Rinnai CHS199100 User manual

Commercial Hybrid System
Installaon and Operaon Manual
—Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other
appliance.
—WHAT TO DO IF YOU SMELL GAS
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your building.
 Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instrucons.
 If you cannot reach your gas supplier, call the re department.
—Installaon and service must be performed by a qualied installer, service agency or the gas supplier.
If the informaon in these instrucons is not followed exactly, a re or explosion
may result causing property damage, personal injury, or death.
WARNING
READ ALL OF THE INSTRUCTIONS THOROUGHLY BEFORE
INSTALLING OR OPERATING THIS SYSTEM.
(This manual is a supplement to the C199i Installaon and
Operaon Manual)
This manual provides informaon on the installaon, operaon, and
maintenance of the water heater. For proper operaon and safety, it
is important to follow the instrucons and adhere to the safety
precauons.
A licensed professional must install the water heater according to the
exact instrucons in this manual.
The consumer must read the enre manual to properly operate the
water heater and to have regular maintenance performed.
FOR INDOOR APPLICATIONS ONLY
CHS199100............ 119 gallon, 199,000 BTU
The Commercial Hybrid System is assembled with mulple and separately
cered components consisng of:
 C199i Commercial Tankless Water Heater
 Storage Tank
 Controller

2Commercial Hybrid System
Table of Contents
This is the safety alert symbol. This symbol alerts you to potenal hazards that can kill or hurt you
and others.
Indicates an imminently hazardous situaon which, if not avoided, will result in personal
injury or death.
Indicates a potenally hazardous situaon which, if not avoided, could result in personal
injury or death.
Indicates a potenally hazardous situaon which, if not avoided, could result in minor or
moderate injury. It may also be used to alert against unsafe pracces.
DANGER
CAUTION
WARNING
Table of Contents ..................................................... 2
Safety Behaviors and Pracces for the
Consumer and Installer ............................................ 3
Installaon Instrucons
(for the licensed professional) ............................. 4
Prepare for Installaon......................................5
Determine Installaon Locaon ........................6
Combuson Air Requirements (Common Vent
Applicaons Only)..............................................7
Commercial Hybrid System
Room Air Installaon .........................................9
Terminal Clearances......................................... 10
Venng Guidelines........................................... 12
Typical Installaons..........................................13
Installaon of Plumbing...................................14
Piping Diagrams for Basic Installaons ............15
Checklist for Plumbing .....................................16
Installaon of Gas Supply ................................17
Connect Electricity ...........................................18
System Controller ............................................19
Condensate ......................................................20
Final Checklist...................................................22
Technical Data ........................................................23
Specicaons ...................................................23
Dimensions.......................................................24
Storage Tank Maintenance.....................................25
Service / Maintenance Log .....................................26
Warranty.................................................................27
Important Safety Informaon
Safety Denions
NOTICE: Rinnai somemes shares customer contact informaon with businesses that we believe provide
products or services that may be useful to you. By providing this informaon, you agree that we can
share your contact informaon for this purpose. If you prefer not to have your informaon shared with
these businesses, please contact customer service and ask not to have your informaon shared. We
will however, connue to contact you with informaon relevant to the product(s) you registered and/
or your account with us.
If you have any quesons or feel that the manual is incomplete contact Rinnai at 1-800-621-9419.

