connect the USB Wireless LAN Adaptor to the [USB TO DEVICE] terminal of the instrument.
3Turn on the power to the instrument.
4If your instrument has a wireless LAN mode setting, set it to Infrastructure Mode.
For instructions on setting your instrument's wireless LAN mode, refer to the Owner’s Manual or the Reference
Manual of your instrument.
5Connect the instrument to the network.
There are three methods of connection:
• Automatic Setup by WPS (page 9)
• Displaying the Networks in the Wireless LAN and Connecting to the Network (page 10)
• Manual Setup (page 11)
Select the appropriate setup method from the above depending on your network environment.
Operation with iOS 6 or later
Note that iPhone and iPad devices running iOS 6 or later may, on rare occasions, fail to recognize the i-MX1.
If this should occur, update the firmware of the i-MX1 to a new version according to the instructions in the attached PDF in the
Yamaha website i-MX1 product page.
Required devices
•USB Wireless LANAdaptor specified for your instrument (This is unnecessary if the wireless LANfunction is included on the
instrument.)
•Access point with router (This is unnecessary if your modem has router capability.)
iPad
iPhone
Access point
Wireless LAN Wireless LAN
USB Wireless
LAN Adaptor

iPhone/iPad Connection Manual 9
Automatic Setup by WPS
If your access point supports WPS, you can easily connect the instrument to access point by WPS,
without making settings, such as key input, etc.
NOTE Check whether your access point supports WPS by referring to the owner’s manual for the access point you
are using.
When using the UD-WL01 USB Wireless LAN Adaptor:
1As illustrated, press and hold the [WPS] button for longer than three seconds.
The LED lamp of the adaptor flashes.
When not using the UD-WL01 USB Wireless LAN Adaptor:
1As illustrated, press the [Start WPS] button via the display of the instrument.
NOTE The button name and displayed name differ depending on the instrument. For details, refer to the
Owner’s Manual or the Reference Manual of your instrument.
LED lamp
[WPS] button
For example, on the CVP-609/CVP-605

iPhone/iPad Connection Manual 10
2Press the WPS button on your access point within two minutes after step 1 above.
When the connection to the wireless network is completed, the LED lamp of the adaptor lights, and
then flashes during communication over the network.
NOTE For details about the operations in the setting of the access point, read the owner’s manual for the
product you are using.
The necessary information is automatically set, and the connection between access point and the
instrument has been completed. Proceed to step 6 on page 12 to connect the access point and iPhone/
iPad. If you cannot set by WPS, follow the instructions in “Displaying the Networks in the Wireless LAN
and Connecting to the Network.”
Displaying the Networks in the Wireless LAN and Connecting to the Network
You can connect the instrument to the Network by selecting it in the wireless LAN display on the
instrument. For more information on displaying networks in the wireless LAN display of the instrument,
refer to the Owner’s Manual or the Reference Manual of your instrument.
1Display the Networks in the wireless LAN display of the instrument.
For example, on the CVP-609/CVP-605: Menu [Wireless LAN]
NOTE If no signal from the access point is received, the access point cannot be listed. Also, closed access
points cannot be listed.
2Connect the instrument to the access point.
From the Networks listed on the display, select the desired one. For a network with a lock icon ( ),
you need to enter the password, and for the network without the lock icon, you can connect the
network only by selecting it.
When connection is done successfully, “Connected” is shown at the top of the display, and the icon
shown below appears according to the signal strength.
Press the WPS button on your
access point.
Strong Weak
