Riso SF5 Series Operating instructions

How to use series
*The operation explanations . illustrations . screen examples shown in this manual are of SF5250.
Turn on the power switch.
1
Feed tray ascent /
descent button
Paper feed tray
lock lever
Feed-tray paper guides
Glass platen
Paper feed setting lever
2
Adjusting the Print Position
in the vertical direction
Adjusting the Print Density and the
Print Position in the horizontal direction
3
4
Paper receiving tray
Control panel
Power switch
Receiving-tray
paper guides
[START] key
[PRINT POSITION] keys
Numeric display
Numeric keys
Sub panel Main panel
Display
Vertical print position adjustment dial
●Please read the RISO SF series user's guide for more details.
For inquiries
Preparation before printing
Placement of Originals
Press the [START]key and check the proof copy
Enter the number of copies to beprinted using the numeric keys
Open the paper feed tray,
place the paper, align the right
and left paper guides to fit, and
turn the lock levers to lock the guides.
Adjust the paper feed pressure. Open the paper receiving tray,
slide the paper guides on the
paper receiving tray to fit the
paper size.
Glass platen
Center mark
or
Align the original with
the center facing downward
and close the platen cover.
Check that the “Ready to Make Master” is
displayed on the screen.
Place the document face up,
align the document setting fence
to the width of the document,
and insert the front end of
the document all the way in.
Comfirm the test printing and adjust the printing position, density, etc.Press the [START]key.
After master making,
one test print comes out.
Set the master making
conditions as necessary.
Press the [START]key to print.Enter the number of copies to be
printed using the numeric keys.
Auto Document Feeder AF-Ⅶ
（Optional Accessary）
Turn off the power switch.
Vertical print position
adjustment dial
Vertical print position
adjustment dial
[DENSITY] keys
(NORMAL) Newsprint paper, fine paper.
(CARD) Smooth cardstock, thick paper.
This fence stops with a
click sound at each
position corresponding to
the standard paper sizes.
When printing is complete,
open the paper guides and
remove the paper.
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

How to replace series consumables
Setting the Master Roll
Replacing the Ink Cartridge
Emptying the Master DisposalBox
Open the front door.
Check that the [Master Making
Unit Release Button] lamp is lit.
If the lamp is off, press the [Master Making
Unit Release Button] to turn it on.
1
Set a new master roll.
5Close the master roll holder.
Remove the tape.
6Close the master making unit
cover. Return the master making
unit to its original position.
Close the front door.
8
Grasp the master making unit
handle and pull it to the front.
Pull out the master making unit
slowly as far as it will go.
2Open the master making
unit cover.
3Open the master roll holder.
Remove the depleted master tube.
4
Remove the cap of the
new ink cartridge.
2Set the new ink cartridge in place.
Align the arrow on the ink cartridge to
the [▼] mark on the print drum (cylinder),
and then insert the ink cartridge as far as
it will go.
3Turn the ink cartridge clockwise
to lock it.
Close the front door.
4
Pull out the master disposal box
horizontally while grasping
the master disposal box handle.
2
If the master disposal box is
locked, slide the lock lever
to the right to unlock it.
1
●Keep the power supply during these operations.
Tilt the master disposal box
as illustrated above a wastebasket.
Grasping the push-out lever
drops the used masters.
3Insert the master disposal box
to its original position.
4
Insert the leading edge of the
master roll under the flap and
advance it, as far as it will go.
If the master roll is loose,
turn the flange and rewind
the master.
7
Protrusion
Arrow
Master disposal box handle
■When master making unit pulled out
Master disposal box
Ink cartridge
Front door
Master making unit
handle
Master Making Unit Release Button
Print drum
(cylinder)
Thermal print head
Flange
Master roll holder
Master roll
Master making unit cover
Master making unit
Master guide
Power switch
Unlock Lock
Unlock
Push-out
lever
Open the front door.
Pull out the depleted ink cartridge.
Turn the ink cartridge
counterclockwise ( ) to unlock it.
Pull out the ink cartridge.
1
Print Drum (Cylinder)
Release Button
