RMB EV Multi-Point AWD User manual

Mutlti Point AWD / Kodiak
Table of Contents
Technical Information---------------------------------------1
Warning Statement------------------------------------------2
Read Before Riding-----------------------------------------3
List of Parts----------------------------------------------------4
Front Bar-------------------------------------------------------6
Tool Kit----------------------------------------------------------7
Assembling The Multi-Point AWD / Multi-Point AWD
KODIAK--------------------------------------------------------8

Disassembling The Multi-Point AWD / Multi-Point
AWD KODIAK-------------------------------------------------15
Charging The Batteries-------------------------------------16
Riding The Multi-Point AWD / Multi-Point AWD
KODIAK---------------------------------------------------------17
Folding The Multi-Point AWD / Multi-Point AWD
KODIAK---------------------------------------------------------21
Battery access------------------------------------------------23
Maintenance--------------------------------------------------25
Wiring Diagram-----------------------------------------------26
Trouble Shooting Guide------------------------------------27
Warranty--------------------------------------------------------29
Instructions for optional attachments--------------------34
1
T
Te ec ch hn ni ic ca al l I In nf fo or rm ma at ti io on n
Multi-Point AWD / Multi-Point AWD KODIAK
Model No. Multi-Point AWD / Multi-Point
AWD KODIAK
Product size 54 L x 29 W x 44 H inch
Motor power
Front: 500w / 800w 48v hub
motor
Rear: 500w / 800w 48v
brushless differential motor
Battery capacity 48v 22Ah Li battery (optional
SLA 13.2AH for plane travel)
Charger 110V-240V, UL approved
Charging time 4-6 hours
Max. speed Up to 16 MPH ( 26 km/h) /
24 MPH ( 39 km/h)
Single charge up to 35 / 31 miles
Max capacity 350 LBS (139kg)
Net weight 151 LBS (69 kg) / 162 LBS
(74 kg)

2
W
Wa ar rn ni in ng g S St ta at te em me en nt t
Multi-Point AWD / Multi-Point AWD KODIAK
3
R
Re ea ad d B Be ef fo or re e R Ri id di in ng g
Multi-Point AWD / Multi-Point AWD KODIAK
WARNING
THE RMB Multi-Point AWD / Multi-Point AWD KODIAK IS
NOT A TOY AND SHOULD NOT BE OPERATED BY
ANYONE UNDER 12 YEARS OLD.
Safety Instructions:
(Please take note of the following before each ride)
 The maximum weight capacity is 350 lbs.
 Only one person at a time should ride.
 Always wear protective gear including knee and elbow pads and
an approved safety helmet when riding the Multi-Point AWD /
Multi-Point AWD KODIAK.
 Before riding, be sure to check that all pivot points, locking
buttons, quick releases, and latches are secured properly.
 The power switch lock must be in the “off” position when the
Multi-Point AWD / Multi-Point AWD KODIAK is being charged.
 Do not use the Multi-Point AWD / Multi-Point AWD KODIAK
when it is raining.
 Do not place the battery near heat or fire.
 Do not expose the charger to water, moisture, or vibration.
 Check if batteries are properly charged and installed.
 Check if all tires are properly inflated.
 Always ride on dry paved surfaces. Be Safe-even though the
Multi Point AWD can traverse over rough terrain, gravel, wet,
extreme incline, and uneven surfaces may be a hazard.

4
L
Li is st t o of f P Pa ar rt ts s
Multi-Point AWD / Multi-Point AWD KODIAK
5
L
Li is st t o of f P Pa ar rt ts s
Multi-Point AWD / Multi-Point AWD KODIAK
1 Multi-function Instrument (Headlight/Ign)
2 Foldable structure
3 Basket
4 Optional wire basket bracket/lamp bracelet
5 Connecting tube
6 Seat
7 Ring-pull steel pin
8 Seat post
9 Basket
10 Rear motor
11 Rear shock absorption
12 Rear fender
13 Rear wheel
14 Battery
15 Front frame Kick stand
16 Dual-purpose QR lock bolt
17 Front fender
18 Front motor
19 Front wheel

6
F
Fr ro on nt t B Ba ar r
Multi-Point AWD / Multi-Point AWD KODIAK
1 Brake lever 9 Front/Rear drive switch
2 LED lights switch 10 Horn button
3 Parking brake 11 Dual drive (AWD) switch
4 Headlight/ign
5 Key switch
6 Dual USB port
7 Forward/reverse switch
8 Throttle
7
T
To oo ol l K Ki it t
Multi-Point AWD / Multi-Point AWD KODIAK
1 Screwdriver
2 Allen wrench （2.5mm）
3 Allen wrench （3mm）
4 Allen wrench （5mm）
5 Allen wrench （6mm）
6 Wrench (8 x 10mm)
7 Wrench (16 x 18mm)
8 Wrench (16 x 18mm)
9 charger

