Ritchie Yellow Jacket ManTooth Series User manual

ManTooth™Dual Pressure
Wireless Digital P/T Gauge
ManTooth
™
Single Pressure
Wireless Digital P/T Gauge
User’s Manual
Made for iPhone 6 Plus, iPhone 6,
iPhone 5s, iPhone 5c, iPhone 5,
iPhone 4s, iPhone 4, iPad Air 2, iPad Air,
iPad mini 3, iPad mini 2, iPad mini, iPad 4,
iPad (3rd generation), iPad 2
iPhone, iPad and Retina are trademarks of Apple Inc.,
registered in the U.S. and other countries. iPad Air
and iPad mini are trademarks of Apple, Inc.
Android and Google Play are trademarks of Google Inc.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Ritchie Engineering is under license.
Other trademarks and trade names are those of their
respective owners.
“Made for iPhone” and “Made for iPad”
mean that an electronic accessory has been
designed to connect specifically to iPhone,
or iPad, respectively, and has been certified
by the developer to meet Apple
performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPhone, or iPad may affect
wireless performance.

Before You Start
Contacng Ritchie
To order accessories, receive assistance, or
locate the nearest YELLOW JACKET distributor.
Safety Informaon
Use the instrument only as specified in this
manual. Otherwise, the protecon provided by
the instrument may be impaired. Refer to the
safety informaon.
A Warning idenfies condions and acons
that pose hazards to the user. A Cauon
idenfies condions and acons that may
damage the instrument or the equipment
under test.
Warning
To avoid personal injury or death, follow these
guidelines:
Most governments and legal authories
require that HVAC technicians be
trained and cerfied in the safe and
proper operaon of HVAC tools, such as
this instrument. Since this tool may be
connected to many types of equipment
through a limitless combinaon of hoses
and fings, proper training is the most
important element of using this tool
safely.
Read the enre Users Manual before
using the instrument.
Use the instrument only as described in
this Users Manual, otherwise the
protecon provided by the equipment
may be impaired.
Do not use the instrument if it is
damaged. Before you use the
instrument, inspect the case. Look for
cracks or loose components.
The instrument contains no internal
user serviceable parts
Do not open the instrument.
Have the instrument serviced only by
Ritchie Engineering Co. or authorized
service centers.
Do not use the instrument if it operates
abnormally. Protecon may be
impaired. When in doubt, have the
instrument serviced.
Do not operate the instrument around
explosive gas, vapor, or dust.
Various refrigerants have been
intenonally excluded for very
significant safety reasons.
Never use refrigerants in this
instrument that are not listed in the Set-
up menu.
The refrigerant database in this unit
may include refrigerants classified as
flammable. If such refrigerants are
selected, the operator may need
addional cerficaons and/or training.
Consult your government and legal
authority and comply fully with all
requirements.
Always wear eye and skin protecon
when working with refrigerants.
Escaping refrigerant vapors will present
afreezing danger. Do not direct
•
•
•
•
•
•
•
•
•
•
•
•
•
2
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

