Rinnai RHFE-263FA 2 Quick start guide

HOME OWNER / INSTALLER
FOR YOUR SAFETY
THIS MANUAL MUST BE READ IN ITS
ENTIRETY BEFORE OPERATING HEATER
RHFE-263FA
ENERGYSAVER
GAS DIRECT VENT WALL FURNACE
Owner’s Operation and Installation Manual
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
WHAT TO DO IF YOU SMELL GAS
•DO NOT TRY TO LIGHT ANY APPLIANCE.
•DO NOT TOUCH ANY ELECTRICAL SWITCH; DO NOT USE ANY PHONE
IN YOUR BUILDING.
•IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S
PHONE. FOLLOW THE GAS SUPPLIER'S INSTRUCTIONS.
•IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE
DEPARTMENT.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
This appliance may be installed in an aftermarket, permanently located, manufactured
home (USA only) or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the Rating Plate. This
appliance is not convertible for use with other gases, unless a certified kit is used.
INSTALLER: MUST LEAVE MANUAL WITH UNIT AFTER INSTALLATION.
OWNER: RETAIN THIS MANUAL SAFELY FOR FUTURE REFERENCE.

WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
REFER TO THE OWNER'S INFORMATION MANUAL
PROVIDED WITH THIS APPLIANCE. INSTALLATION AND
SERVICE MUST BE PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
ENERGYSAVER RHFE-263FA
Operation Manual
Table of Contents Page
FEATURES OF THE RHFE-263FA UNITS ............................................................1
SAFETY DEVICES ................................................................................................1
IMPORTANT POINTS / USAGE AND INSTALLATION MUSTS ............................3
DIMENSIONS ........................................................................................................5
SPECIFICATIONS .................................................................................................6
SAFETY POINTS ..................................................................................................8
GETTING TO KNOW YOUR NEW RHFE-263FA ..................................................10
CONTROL PANEL .................................................................................................11
CUT-AWAY DIAGRAM ...........................................................................................12
NOTICE BEFORE INSTALLATION .......................................................................13
INSTALLATION INSTRUCTIONS ..........................................................................14
GAS CONNECTION ..............................................................................................15
CANADIAN VENT REGULATIONS .......................................................................16
LOCATION / CLEARANCES .................................................................................17
SLEEVE AND MANIFOLD INSTALLATION ...........................................................19
FITTING UNIT .......................................................................................................21
OPERATING INSTRUCTION LABEL ....................................................................23
ADDITIONAL CUSTOMER OPERATING INFORMATION ....................................24
TESTING ...............................................................................................................30
CHECK ..................................................................................................................30
PRE-SERVICE CHECK .........................................................................................31
TROUBLE SHOOTING ..........................................................................................32
ERROR MESSAGES..............................................................................................33
MAINTENANCE / SERVICE ..................................................................................34
WIRING DIAGRAM ................................................................................................35
WARRANTY INFORMATION .................................................................................36
SCHEMATIC DIAGRAM ........................................................................................38
PARTS LIST ...........................................................................................................43
RHFE-263FA FLOW DIAGRAM ............................................................................47
EXTENDED FLUE PIPE KIT .................................................................................48
TECHNICAL DATA ................................................................................................52

FEATURES OF THE RHFE-263FA UNITS
SAFETY DEVICES
–1 –
◆Clean Heating Forced Flue Type
◆Easy Operation One-Touch Ignition
◆Sensible Temperature Control Feature
◆Comfortable Room Temperature Control and Display
◆Warm Air Outlet at Floor Level (Keeps Your Feet Warm)
◆Child Safety Lock
◆Room Temperature Setting Memory
◆Dirty Air Filter Indicator Lamp
◆Energy-Saving Economy Setting
◆Humidifier Tray
◆Air Flow Directional Louvers
◆Direct Vent Easily Installed
◆Proportional Heating Variable Capacity
◆Hush! Quiet Operation
◆Modern Design Minimizes Floor Space Requirements
◆Failure Message Display
Spark Safety Device: Automatically shuts unit down when there is an abnormal spark at time
of ignition.
Flame Failure Device: Activated when burner flame fails. This prevents raw gas from being
released.
Overheat Switch: This device automatically cuts the gas off if the heater exceeds a
predetermined temperature. This is normally caused by an
obstruction in front of the louvers, or a blocked fan filter.
Fusible Links: Backs up the overheat switch. If the fusible link cuts the unit off, a
service call by an authorized person is required to replace the link.

