65-2301RKSS

Toxic Detector

Operator’s Manual

Part Number: 71-0273RK

Revision: A

Released: 7/17/19

65-2301RKSS Toxic Detector

WARNING

Read and understand this instruction manual before operating

detector. Improper use of the detector could result in bodily harm or

death.

Periodic calibration and maintenance of the detector is essential for

proper operation and correct readings. Please calibrate and maintain

this detector regularly! Frequency of calibration depends upon the

type of use you have and the sensor types.

Typical calibration frequencies for most applications are between 3

and 6 months, but can be required more often or less often based on

your usage.

65-2301RKSS Toxic Detector

Product Warranty

RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials,

workmanship, and performance for a period of one year from date of shipment from RKI Instruments,

Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of

charge. This warranty does not apply to those items which by their nature are subject to deterioration

or consumption in normal service, and which must be cleaned, repaired, or replaced on a routine

basis. Examples of such items are:

Warranty is voided by abuse including mechanical damage, alteration, rough handling, or repair

procedures not in accordance with the operator’s manual. This warranty indicates the full extent of

our liability, and we are not responsible for removal or replacement costs, local repair costs,

transportation costs, or contingent expenses incurred without our prior approval.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER

WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL

OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF RKI INSTRUMENTS,

INC. INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO

EVENT SHALL RKI INSTRUMENTS, INC. BE LIABLE FOR INDIRECT,

INCIDENTAL, OR CONSEQUENTIAL LOSS OR DAMAGE OF ANY KIND

CONNECTED WITH THE USE OF ITS PRODUCTS OR FAILURE OF ITS

PRODUCTS TO FUNCTION OR OPERATE PROPERLY.

This warranty covers instruments and parts sold to users by authorized distributors, dealers, and

representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for any accident or damage caused by the operation of this gas

monitor, and our warranty is limited to the replacement of parts or our complete goods.

a) Absorbent cartridges d) Batteries

b) Pump diaphragms and valves e) Filter elements

c) Fuses

65-2301RKSS Toxic Detector

Table of Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

65-2300RK Toxic Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Junction Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Mounting the Toxic Detector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Wiring the Toxic Detector to a Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Introducing Incoming Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the Zero (Fresh Air) Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Preventive Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Replacing Components of the Toxic Detector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Preparing for Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting the Zero (Fresh Air) Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting the Response Reading (Span). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

65-2301RKSS Toxic Detector • 5

Overview

This manual describes the 65-2301RKSS toxic detector. This manual also describes how to install, start

up, maintain, and calibrate the toxic detector when used with a gas monitoring controller. A parts list

at the end of this manual lists replacement parts and accessories for the toxic detector.

The 65-2301RKSS detector can be used for various target gases which are listed in Table 1 below. For a

particular target gas, the part number of the toxic detector will be of the format 65-2301RKSS-XXX. For

example, 65-2301RKSS-NH3 is for ammonia (NH3) detection.

Specifications

WARNING: Do not use this product in a manner not specified in this instruction manual.

Table 1 lists specifications for the various 65-2301RKSS toxic detectors.

WARNING: When using the 65-2301RKSS, you must follow the instructions and warnings in this

manual to assure proper and safe operation of the 65-2301RKSS and to minimize the

risk of personal injury. Be sure to maintain and periodically calibrate the 65-2301RKSS

as described in this manual.

Table 1: Specifications

Target Gas 65-2301RKSS-ASH3: Arsine (AsH3)

65-2301RKSS-CL2: Chlorine (Cl2)

65-2301RKSSCL-10: Chlorine (Cl2)

65-2301RKSS-HCN: Hydrogen Cyanide (HCN)

65-2301RKSS-NH3: Ammonia (NH3)

65-2301RKSS-SO2: Sulphur Dioxide (SO2)

65-2301RKSS-PH3: Phosphine (PH3)

Sampling Method Diffusion

Detection Range AsH3: 0 - 1.50 ppm

Cl2: 0 - 3.00 ppm

Cl2: 0 - 10.0 ppm

HCN: 0 - 15.0 ppm

NH3: 0 - 75.0 ppm

SO2: 0 - 6.00 ppm

PH3: 0 - 1.00 ppm

Accuracy ± 10% of reading or ± 5% of full scale (whichever is greater)

Response Time • Cl2and NH3: T90 in 90 seconds

• All others: T90 in 45 seconds

Operating Temperature &

Humidity • 14°F to 104°F (-10°C to 40°C)

• 20% to 90% Relative Humidity

6 • 65-2301RKSS Toxic Detector

Description

This section describes the components of the 65-2301RKSS. The 65-2301RKSS includes the 65-2300RK

toxic detector and a junction box. Figure 1 below shows the components of the 65-2301RKSS.