refrigerant vapors venng from hoses
towards the skin.
Maximum Working Pressure: 700 psia
(4.83 MPa)
Because this instrument allows for
various inputs including electrical and
mechanical, care must be taken to
observe any ways that an electrical
shock hazard could develop. Example:
Wet or humid condions, along with a
sensor, could allow an electrical path
across the instrument. Keep all
interconnected equipment clean,
organized, and in proper condion. Do
not use the instrument if you are not
qualified to recognize potenal
electrical faults.
Cauon
To avoid damage to equipment, follow these
guidelines:
Do not allow pressures beyond the
specificaons listed in this manual.
Do not aempt to introduce liquid or
samples heavily laden with oil into the
instrument.
Read and observe instrucons and
specificaons related to the baeries
used in this instrument that may cause
damage to it.
Do not use this instrument on systems
containing leak sealing chemicals. These
leak sealants can collect and harden in
the instrument, causing permanent
damage.
Only use this instrument with the
protective boot in place as this protects
the charging port and temperature
probe connecon ports from unwanted
contaminants.
Do not use damaged USB chargers to
recharge the ManTooth PT Module as
this could damage the circuitry and/or
baery.
Only use with refrigerants approved for
use with the ManTooth PT Module. Use
of unapproved refrigerants may cause
damage to the ManTooth PT Module. A
complete list of approved refrigerants
can be found in the ManTooth RSA app
in the “Select Refrigerant” opon.
Geng Started
The ManTooth PT Module is a precise
instrument to accurately measure and report
the crical informaon needed to service
refrigeraon and air-condioning equipment.
The ManTooth PT Module reports the system
informaon directly to your smartphone or
tablet by means of a class 1 Bluetooth v.2.1
radio. The ManTooth PT Module is compable
with any iOS device running iOS 7.0 or later and
Android devices running Android 4.0.3 (Ice
Cream Sandwich) or later.
Before you use your ManTooth PT Module for
the first me you should make sure that it is
fully charged. You will also need to download
the free ManTooth RSA Pressure/Temperature
App from the Apple App Store for iOS devices
or the Google Play store for Android devices.
You can either use the QR code links that are
on your ManTooth PT Module packaging,
follow the links that are available on
YellowJacket.com, or just search for Yellow
Jacket ManTooth in either app store.
Pairing
To display service readings your ManTooth PT
Module must be connected via Bluetooth to an
iOS phone or tablet running iOS 7.0+ or an
•
•
•
•
•
•
•
•
•
3

Android phone or tablet running Android 4.0.3+
(Ice Cream Sandwich or later). To connect your
ManTooth PT Module to your phone or tablet
the two must first be paired to one another.
The pairing of the module to your device is
done in your phone or tablet’s sengs.
**Note** you only need to pair your ManTooth
PT Module the first me you connect it to your
phone or tablet, however, if you force your
phone or tablet to “forget” your ManTooth PT
Module you will need to re-pair. **Note** your
ManTooth PT Module can be paired with
mulple devices at the same me. However, it
can only be connected and sending readings to
one phone or tablet at a me.
To pair your ManTooth PT Module you first
need to open the sengs menu on the phone
or tablet you wish to pair to your ManTooth PT
Module. Next tap on “Bluetooth” to enter the
Bluetooth sengs. Be sure to turn your phone
or tablet’s Bluetooth radio on if it is not already
on.
Next turn your ManTooth PT Module on by
pressing and releasing the power buon on the
main module. If you have a 67002 dual unit the
main module is the one that says “ManTooth
PT Module” on the label not the one that says
“ManTooth PT Tether Module”. The module
will go through a brief start up sequence then
the light on your ManTooth PT Module should
start to blink blue. This means that your
ManTooth PT Module is searching for available
Bluetooth devices to connect with. Next, if you
are using an Android phone or tablet, tap on
“Scan” at the boom of the screen to scan for
available devices. Apple iOS devices should
automacally scan for available Bluetooth
devices.
Your ManTooth PT Module should then show
up as an available device to pair with on your
phone or tablet’s screen. This may take up to
30 seconds.
**Note** Your ManTooth PT Module’s name is
the same as the serial number and is printed on
the main module’s label just above the model
number (67001 or 67002).
Once your ManTooth PT Module shows up as
an available device tap on it’s name to pair it
with your phone. On Android systems a
“Bluetooth pairing request” alert may pop up
asking to confirm the passkey tap on “OK” to
connue.
Apple iOS Android
Apple iOS Android
4

Aer pairing your Apple iOS phone or tablet to
your ManTooth PT Module it should show up as
either “Connected” or “Not Connected” rather
than “Not Paired” on the Bluetooth sengs
screen. On Android devices under the “Paired
devices” secon on the Bluetooth sengs
screen.
On Apple iOS devices once your ManTooth PT
Module is paired if it is listed as “Connected”
the light on the module will glow a solid blue.
However, on all Android devices or if your iOS
device lists your ManTooth PT Module as “Not
Connected” the light will connue to blink blue.
This is normal.
ManTooth RSA App
This secon will go over the various funcons,
sengs, and procedures of the ManTooth RSA
Pressure/Temperature App.
If you have not already downloaded the Yellow
Jacket ManTooth RSA Pressure/Temperature
App go to either the Apple App Store or the
Google Play Store now to download the free
app. You can either use the QR code links that
are on your ManTooth PT Module packaging,
follow the links that are available on
YellowJacket.com, or just search for Yellow
Jacket ManTooth in either app store.
General Sengs
The General Sengs menu is where you can set
up and change various funcons of your
ManTooth RSA app to personalize it for your
specific needs.
To access the general sengs on the first
screen available upon opening the ManTooth
RSA app tap on the gear in the upper right
corner of the screen.
Apple iOS Android
Android
5

