RJS inspector 5000 Manual

Inspector 5000™
Auto Optic
Operator’s Guide
Manual P/N 003-4500
Revision: C
October 2021
THIS MANUAL APPLIES ONLY TO FIRMWARE 1.109 OR LATER
RJS Technologies
701 Decatur Ave North, Suite 107
Minneapolis, MN 55427 U.S.A.
[phone]
www.rjs1.com

Copyrights
The copyrights in this manual are owned by RJS. All rights
are reserved. Unauthorized reproduction of this manual or
unauthorized use of the Inspector 5000 software may result
in imprisonment of up to one year and fines of up to
$10,000.00 (17 U.S.C. 506). Copyright violations may be
subject to civil liability.
Reference RJS P/N 003-4500 Revision C
All Rights Reserved.

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
i
TABLE OF CONTENTS
1.0 PREFACE 1
1.1 PROPRIETARY STATEMENT 1
1.2 STATEMENT OF FCC COMPLIANCE:USA 1
1.3 STATEMENT OF FCC COMPLIANCE:CANADA 1
1.4 CE: 1
1.5 DOCUMENTATION UPDATES 2
1.6 COPYRIGHTS 2
1.7 UNPACKING AND INSPECTION 2
1.8 BATTERIES 3
1.9 TECHNICAL SUPPORT 3
1.10 TRADEMARKS 3
2.0 WARRANTY 4
2.1 GENERAL WARRANTY 4
2.2 WARRANTY LIMITATIONS 4
2.3 SERVICE DURING THE WARRANTY PERIOD 4
3.0 INTRODUCTION 6
3.1 INSPECTOR 5000 DESCRIPTION AND FEATURES 6
3.2 MAINTENANCE 7
3.3 TEMPERATURE SPECS 7
4.0 THE INSPECTOR 5000 AUTO OPTIC 8
5.0 MAIN MENU SELECTIONS 9
5.1 POWER ON/OFF 9
5.2 SCREEN NAVIGATION 10
FOR NORMAL OPERATIONS 10
SPECIAL FUNCTIONS 10
POWER ON11
5.3 FIELD CALIBRATION 12
INSPECTOR 5000 CALIBRATION INTERVAL 12
VERIFYING THE INSPECTOR 5000 IS CALIBRATED 14
CALIBRATING THE INSPECTOR 5000 15
5.4 SETUP 20
SYMBOLOGY SETTINGS 21
CAMERA SETTINGS 24
AUTO OPTIC SETTINGS 26

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
ii
LASER SETTINGS 28
SYSTEM SETTINGS 29
EXIT /SAVE SETTINGS 33
6.0 SCANNING SYMBOLS 35
6.1 SCANNING TECHNIQUES 35
6.2 SCANNING RESULTS 36
6.3 PASS/FAIL SCREEN 37
6.4 MULTIPLE SCAN AVERAGING RESULTS 38
7.0 GRADE ANALYSIS SCREEN 39
7.1 RESULTS EXPLANATION 41
TABLE 7-A (CODE IDENTIFIER DESCRIPTIONS) 41
TABLE 7-B (ABBREVIATED CODE IDENTIFIER DESCRIPTIONS)42
7.2 ISO PARAMETER HISTORY RESULTS 49
8.0 ENCODE ANALYSIS SCREEN 51
ACCEPTABLE GS1-128 ENCODE ANALYSIS SCREEN 51
FAILURE GS1-128 ENCODE ANALYSIS SCREEN 53
FAILURE UPC-A ENCODE ANALYSIS SCREEN 54
9.0 PROFILE ANALYSIS SCREEN 55
AN EXAMPLE OF THE ANALOG PROFILE ANALYSIS SCREEN: 56
AN EXAMPLE OF THE GREY-SCALE IMAGE SCREEN: 57
AN EXAMPLE OF THE BLACK/WHITE IMAGE SCREEN: 58
10.0 VIEWING SAVED INSPECTION REPORTS 59
EXAMPLE OF THE REPORT (DATABASE)SCREEN: 59
EXAMPLE OF THE REPORT (DATABASE)SCREEN AFTER
SCROLLING TO OLDER REPORTS: 60
11.0 CONNECT TO OTHER DEVICES 61
CONNECT TO COMPUTER 61
CONNECT TO PRINTER 61
APPENDIX A (ISO/ANSI PARAMETER ANALYSIS) 62
TABLE A-1 (NUMERIC TO LETTER GRADE CONVERSION) 62
DECODABILITY 62
MODULATION 63
SYMBOL CONTRAST 63
DEFECTS 64
EDGE CONTRAST MINIMUM 64
REFERENCE DECODE 65
EDGE DETERMINATION 66