Figure 1: 65-2301RKSS Component Location

65-2300RK Toxic Detector

The 65-2300RK toxic detector consists of the detector housing body, detector housing cap,

splashguard, cap gasket, and the plug-in sensor.

Figure 2: 65-2300RK Toxic Detector Component Location

3/4 NPT Conduit Hub

Stainless Steel

Junction Box

Toxic Detector

Locking Set Screw

Text Oriented

This Way

Splash Guard

(removable)

Sensor

(different for each detector type)

Detector Housing

Cap

Cap Gasket

Detector Housing Body

(different for each detector type)

65-2301RKSS Toxic Detector • 7

Detector Housing Body

The detector housing body protects the electronic components within the housing. Use the mounting

threads at the top of the housing to screw the toxic detector into a 3/4 NPT hub. Two wires extend

from the top of the detector housing body. Use these wires to connect the toxic detector to a controller.

One of the wires is black and one of the wires is color coded depending on the detector type. See

Figure 4 on page 9 for the color code assignments.

The housing body includes a 12 position connector at the bottom of the housing body. The plug-in

sensor mates to this connector. A pre-amplifier located between the connector and the two

interconnect wires conditions the sensor’s signal before the signal reaches the controller.

Housing Cap, Cap Gasket, & Splashguard

The housing cap screws onto the detector housing. It retains the sensor and protects it from damage. A

removable splashguard is screwed onto the detector cap to protect the sensor from impact damage,

direct water spray, and splashing. Unscrew the detector cap to access the sensor for maintenance or

replacement. A cap gasket seals the interface between the housing and cap.

Plug-in Sensor

The plug-in sensor is secured in the detector assembly by the housing cap. There is a different sensor

for each target gas. Through a series of chemical and electrical reactions, the sensor produces an

electrical output that corresponds to the detection range of the sensor.

Junction Box

The stainless steel, corrosion resistant junction box allows you to install the detector at a mounting site

that is remote from a controller, and it protects the detector wiring connections. Two conduit hubs

allow you to mount the detector to the junction box and connect the wiring from the detector to a

controller. An O-ring seals the interface between the junction box cover and the junction box base.

The terminal block within the junction box facilitates the wiring process. A cover on the front of the

junction box allows access to the interior of the junction box. A locking set screw on the junction box

cover allows you to secure the junction box cover and prevent it from being removed.

Installation

This section describes procedures to mount the toxic detector in the monitoring environment and wire

the detector to a controller.

Mounting the Toxic Detector

1. Select a mounting site that is representative of the monitoring environment. Consider the

following when you select the mounting site.

• Select a site where the detector is not likely to be bumped or disturbed. Make sure there is

sufficient room to perform start-up, maintenance, and calibration procedures.

• Select a site where the target gas is likely to be found first.

NOTE: If your application does not require a specific mounting site, mount the detector at

approximately breathing level.

8 • 65-2301RKSS Toxic Detector

Figure 3: Outline & Mounting Dimensions, 65-2301RKSS

2. At the mounting site you select, hang or mount the junction box with the detector facing down

(see Figure 3).

CAUTION: Mount the toxic detector with the detector facing down (see Figure 3.)

Wiring the Toxic Detector to a Controller

WARNING: Always verify that power to the controller is OFF before you make wiring connections.

1. Turn off the controller.

2. Turn off or unplug power to the controller.

3. Remove the junction box cover.

4. Guide a two-conductor, shielded cable or two wires in conduit through the unused conduit hub of

the junction box.

2.40

3.15

3.66

Text Oriented

ThisWay

Junction

Box

Toxic

Detector

.20 Dia. x .45

Slot, 2X

3/4 NPT

Conduit Hub

10.00 Max

1.10

65-2301RKSS Toxic Detector • 9

5. Connect the two wires to the detector using the terminal block.

CAUTION: If using shielded cable, leave the drain wire insulated and disconnected at the detector. You will

connect the opposite end of the cable’s drain wire at the controller.