8
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
1. Unpack the Multi-Point AWD / Multi-Point
AWD KODIAK carefully so that you do not
misplace any of the parts.
2. Place the Multi-Point AWD / Multi-Point AWD
KODIAK on a flat, level surface.
3. Take out the kickstand and spring. Put the
kickstand on the suitable position on front half
of the scooter. Fasten the kickstand on front
half of the scooter with the provided screws.
9
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
Open the spring with the screwdriver or other
tool and then connect the spring to kickstand.
4. Flip the spring-loaded kickstand down to form
a tripod. Stand the front half of the scooter
upright. Insert the steering column into the top
of the folding structure to form a complete
steering assembly and insert the bottom of
the folding structure into the steering tube.

10
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
5. Once the handlebar assembly is inserted into
the steering tube, open the folding structure to
adjust the steering column and then tighten.
6. Ensure that the handlebar is facing front, the
brake on the left and the throttle on the
right, tighten using the enclosed 5mm wrench.
Lift lever to tighten and then twist lock ring.
11
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
*Note: The folding structure lever is intentionally
off center to allow the handlebars to fold to the
side. Be sure that the pivot hinge is facing the
throttle side. Handlebar will fold to the right of
scooter.
NOTE: To adjust handlebar height, loosen the
clamp on the steering column, adjust the
handlebars to the desired height, and then
retighten the clamp.

12
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
7. With the front half completed, place front and
rear halves of the Multi-Point AWD / Multi-
Point AWD KODIAK on a flat, level surface.
Position each half close enough so they are
lined up. Extend the kick stand. Remove the
bolt from the female part (B). Insert the male
part (A) into the female part (B), and then
tighten the bolt provided. (Tip: once
connected, gently lift up and down by the
curved support while tightening the bolt to
achieve best results)
13
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
8. With key in the off position, make sure you
connect the power line to the battery after
assembly and likewise, be sure to disconnect the
power line from the battery prior to disassembly.
9. The power connector wires are fitted with male
to female plugs that have an alignment notch.
Take note when plugging in.

14
A
As ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -
P
Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
10. Plug the additional power connecting wires
into the corresponding socket on the battery box.
15
D
Di is sa as ss se em mb bl li in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / /
M
Mu ul lt ti i- -P Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
1. Turn off power.
2. Unplug the power/control wires that connect to
the front half of the scooter to the rear half.
3. Reverse assembly steps and gently separate.
NOTE: In the rare instance the Quick Release
Mechanism becomes too tight to release easily,
turn the special screw upside down and screw in
using the outer threads. This will apply pressure
to release the mechanism. If you live in a high
moisture climate, apply a thin grease to the Quick
release mechanism to protect it from corrosion.

16
C
Ch ha ar rg gi in ng g T Th he e B Ba at tt te er ri ie es s
Multi-Point AWD / Multi-Point AWD KODIAK
●Before you ride the Multi-Point AWD / Multi-
Point AWD KODIAK for the first time you must
charge the batteries for 4-6 hours or until the
charger light turns green using only the supplied
charger.
●To charge the batteries, plug the charger into
the charger socket located on the front left side of
the floor deck. Then plug the charger into a wall
outlet. Red light on charger indicates charging,
green light indicates charged.
Warning: Never charge scooter longer than
10 hours. If the charger does not turn green
by 10 hours or for SLA battery option, you
smell a Sulphur odor after a long charge there
is a problem and contact the dealer for
instructions.
17
R
Ri id di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
●Once you have completed the initial charge you
are ready to ride. Remember, this is not a toy.
The Multi-Point AWD / Multi-Point AWD KODIAK
can reach speeds up to16mph-24mph depending
on the model, terrain, and the weight of the rider.
You must wear a helmet and protective pads. Be
aware of all local laws and ordinances that
govern and/or restrict the use of powered
scooters. The laws and ordinances vary greatly
from municipality to municipality. It is your
responsibility to know and abide by your local
restrictions.
●To ride, insert the key into the key switch and
turn the key in clockwise direction till the first click.
The battery gauge will be illuminated indicating
that the battery is in operation. Turn the key to
the second click in clockwise direction for
headlight.