Service Management
Your Informaon
Here you can set your own name and your
company name. This informaon will
automacally appear in the e-mails containing
the system readings which you can send
directly from within the app.
Locaons and Equipment
Here you are able to create new locaons, add
addional units to exisng locaons, remove
units from locaons or completely remove
exisng locaons. **Note** If you delete an
enre locaon all screen shots associated with
this locaon and any equipment at this locaon
will all be deleted. Deleted locaons and
associated screen shots can not be retrieved.
Similarly if you delete equipment from a
locaon the screen shots associated with that
equipment will also deleted. Deleted
equipment and associated screen shots can not
be retrieved.
Preferences
Temperature Preference
Set the units that the temperature readings
from the temperature sensors, Vapor
Saturaon, Liquid Saturaon, and the values for
Superheang and Subcooling are displayed in.
Opons are degrees Fahrenheit (°F) or degrees
Celsius (°C). Default temperature units are
degrees Fahrenheit (°F)
Pressure Preference
Set the units that the pressure readings are
displayed in. Available units are bar, pounds per
square inch absolute (psia), pounds per square
inch gauge (psig), kilopascals (kPa),
Megapascals (MPa), and kilogram per square
cenmeter (kg/cm^2). The default pressure
units are pounds per square inch gage (psig)
Auto Sleep
This opon will disable your phone or tablet’s
automac sleep funcon so that while you are
in a session taking readings your phone or
tablet will not automacally go to sleep which
could disrupt your session and readings. The
default auto sleep seng is Override Auto
Sleep = Off.
Device Management
Power Down Connected Devices
This is another way of shung offyour
connected ManTooth PT Module(s) if you are
not near enough to your module(s) to press the
6

power buon(s) and want to turn the power
completely off.
Calibrate Device Readings
This gives you the opon to adjust the
calibraon of your ManTooth PT Module’s
pressure readings or temperature readings
away from the factory defaults.
Restore Factory Defaults
This will clear any calibraon adjustments that
have been done on the ManTooth PT Module
since it lethe factory.
Auto Off
This slider gives you the opon of having your
ManTooth PT Module automacally turn itself
offaer a designated period of me. It can be
set anywhere from 1 to 90 minutes. Aer the
ManTooth PT Module has been connected for
the specified auto offme an alert will pop up
asking if you would like to reset the auto off
mer if you wish to reset the mer simply tap
anywhere on the screen. Also included is an
auto offnever seng. Moving the slider all the
way to the lewill set the auto off mer to
never. Default is Auto Off= 5 min.
Geng Back to the Previous
Screen
To return to the previous screen from the one
you are currently viewing tap on the icon in the
upper lehand corner. This funcon is the
same in all of the screens in the ManTooth RSA
App.
Service History
In service history you are able to browse
through data that was saved during previous
service sessions. Saved data is organized
alphabecally by locaon then by each
locaon’s equipment finally by date and me
the data was taken. If you tap on the desired
service history reading you can see the reading
that was taken and either email the reading to
someone or delete it. Remember once you
have deleted a reading it can not be retrieved!
7