Commercial Hybrid System 3
CAUTION
 BURN HAZARD. Hot exhaust and vent may cause
serious burns. Keep away from the water heater
unit. Keep small children and animals away from
the unit.
 Hot water outlet pipes leaving the unit can be hot
to touch.
Safety Behaviors and Pracces for the Consumer and Installer
 Before operang, smell all around the appliance
area for gas. Be sure to smell next to the oor
because some gas is heavier than air and will sele
on the oor.
 Keep the area around the appliance clear and free
from combusble materials, gasoline, and other
ammable vapors and liquids.
 Combusble construcon refers to adjacent walls
and ceiling and should not be confused with
combusble or ammable products and materials.
Combusble and/or ammable products and
materials should never be stored in the vicinity of
this or any gas appliance.
 Always check the water temperature before
entering a shower or bath.
 To protect yourself from harm, before performing
maintenance:
 Turn o the electrical power supply by
unplugging the power cord or by turning o the
electricity at the circuit breaker. (The
temperature controller does not control the
electrical power.)
 Turn o the gas at the manual gas valve, usually
located immediately below the water heater.
 Turn o the incoming water supply. This can be
done at the isolaon valve immediately below
the water heater or by turning o the water
supply to the building.
WARNING
 Use only your hand to push in or turn the gas
control knob. Never use tools. If the knob will not
push in or turn by hand, do not try to repair it; call a
licensed professional. Force or aempted repair
may result in a re or explosion.
 Do not use this appliance if any part has been under
water. Immediately call a licensed professional to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
 Do not use substute materials. Use only parts
cered for the appliance.
 Should overheang occur or the gas supply fail to
shut o, turn o the manual gas control valve to the
appliance.
 Do not adjust the DIP switch unless specically
instructed to do so.
 Do not use an extension cord or an adapter plug
with this appliance.
 Any alteraon to the appliance or its controls can be
dangerous and will void the warranty.
 Proper venng is required for the safe operaon of
this appliance.
California law requires this noce to be provided:
California Proposion 65:
This product contains chemicals known to the state of California to cause cancer, birth defects, or other
reproducve harm.
WARNING

4 Commercial Hybrid System
A licensed professional must install the appliance,
inspect it, and leak test it before use. The warranty
will be voided due to any improper installaon.
The installer should have skills such as:
 Gas sizing.
 Connecng gas lines, water lines, valves, and
electricity.
 Knowledge of applicable naonal, state, and
local codes.
 Installing venng through a wall or roof.
 Training in installaon of Rinnai water heaters.
(Training can be accessed on-line at
www.trainingevents.rinnai.us)
Installaon Steps
Prepare for Installaon ......................................5
Determine Installaon Locaon.........................6
Venng Guidelines ...........................................12
Installaon of Plumbing ...................................14
Checklist for Plumbing .....................................16
Installaon of Gas Supply.................................17
Connect Electricity ...........................................18
Checklist for Gas and Electricity.......................19
System Controller.............................................19
Condensate ......................................................20
Final Checklist...................................................22
General InstruconsInstaller Qualicaons
DO NOT
 Do not install the Commercial Hybrid System
outdoors.
 Do not install the appliance in an area where water
leakage of the unit or connecons will result in
damage to the area adjacent to the appliance or to
lower oors of the structure. When such locaons
cannot be avoided, it is recommended that a
suitable drain pan, adequately drained, be installed
under the appliance. The pan must not restrict
combuson air ow.
 Do not obstruct the ow of combuson and
venlaon air. Combuson air shall not be
supplied from occupied spaces.
 Do not use this appliance in an applicaon such as
a pool or spa heater that uses chemically treated
water . (This appliance is suitable for lling large or
whirlpool spa tubs with potable water.)
 Do not use substute parts that are not authorized
for this appliance.
MUST DO
 The installaon must conform with local codes or,
in the absence of local codes, with the Naonal
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
Natural Gas and Propane Installaon Code, CSA
B149.1.
 The appliance, when installed, must be electrically
grounded in accordance with local codes or, in the
absence of local codes, with the Naonal Electrical
Code, ANSI/NFPA 70, or the Canadian Electrical
Code, CSA C22.1.
 The appliance and its appliance main gas valve
must be disconnected from the gas supply piping
system during any pressure tesng of that system
at test pressures in excess of 1/2 psi (3.5 kPa)
(13.84 in W.C.).
 The appliance must be isolated from the gas supply
piping system by closing its individual manual
shuto valve during any pressure tesng of the gas
supply piping system at test pressures equal to or
less than 1/2 psi (3.5 kPa) (13.84 in W.C.).
Type of installaon
 For installaon in commercial applicaons only.
Installaon Instrucons
(for the licensed professional)