18
R
Ri id di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
●Hold onto the front bar with both hands. Your
left fingers will control the front brakes and your
Right foot will control the rear brakes. Your right
hand will control the throttle. As you twist the
throttle towards yourself, the speed will increase.
Release the throttle and apply the brake to stop.
You will control the speed of the scooter by using
both the throttle and the brake. When the brakes
are used, the power to the throttle is cut off.
NOTE 1: WARNING: Never try stunts. Always
maintain a safe speed.
NOTE 2: When scooter is parked, please remove
the key, this will avoid anyone from accidentally
turning the throttle causing the scooter to speed
forward. Failure to do this could lead to an
accident.
NOTE 3: If you need to stop in an emergency or
kill power quickly, you can turn the key off.
NOTE 4:When you use reverse, the scooter must
be stopped, and then push the “F-R” switch to “R”,
the horn will send out a noise, then GENTLY turn
the throttle to back up. Warning, do not twist
throttle to full power when in reverse.
19
R
Ri id di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
When finishing reverse, push the switch back to
“F”. (forward/reverse switch)
NOTE 5:
The Maximum output of dual port USB
is 5V, 2A which will charge all phones and tablets.

20
R
Ri id di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
NOTE 6: The Multi-Point AWD / Multi-Point AWD
KODIAK provides the driver the flexibility to drive
in 3 different modes; Front wheel drive, Rear
wheel drive, or All Wheel Drive. (1) Front wheel
drive- Press the “DD” Dual Drive (fig. 2) button
so that it is in the “OUT” or off position and press
“FD” (front drive) (fig.1) button on the left side of
the handlebar. (2) Rear Wheel Drive- Press the
“DD” (fig. 2) button so that it is in the “OUT” or off
position and press “RD” (rear drive) (fig. 1) button
on the left side of the handlebar. (this is the most
economical mode to drive in) (3) All Wheel
Drive- Press the “DD” (fig. 2) button so that it is
in the “IN” or on position. (it does not matter what
position the “FD” or “RD” buttons are in when in
AWD mode.
Note: If the “FD RD” button is on “ ”
position, the Multi Point AWD is not
connected to any motors and will not operate.
21
F
Fo ol ld di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
1. Turn off the key switch
2. Unlock the clamp safety ring by twisting to the
left.
3. Pull clamp lever down to release.

22
F
Fo ol ld di in ng g T Th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / / M Mu ul lt ti i- -P Po oi in nt t
A
AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
4. Tilt the handlebar in the direction of its hinge.
5. Carefully lower the handlebar assembly.
23
B
Ba at tt te er ry y a ac cc ce es ss s f fo or r t th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / /
M
Mu ul lt ti i- -P Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
G
Ge en nt tl ly y p pe ee el l b ba ac ck k t th he e e ed dg ge es s o of f t th he e r ru ub bb be er r
f
fl lo oo or r m ma at t t to o a ac cc ce es ss s t th he e f fo ou ur r s sc cr re ew ws s t th ha at t
s
se ec cu ur re e t th he e b ba at tt te er ry y a ac cc ce es ss s p pa an ne el l. . U Un ns sc cr re ew w
t
th he e f fo ou ur r s sc cr re ew w a an nd d l li if ft t t th he e a ac cc ce es ss s p pa an ne el l u up p. .
*
*n no ot te e: : d do o n no ot t t tr ry y t to o u un ns sc cr re ew w t th he e p pl la as st ti ic c
s
sc cr re ew ws s t th ha at t h ho ol ld d d do ow wn n t th he e r ru ub bb be er r m ma at t. .

24
B
Ba at tt te er ry y a ac cc ce es ss s f fo or r t th he e M Mu ul lt ti i- -P Po oi in nt t A AW WD D / /
M
Mu ul lt ti i- -P Po oi in nt t A AW WD D K KO OD DI IA AK K
Multi-Point AWD / Multi-Point AWD KODIAK
U
Un np pl lu ug g t th he e p po ow we er r l li in ne e f fr ro om m t th he e b ba at tt te er ry y
p
pa ac ck k a as s s sh ho ow wn n. .
L
Li if ft t b ba at tt te er ry y p pa ac ck k u us si in ng g t th he e p pr ro ov vi id de ed d h ha an nd dl le e
25
M
Ma ai in nt te en na an nc ce e
Multi-Point AWD / Multi-Point AWD KODIAK
Battery: (for professional use only)
The RMB Multi-Point AWD / Multi-Point AWD
KODIAK is powered by 48v 22ah lithium battery.
We also offer a 48v 13.2ah SLA battery for those
who need to take their Multi-Point AWD / Multi-
Point AWD KODIAK on planes, ships etc. that
forbid lithium. The chargers for Lithium and SLA
are different but have the same charge ends for
convenience to swap battery types. You must be
sure to use the proper charger for the type of
batteries you have installed or you may
destroy your batteries! Other than recharging,
these batteries need no maintenance. Our lithium
batteries are protected with a BMS (battery
management system) built into the battery pack
to protect it from overcharging and undercharging.
For best practice, keep the batteries away from
heat and try to keep your charge between 30-
90% during use. Lithium can form a memory