–2 –
Overcurrent Prevention Device: This is a 3 amp. glass fuse found on P.C. board. Designed
to shut unit down in case of overcurrent. If fuse blows, all
indicator lamps will be “OFF”.
Power Outage Safety Device: This safety device cuts off gas passage and stops
operation.
Local and state codes must be adhered to prior to installation.
Rinnai is continually updating and improving products. Therefore, specifications are subject to change
without prior notice.
Thank you for purchasing a Rinnai gas forced flue heater.
Before using this product, please read this manual carefully to insure proper use of the product.
Please read the attached warranty thoroughly and keep it in a safe place.
GENERAL INFORMATION
THIS SERIES HEATER IS DESIGN CERTIFIED BY CSA
INTERNATIONAL AS A DIRECT VENT WALL FURNACE AND
MUST BE INSTALLED ACCORDING TO THESE INSTRUCTIONS.
ALTERATION OF THE ORIGINAL DESIGN INSTALLED OTHER
THAN AS SHOWN IN THESE INSTRUCTIONS OR USED WITH
A TYPE OF GAS NOT SHOWN ON THE RATING PLATE, IS
THE RESPONSIBILITY OF THE PERSON AND COMPANY
MARKING THE CHANGE.
※See conversion for setting gas pressures.
*There are two 1/8" NPT test points for measuring differential pressure, one is located on the modulating
gas valve, the other is located on the burner manifold. The minimum inlet gas supply pressure is for
the purposes of input adjustment.
Minimum supply gas pressure
Maximum supply gas pressure
Manifold test pressure
NAT.
3.5" (89mmH2O)
10.5" (267mmH2O)
Factory set
LPG
8.0" (203mmH2O)
13.0" (330mmH2O)
Factory set

IMPORTANT POINTS / USAGE AND INSTALLATION MUSTS
–3 –
Unpack heater and check for damage. (DO NOT INSTALL DAMAGED HEATER.) If heater is
damaged, contact your supplier for advice. Before installing a heater, check the label for the correct gas
type (see label on heater). Refer to local gas authority for confirmation of gas type if you are in doubt.
Included in Carton:
Customers Operating Information
Manual valve set
IMPORTANT
Before using this product, please read this manual carefully to insure proper use of product.
1. The installation must conform with local codes or, in absence of local codes, the National Fuel Gas
Code, ANSI Z223.1 or the Canadian Installation Code, CAN/CGA-B149.
2. For information on gas type, see data plate on the appliance.
3. This heater must not be installed where curtains or other combustible materials could come into
contact with it. In some cases curtains may need restraining.
4. This appliance is not designed to be built in.
5. If you move, check the gas type in the area where you are moving to. The local gas authority will be
able to advise on local regulations.
6. This heater discharges a large volume of warm air at low level to provide even heat distribution. If
the air in the room contains cooking vapor or cigarette smoke, and the heater is used on a carpet,
the surface of the carpet may become discolored. In addition, some nylon carpets contain dyes
which may be affected by the warm air flow. Some soft vinyl surfaces are also subject to distortion,
or discoloration by warm air. To prevent discoloration of carpets, etc., a mat should be placed under
the appliance, extending about 30" (750mm) in front of it.
Diagram shows minimum
clearances from combustible
materials.
7. Read these rules and the instructions carefully. Check all local codes. Failure to follow these could
cause a malfunction of the heater resulting in death, serious bodily injury and/or property damage.
8. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
If a conversion of the unit is needed, conversions must be performed at Rinnai America or
authorized agent at owner's expense.
9. WARNING: Any change to this heater or its controls can be dangerous.
10. If a gas leak is suspected, turn heater off, turn gas supply valve off at appliance connector valve.
Open windows to ventilate area immediately and contact your dealer or gas company.
11. DO NOT PLACE CLOTHING OR FLAMMABLE MATERIALS, GASOLINE AND OTHER
FLAMMABLE VAPORS AND LIQUIDS, ON OR NEAR THE HEATER.
10"(250mm)
2"(50mm)
40"(1m)
2"(50mm)

–4 –
12. YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN THEY ARE IN THE SAME
ROOM WITH THE HEATER.
13. LPG containers must not be installed indoors.
14. Do not use this room heater if any part has been under water. Immediately call a qualified service
technician to inspect the room heater and to replace any part of the control system and any gas
control which has been under water.
15. Adequate clearances for accessibility for purposes of servicing, proper operation and adequate
combustion and ventilation air should be provided.
16. Adequate clearances around air openings should be provided.
17. Do not install in areas where curtains, drapes, clothing, or other moving flammables are within 10
inches of this unit.
18. Periodic examination of the venting system is required.
19. The flow of combustion and ventilation air should not be obstructed.
20. A manufactured home (USA only) or mobile home OEM installation must conform with the
Manufactured Home Construction and Safety Standard, Title 24CFR, Part 3280, or, when such a
standard is not applicable, the Standard for Manufactured Home Installations, ANSI Z225.1 or
Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4.
21. "This appliance must be installed in accordance with the current standard CSA Z240.4 GAS
EQUIPPED RECREATIONAL VEHICLES AND MOBILE HOUSING. Cet appareil doit ette installe
conformement aux, exigences de la norme Z240.4 en vigeuer de l’ACNOR, Installations de gaz dans
les constructions mobiles et vehicules recreatifs."
22. If a blockage occurs at the vent terminal due to snow, ice, leaves, spider webs or other type of
obstructions, the unit will stop working. The unit will not function until the blockage has been
removed. If the unit then fails to operate, contact a qualified service agency.
23. For a manufactured home (USA only) or mobile home OEM or residential installation,this unit has been
designed and certified to be converted from natural gas to propane or vice-versa. When provisions are
being made to convert this unit, a certified conversion kit must be used. You must also readjust manifold gas
pressure to specifications indicated in the conversion manual. If in doubt, contact Rinnai America for
assistance.
24. Clothing or other flammable material should not be placed on or near the appliance.