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
iii
REFLECTANCE MINIMUM 66
TRADITIONAL BAR ANALYSIS TOLERANCE 67
APPENDIX B (SYMBOLOGY ANALYSIS) 68
SYMBOLOGY ANALYSIS PARAMETERS 68
TABLE B-1 (PARAMETER/ERROR MESSAGE) 68
TABLE B-2 (PARAMETERS CHECKED BY SYMBOLOGY) 69
APPENDIX C (ISO/ANSI DECODABILITY) 71
ISO/ANSI DECODABILITY CALCULATIONS 71
TABLE C-1 (DECODABILITY PERCENTAGE RANGES TO
NUMERIC AND LETTER GRADES) 72
APPENDIX D (REFLECTANCE PARAMETER GRADING) 73
TABLE D-1 (MODULATION PERCENTAGE RANGES TO NUMERIC
AND LETTER GRADES) 73
TABLE D-2 (SYMBOL CONTRAST PERCENTAGE RANGES TO
NUMERIC AND LETTER GRADES) 74
TABLE D-3 (DEFECTS PERCENTAGE RANGES TO NUMERIC AND
LETTER GRADES) 75
APPENDIX E (QUIET ZONE ANALYSIS) 76
QUIET ZONE ANALYSIS 76
TABLE F-1 (ACCEPTABLE PARAMETERS -SYMBOLS WITHOUT
ADDENDUMS) 76
TABLE F-2 (ACCEPTABLE PARAMETERS -SYMBOLS WITH
ADDENDUMS) 76
APPENDIX F (SPECIFICATIONS) 77
SPECIFICATIONS 77
TABLE F-1 (SPECIFICATIONS —STANDARD) 78
TABLE F-2 (SPECIFICATIONS —GENERAL DISTRIBUTION) 79
TABLE F-3 (SPECIFICATIONS —DIRECT CORRUGATE) 80
TABLE F-4 (SPECIFICATIONS —REGULATED HEALTHCARE) 81
TABLE F-5 (SPECIFICATIONS —PHARMACY) 82
TABLE F-6 (SPECIFICATIONS —NON-REGULATED
HEALTHCARE) 83

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
iv
APPENDIX G (CODE 128) 84
CODE 128 84
TABLE G-1 (CODE 128 —SUBSET A) 86
TABLE G-2 (CODE 128 —SUBSET B) 87
TABLE G-3 (CODE 128 —SUBSET C) 88
GS1-128 SYMBOLOGY SPECIFICATION 90
APPENDIX H (MAGNIFICATIONS) 92
UPC/EAN MAGNIFICATIONS &BAR WIDTH DEVIATIONS 92
APPENDIX I (APERTURE SELECTION) 93
APPENDIX J (PRINT FUNCTIONS) 94
PRINTING REPORTS 94
VCIR PRINT SCREEN –NEW BAR CODE INSPECTION 94
VCIR PRINT SCREEN –BAR CODE INSPECTION FROM
STORAGE 95
TP140APRINT SCREEN -BAR CODE INSPECTION FROM
STORAGE 95
PRINTOUT OPTIONS 96
ANALYSIS ONLY 96
ANALYSIS +PROFILE 96
ANALYSIS +BAR/SPACE 96
PREVIOUS DAY 96
PREVIOUS XX DAYS 96
DATE/TIME RANGE 97
EXAMPLES REPORTS 99
FIGURE J-1 (ANALYSIS ONLY DATA) 99
BAR WIDTH -ACCEPTABLE 100
BAR WIDTH -WARNING 100
BAR WIDTH -REJECTED 100
FIGURE J-2 (SCAN REFLECTANCE PROFILE DATA) 101
APPENDIX K (BATTERY INFORMATION) 102
BATTERY LEVEL 102
LOW BATTERY DISPLAY 103
BATTERY AND CHARGER 103
APPENDIX L (FIELD FIRMWARE UPGRADE) 104
APPENDIX M (BAR CODE DEFINITIONS) 107