Commercial Hybrid System 5
Prepare for installaon
Parts included
Tools needed
Materials needed
 You must follow the installaon instrucons and
those in Care and Maintenance for adequate
combuson air intake and exhaust.
INFORMATION
 If a water heater is installed in a closed water
supply system, such as one having a backow
preventer in the cold water supply line, means
shall be provided to control thermal expansion.
Contact the water supplier or local plumbing
inspector on how to control thermal expansion.
 Should overheang occur or the gas supply fail to
shut o, turn o the manual gas control valve to
the appliance.
 Keep the air intake locaon free of chemicals, such
as chlorine or bleach, that produce fumes. These
fumes can damage components and reduce the life
of your appliance.
 Commercial Hybrid System
 Temperature and Pressure Relief Valve (Tank)
 Pressure Relief Valve (Preinstalled on Tankless)
 Non-Return Flue Check w 3" PVC Adapter
 Pipe wrenches (2)
 Adjustable pliers
 Screwdrivers (2)
 Wire cuers
 Gloves
 Safety glasses
 Level
Tools that might be needed
 Hammer drill with
concrete bits
 Saw
 Threading machine with
heads and oiler
 Core drill with diamond
head
 Torch set
 Copper tubing cuer
 Steel pipe cuer
Materials that may be needed
 Soap or gas leak
detector soluon
 Approved venng
 Teon tape
(recommended) or pipe
compound
 Pipe insulaon
 Heat tape
 Electrical wire and
conduit per local code
 PVC glue/cement
 5/8” ID PVC exible
tubing
 2 conductor 22 AWG
wire for controller
 Single gang electrical
box
 Wire nuts
 Unions and drain valves
 Drain Pan
 Earthquake Strap
General Instrucons (connued)

6 Commercial Hybrid System
Determine Installaon Locaon
You must ensure that clearances will be met and that the
vent length will be within required limits. Consider the
installaon environment, water quality, and need for
freeze protecon. Requirements for the gas line, water
lines, electrical connecon, and condensate disposal can
be found in their respecve installaon secons of this
manual.
Minimum Clearances
The minimum clearances from both combusbles
and non-combusbles construcon is:
0 inches from the sides
0 inches from the back
12 inches from the top
6 inches from the front
0 inches from vent components and condensate drain
line.
*The clearance for servicing is 24 inches in front of
the water heater.
**The clearance for servicing the anode rods is
54 inches from the top of the water heater.
**12” Min
0” Min
0” Min 0”
Checklist to Determine Installaon
Locaon
□The water heater is not exposed to corrosive
compounds in the air.
□The water heater locaon complies with the
clearances.
□For indoor models, the planned venng will not
exceed the maximum length for the number of
elbows used.
□The planned venng terminaon/air intake
locaon meets the clearances.
□Indoor air is not being used for combuson unless
installed in common vent applicaon.
□The water supply does not contain chemicals or
exceed total hardness that will damage the heat
exchanger.
□The installaon must conform with local codes or,
in the absence of local codes, with the Naonal
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
Natural Gas and Propane Installaon Code, CSA
B149.1.
□Leave the enre manual taped to the water
heater, or give the enre manual directly to the
consumer.
*6” Min
Door

Commercial Hybrid System 7
Combuson Air Requirements
Room air can only be used in applicaons that ulize either the approved Rinnai common vent method, or the
commercial hybrid system (Refer to Rinnai Common Vent manual for further details regarding common vented
applicaons)
This water heater requires adequate combuson air for venlaon and diluon of ue gases. Failure to provide
adequate combuson air can result in unit failure, re, explosion, serious bodily injury or death. Use the detailed
descripon in the C199 installaon and operaon manual to ensure adequate combuson air is available for
correct and safe operaon of this water heater.
REFER TO THE C199 MANUAL FOR SPECIFIC DETAILS ON:
 Determining Vent Conguraon
 Combuson Air Requirements
Combuson Air Check Valve
(Included with System)
Part # 109000533
Room Air in Single Unit Applicaons
 Room air can be used for combuson air in
commercial hybrid system applicaons only.
 Single unit room air applicaons must terminate
vercally
 Single unit horizontal terminaon is not permied.
Single unit room air applicaons must use the
combuson air check valve provided.