6. Secure the junction box cover to the junction box.

7. Route the cable or wires leading from the toxic detector through one of the conduit hubs at the

controller housing. Use appropriate conduit fittings and construction technique for the

environmental rating of the controller. RKI controllers are typically rated NEMA 4X.

CAUTION: Do not route power and detector wiring through the same conduit hub. The power cable may

disrupt the transmission of the detector signal to the controller.

8. Connect the wires to the applicable controller terminal strip. See the controller operator’s manual

and the controller’s detector head specification sheet for the 65-2301RKSS detector.

Figure 4: Wiring the Toxic Detector to a Controller

9. If using shielded cable, connect the cable’s drain wire to an available chassis ground at the

controller. RKI controllers typically have a ground stud that is a convenient grounding location.

10. Reinstall the junction box cover.

(+) See Table

Controller Housing

Controller Detector Terminals,

Typical Designations

Gas TypeTable

AsH3 brown

CL2 yellow

CL-10 yellow

HCN white

NH3 red

PH3 green

SO2 blue

Gas Type + Wire

0-10ppmCl2

0-3ppmCl2

Shielded Cable

ESM-01 Detector

Black (S)

Terminal Strip

10 • 65-2301RKSS Toxic Detector

Start Up

This section describes procedures to start up the toxic detector and place the detector into normal

operation.

Introducing Incoming Power

1. Complete the installation procedures described earlier in this manual.

2. Verify that the power wiring to the controller is correct and secure. Refer to the controller

operator’s manual.

3. Turn on or plug in the incoming power, then turn on the controller.

4. Verify that the controller is on and operating properly. Refer to the controller operator’s manual.

CAUTION: Allow the detector to warm up for 5 minutes before you continue with the next section, “Setting

the Zero Reading”.

Setting the Zero (Fresh Air) Reading

CAUTION: If you suspect the presence of the target gas in the monitoring environment, use the calibration kit

and a zero air calibration cylinder to introduce “fresh air” to the toxic detector and verify an

accurate zero setting. See “Calibration” on page 14 for instructions to introduce zero air to the

detector.

1. Verify that the detector is in a fresh air environment (environment known to be free of toxic and

combustible gases, and of normal oxygen content, 20.9%).

2. Verify a reading of 0 ppm at the controller.

If the display reading is 0 ppm, start up is complete. The toxic detector is in normal operation.

If the display reading is not 0 ppm, continue with step 3.

3. Perform a zero (fresh air) adjustment operation at the controller. See the controller operator’s

manual for instructions.

Maintenance

This section describes maintenance procedures. It includes preventive maintenance, troubleshooting,

and component replacement procedures.

Preventive Maintenance

This section describes a preventive maintenance schedule to ensure the optimum performance of the

toxic detector. It includes daily and quarterly procedures.

Daily

Verify a display reading of 0 ppm at the controller. Investigate significant changes in the display

reading.

Quarterly

Calibrate the toxic detector as described in “Calibration” on page 14.

65-2301RKSS Toxic Detector • 11

Troubleshooting

The troubleshooting guide describes symptoms, probable causes, and recommended action for

problems you may encounter with the toxic detector.

NOTE: This troubleshooting guide describes detector problems only. See the controller operator’s

manual for problems you may encounter with the controller.

Fail Condition

Symptoms

• The controller indicates a fail condition.

Probable causes

• The detector wiring is disconnected or misconnected.

• The plug-in sensor is not properly plugged into the socket in the detector housing body.

• The detector’s zero reading is low enough to cause a fail condition.

• The detector is malfunctioning.

Recommended action

• Verify that the detector wiring is correct and secure.

• Confirm that the plug-in sensor is installed properly.

• Perform a zero (fresh air) adjustment. A full calibration is recommended.

• If the fail condition continues, replace the plug-in sensor as described later in this section.

• If the fail condition continues, contact RKI for further instruction.

Slow or No Response/Difficult or Unable to Calibrate

Symptoms

• Unable to accurately set the zero or response reading during the calibration procedure.

• The detector requires frequent calibration.

