Roadtrek CS Adventurous 2019 User manual

www.roadtrek.com
2019 OWNER’S MANUAL

2
Contents
Introduction to Your Roadtrek .......................................................................................................................................................................................7
Disclaimer.......................................................................................................................................................................................................................7
Copyright........................................................................................................................................................................................................................7
References ...............................................................................................................................................................................................................8
Do’s and Don’t’s ............................................................................................................................................................................................................8
Symbol Legend ..............................................................................................................................................................................................................8
Regulatory Warnings......................................................................................................................................................................................................8
Information, Cautions and Warnings..............................................................................................................................................................................9
Before You Head Out...................................................................................................................................................................................................11
Coming Home ..............................................................................................................................................................................................................12
Interior Living Space ....................................................................................................................................................................................................15
Cabinets .......................................................................................................................................................................................................................15
Cabinet Adjustment .....................................................................................................................................................................................................16
Galley Cabinets ............................................................................................................................................................................................................17
Galley Instant Hot Water Dispenser.............................................................................................................................................................................18
Lights............................................................................................................................................................................................................................20
Tables Legs and Leg Mounts.......................................................................................................................................................................................21
Table Storage and Front/Rear Lounge Table Setup ....................................................................................................................................................22
Front Swivel Seats .......................................................................................................................................................................................................24
Window Treatments .....................................................................................................................................................................................................27
Rear Windows and Sliding Passenger Side Door ........................................................................................................................................................28
Roadtrek Inc.

3
Front Window Treatments............................................................................................................................................................................................29
Ventilation.....................................................................................................................................................................................................................30
Sleeping Facilities ........................................................................................................................................................................................................31
Twin and King Bed Setup ............................................................................................................................................................................................31
Bathroom Facilities ......................................................................................................................................................................................................33
Shower Setup...............................................................................................................................................................................................................34
Refrigerator ..................................................................................................................................................................................................................36
Microwave Oven ..........................................................................................................................................................................................................36
Propane Cooktop.........................................................................................................................................................................................................37
Water Heater ................................................................................................................................................................................................................37
Optional Induction Cooktop.........................................................................................................................................................................................38
Home Theatre System .................................................................................................................................................................................................39
Optional HDTV .............................................................................................................................................................................................................39
Outside Your Roadtrek ................................................................................................................................................................................................40
Running Boards on Drivers Side ............................................................................................................................................................................40
Awning....................................................................................................................................................................................................................42
Rear Doors .............................................................................................................................................................................................................44
Exterior Step...........................................................................................................................................................................................................45
Shore Power...........................................................................................................................................................................................................46
Utilities..........................................................................................................................................................................................................................47
Fresh Water............................................................................................................................................................................................................47
City Water...............................................................................................................................................................................................................48
Roadtrek Inc.

4
Waste Water...........................................................................................................................................................................................................49
Indicators................................................................................................................................................................................................................50
Air Conditioning and Thermostat ...........................................................................................................................................................................50
Alde Hydronic Heating System ..............................................................................................................................................................................51
Dumping.......................................................................................................................................................................................................................53
Monitor Panel ...............................................................................................................................................................................................................54
Power Sources.............................................................................................................................................................................................................54
12-Volt DC Power ..................................................................................................................................................................................................54
Inverters..................................................................................................................................................................................................................55
Other Switches.............................................................................................................................................................................................................55
Patio Lights ............................................................................................................................................................................................................56
Water Pump Switch ...............................................................................................................................................................................................56
Tank and Charge Indicators...................................................................................................................................................................................56
Distribution Panel, AC Breaker and 12-Volt Fuse Panels ............................................................................................................................................57
(Optional) Solar Panels.................................................................................................................................................................................................58
Outlets..........................................................................................................................................................................................................................58
Electrical System..........................................................................................................................................................................................................59
Coach Batteries......................................................................................................................................................................................................59
Battery Disconnect Switch.....................................................................................................................................................................................59
Inverter Charger .....................................................................................................................................................................................................59
Alternator Charger and Battery Separator .............................................................................................................................................................59
Batteries .................................................................................................................................................................................................................60
Roadtrek Inc.