DIMENSIONS
–5 –
FLUE MANIFOLD POSITION
IMPORTANT
Before drilling the flue hole, check for water and gas pipes as well as electric cables. Use a 3 1/8"
(80mm) drill for hole through the wall. Center of hole must be located exactly at specified point. See
diagram. For weatherboard walls, drill through center of weatherboard from outside.
Then drill from inside through plasterboard.
Flue Hole
3 1/8"
(80mm)
inches (mm)
3 7/16" (88)
4 5/16"
(109.5) 4 3/4" (121)
WALL OPENING
POSITION
GAS CONNECTION
26 5/8" (676.5)
3 1/8"
(φ80)
10 3/8" (264.5)
24 1/4" (616)
16 3/4" (425)
FLUE
ELBOW 4 1/2"
(114)
6 1/2" (165)
3 3/8" (85)
1 5/8" (41.2)
1" (25)
12 1/16" (306.5)
4 9/16" (116.5)
GAS CONNECTION
4 5/16"
(109.5)
WALL OPENING
POSITION
3 1/8"
(φ80)
10 3/8" (264.5)
FLUE
ELBOW
4 1/2"
(114)

SPECIFICATIONS
–6 –
MODEL ＃
RHFE-263FA-P
PROPANE
BTU/h MIN. CLEARANCES
INPUT OUTPUT SIDE TOP
LO:96.4
HI:128.5
LO:96.4
HI:128.5
FRONT
2"
(50mm) 10"
(250mm) 40" (1m)
40"
(1m)
FAN CFM
OUTPUT
10"
(250mm)
2"
(50mm)
Low
5,500
High
11,000
Low
4,450
High
8,800
Low
4,600
High
8,800
Low
5,700
High
11,000
SPECIFICATIONS
Type of Appliance Fan forced flued gas furnace
Model RHFE-263FA ENERGYSAVER
Width−16 3/4"(425mm)
Dimensions Depth−9 13/16" with back spacer (250mm with back spacer)
Height−26 5/8" (676.5mm)
Weight Approx. 37 lbs.
Connections Electrical−AC 120V 60Hz 47 watts
Gas−1/2" female NPT
Combustion System Stainless steel bunsen burner
Ignition System Continuous spark
Operation Finger touch control buttons
Temperature Control Electronic thermostat HI-LOW/OFF
Up/down switch 2°F increments
Temperature Range Modulates Continuous
LOW＝55°F 60°F〜80°F HI＝High Combustion
Warm Air Outlet Bottom front louver
Indicator/Lamps Operation/Combustion, Filter, SetTemp., RoomTemp., Economy, Function Lock.
Operating Buttons ON/OFF, Up/down, Function-lock, Economy
Economy Mode Energy saving feature
Humidifier Tray Capacity−1.5 pints (700cc)
RHFE-263FA-N
NATURAL

–7 –
Safety Devices
Noise Level Range HI〜LOW＝38〜31dB
TYPE
SPECIFICATIONS FOR VENT SIZES
S Thin Walls Mobile Home
Wood Walls
Wood/Brick
Brick/Block
Special
3"−4 1/2"
(75−115)mm
4 1/2"−9 1/2"
(115−240 )mm
9 1/2"−15 3/4"
(240−400 )mm
15 3/4"−23 5/8"
(400−600 )mm
23 5/8"−31 1/2"
(600−800 )mm
A
B
C
D
3 1/8" (80mm)
13ft., 2 90°bends (4m, 2 90°bends)
Combustion Method
Air Supply Exhaust
Radiation Method
Forced combustion
Closed Type
Forced convection
Wall Penetration
Hole
Max. Extended
AIR SUPPLY/
EXHAUST PIPE
Flame failure –Flame rod
Over heat –Bi-metal switch, thermal fuse, thermistor
Power failure –PCB
Power surge –3 Amp. fuse
Fan delay –Micro computer timer
Pre-purge –Combustion fan, pre-purge timer, spark sensor
Room over heat –Automatic cut off at 104°F after 10 minutes
** BTU - Efficiency increases with vent length. Clearances from combustibles (See page 3).
** Thermal efficiency rating determined under continuous operating conditions, and was determined
independently of any installed system.

SAFETY POINTS
–8 –
Do not restrict the warm air discharge by
placing articles in front of the heater. This appliance must not be used for any purpose other than heating.
Do not install the heater in an unusually
dusty area.
Do not allow anyone to sit on or lean against
the appliance.
Do not spray aerosols while the heater is
operating. Most aerosols contain butane
gas, and can be a fire hazard if used near
this heater when it is in use.
Do not allow curtains or other flammable or
combustible materials to come into contact
with the heater.
Combustible materials must not be placed
where the heater could ignite them.