NOTE: Under “normal” circumstances, the detector requires calibration once every three months.

Some applications may require a more frequent calibration schedule. See “Calibration

Frequency” on page 13 for a discussion of the calibration frequency.

Probable causes

• The calibration cylinder is low, out-dated, or defective.

• The incorrect calibration cup or regulator is being used.

• The plug-in sensor face is blocked with dirt or some other particulate contamination.

• The detector is malfunctioning.

Recommended action

1. Verify that the calibration cylinder contains an adequate supply of a fresh test sample.

2. Confirm that you are using the correct calibration cup and regulator for your detector type. See

Table 2 on page 14 for a list of the required calibration cups and regulators.

3. Check the plug-in sensor face and remove any particulate contamination if necessary.

12 • 65-2301RKSS Toxic Detector

4. If the calibration/response difficulties continue, replace the plug-in sensor as described later in

this section.

5. If the calibration/response difficulties continue, contact RKI Instruments, Inc. for further

instruction.

Replacing Components of the Toxic Detector

This section includes a procedure to replace the plug-in toxic sensor and one to replace the entire toxic

detector assembly. In most cases, it is not necessary to replace the entire detector assembly.

Replacing The Plug-in Toxic Sensor

CAUTION: The plug-in sensor contains electrolyte which is a dilute acid. Do not disassemble the sensor when

replacing it with a new one. If sensor electrolyte comes in contact with your skin, wash affected

area thoroughly with soap and water.

1. Turn off the controller.

2. Turn off or unplug power to the controller.

3. Unscrew the detector housing cap with the splashguard from the detector housing body. Make

sure not to lose the cap gasket.

4. Unplug and remove the toxic sensor.

5. Remove the black plug from the top of the replacement sensor.

6. Carefully plug the replacement sensor into the connector that is located in the detector housing

body.

WARNING: You must replace the plug-in sensor with the same type of sensor that is installed. A

detector cannot be converted from one type of detector to another by using a different

plug-in sensor. For example, if you are replacing a Cl2sensor, you must replace it with a

Cl2sensor.

7. Make sure the cap gasket is in place and screw the detector housing cap with the splashguard back

onto the detector housing body.

8. Turn on power to the controller.

9. Turn on the controller.

CAUTION: Allow the replacement sensor to warm up for 5 minutes before you continue with the next step.

10. Calibrate the detector as described in “Calibration” on page 14.

Replacing the Toxic Detector

NOTE: In most cases, it is only necessary to replace the plug-in sensor.

1. Turn off the controller.

2. Turn off or unplug incoming power to the controller.

3. Remove the junction box cover.

4. Disconnect the detector leads from the terminal block in the junction box. Note the position of the

color-coded leads as you remove them.

65-2301RKSS Toxic Detector • 13

5. Unscrew the detector from the controller conduit hub or junction box conduit hub.

6. Guide the detector leads of the replacement detector through the junction box conduit hub, then

screw the mounting threads of the detector into the hub. If necessary for environmental

conditions, apply thread sealant or Teflon tape to the hub and/or detector threads to seal them.

7. Connect the detector leads to the terminal block the same way the old detector was wired (see

Figure 4 on page 9). See the controller operator’s manual and the controller’s detector head

specification sheet for the 65-2301RKSS to verify the connections to the controller are correct.

8. Reinstall the junction box cover.

9. Turn on or plug in power to the controller.

10. Turn on the controller.

CAUTION: Allow the replacement detector to warm up for 5 minutes before you continue with the next step.

11. Calibrate the replacement detector as described in “Calibration” on page 14.

Calibration Frequency

Although there is no particular calibration frequency that is correct for all applications, a calibration

frequency of every 3 months is adequate for most toxic detector applications. Unless experience in a

particular application dictates otherwise, RKI Instruments, Inc. recommends a calibration frequency of

every 3 months for the toxic detector.

If an application is not very demanding, for example detection in a clean, temperature controlled

environment where toxic gas is not normally present, and calibration adjustments are minimal at

calibration, then a calibration frequency of every 6 months is adequate.

If an application is very demanding, for example if the environment is not well controlled or if toxic

gas is often present, then more frequent calibration than every 3 months may be necessary.