5
On Board 120-Volt AC Power/3000W Inverter ............................................................................................................................................................61
Engine Generator .........................................................................................................................................................................................................62
Alarms and Warnings ...................................................................................................................................................................................................63
Propane and CO Alarm ..........................................................................................................................................................................................63
Smoke Alarm..........................................................................................................................................................................................................63
Fire Extinguisher...........................................................................................................................................................................................................64
Flat or Leaking Tire Maintenance.................................................................................................................................................................................65
Tow Hitch and Tow Rating...........................................................................................................................................................................................66
XL Edition Information..................................................................................................................................................................................................67
Maintenance.................................................................................................................................................................................................................68
Tires........................................................................................................................................................................................................................68
Occupant Cargo Carrying Capacity.......................................................................................................................................................................68
Owner Maintenance Checks ........................................................................................................................................................................................69
When You Stop for Fuel or Weekly ........................................................................................................................................................................69
Every Other Week ..................................................................................................................................................................................................69
At Least Every Three Months .................................................................................................................................................................................69
At Least Twice a Year ............................................................................................................................................................................................70
At Least Once a Year .............................................................................................................................................................................................70
Roadtrek Inc.

6
How to Obtain the Limited Warranty...................................................................................................................................................................... 73
How to Get Service ................................................................................................................................................................................................73
Roadside Assistance Plan......................................................................................................................................................................................75
Arbitration Provision...............................................................................................................................................................................................74
Registration ............................................................................................................................................................................................................77
Aftermarket Disclaimer..................................................................................................................................................................................................78
Regulatory Notices....................................................................................................................................................................................................... 79
HOW TOs ..................................................................................................................................................................................................................... 79
Roadtrek Inc.
Roadtrek Limited Warranty ..........................................................................................................................................................................................73
Contacting Roadtrek ................................................................................................................................................................................................73
Specifications .............................................................................................................................................................................................................74

7
Introduction to Your Roadtrek
Congratulations on the purchase of your Roadtrek, and welcome to the family. The information included in this manual is meant to help and guide
you through the many functions your Roadtrek has to offer.
Please keep this manual in your vehicle as a reference for when you are traveling. If you have any questions or comments on information found in
this document, please contact us at [e-mail].
Disclaimer
This owner’s manual was created to help owners with general use, maintenance and care of their RVs. Roadtrek Inc., conducts ongoing
product development and uses photos from multiple brands and vehicles to create these instructions. The included images may not reflect
exact makes and/or models; however, the information remains relevant and useful. These instructions are provided as general guidelines only,
as certain add-ons or customization to an RV may change the manner in which these operations are performed.
Copyright
Roadtrek Inc reserves the right to make changes at any time, without notice to colors, materials, equipment, specifications and models. The
information contained in this manual is intended as a guide only, as continuous improvements are ongoing. Some motorhomes may be
shown with equipment that is optional. Accessories shown in any photograph may not be included.
This manual is released under a Creative Commons Attribution-Non-Commercial-No Derivatives 4.0 International License [1].
In summary, you may:
•Copy any portion of this manual in any form for personal use;
•Distribute this manual complete with all its original unmodified content;
•Modify this manual for your own personal, non-commercial use.
In summary, you may not:
•Use this manual for any commercial use whatsoever;
•Modify this manual except as provided for in the full license and then distribute the resulting work;
•Charge for this manual other than reasonable media and shipping costs.
Roadtrek Inc.

8
All images used in this manual remain the property of Roadtrek Inc. They are for illustrative purposes only and may or may not be representative
of the upfit in your Roadtrek. Contact Roadtrek Inc. for alternate licensing arrangements if you want to use or distribute this manual commercially.
References
[1] http://creativecommons.org/licenses/by-nc-nd/4.0/
Do’s and Dont’s
Symbol Legend
Information: Useful information and knowledge.
Warning: Not following this instruction may lead to negative
results. Caution: You should follow this instruction.
Danger: DO NOT perform this action. Doing so may result in severe damage, injury or death. Regulatory Warnings
LEVEL
ITEM
INSTRUCTION
Danger
Do not place propane cylinders inside the vehicle.
•Propane cylinders are equipped with safety devices that relieve excessive pressure by discharging propane to
the atmosphere.
•Propane gas is highly flammable. This action can lead to fire or explosion and result in serious injury or death.
Warning
Do not use gas cooking appliances for comfort heating.
•This can lead to carbon monoxide poisoning, which can lead to serious injury or death.
Warning
Gas cooking appliances need fresh air for safe operation.
•Open vents or windows slightly or turn on exhaust fan prior to using cooking appliance.
•Gas flames consume oxygen, which should be replaced to ensure proper operation.
•Improper use can result in serious injury or death.
Roadtrek Inc.