8 Commercial Hybrid System
Combuson Air Requirements
Exhaust
Vent terminaon per ANSI Z223.1/NFPA 54.
For clearances not specied in ANSI Z223.1/
NFPA 54, clearances are in accordance with
local installaon codes and the require-
ments of the gas supplier.
□Verify proper clearances around the vents .
□Ensure that the Combuson Air Requirements are
followed that will provide sucient combuson
air for the appliance.
□Ensure approved venng components have been
used.
□All horizontal vent runs must be sloped up away
from the water heater a minimum of 1/4 “ (6 mm)
per foot.
□Verify that there is adequate combuson air.
□Ensure if installed in common vent applicaon
ulizing room air that exhaust is terminang
vercally only. (Reference Common Vent manual
for further details.)
□Installaon complies with Naonal Fuel Gas
Code, ANSI Z223.1/NFPA 54 as well as local and
state regulaons therein.
□The water heater is not subjected to corrosive
compounds in the air.
Checklist for Combuson Air and
Venng Requirements
Exhaust

Commercial Hybrid System 9
Exhaust Adapter Ring to be removed and discarded
for concentric vent or room air conguraon.
Commercial Hybrid System Room Air Installaon
Removal of Exhaust Adapter Ring
1. Remove fastener from concentric ue
connecon.
2. Remove exhaust adapter ring.
3. Install the non-return ue check adapter. Ensure
it is properly seated.
4. Secure the adapter to the unit with a screw.
 Prior to the installaon of the vent system, the unit must be properly adjusted for the venng conguraon
selected for the applicaon.
 Any issues resulng from improper installaon will not be covered by warranty.
 Non-return ue check adapter is included with every commercial hybrid system.
NOTICE

10 Commercial Hybrid System
INSIDE
CORNERDETAIL
FIXED
CLOSED
OPERABLE
FIXED
CLOSED
OPERABLE
B
B
B
A
J
BM
C
F
B
B
E
D
L
G
A
H
K
I
[1] A vent shall not terminate directly above a sidewalk or paved driveway
that is located between two single family dwellings and serves both
dwellings.
[2] Permied only if veranda, porch, deck, or balcony is fully open on a
minimum of two sides beneath the oor.
 For clearances not specied in ANSI Z223.1/NFPA 54, clearances are in
accordance with local installaon codes and the requirements of the gas
supplier.
Clearance to opposite wall is 24 inches (60 cm).
X
V
AIR SUPPLY INLET
VENT TERMINAL
AREA WHERE TERMINAL
IS NOT PERMITTTED
A vent terminaon must be installed to bring in combuson air and expel exhaust to the outside.
SNOW
TERMINATION
Clearance in
Ref. A also
applies to
anticipated
snow line
Ref Descripon Canadian Installaons US Installaons
AClearance above grade, veranda, porch, deck, or balcony 12 inches (30 cm) 12 inches (30 cm)
BClearance to window or door that may be opened 36 inches (91 cm) 12 inches (30 cm)
CClearance to permanently closed window **
D
Vercal clearance to venlated sot, located above the terminal within
a horizontal distance of 2 feet (61 cm) from the center line of the
terminal
**
EClearance to unvenlated sot **
FClearance to outside corner **
GClearance to inside corner **
HClearance to each side of center line extended above meter/regulator
assembly
3 feet (91 cm) within a height 15
feet (4.5 m) above the meter/
regulator assembly
*
IClearance to service regulator vent outlet 36 inches (91 cm) *
JClearance to nonmechanical air supply inlet to building or the 36 inches (91 cm) 12 inches (30 cm)
KClearance to a mechanical air supply inlet 6 feet (1.83 m) 3 feet (91 cm) above if within 10
feet (3 m) horizontally
LClearance above paved sidewalk or paved driveway located on public
property 7 feet (2.13 m) *
MClearance under veranda, porch, deck, or balcony 12 inches (30 cm)  *
Direct Vent Terminal Clearances

Commercial Hybrid System 11
REFER TO THE C199 MANUAL FOR SPECIFIC DETAILS ON:
 Approved Vent Manufacturers and Terminaons
 Terminaon Clearances
 Maximum Vent Length
 Flue Installaon with Concentric Venng
 Common Vent Applicaon
 Twin Pipe PVC/CPVC Vent Installaon
 Consumer Operaon Guidelines for the Safe Operaon of your Water
Heater
 How to use the C199 Temperature Controller
 C199 Diagnosc Codes
 C199 Required Maintenance (Draining of the tankless water heater will
require the lower enclosure to be removed. Reference page 17 to remove
the enclosure.)
 C199 Replacement Parts

