RITS-N RC400 User manual

Thank you for purchasing the dual purpose RC400 Wired Digital Door Key / Digital Touch Pad.
3 GENERAL INFORMATION
Unfasten the screw bolt,
and use a flat blade (⊖)screwdriver
to disassemble it,
as shown in the figure below.
Water proof pad (Silicone rubber)
Between outside gaps
Screw bolt for
disassembling
/assembling
Lower case
Connection
wire hole
Mounting screws
Disassembling the upper case
Water proof pad (Silicone rubber)
(When assembling the product,
the water proof pad should
not be twisted)
1 COMPOSITION & SPECIFICATIONS
Wired Digital Door Key (RC400)
Mounting screws (4x16)
Mounting template
Connection wire
1EA
2EA
1EA
1EA
User’s Manual 1 copy
Power supply
Relay contact capacity
Operating temp
Type
Power consumption
International Protection
DC 12~30V, AC 12~24V
DC30V / 1A
-20℃~50℃
ISO14443A(Mifare) / 13.56MHz
300mA Under
IP54 (Recommend for Indoor Use)
CompositionSpecification
: Error : Touch : Acon / Set
Digital
Wired Door Key (RN-RC400)
User’s Guide
Digital
Wired Door Key (RN-RC400)
User’s Guide
2 DIMENSION
Unit : mm
3 OPERATION CHECK & CAUTION
5 CONTACT TIME
4 HOW TO USE
1. Be sure to connect DC12 ~ 30V / AC12 ~ 24V.
2. When it powers on, the LEDs will be displayed sequentially: once all LEDs have been displayed, “beep” sound is heard.
3. Since this system is capacitive touch type, it will not respond to a gloved hand.
①②③④ ⇒ ①②③④ ⇒ # ⇒ ① ⇒ # ⇒ Access card (Serial registration is possible) ⇒ # ⇒ * (end)
①②③④ ⇒ ①②③④ ⇒ # ⇒ ① ⇒ # ⇒ Card address(0001~0500) ⇒ Card ⇒ # ⇒ * (end)
Example) Serial registration : if the first address is [0100], next address is [0101] automatically increase.
①②③④ ⇒ ①②③④ ⇒ # ⇒ ③ ⇒ # ⇒ Card address (4digit or serial delete) ⇒ # ⇒ * (end)
4) [Contact Time]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑤ ⇒ # ⇒ 01~60 (01sec.~60sec.) ⇒ # ⇒ * (end)
Example) 5’s Setup : 0+5, 20’s Setup : 2+0 (2sec at the time of initial release)
5) [All Card Delete]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑥ ⇒ # (end)
6) [All Password Delete]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑦ ⇒ # (end)
7) [Card or Password Delete]
Card : ①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑧ ⇒ # ⇒ Access Card (Serial possible) ⇒ # ⇒ * (end)
Password : ①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑧ ⇒ # ⇒ Password ⇒ # (Delete) ⇒ * (end)
8) [Toggle mode contact change]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ②ⓞ ⇒ # ⇒ Set value (ⓞ~①) ⇒ # ⇒ * (end)
Set value - ⓞ : Normal , ① : Toggle mode (ⓞ at the time of initial release)
9) [Operation mode setting]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ⑨ ⇒ # ⇒ Set value (ⓞ~①) ⇒ # ⇒ * (end)
Set value - ⓞ:NO, ①: NC (ⓞ at the time of initial release)
10) [Illumination brightness setting]
①②③④ ⇒ ①②③④ ⇒ # ⇒ ①② ⇒ # ⇒ Set value ⓞ~⑨) ⇒ # ⇒ * (end)
Set value -ⓞ: Illumination OFF, ⑨: The highest degree of brightness (② at the time of initial release)
Set the brightness of the illumination at standby state. In case brightness of the illumination is set at OFF,
when touch pad is pressed, number is displayed.
11) [System number change]
①②③④ ⇒ ①②③④ ⇒ # ⇒ * ⇒ # ⇒ # ⇒ System number in use ⇒ # ⇒ system number to be changed ⇒ # (end)
System Number: Refers to the number ①②③④ used to set menu.
12)
[System Initialization]
①②③④ ⇒ ①②③④ ⇒ * ⇒ # ⇒ Initialization ⇒ Exit after the LEDs blink. ⇒ (end)
①②③④ ⇒ ①②③④ ⇒ # ⇒ ② ⇒ # ⇒ Password(4digit) ⇒ # ⇒ * (end)
(Serial registration)
Power (DC 12~30V, AC 12~24V)
Yellow
Yellow
White
White
Gray
Gray
External Input
Output Contact
2) [Password Registration]
3) [Card address Delete]
1) [Card Registration]
6 EM LOCK WIRING
Output Contact
EM Lock
Adapter
Wiring
Wired Digital
Door Key
Upper case
20
41
150
MSIP-CRM-RSN-RN-RC400
NO. 10-1456214
Patent application
※ Use after removing the protective film

Digital
Wired Door Key (RN-RC400)
User’s Guide
[Open a door]
Password (4 digits) ⇒ # (If more than 4 digit password is entered,
just the last four digits should be identical (right) with your preset
password to open the door.)
Password (4 digits) → #
Key in the following digits
1234 → 1234 → # → 1 → #
Access Card (Serial registration is possible)
OR
Card address(0001~1000) → Access Card # → * (End)
# → * (End)
Key in the following digits
1234 → 1234 → # → 2 → # Insert 4 digit keycode password
[Note] Serial registration (If the first address will be [0100], next address is [0101] automatically increase.)
[Card registration] Card type : ISO 14443 (Mifare)
[Password registration]
indicator will appear and
the door key will be operating.
[WARNING & CAUTION]
If operator touch the key pad with a
gloved hand, it may cause malfunctioning.
Fragile Be careful not to expose it to falling.
[How to block external input]
password (4 digits) -> *
[Note] Disconnect the input of white line which is external
input. Door is opened and automatically released.
is blinking twice and
setting is completed.
Enter your password (4 digits),
and press the
MSIP-CRM-RSN-RN-RC400
NO. 10-1456214
Patent application
*key.