26
M
Ma ai in nt te en na an nc ce e
Multi-Point AWD / Multi-Point AWD KODIAK
so approximately once a month, you can drain
the battery to almost fully discharged and then
fully recharge. For extended storage, leave the
pack between 40-50% charged. For SLA
batteries there is no memory and it is best to
keep them fully charged whenever possible and
charge the battery after each use. For SLA, you
must also charge your Multi-Point AWD / Multi-
Point AWD KODIAK if it has not been used for 30
days or more. If you need to replace the battery
pack, it is located inside the battery compartment
under the footboard. To get to the battery pack,
remove the compartment cover by loosening the
front screws and lifting the floor board. To remove
the batteries, disconnect the connectors between
the battery pack and the scooter. Replace the
battery pack with a new one and reconnect the
connector and charge the new battery pack as
previously described.
27
M
Ma ai in nt te en na an nc ce e
Multi-Point AWD / Multi-Point AWD KODIAK
Chassis: (every 1-3 months)
Depending on use:
(1) It is recommended to inspect and if
necessary, tighten any loose nuts and
bolts.
(2) Inspect electrical connections. For moist
climates, apply electrical grease to all
electrical connectors to avoid corrosion.
(3) Apply thin grease to the male and female
mechanism that connects the front half of
the scooter to the rear half.
(4) Check tire pressure (low pressure will
affect speed and range)

28
W
Wi ir ri in ng g D Di ia ag gr ra am m
Multi-Point AWD / Multi-Point AWD KODIAK
29
T
Tr ro ou ub bl le e S Sh ho oo ot ti in ng g G Gu ui id de e
Multi-Point AWD / Multi-Point AWD KODIAK
Problem Cause Solution
The power light
on the
instrument
does not
illuminate when
the Multi-Point
AWD / Multi-
Point AWD
KODIAK is on.
1. Battery is
discharged.
2. Loose
connection
inside Multi-
Point AWD /
Multi-Point AWD
KODIAK.
3. Fuse is blown.
4. The
instrument is
defective.
1. Recharge your
Multi-Point AWD /
Multi-Point AWD
KODIAK.
2. Remove the
screws that hol
d the
battery compartment
cover and raise the
cover. Visually
inspect all wire
connections
making
sure there are no
loose wires,
reconnecting those
that are.
3. Replace the fuse.
4. Replace the
instrume
nt.
The power
indicator on the
instrument
illuminates but
Multi-Point
AWD / Multi-
Point AWD
KODIAK still
does not work.
1. The throttle
handle is not
operating
properly.
1. Replace the
throttle handle. Call
Customer Service to
order a new throttle

30
T
Tr ro ou ub bl le e S Sh ho oo ot ti in ng g G Gu ui id de e
Multi-Point AWD / Multi-Point AWD KODIAK
When the brake
lever is
squeezed the
Multi-Point
AWD / Multi-
Point AWD
KODIAK does
not stop.
1. The brakes
are not adjusted
properly.
1. Adjust the brake
by loosening the bolt
on the rear brake
wheel, pull the cable
and retighten the
bolt.
Scooter is
losing speed.
1. Low battery
2. Battery is
defective.
3. Low tire
pressure.
1. Recharge your
battery for 4~6 hours.
2. Replace battery.
Call Customer
Service to order a
new battery.
3. air tires up to
correct pressure.
31
W
Wa ar rr ra an nt ty y
Multi-Point AWD / Multi-Point AWD KODIAK
The Limited Warranty does not cover or apply to
the following: Normal wear and tear; any damage,
failure and/or loss caused by accident, misuse,
neglect, abuse and/or failure to follow instructions
or warnings as stated on the product or in the
applicable owner’s manual or other printed
materials provided with the product; damage,
failure and/or loss caused by the use of the
product in any other manner for which such
products were not specifically designed.
RMB EV warrants the Multi-Point AWD / Multi-
Point AWD KODIAK for six (6) months according
to the following terms. Batteries and tires are
warranted for three (3) months. This warranty
extends to the original retail purchaser only and
commences on the date of the original retail
purchase. Any part of the RMB EV product
manufactured or supplied by RMB EV and found
in the reasonable judgment of RMB EV to be
defective in material or workmanship will be
repaired or replaced by an authorized RMB EV
service dealer without charge for parts or labor.
RMB EV is responsible for the expense of
delivering the warranty replacement parts.
However, if the customer chooses not to replace