Start Session
Sessions are where you connect your phone or
tablet with your ManTooth PT Module to see
and collect system readings. To begin a new
session tap on “Start Session” in the App home
screen.
Session Sengs
Using the correct sengs that are specific for
the current system you are servicing will ensure
the best possible pressure readings as well as
liquid and vapor saturaon values.
Set Elevaon
Seng the elevaon will enable your
ManTooth RSA app to correct for elevaon
pressure variaons allowing for more accurate
pressure readings. You may either use your
phone or tablet’s built in GPS to determine
your elevaon or input the elevaon manually
by taping on the elevaon and entering your
elevaon above sea level in feet. **Note**
“Use GPS to Find Locaon” funconality may
not work on all devices especially those without
cellular service.
Set Refrigerant
To set the refrigerant for the current session
tap on “Refrigerant” then scroll through the list
of almost 100 NIST refrigerants and select the
refrigerant corresponding to the unit you will
be servicing. If you accidently select an
incorrect refrigerant do not worry you can also
change the refrigerant later in the readings
screen. Seng a refrigerant is mandatory
before moving to the next screen.
************WARNING************
Refrigerants classified as flammable are in red
text. If such refrigerants are selected, the
operator may need addional cerficaons
and/or training. Consult your local government
and legal authority and comply fully with all
requirements.
***************************************
Set Locaon Details
If you want to organize your saved data in
session history you can enter the locaon
informaon for the current service session. This
informaon will show up in the service reports
you can email and is how the service history
will be organized. Here you have the ability to
either add a new locaon or select an exisng
locaon. Once you have designated a locaon
you can also designate what equipment is being
serviced during the session. Locaons can have
8

mulple pieces of equipment associated with
them so you can keep track of each individual
unit at locaons that may have more than one
system. Saved session data will be saved to
“Session History” in the app’s main menu and
sorted first alphabecally by business name or
customer last name, then alphabecally by
assigned equipment name, and lastly by the
date and me the data was saved. **Note**
Locaon details are oponal. Any saved session
data without an assigned locaon will be saved
under “No Locaon” and appear at the end of
the Service History list. The “No Locaon” data
will be sorted simply by date and me. You can
not assign a locaon to data at a later me.
Assign Devices and Zero
Assign Detected Devices
Now you are ready to connect your ManTooth
PT Module to your current session. To connect
your module first tap on “Devices None
Specified”, this will take you to the next screen.
Tap on the ManTooth PT Module(s) that you
wish to connect to your session from the list of
devices that are displayed. Remember your
Module’s name is the serial number printed on
the main label and should take the form of
YJPT-XXXX-XXXX. Next tap the save icon in the
upper right corner of the screen to save the
module(s) to the session. **Note** On iOS
devices you must tap on “Connect a Device” to
first connect your device to your phone or
tablet and then select it under the “Select From
Connected Devices” heading to fully connect it
to your session. **Note** to connect to your
ManTooth PT Module(s) your module(s) must
be on and searching for a connecon (where
the blue light is blinking).
Apple iOS Android
9

Aer you save your module(s) to the session
they will be displayed at the top of the screen
under “Assign Detected Devices”. The pressures
from the connected module(s) will be displayed
at the boom of the screen. To zero the
pressure transducer readings tap on “Zero”
next to the corresponding pressure. **Note**
It is recommended that you zero the pressure
transducer(s) at the beginning of each new
session before connecng your ManTooth PT
Module to a system. This will ensure the most
accurate device readings.
Aach Devices
Before starng the session you have one more
chance to check to make sure that the pressure
transducers are zeroed. While in the “Aach
Devices” screen is the appropriate me to
connect your ManTooth PT Module to your
system. Connecng the ManTooth PT Module
to the system before beginning your session
will also ensure that the average, minimum,
and maximum readings are accurate.
Readings
The readings screen will display the pressures
and temperatures as measured by the
ManTooth PT Module, display the liquid and
vapor saturaon values, as well as calculate and
display the superheat and subcooling values.
The first me you connect your ManTooth PT
Module to a new phone or tablet you will have
to assign the pressure transducers and
temperature sensors. These assignments are
not permanent and can be changed at anyme.
**Note** the pressure transducer in every
ManTooth PT Module (main or tethered) is
capable of accurately reading pressures up to
700 psia (48.3 bar) and therefore can reliably
be used on either the high or low side.
10

