Risco ProSYS B5 User manual

1
Installation Guide
Panel Accessory Plastic Box
Installation Holes Map
Note: This box is only suitable for devices powered by voltages below 60VDC
or 42.4VAC.

2
Installation of Accessories (Maximum of 2)
ProSYS 8 Zone Expansion Module
ProSYS 4 Relay Output Module
ProSYS 8 O.C. Output Module
ProSYS Event Log Expansion Module (512, 999)
ProSYS X-10 Expansion Module
Connection holes: 1, 2, 13, 14 and/or 3, 4, 15, 16

3
Installation of a single 16 Zone Expander
Connection holes: 7, 10, 17, 18

4
Installation of GT Accessories (Maximum of 2)
Zone Expander (Code 02083)
Relay Output Expander (Code 02085)
ID Expander (Code 02087)
Connection holes: 5, 8, 11 and/or 6, 9, 12
Technical Specifications:
Dimensions: 192 mm x 150 mm x 57 mm
Certification:
EN50131-3 Grade 3 Environmental class II
Ordering Information:
Model Description
ProSYS B5 Plastic accessory box with tamper
RTTE Compliance Statement:
Hereby, RISCO Group declares that this equipment is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. For the CE Declaration of
Conformity please refer to our website: www.riscogroup.com.
© RISCO Group 07/2015 5IN1151 C