12 Commercial Hybrid System
Venng Guidelines
DO NOT
 Do not use cellular core PVC/CPVC.
 Do not use Radel, ABS, or galvanized material to
vent this appliance.
 Do not cover non-metallic vent pipe and ngs
with thermal insulaon.
 Do not combine vent components from dierent
manufacturers.
 Vent diameter must not be reduced.
 Do not connect the venng system with an
exisng vent or chimney.
 Do not common vent with the vent pipe of any
other manufacturer’s water heater or appliance.
Rinnai water heaters can only be common vented
using a Rinnai cered common vent system.
MUST DO
 This water heater is a direct vent water heater and
therefore is cered and listed with the vent
system. You must use vent components that are
cered and listed with the water heater model.
 The vent system must vent directly to the outside
of the building and use outside air for combuson.
Excepons:
- Approved Rinnai Common Vent Applicaons
- Commercial Hybrid System Applicaons
 Avoid dips or sags in horizontal vent runs by
installing supports per the vent manufacturer’s
instrucons.
 Support horizontal vent runs every four feet and
all vercal vent runs every six feet or in
accordance with local codes.
 Venng should be as direct as possible with a
minimum number of pipe ngs.
 Vent connecons must be rmly pressed together
so that the gaskets form an air ght seal.
 The vent piece connected to the water heater
must be secured with one self-tapping screw.
INFORMATION
 Refer to the instrucons of the vent system
manufacturer for component assembly
instrucons.
 If the vent system is to be enclosed, it is suggested
that the design of the enclosure shall permit
inspecon of the vent system. The design of such
enclosure shall be deemed acceptable by the
installer or the local inspector.
NOTICE
If it becomes necessary to access an enclosed vent
system for service or repairs, Rinnai is not responsible
for any costs or dicules in accessing the vent
system. The warranty does not cover obtaining
access to a vent system in an enclosed environment.

Commercial Hybrid System 13
AHot Water Outlet *
BHot Water Outlet Valve *
CTemperature-Pressure Relief
Valve
DCold and Hot Unions *
ECold Water Supply Valve *
FCold Water Supply *
GThermal Expansion Tank *
HVent pipe (concentric shown for
illustraon purposes, see venng
secon for other opons)
*
IOperaon Unit / Temperature
Control
JDrain Pan *
KTemperature-Pressure Relief
Valve Discharge Pipe
(do not cap, plug, or reduce )
*
LDrip Leg (Sediment Trap) *
MGas Union *
NGas Control Valve
OThermostac Mixing Valve *
PNon-Tempered Return Line *
QNon-Tempered Supply Line *
Typical Installaons
* Field Supplied
MIXING VALVE INSTALLATION
AB
C
D
D
E
F
G
H
I
J
K
L
M
N
HOT WATER
OUTLET
COLD WATER
SUPPLY
QO
P
(Route condensate through
enclosure to drain)

14 Commercial Hybrid System
Installaon of Plumbing
Pressure Relief Valve Requirements
An approved pressure relief valve (preinstalled) is
required by the American Naonal Standard (ANSI
Z21.10.3) for all water heang systems and shall be
accessible for servicing.
DO NOT
 Do not plug the relief valve and do not install any
reducing ngs or other restricons in the relief
line. The relief line should allow for complete
drainage of the valve and the line.
 Do not place any other type valve or shuto device
between the relief valve and the water heater.
MUST DO
 The relief valve must comply with the standard for
Relief Valves and Automac Gas Shuto Devices for
Hot Water Supply Systems ANSI Z21.22 and /or the
standard Temperature, Pressure, Temperature and
Pressure Relief Valves and Vacuum Relief Valves,
CAN1-4.4.
 The pressure relief valve must be rated up to 150 psi
and to at least the maximum BTU/hr of the
appliance.
 The discharge from the pressure relief valve should
be piped to the ground or into a drain system per
local codes.
 The pressure relief valve must be manually operated
once a year to check for correct operaon.
 The relief valve should be added to the hot water
outlet line and near the hot water outlet according
to the manufacturer’s instrucons. DO NOT place
any other type valve or shut o device between the
relief valve and the water heater.
INFORMATION
If a relief valve discharges periodically, this may be due
to thermal expansion in a closed water supply system.
Contact the water supplier or local plumbing inspector
on how to correct this situaon. Do not plug the relief
valve.
Water discharged from the pressure relief valve could
cause severe burns instantly or death from scalds.
Install the Temperature-Pressure Relief (T&P) Valve
according to these instrucons.
The tank poron of this system is provided with a
combinaon temperature-pressure relief valve. For
safe operaon of the water heater, the relief valve(s)
must not be removed from its designated point of
installaon or plugged.
An approved Temperature-Pressure Relief Valve is
required by the American Naonal Standard (ANSI
Z21.10.3) for all water heang systems, and shall be
accessible for servicing.
DO NOT
 Do not plug the T&P valve and do not install any
reducing ngs or other restricons in the relief
line. The relief line should allow for complete
drainage of the T&P valve and the line.
 Do not place any other type valve or shut o
device between the relief valve and the water
heater.
 Do not pipe temperature-pressure relief valve,
pressure relief valve, and/or condensate drain
together into a common pipe.
MUST DO
 The T&P valve must comply with the standard for
Relief Valves and Automac Gas Shuto Devices for
Hot Water Supply Systems ANSI Z21.22 and /or the
standard Temperature, Pressure, Temperature and
Pressure Relief Valves and Vacuum Relief Valves,
CAN1-4.4.
 The T&P valve must be rated up to 150 psi and to
at least the maximum BTU/hr of the appliance.
 The discharge from the T&P Valve should be piped
to the ground or into a drain system to prevent
exposure or possible burn hazards to humans or
other plant or animal life. Follow local codes.
Water discharged from the relief valve could cause
severe burns instantly, scalds, or death.
 The Temperature-Pressure Relief Valve must be
manually operated once a year to check for correct
operaon.
Temperature-Pressure Relief Valve
Requirements
WARNING