Refrigerant
The refrigerant for the session can be changed
by taping on the refrigerant and selecng the
refrigerant that is in the equipment you are
currently working with. If you forgot or selected
the wrong refrigerant in the Session Sengs
this is where the refrigerant can be changed.
Pressure
To assign pressure readings to either the high
or low side simply tap on the box that contains
the value you wish to assign and select the
sensor that you want to assign to that spot.
**Note** on dual units with 2 transducers the
main unit is #1 and the tethered unit is #2. If
you are using two single units reference the
device name/serial number to determine which
pressure is associated with which device.
Liquid and Vapor Saturaon
Liquid and Vapor Saturaon values are
calculated automacally by the app based on
the measured pressure and the refrigerant
selected.
Temperature
To assign temperature readings to either the
high or low side simply tap on the box that
contains the value you wish to assign and select
the sensor that you want to assign to that spot.
**Note** the label on the ManTooth PT
Module denotes which temperature port is T1
and which is T2 for easy reference.
Subcooling and Superheat
To set the subcooling and superheat values tap
on the “Subcooling” or “Superheat” box and
enter the data requested. For subcooling just
enter the the desired value for subcooling. For
superheat enter the outdoor dry bulb
temperature and the indoor wet bulb
temperature. The app will then take this data
and automacally calculate the target
superheat value. Once you have entered the
necessary informaon save the values by taping
on the save icon in the top right corner of the
screen
Saving Data
To save the data currently on the screen tap on
the screen shot icon on the top right corner of
the readings screen.
11

Once you choose to save the data you will be
given the opon to save and email which will
save it to your session history and imbed the
data into an email report for you to send to
whoever you want, discard the snapshot you
just took, or just save it to your session history
for later reference and use. **Note** the
phone or tablet you are using must be
connected to cellular service or WiFi to send
emails. If your phone or tablet does not have
the proper service to send an email when the
screen shots are taken you can save the data
and then access it at any me from the
“Session History” secon on the app’s home
screen. Any saved service data can be emailed
from within “Session History”.
Other Buons
At the boom of the readings screen there are
two addional buons.
The first is labeled “Clear readings” This will
clear the minimum, maximum, and average
readings of the session. This funcon is
especially useful for determining system
stability.
The other opon is “Exit Session”. This will not
only exit the readings screen but will take you
all the way back to the home screen of the
ManTooth RSA app.
ManTooth™ PT Module
1
2
3
4
56 7 8 9
1: Status Light
2: Power Buon
3: Device Name
4: Temperature Probe Indicators
5: Micro USB charging port
6: ¼ inch flare fing pressure transducer
connecon
7: ¼ inch flare fing with Schrader core
pressure transducer connecon
12

8: ManTooth thermistor temperature clamp
9: Temperature probe jacks
**Note** On 67002 tethered units numbers 1-
4, 5, and 9 are on the main unit only. The
tethered unit is only equipped with the flair
fings for measuring refrigerant pressure and
adjusng charge.
Status Light
The mul-colored LED indicates the status of
your ManTooth PT Module.
Blinking Blue: The module is on and searching
for a Bluetooth connecon. This will connue
from when you turn on your ManTooth PT
Module unl you connect to it within the
ManTooth RSA Pressure/Temperature app.
**Note** If your ManTooth PT Module looses
connecon to your phone or tablet it will
automacally revert back to this searching for a
connecon mode.
Solid Blue: The module is on and connected to
aphone or tablet via Bluetooth.
Solid Green: The module is connected to a
power source via the Micro USB port and is
charging. **Note** once the unit is fully
charged the green light will turn off.
Blinking Red (Short): The module will blink
short flashes of red to indicate that it is sending
data to a connected device. This will occur
while the light is solid blue.
Blinking Red (Long): The module will flash long
blinks of red when the baery level is below
10% of total life remaining.
Power Buon
To turn your ManTooth PT Module on or off
push and release the power buon once.
Device Name
Your ManTooth PT Module’s name is displayed
right on the label for easy reference. The name
takes the form of YJPT-XXXX-XXXX. The device
name serves as your ManTooth PT Module’s
name within the ManTooth RSA app, its serial
number, as well as its Bluetooth name that will
appear on your phone or tablet when pairing.
Temperature Probe Indicator
On the label of the ManTooth PT Module T1
and T2 are printed onto the label to indicate
which temperature port on the back of the
device corresponds to temperature port 1 (T1)
and temperature port 2 (T2).
Micro USB Charging Port
The ManTooth PT Module is designed to be
charged using any standard Micro USB charging
cord and corrisponding USB charger.
¼ Inch Flare Fing Pressure Transducer
Connecon
The flare fing on the front of the ManTooth
PT Module directs to the pressure transducer
with a working pressure range of 0-700 psia.
The fing is equipped with an “Adjust-a-Valve”
opener and sized to fit most system access
ports for easy access to most AC and
refrigeraon units. The compact size of the
ManTooth PT Module and no hose connecon
system reduces charge loss that can occur from
hoses used in charging through a standard test
and charge manifold. Adapters to connect the
ManTooth PT Module to other size access ports
are available from Yellow Jacket.
¼ Inch Flare Fing With Schrader Core
Pressure Transducer Connecon
The Schrader core fing on the ManTooth PT
Module allows for recovering refrigerant,
adding charge, or removing charge all without
13