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
1
1.0 Preface
1.1 Proprietary Statement
The Inspector 5000 Operator’s Guide contains proprietary
information of RJS. It is intended solely for the use of
parties operating and maintaining the equipment
described herein. This information may not be used,
reproduced, or disclosed to any other parties for any other
purpose without the express written permission of RJS.
1.2 Statement of FCC Compliance: USA
The equipment described in this manual has been tested
and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide a reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this operator’s
manual, may cause harmful interference to radio
communications. Operating this equipment in a residential
area is likely to cause harmful interference in which case
the user will be required to correct the problem at their
own expense.
1.3 Statement of FCC Compliance: Canada
This Class A digital apparatus meets all requirements of
the Canadian interference-Causing Equipment
Regulations.
Cet appareil numénque de la classe A respecte toutes les
exigences du Règlement sur le maténel brouilleur du
Canada.
1.4 CE:
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
2
accordance with this operator’s manual, may cause
harmful interference to radio communications. Operating
this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the problem at your their expense.
1.5 Documentation Updates
RJS strives to provide the best possible documentation.
This manual, or any of our manuals, may be updated
without notice.
1.6 Copyrights
The copyrights in this manual are owned by RJS. All rights
are reserved. Unauthorized reproduction of this manual or
unauthorized use of the software may result in
imprisonment of up to one year and fines of up to $10,000
(17 U.S.C.506). Copyright violations may be subject to
civil liability.
1.7 Unpacking and Inspection
Carefully unpack the components and save the container.
If the container is crushed, punctured or water damaged
you can use the container to prove a claim against the
carrier. RJS is not responsible for transportation damage.
Your Inspector 5000 is packaged in a custom made container.
After removing the unit from the shipping box make sure you
have:
Main display unit
Auto-optic scan head and cable
Calibration plaque
Operator’s manual
Print Test sheets
Battery charger

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
3
1.8 Batteries
The Inspector 5000 has an integrated lithium ion battery
pack installed in the unit.
The battery is not field replaceable and must be returned
to RJS for repair/replacement.
Warning:
DO NOT use any battery chargers other than the
Inspector 5000 battery charger. Use of non-RJS battery
chargers could damage your bar code verifier and/or
result in a fire.
1.9 Technical Support
Please read the manual.
If you need assistance over the phone, please have the
following information ready:
Model and serial number of your unit
Have a test print available, if applicable
Detailed explanation of the problem or question
Your company’s phone and email information
1.10 Trademarks
The following are trademarks of RJS:
RJS
RJS Systems International
Inspector
RJS Inspector
RJS
701 Decatur Avenue North, Suite 107
Minneapolis, MN 55427 U.S.A.
[phone]
[email protected]

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
4
2.0 Warranty
2.1 General Warranty
Warranty information: [phone]
RJS warrants your Inspector 5000 to be free from defects
in material and workmanship for a period of 1 year from
the date of shipment from RJS’ factory location.
The liability of RJS under this warranty is limited to
repairing or replacing the defective part and/or unit. RJS
may optionally choose to issue credit for any unit returned
during the warranty period.
You must promptly notify RJS of any defect in order to
receive the full protection of this warranty.
2.2 Warranty Limitations
The warranty set forth above is exclusive and no other
warranty, whether written or oral is expressed or implied.
RJS specifically disclaims the implied warranties of
merchantability and fitness for a particular purpose.
Some states or provinces do not allow limitation on how
long an implied warranty lasts, so the above limitation or
exclusion may not apply to you. However, any implied
warranty of merchantability or fitness is limited to the one
year duration of this written warranty.
RJS shall in no event be liable for any indirect, incidental,
or consequential damages, including but not limited to
damages which may arise from loss of anticipated
profits or production delivery delays, spoilage of material,
increased costs of operation of business or otherwise.
2.3 Service during the Warranty Period
If your Inspector 5000 should fail during the warranty
period, contact RJS or its authorized representative

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
5
immediately upon discovery of the defect. A Return
Authorization Number (RMA number) may be obtained by
visiting our website address:
http://www.rjs1.com/rma-request/
You will be asked to ship the product in its original
packing, freight prepaid, with the RMA number visibly
written on the outside of the carton to the RJS factory in
Minneapolis, MN U.S.A
Be sure to include any samples or printouts or other
information that will help us to understand the problem.
Your repair will be given priority treatment, or your unit
may be replaced at RJS’s option. The repaired item will be
returned UPS/United States Postal Service ground, freight
prepaid. At your request we will ship express or overnight
if you need premium service and agree to pay the
additional cost.