9
Caution
Do not fill propane containers to more than 80% of their capacity.
•A properly filled container contains approximately 80 percent of its volume as liquid propane.
•Overfilling propane container(s) can result in uncontrolled propane flow, which could lead to a fire or explosion
and result in serious injury or death.
Warning
When using an outdoor cooking area, the vehicle must be level and stabilized. Do not violate manufacturers’
instructions on required clearances for cooking appliances during use. Do not store cooking appliances until cool
to the touch. Failure to do so can lead to a fire and result in serious injury or death.
Danger
If you smell propane:
1. Extinguish any open flames and all smoking materials.
2. Shut off propane supply at the container valve(s) or propane supply connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating openings.
5. Leave the area until the odor clears.
6. Have the propane system checked and leakage source corrected before using again.
7. Ignition of flammable vapors could lead to a fire or explosion and result in serious injury or death.
Warning
Vehicles and equipment powered by internal combustion engines and placed in recreational vehicles can cause
carbon monoxide poisoning or asphyxiation, which could result in serious injury or death.
•Do not store, transport, or dispense fuel inside this vehicle.
Danger
The propane tank valve must be closed and all pilot lights, appliances and their igniters must be turned off during
refueling of the motor fuel tank and/or the propane fuel tank. Only qualified personnel should refuel your propane
tank. Please see page 41 & 53 for further information. (Do not operate vehicle with propane valve open.)
Warning
Portable fuel burning equipment, including wood, charcoal, and liquid fuel grills and stoves, should not be used
inside your vehicle. Use of this type of equipment inside your vehicle may cause a fire or asphyxiation.
Information, Cautions and Warnings
LEVEL
ITEM
COMMENT
Seat Belts
Use only forward-facing seats equipped with factory installed seat belts while the vehicle is in motion. All
passengers must be seated in these seats only, with the seat belts fastened while the vehicle is in motion.
TV
Turn the TV off and stow it while the vehicle is in motion.
TV
The flat screen TV should not be stored inside the Roadtrek in cold temperatures. Remove it to reduce the
chance of damage from the cold. Check the Owner's Manual for the TV for storage and operating temperatures.
TV
To remove the TV, release the bracket on the back of the TV mounting bracket and remove the RCA cables,
power supply cable and antenna cable.
Roadtrek Inc.

10
Propane
Purchase propane from a reputable propane facility. Contaminated propane is a common cause of system failure
and is not covered under any warranty.
Propane
The BBQ quick disconnect (If Equipped) is regulated to 10 P.S.I. Please ensure that all devices connected to this
are either rated for high "pressure" or have their own regulator. Many grills sold in the United States are "low
pressure" (1/2 P.S.I.) and will require an additional regulator to step the pressure down to a useable level. If
hooked directly to the BBQ quick disconnect, there will be a severe fire hazard.
Propane Leak
Detector
Do not block the air circulation in the area where the Propane Leak Detector is located.
Propane Leak
Detector
Battery disconnect switch must be in the "ON" position for the propane detector to function.
Flammable
Liquids and
Gasses
Do not store gasoline or other flammable liquids inside your vehicle.
Heating
Never use cooking appliances or unvented propane heaters for space heating purposes. They need fresh air for
safe operation.
Heating
The heating furnace provides its own outside combustion air and exhausts to the outside.
Carbon
Monoxide
Leak Detector
Do not block the air circulation in the area where the Carbon Monoxide Leak Detector is located.
Carbon
Monoxide Leak
Detector
Battery disconnect switch must be in the "ON" position for the Carbon Monoxide Leak Detector to function.
110 V Electrical
Servicing
Prior to servicing any 110V, unplug the output lead from the power inverter.
Exterior Access
Doors
Ensure the shore power cord and city water supply lines are disconnected and in their stored positions before
the vehicle is put in motion.
Awning
Close the sliding side door prior to opening or closing the awning.
Dining Table
When storing the two dining tables, secure in place using the clips attached.
Counter Space
Make sure the stove is off and has cooled prior to using the counter space.
Roadtrek Inc.