disconnecng your ManTooth PT Module from
the system.
ManTooth Thermistor Clamp
The thermistor pipe clamp probe is capable of
clamping to and measuring the temperature of
pipes ranging in size from ¼ inch to 1 ⅜inches.
The probe is capable of measuring with an
accuracy of 0.2°C from 0°C to 70°C with a full
range of -40°C to 130°C. For best long term
stability of your thermistor pipe clamp probe
avoid storing it at temperatures exceeding 75°C
(167°F).
Thermistor Probe Jacks
Each ManTooth PT Module is equipped with 2
temperature probe jacks for use with
ManTooth Thermistor Clamps.
Instrumentaon Specificaon
Pressure
Sensing
Resoluon
0.1 psi, 0.1 bar, 1 kPa, 0.01
MPa, 0.01 kg/cm^2
Pressure
sensing
accuracy
0.5% of full scale at 25°C
1% of full scale 55°F to 130°F
2% of full scale -40°F to 248°F
Working
Pressure
0 to 700 psia (48.3 bar)
Proof
Pressure
Tolerable pressure without
internal damage
1000 psia
Burst Pressure
Tolerable pressure without
loss of seal
1500 psia
Temperature
Sensor Range
(instrument)
Sensing element
-40°F to 266°F
(-40°C to 130°C)
Max Cord temp
176°F (80°C)
Max Clamp Temp
203°F (95°C)
Temperature
Display
Resoluon
0.1
°F or °C
Temperature
Accuracy
(Instrument)
±0.2°C (±0.36°F)
Working
Temperature
-4°F to 160°F Limited by
baery
Storage
Temperature
-4°F to 160°F
For best baery performance
do not store at over 100°F
Working
humidity
0 to 95% RH (non-condensing)
IP Class
IP 50
Baery Life
10+ hours connuous
Range
Up to 400 Feet
Limited by Phone or Tablet
Bluetooth radio strength
Bluetooth
Radio
Class 1 Bluetooth 2.1 Radio
Size
6” long x 1.6” wide x 2.3” thick
(15.3 x 4 x 5.8 cm)
Weight
0.5 lbs (225 grams)
Superheat
and Subcool
Automacally calculated by
the ManTooth App
Max. and Min.
Pressures
Displays and records the
maximum and minimum
pressures
Refrigerant
Database
98 NIST refrigerant profiles
included; upgradeable
Share
Screenshots
Screenshot feature allows you
to save pressure and
temperature readings from
your sessions which can be
automacally organized by
locaon and unit being
serviced
Temperature
Sensors
Capable of measuring 2
temperatures using high
accuracy NTC thermistors
Pressure
Transducers
67001 – one pressure
transducer
67002 – two pressure
14

transducers
System
aachment
Very small internal volume
minimizes refrigerant loss
during system analysis.
Standard manifolds and hoses
can lose over 50 mes more
refrigerant with each
connecon
Pressure
Zeroing
Simple single buon zeroing at
the start of each session
Elevaon
Compensaon
Enter elevaon at the start of
the session for effortless psia
compensaon
Baery
Rechargeable LiPo baery for
long baery life and excellent
recharging capability for the
life of your ManTooth
15

Warranty Policy
The YELLOW JACKET ManTooth Wireless Digital
P/T Gauge from Ritchie Engineering Company,
Inc. is guaranteed to be free from material and
workmanship defects for a period of two years.
All other YELLOW JACKET products included
in this package are guaranteed to be free from
material and workmanship defects for a period of
one year. These guarantees do not cover prod
-
ucts that have been altered, abused, misused or
improperly maintained.
©2014 Ritchie Engineering Co., Inc.
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