Commercial Hybrid System 15
Piping Diagram for Basic Installaons
Commercial Hybrid
Single Unit Circulation
Note:
Installation must conform to applicable code
and all requirements listed in the installation
manual. Balancing valves, equivalent piping,
pressure gauges, and temperature gauges are
to be used as necessary to ensure proper flow
between units.
Condensate piping shall be CPVC or PVC
material and shall not be smaller than the
drain connection on the appliance.
Components of condensate drainage shall be
CPVC or PVC material. All components shall
be selected for the pressure and temperature
rating of the installation.
Where the drain pipes from more than one
unit are manifolded together for condensate
drainage, the pipe or tubing shall be sized in
accordance with an approved method as
dictated by local codes.
Condensate must be disposed of
according to local codes.
Building Hot Water Supply Line
Condensate Drain Line
Pipe T&P to Open Drain
Building
Circulation
Pump
Gas Supply
Building Hot Water
Return Line
(Optional)
Cold Water Supply
Tank
T&P
Tankless
PRV

16 Commercial Hybrid System
Connect Water Heater to Water Supply
Water connecons to the Commercial Hybrid System
should follow all state and local plumbing codes.
If this is a standard installaon, refer to the Piping
Diagram for Basic Installaon.
1. Use of this layout should provide a trouble free
installaon for the life of the water heater. Before
making the plumbing connecons, locate the
COLD water inlet and the HOT water outlet. The
COLD water inlet is a 2” MNPT ng on the lower
poron of the tank below the tankless unit. The
HOT water outlet is a 2” MNPT ng located at
the top of the tank. Install a shut-o valve close to
the water heater in the cold water line. It is rec-
ommended that unions be installed in the cold
and hot water lines so that the water heater can
be easily disconnected, if servicing is required.
2. When assembling the hot and cold piping, use a
good food grade pipe joint compound, and ensure
all ngs are ght. It is imperave that open
ame is not applied to the inlet and outlet ngs,
as heat will damage or destroy the plasc lined
ngs. This will result in premature failure of the
ngs, which is not covered by the warranty.
□Ensure that hot and cold water lines are not
crossed to the unit and are leak free.
□Ensure that a pressure relief valve is installed with
a rang that exceeds the BTU input of the water
heater model. Refer to the rang plate on the
side of the water heater for BTU input.
□Clean the inlet water lter by closing the cold and
hot water inlet isolaon (shut-o) valves. Put a
bucket under the lter at the boom of the water
heater to catch any water that is contained inside
the unit. Unscrew the water lter. Rinse the
lter to remove any debris. Install the lter and
open the isolaon valves.
□Check for proper water pressure to the water
heater. Minimum water pressure is 50 psi. Rinnai
recommends 60-80 psi for maximum
performance.
□ Ensure any issues regarding water quality have
been properly addressed.
DO NOT OPERATE THIS WATER HEATER UNLESS IT IS
COMPLETELY FULL OF WATER. To prevent damage to
the appliance all air must be relieved from the system
and a hot water xture must be owing water before
the water heater is plugged in and turned on. To
ensure safe and eecve operaon of the water
heater use the following lling procedure:
To ll the water heater:
1. Ensure the drain valve located at the boom
of the tank is closed.
2. Open nearest hot water xture in the
plumbing system.
3. Open the cold supply valve to the water
heater.
4. Keep the hot water xture open unl the
tank is lled and constant ow is obtained at
the xture.
5. Check water heater connecons and
plumbing system for damage or leaks. Repair
if needed.
Filling the System
Checklist for Plumbing
NOTICE
DO NOT OPERATE THIS WATER HEATER UNLESS IT IS
COMPLETELY FULL OF WATER