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
6
3.0 Introduction
3.1 Inspector 5000 Description and Features
The Inspector 5000 is an advanced technology bar code
verifier that makes it easy to decode bar code symbols
and to evaluate symbol compliance with industry
standards.
Features
Four aperture sizes selectable from setup screen
Two light wavelengths selectable from setup
screen
Provides scan head light color and aperture size
(display/print)
Auto-discriminates between many different
symbologies
Auto-print mode
Bi-directional scanning
Profile display with color coded indications for
Decodability, Modulation, and Defects
Calculates the Narrow Bar Width (NBW) of bar
code symbols
Calculate and display print contrast signals
(PCS)
Low battery indicator
Multiple scan averaging
Power-down is automatic after short period of
disuse
Programmable, multi-scan analysis
Specially designed Auto Optic ensures accurate
scanning angle
Store and print capabilities
Visual and audible signals

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
7
3.2 Maintenance
To ensure the best possible scanning conditions, keep the
display window clean. Use a soft, damp, lint-free cloth to
clean the window.
Do not use solvents on the unit or on any of the
components. You may use alcohol to clean the unit.
3.3 Temperature Specs
Do not operate or store your unit or components in
temperatures outside the range of 20° - 105°.
Do not operate or store your unit in conditions of high
humidityover 80%.

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
8
4.0 The Inspector 5000 Auto Optic
Auto Optic Scanner
LCD
Window
Battery Charger
Serial inte
r
face
Keypad
Buttons
Ethernet
USB

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
9
5.0 Main Menu Selections
5.1 Power On/Off
Power button
Press and hold the Power button for 1 second to turn On
the Inspector 5000. The RJS logo will be displayed for
three seconds (on the bottom of the screen is the
firmware version), then the Grade screen will displayed.
The Inspector 5000 can be turned Off by the following
methods:
1. Press and hold the Power button for 4 seconds
2. System time out (default is sleep mode after 1
minute (screen turns off) and power down after 15
minutes)

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
10
5.2 Screen Navigation
The Inspector 5000 screens are navigated by using the
seven buttons on the keypad.
Power
Up Arrow
Left Arrow
Down Arrow
Print
Select
Right Arrow
For normal operations
Left Arrow and Right Arrow buttons change which
screen (Grade/Encode/Profile/Report) is displayed
Up Arrow and Down Arrow buttons move the cursor up
and down on the current screen
Print button will send the inspection report(s) to either the
TP140A printer or the VCIR PC software program.
Special Functions
Power button, in addition to turning the unit On and Off,
the Power button will toggle between normal operations
and displaying the Instruction screens
To display the Calibration screen - press and hold the
Print button and then press the Left Arrow button
To display the Setup screen - press and hold the Print
button and then press the Right Arrow button
To display the System Information screen - press and
hold the Print button and then press the Power button

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
11
To jump the cursor to the bottom of the screen, press and
hold the Print button and then press the Down Arrow
button
To jump the cursor to the top of the screen, press and
hold the Print button and then press the Up Arrow button
Power On
When the Inspector 5000 is turned On, the GRADE
(grading) screen will display the last bar code inspected:
In addition to GRADE, the other screens are ENCODE,
PROFILE, and REPORT.
Note: A bar code can be scanned at any time except:
1. When the unit is printing
2. Setup screen is open
3. Profile screen is open
4. When a pop-up window is displayed
5. During calibration

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
12
5.3 Field Calibration
The Inspector 5000 requires periodic field calibration. The
interval depends on the environment where the bar code
verifier is used.
Inspector 5000 calibration interval
A clean room may be able to go two weeks between
calibrations while a dusty, high temperature, high humidity
environment may require daily calibration. Once per week
is appropriate for most facilities.
The Setup screen has a parameter “Days between
calibration”that is used to designate the required
calibration interval (default is 7).
The date of the last field calibration (and last factory re-
certification) can be viewed from the Status screen (press
and hold Print and then Power arrow), when expired the
fields will be highlighted in red.

Operator’s Guide Inspector 5000™ Auto Optic
003-4500 RJS, Minneapolis, MN
13
The Inspector 5000 will prompt the user when there is one
day before the field calibration will expire:
The Inspector 5000 will prompt the user when the field
calibration has expired. The inspection results will be
viewable on the screen but will not be saved in the
database and may not be printed:

Inspector 5000™ Auto Optic Operator’s Guide
RJS, Minneapolis, MN 003-4500
14
Press and hold Print button then press Left Arrow button
(at the same time) to display the Calibration screen:
Verifying the Inspector 5000 is calibrated
From the main calibration screen the unit is setup to
measure reflectance. This allows you to check the
calibration of the unit by placing the Auto Optic on the RJS
Calibration Plaque (P/N 002-7410), white or black fields,
and verifying that the reflectance value matches the stated
values.
Verify that reflectance values are within +/- 2% (of the
value written the calibration plaque –“High Reflectance
Value Target Values: Red (660nm)”) for white and +/- 2%
(of the value written the calibration plaque –“Low
Reflectance Value Target Values: Red (660nm)”) for
black.