14 • 65-2301RKSS Toxic Detector

Calibration

This section describes how to calibrate the toxic detector. It includes procedures to prepare for

calibration, set the fresh air reading, set the response reading, and return to normal operation. It

describes calibration using a calibration kit that includes a calibration cup, calibration gas, sample

tubing, and a fixed flow regulator with an on/off knob. The required sample flow rate and calibration

cup depend on the detector being calibrated. Table 2 below lists the required calibration cups and

regulators for the various toxic detectors.

WARNING: RKI Instruments, Inc. recommends that you dedicate a regulator for use with chlorine

(Cl2) gas and that you do not use that dedicated regulator for any other gases,

particularly hydrogen sulfide (H2S).

WARNING: Not using the recommended calibration cup, sample flowrate, and specified flow

direction (for 81-1138RK calibration cup only) will result in an inaccurate calibration.

Make sure to use the calibration cup and sample flow rate listed in Table 2 for your

target gas when performing a calibration. Also make sure to connect the sample tubing

to the calibration cup port that results in the specified flow direction for the 81-1138RK

calibration cup.

Preparing for Calibration

1. Unscrew the splashguard from the detector housing cap. Make sure the cap remains securely

screwed onto the housing body.

2. Push the calibration cup onto the plug-in sensor that sticks through the housing cap. The

calibration cup seals to the sensor with an O-ring.

3. Screw the regulator into the zero air calibration cylinder.

4. Use the sample tubing to connect the regulator to the calibration cup. Make sure to connect the

tube to the inlet side of the calibration cup if using the 81-1138RK calibration cup which is marked

on the outside bottom to show the required flow direction through the cup.

Table 2: Required Calibration Cups and Flow Rates

Detector Type Required

Calibration Cup

Required Regulator/

Flowrate for Calibration

Gas

Flow Direction

Specified on

Calibration Cup

Arsine (AsH3) 81-1138RK 81-1051RK, 0.5 LPM (liters

per minute) Yes

Chlorine (Cl2), 0 - 3.00 ppm

and 0 - 10.0 ppm 81-1138RK-CL2 81-1051RK, 0.5 LPM No

Hydrogen Cyanide (HCN) 81-1138RK 81-1051RK, 0.5 LPM Yes

Ammonia (NH3) 81-1138RK-NH3 81-1051RK-25, 0.25 LPM No

Phosphine (PH3) 81-1138RK 81-1051RK, 0.5 LPM Yes

Sulphur Dioxide (SO2) 81-1138RK 81-1051RK, 0.5 LPM Yes

65-2301RKSS Toxic Detector • 15

NOTE: If you can verify that the toxic detector is in a fresh air environment, you do not need to apply

zero air to the detector before adjusting the fresh air reading.

5. Put the controller into its calibration program. See the controller operator’s manual for

instructions to enter the calibration program.

Setting the Zero (Fresh Air) Reading

1. Follow the instructions in the controller operator’s manual for setting the zero reading.

2. When the instructions call for applying zero air to the detector, turn the regulator’s on/off knob

counterclockwise to open it. Gas will begin to flow.

3. Allow the gas to flow for two minutes.

4. Set the fresh air reading according to the controller operator’s manual.

5. Turn the regulator’s on/off knob clockwise to close it.

6. Unscrew the regulator from the zero air calibration cylinder. Leave the sample tubing connected to

the regulator and the calibration cup.

NOTE: Depending on the size of your zero air cylinder, it is possible that you will have a different

regulator for the zero air cylinder and toxic gas cylinder. If necessary to fit the calibration

toxic gas cylinder, change the regulator.

Setting the Response Reading (Span)

1. Screw the regulator into the calibration gas cylinder.

2. Follow the directions in the controller operator’s manual for setting the response (span) reading.

3. When the directions call for exposing the detector to gas, turn the regulator’s on/off knob

counterclockwise to open it. Gas will begin to flow.

4. Allow the gas to flow to the detector for 2 minutes.

5. Set the response reading according to the controller operator’s manual.

6. After setting the response reading, turn the regulator’s on/off knob clockwise to turn it off.

7. Unscrew the regulator from the cylinder and gently pull the calibration cup off of the plug-in

sensor.

NOTE: For convenience, leave the regulator and calibration cup connected by the sample tubing.