11
Battery
Battery acid can burn your skin and damage clothing. Protective eye wear and gloves should be worn while
handling batteries. Effective June 2010, all Roadtrek Inc installed batteries are sealed AGM or Lithium
batteries that do not require the addition of water.
Battery
Disconnect the inverter/charger prior to disconnecting the auxiliary battery.
Generator
The Roadtrek is supplied with an optional DC generator located either behind the rear axle on the driver’s side or
in the engine compartment. Never submerge the generator. Use a spotter when launching a boat or crossing
streams.
Waste Water
Storage and
Dumping
Close the black water gate valve before using the waste water system.
Freezing
Under moderate subfreezing conditions, antifreeze is required in the exterior fresh water, grey water and the
black waste water tank. Use RV antifreeze in accordance with the manufacturer's instructions.
Electrical
Servicing
This unit has a 12-VoltDC, 110VAC and optional 36-volt solar system. These systems need to be disconnected
before working on them.
Before You Head Out
Your new Roadtrek is ready to go with just a little bit of preparation. To prepare for your first trip, you should:
•Read this manual.
•Contact your dealer with any questions.
•Plan your trip.
Then use this quick checklist:
•The day before your trip:
oCharge your RV batteries by plugging in overnight. (*With your standard Lithium batteries, your inverter must be in the On position.*)
oCool your refrigerator by turning it on.
oChill any beverages or other refrigerated items in your home refrigerator.
oFlush and fill your fresh water tank with clean tap water.
•The day of the trip:
oLoad the refrigerator with beverages and other perishable items (from your home refrigerator).
Roadtrek Inc.

12
Coming Home
When you come home, there are a few maintenance tasks you should do to get your Roadtrek ready to go for next time. Refer to other sections in
this manual for the procedures listed here.
•On your way home, dump the grey and black waste water tank at a convenient facility. See the HOW TO’s: Waste Water Dumping for a
concise description of the procedure to do this. Some RV parks and gas stations will let you dump for a fee, some city wastewater plants
will let you dump for free but there is no real pattern, so local knowledge is vital in locating dump stations.
•The website http://www.sanidumps.com is a good resource. The website with maps for each state and province is
http://www.sanidumps.com/maps/help.php.
•At home, flush the water tank and fill it with fresh chlorinated water if you will be using it in the next few days. Otherwise, drain the tank.
Don't let water you are planning to use sit in your tank for more than a week or so, and don't let any water sit in your tank for more than
two weeks, whether you plan on using it or not. Over time, the chlorine evaporates allowing bacteria to grow.
•To flush the tank, fill it using the fill port located on the driver's side body panel located just behind the front axle under the running board
or the gravity fill located on the passenger side front door pillar. (See images below) (Picture 12.2).
Picture 12.1
Picture 12.2
30AMP Power Plug Connector.
Located in Drivers Side Running Between
Front and Rear Axles.
City Water Intake Located Behind Front
Axle on Drivers Side Behind Hinged
Running Board.
Roadtrek Inc.

13
Coming Home (Continued)
•Plug in the shoreline connection overnight to fully charge batteries.
•Turn off and clean out the refrigerator and prop the door open to let it air out.
•If you plan on storing your Roadtrek for an extended period, turn off the Battery Disconnect Switch and the Inverter Switch to keep from
draining your AGM or optional Lithium battery(ies).
•* If you turn everything off, your solar panels (If Equipped), will keep your coach batteries charged to a safe level while your Roadtrek is
parked.
oSolar panels will only keep your Roadtrek charged when parked outside.
•If you don't turn everything off, even with solar panels, you will probably come back to dead batteries.
oBecause electronic systems on your coach need small amounts of electricity even when off, the batteries will completely be drained
over a period of time.
oWith optional Lithium batteries, the battery switch(es) need to be on so the solar panel(s) can provide a charge to them. Turn the
switch(es) off at the end of the day to maintain the battery charge.
•If you are not planning on storing your coach for an extended period, it is recommended that you plug in your coach to charge the batteries
to keep them from draining.
oPlug your coach into a dedicated power outlet. (Dedicated outlets supply a cleaner line of electricity supplied to the coach) (Picture
14.1 On Next Page)
oTurn on your battery disconnect switch. (Picture 14.2 On Next Page)
oIf your motorhome is equipped with Roadtrek’s optional EcoTrek Lithium battery system, turn on your Lithium Battery switches and
make sure theblue light is illuminated. (Picture 14.3 On Next Page)
oTurn your inverter to the On position. (Picture 14.4 On Next Page)
Roadtrek Inc.