Commercial Hybrid System 17
Installaon of Gas Supply
MUST DO
 A manual gas valve must be placed in the gas
supply line to the water heater. Install a union
between the gas valve and the appliance for future
servicing or unit removal.
 Check the type of gas and the gas inlet pressure
before connecng the water heater. If the water
heater is not of the gas type that the building is
supplied with, DO NOT connect the water heater.
Contact the dealer for the proper unit to match the
gas type.
 Check the gas supply pressure immediately
upstream at a locaon provided by the gas
company. Supplied gas pressure must be within
the limits shown in the Specicaons secon with
all gas appliances operang.
 Before placing the appliance in operaon all joints
including the heater must be checked for gas
ghtness by means of leak detector soluon, soap
and water, or an equivalent nonammable
soluon, as applicable. (Since some leak test
soluons, including soap and water, may cause
corrosion or stress cracking, the piping shall be
rinsed with water aer tesng, unless it has been
determined that the leak test soluon is non-
corrosive.)
 Use approved connectors to connect the unit to
the gas line. Purge the gas line of any debris before
connecon to the water heater.
 Any compound used on the threaded joint of the
gas piping shall be a type which resists the acon of
liqueed petroleum gas (propane / LPG).
 The gas supply line shall be gas ght, sized, and so
installed as to provide a supply of gas sucient to
meet the maximum demand of the heater and all
other gas consuming appliances at the locaon
without loss of pressure.
 Always check all gas pipe connecons and ngs
for leaks before operang the water heater. Use
soapy water on all ng and visually inspect for
bubble formaon. Rinse o soapy water and wipe
dry.
General Instrucons
WARNING
1. If you are not knowledgeable or qualied to
install gas lines or connecons, then contact a
licensed professional to install the gas supply.
2. Turn o 120v power supply.
3. Turn o the gas.
4. Gas is ammable. Do not smoke or provide other
ignion sources while working with gas.
5. Do not turn on the water heater or gas unl all
fumes are gone.
In order to access the gas connecons, remove the
plasc rivet screws that aach the lower enclosure to
the assembly. Proceed to then remove the lower
enclosure.
Gas Connecon
(3/4” MNPT)
Lower Enclosure
REFER TO THE C199 MANUAL FOR
SPECIFIC DETAILS ON:
 Size the Gas Pipe
Gas
Valve
Union

18 Commercial Hybrid System
Connect Electricity
Do not rely on the gas or water piping to ground the
water heater. A terminal block inside the controller
should be used for the grounding connecon.
The water heater requires 120 VAC, 60 Hz power from
a properly grounded circuit.
The wiring diagram is located on the Technical Sheet
aached to the inside of the front cover.
WARNING
Do not use an extension cord or an adapter plug with
this appliance.
The water heang system must be electrically
grounded in accordance with local codes and
ordinances or, in the absence of local codes, in
accordance with the Naonal Electrical Code, ANSI/
NFPA No. 70.
The tankless water heater is equipped with a three-
prong (grounding) plug for your protecon against
shock hazard and should be plugged directly into the
three-prong receptacle located at the boom of the
controller.
REFER TO THE C199 MANUAL FOR
 HIGH ALTITUDE ADJUSTMENT
 ADJUSTMENT FOR VENT LENGTH
 Installaon of Temperature Controller
Low Voltage
Thermistors
Terminal
Block
Green White Black
Green
White Black
Tankless Supply
Output: 120 Volt
(3 Prong Receptacle
already connected to
tankless from factory)
DO NOT connect power to the commercial hybrid
system prior to compleng installaon and the
system has been lled with water.
ATTENTION
Green White Black
Green White Black
PRE-WIRED PUMP
CONNECTION
PRE-WIRED
SUPPLY POWER
Power
Supply
Pump Control
Output: 120 Volt
Supply Power
Input: 120 Volt
(3 Prong Plug)
Do not rely on the gas or water piping to ground the
water heater. A terminal block inside the controller
should be used for the grounding connecon.
The water heater requires 120 VAC, 60 Hz power from
a properly grounded circuit.
The wiring diagram is located on the Technical Sheet
aached to the inside of the front cover.