32
W
Wa ar rr ra an nt ty y
Multi-Point AWD / Multi-Point AWD KODIAK
the parts, the expense of delivering the Multi-
Point AWD / Multi-Point AWD KODIAK to the
factory / authorized service dealer for
warranty work or the expense of returning it
back to the owner after repair/ replacement
will be paid for by the owner. RMB EV’s
responsibility in respect to claims is limited to
making the required repairs or replacements and
no claim of breach of warranty shall be cause for
cancellation or rescission of the contract of sale
of any RMB EV product. Proof of date of
purchase will be required by the dealer to
substantiate any warranty claim. An authorized
RMB EV service dealer must perform all warranty
work. The warranty is limited to thirty (30) days
from the date of purchase for any RMB EV
product that is used for rental demonstration,
commercial purposes, or any other income
producing purpose. This warranty does not cover
any RMB EV product that has been subject to
misuse, neglect, negligence or accident, or has
been operated in any way contrary to the
operating instructions as specified in RMB EV’s
owner’s manual. This warranty does not apply to
any damage to RMB EV products that is the
result of improper maintenance or to any RMB
33
W
Wa ar rr ra an nt ty y
Multi-Point AWD / Multi-Point AWD KODIAK
EV product that has been altered or modified so
as to adversely affect the products operation,
performance, or durability, or that has been
altered or modified to change its intended
use. This warranty does not extend to repairs
made necessary by normal wear and or by use of
parts that are incompatible with RMB EV
products. In addition, this warranty does not
cover items that experience normal wear and
tear. RMB EV reserves the right to improve the
design of the product without assuming any
obligations to modify any product previously
manufactured. All warranties are limited in
duration to the six (6) months warranty
period. Any such implied warranties including
merchantability, fitness for a particular purpose or
otherwise are disclaimed in their entirety after the
expiration of the appropriate thirty day warranty
period. RMB EV’s obligation under this warranty
is strictly and exclusively limited to the repair and
replacement of defective parts and RMB EV does
not assume any other obligation. Some states do
not allow limitations on how long an implied
warranty lasts, so the above limitation may not
apply to you. RMB EV assumes no responsibility
for incidental consequential or other damages
including but not limited to expense of returning

34
W
Wa ar rr ra an nt ty y
Multi-Point AWD / Multi-Point AWD KODIAK
the Multi-Point AWD / Multi-Point AWD KODIAK
to an authorized service dealer and expense of
delivering it back to the owner, mechanics travel
time, telephone charges, rental of a like product
during the time the warranty service is being
performed, travel loss, or damage to personal
property, loss of revenue, loss of time, or
inconvenience. Some states do not allow the
exclusion or limitation of incidental or
consequential damages so the above limitations
may not apply to you.
WHAT RMB EV WILL DO:
RMB EV will, at its sole option, either repair,
replace or refund the purchase price of any unit
that does not conform to this limited warranty.
RMB EV may choose at its option to use
functionally equivalent reconditioned, refurbished,
or new units or parts or any units. You are
responsible to get the unit back to RMB EV.
35
W
Wa ar rr ra an nt ty y
Multi-Point AWD / Multi-Point AWD KODIAK
HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please email, call, or
fax to the following telephone numbers for RMB
EV Customer Service - warranty repair
Tel. [phone] or Fax.[phone],
Email: [email protected] (email is best)
DO NOT RETURN YOUR PRODUCT TO ANY
ADDRESS.
Please call, email, or write for the location of the
RMB EV authorized service center nearest you
and for the procedures for obtaining warranty
claims.

36
Instructions for optional attachments
Multi-Point AWD / Multi-Point AWD KODIAK
Instructions on the use of the alarm
1. Take out the alarm.
2. Connect the battery and install on seat post.
3. The “1” button is the alarm button. When
pressing it gently, the horn will ring one loud,
after three seconds, the scooter will be on alert.
Touching or moving the scooter, activates alarm
and horn will ring continuously.
37
Instructions for optional attachments
Multi-Point AWD / Multi-Point AWD KODIAK
4. The “2” button is the disarm button. Pressing
this button gently, the horn will ring one loud,
then the alert is removed.