14
Coming Home (Continued)
Optional EcoTrek Lithium Battery
Switches Located on Overhead
Storage Cabinet Wall Over
Passenger Seat.
Coaches Monitor Panel with
Battery Disconnect Switch
Shown.
30AMP Shore Power Cord Coach
Connect Port.
Coach Inverter Switch in the On
Position.
Picture 14.1
Picture 14.2
Picture 14.3
Picture 14.4
Roadtrek Inc.

15
Interior Living Space
Do not attempt to close the cabinet doors while the latch button is pressed in. This could break the latch. Always make sure the button is
out before attempting to close a cabinet door. (Picture 15.2)
It is not recommended to keep large, round, and/or heavy objects in a cabinet unsecured as they may roll around and apply excessive
pressure to the inside of the cabinet doors as you drive. The objects may shift position with vehicle motion and cause injury when the
cabinets are opened. For this reason, Roadtrek recommends that you are aware of the weight and stability of objects that you store in
overhead cabinets.
The cabinet hinges may go out of adjustment due to heavy weight stored in the cabinet, experience large swings in temperature or
humidity, frequent travel on bumpy roads at high speeds frequently and sometimes as part of normal wear and tear. You will know the
cabinet is out of adjustment when it will not open with the button out, or not latch with the button in.
Push Button for Cabinet Latches
In Closed Position.
Push Button for Cabinet Latches
In Opened Position.
Picture 15.1
Picture 15.2
Cabinets
Your Roadtrek is equipped with cabinet latches which
prevent the door from opening while the vehicle is in
motion. The push buttons on the cabinet latches toggle
from latched (button in) (Picture 15.1) to unlatched
(button out) (Picture 15.2) by pressing the button.
To open a cabinet, press the button to unlatch and pull
gently on the button, and the cabinet door will open.
To close a cabinet, make sure the latch is still open
(button out), then close the door. Once the cabinet door
is closed, press the latch button in to lock the cabinet.
Roadtrek Inc.

16
Cabinets Continued
To open a cabinet stuck shut with the button out, apply pressure UPWARD with your thumbs on both bottom corners of the cabinet door while
simultaneously applying gentle pressure to open it, as shown above left. (Picture 16.1)
DO NOT FORCE THE DOOR OPEN BY PULLING OR PRYING ON IT - you will break the latch.
The screw in the top part of the hinge nearest the pivot point adjusts the vertical location of the door (Picture 16.2). Screw out to raise the door
and screw in to lower the door or fix doors that won't stay shut when latched, as shown above left.
Cabinet Adjustment
The screw on the long bracket hinge is used to apply or reduce the friction needed on your cabinet door to open and close the cabinet door
smoothly. Using an allen wrench, turn the screw to the right to tighten the hinge and put more friction on your cabinet door. Turn the screw to the
left to loosen the pressure that is applied and allow for the cabinet to be opened with less force. (Picture 16.2.)
Apply Moderate Upward Pressure and
Gentle Outward Pressure with One or Two
Fingers on the Bottom Corners of the Door
to Open a Stuck Cabinet.
Adjustments to the Cabinet Hinges Will
Allow for Tightening and to Loosen the
Friction Required to Open and Close the
Cabinet Door.
Picture 16.1
Picture 16.2
Roadtrek Inc.