Commercial Hybrid System 19
SYSTEM CONTROLLER
NORMAL OPERATION (SLOW PULSE)
THERMISTOR ERROR (RAPID PULSE)
PUMP ON (SOLID GREEN LIGHT)
PUMP OFF (NO LIGHT)
Checklist for Gas and Electricity
□A manual gas control valve is placed in the gas
line to the water heater.
□Check the gas lines and connecons for leaks.
□Conrm that the gas inlet pressure is within
limits.
□Conrm that the water heater is rated for the gas
type supplied.
□Conrm that the electricity is supplied from 120
VAC, 60 Hz power source and is in a properly
grounded circuit.
□Conrm that an extension cord or an adapter plug
has NOT been used with the water heater.
The system controller maintains communicaon
between the tank and tankless to eecvely control
the tank temperature based on the selected
temperature on the tankless unit.
By reading the tank temperature (J22) and tankless
outlet temperature (J2), the System Controller will
energize (120V) the pump when the tank
temperature drops. When the tank temperature
returns to the selected set temperature the System
Controller will de-energize the pump and remain in
standby unl the tank temperature drops again.
When power is supplied, the System Controller will
maintain pump operaon. If system is not in use for
an extended period of me, Disconnect power from
the system.
ATTENTION
CONTROLLER DIAGNOSTICS

20 Commercial Hybrid System
Condensate
Condensate can form in the vent of high eciency
direct vent appliances. Without proper drainage,
condensate will damage the heat exchanger.
To prevent condensate damage, follow these
instrucons.
DO NOT
 Do not connect the condensate drain pipe directly
to the rain sewer.
 Do not connect the condensate drain line with an
air condioning evaporator coil drain.
 Do not pipe condensate drain, temperature-
pressure relief valve, and/or pressure relief valve
together into a common pipe.
MUST DO
 Use only venng that is approved and idened as
acceptable for your parcular model.
 Slope the venng toward the appliance according
to the vent manufacturer’s installaon
instrucons.
 All condensate must drain and be disposed of
according to local codes.
 Use only corrosion resistant materials for the
condensate drain lines such as PVC pipe or plasc
hose.
 The condensate drain pipe (along its enre length)
must be at least the same diameter as the drain
line, (1/2 inch NPT).
 The end of the condensate drain pipe should be
open to the atmosphere. The end should not be
under water or other substances.
 To minimize freezing of the condensate, run the
condensate drain line through an interior wall or
between insulaon and an interior wall.
Checklist for Venng and
Condensate
□Verify proper clearances around the vents and air
intakes.
□Ensure you have used the correct venng
products for the model installed and that you
have completely followed the venng
manufacturer’s installaon instrucons and these
installaon instrucons.
□Verify that the vent system does not exceed the
maximum length for the number of elbows used.
 Ensure that condensate drain, PRV, and T & P are
piped separately to their own dedicated drain
lines.
INFORMATION
 Water heaters have an integrated condensate
collector.
 The condensate drain pipe should be as short as
possible and have a downward pitch.
 If the condensate drain gets blocked, a diagnosc
code will display on the controller. If this occurs,
the condensate drain must be cleaned.
 The condensate trap will automacally prime (self-
prime) during operaon of the unit as condensate
forms. Condensate draining from the unit
indicates that the trap is full and that there is no
blockage in the condensate drain. It is not
necessary to add water to the condensate trap.
 A condensate neutralizer kit, 804000074, is
available from Rinnai. The kit allows condensate
to ow through neutralizing media that raises the
pH of the condensate to a level that will help
prevent corrosion of the drain and public sewer
system.