8. Allow about 45 seconds for the gas reading to decrease below the alarm points and then return the

controller to normal operation.

NOTE: If you do not allow the gas reading to decrease below the alarm points, then unwanted

alarms may occur.

9. Verify that the controller display reading decreases and stabilizes at 0 ppm.

10. Store the components of the calibration kit in a safe and convenient place.

16 • 65-2301RKSS Toxic Detector

Parts List

Table 3 lists replacement parts and accessories for the toxic detector.

Table 3: Parts List

Part Number Description

06-1283RK Calibration kit sample tubing, 3 foot Teflon w/flexible tubing on ends

07-0125RK Detector housing cap gasket

07-7151RK O-ring for junction box

10-5153RK Lid locking set screw for junction box

18-0416RK-11 Junction box with cover, stainless steel

65-2300RK-ASH3 Replacement detector assembly, AsH3(includes plug-in sensor)

65-2300RK-CL2 Replacement detector assembly, Cl2, 0 - 3.00 ppm range (includes plug-in sensor)

65-2300RK-CL-10 Replacement detector assembly, Cl2 , 0 - 10.0 ppm range (includes plug-in sensor)

65-2300RK-HCN Replacement detector assembly, HCN (includes plug-in sensor)

65-2300RK-NH3 Replacement detector assembly, NH3 (includes plug-in sensor)

65-2300RK-PH3 Replacement detector assembly, PH3(includes plug-in sensor)

65-2300RK-SO2 Replacement detector assembly, SO2(includes plug-in sensor)

71-0273RK 65-2301RKSS Operator’s Manual (this document)

81-0076RK Zero air calibration cylinder, 17 liter

81-0076RK-01 Zero air calibration cylinder, 34 liter steel

81-0076RK-03 Zero air calibration cylinder, 103 liter

81-0170RK-02 Calibration cylinder, 5 ppm SO2in nitrogen, 58 liter

81-0170RK-04 Calibration cylinder, 5 ppm SO2in nitrogen, 34 liter aluminum

81-0175RK-02 Calibration cylinder, 10 ppm NH3in nitrogen, 58 liter

81-0175RK-04 Calibration cylinder, 10 ppm NH3in nitrogen, 34 liter aluminum

81-0185RK-02 Calibration cylinder, 0.5 ppm PH3 in nitrogen, 58 liter, used to calibrate PH3and

AsH3detectors, see conversion factor on AsH3plug-in sensors

81-0185RK-04 Calibration cylinder, 0.5 ppm PH3 in nitrogen, 34 liter aluminum, used to calibrate

PH3and AsH3detectors, see conversion factor on AsH3plug-in sensors

81-0190RK-02 Calibration cylinder, 5 ppm Cl2in nitrogen, 58 liter

81-0190RK-04 Calibration cylinder, 5 ppm Cl2in nitrogen, 34 liter aluminum

81-0192RK-02 Calibration cylinder, 2 ppm Cl2in nitrogen, 58 liter

65-2301RKSS Toxic Detector • 17

81-0192RK-04 Calibration cylinder, 2 ppm Cl2in nitrogen, 34 liter aluminum

81-0196RK-02 Calibration cylinder, 10 ppm HCN in nitrogen, 58 liter

81-0196RK-04 Calibration cylinder, 10 ppm HCN in nitrogen, 34 liter aluminum

81-1050RK Regulator with gauge and knob, 0.5 LPM, for 17 liter and 34 liter steel calibration

cylinders (cylinders with external threads), used for 34 liter zero air cylinder only

81-1051RK Regulator with gauge and knob, 0.5 LPM, for 34 liter aluminum, 58 liter, and 103

liter calibration cylinders (cylinders with internal threads)

81-1051RK-25 Regulator with gauge and knob, 0.25 LPM, for 34 liter aluminum, 58 liter, and 103

liter calibration cylinders (used to calibrate NH3toxic detector only)

81-1138RK Calibration cup, general (SO2), for ESM-01, use 0.5 LPM flow

81-1138RK-CL2 Calibration cup, for ESM-01 Cl2, use 0.5 LPM flow

81-1138RK-NH3 Calibration cup, for ESM-01 NH3, use 0.25 LPM flow

81-F503RK Calibration kit, includes regulator, calibration cup, and a 58 liter 10 ppm NH3in