17
Galley Cabinets
Picture 17.1
Picture 17.2
Picture 17.3
Picture 17.4
Stainless Steel Sides and Backing
Protecting Cabinets and Appliances.
Galley Cabinets and Drawers View from
Rear of Coach.
Lower Cabinet at Rear of Galley Houses
Alde components. *Note – Storage Not
Available in This Cabinet.*
Picture 17.5
The Rear Kitchen Galley Closet Has Four
Levels with Three Removable Shelves.
Three Slide Out Drawers Beneath Galley
Cooktop. *Note – Shown with Optional
Induction Cooktop.*
Picture 17.6
Three Level Storage Cabinet
Located Beneath Galley Sink.
Roadtrek Inc.

18
Galley Cabinets (Continued)
(*Note – All of these drawers have conventional non-locking knobs and a friction closure mechanism to secure them while your
Roadtrek is in motion. Make sure they are completely closed before driving.)
In your kitchen galley, your sides and back splash area are protected from cooking elements by stainless steel panels. (Picture 17.1 on Previous
Page.)
A view of your galley cabinetry and drawers are visible from the rear of your coach. (Picture 17.2 on Previous Page.)
Immediately beneath the galley shelved cabinet is a cabinet door. Inside is components for the Alde system and no storage is possible. (Picture
17.3 on Previous Page.)
The rear cabinetry closet has four levels with three removable shelves. To remove shelves, lift from holders, turn slightly and remove. Store in a
safe location to avoid damage. (Picture 17.4 on Previous Page.)
The kitchen galley has three deep-storage drawers located beneath the galley cooktop. (Picture 17.5 on Previous Page.)
A three-level storage cabinet is located below the sink. (Picture 17.6 on Previous Page.) *Note – Depending on coach options, storage may
have limitations.*
Galley Instant Hot Water Dispenser
Picture 18.1
The Lower Galley Compartments Contain
Alde Components.
Picture 18.2
Picture 18.3
Storage Compartment Below Sink
Contains Instant Hot Water System.
Instant Hot Water Faucet.
Roadtrek Inc.

19
Galley Instant Hot Water Dispenser (Continued)
The lower galley compartments contain components for the Alde and instant hot water systems. (Picture 18.1 on Previous Page.) (*Note – Due to
the components in these compartments, storage is not recommended.)
The galley compartment beneath the sink contains the Instant Hot Water Tank and Water Filter. (Picture 18.2 on Previous Page.)
The instant hot water faucet located on top right side of galley sink. Push handles back to start the flow of water. (Picture 18.3 on Previous Page.)
Lift the galley sink lid and rotate the instant hot water faucet towards the sink before starting the flow of water. Failure to do so could result
in damage to galley area and personal injury from hot water dispensed. (Picture 19.1.)
The instant hot water dispenser switch is located on the side of the galley above the sink area. (Picture 19.2.) * Note - If optioned with Induction
Stove, galley inverter powers Instant Hot Water controls. Otherwise the coach’s inverter will power the instant hot water system.*
Turn the instant hot water dispenser off when not in use as this appliance uses a large amount of electricity to operate. Failure to do
so could result in significant drain on your battery system.*For detailed information on this appliance, consult the Products/Appliance
Owner's Manual that accompanies your coach.
Picture 19.1
Lift the Galley Sink Cover and Rotate
Instant Hot Water Faucet Towards Sink.
Picture 19.2
Instant Hot Water Dispenser Switch Located
on Right Side of Galley Above Sink Area.
Roadtrek Inc.

20
Lights
For the 12-Volt ceiling lights to operate, your coach’s battery disconnect switch must be in the On position. (Picture 20.1)
The 12-Volt oval ceiling lights are individually controlled and are turned on by lightly pushing the lens area of a given light until you hear a click,
and then release. (Picture 20.2)
NOTE: These are LED lights which consume very little electricity. (Pictures 20.2 and 20.3)
Picture 20.1
Picture 20.2
Picture 20.3
Battery Disconnect Switch in On Position.
Picture of 12-Volt Lighting off. Gently Push
Upwards on Lights Lens Cover Until You
Hear a Click and Release to Turn On.
Picture of 12-Volt Lighting in the On
Position. Gently Push Upwards on a
Light’s Lens Cover Until You Hear a Click
and Then Release to Turn Them Off.
Roadtrek Inc.
