Roadtrek SS AGILE 2020 User manual

2020 OWNE R ’S MAN UAL
www.roadtrek.com

Roadtrek Inc.
Contents
Introduction to Your SS Agile ..............................................................................................................................................................................7
Disclaimer....................................................................................................................................................................................................................7
Copyright.....................................................................................................................................................................................................................7
References ..............................................................................................................................................................................................................8
Do’s and Don’ts ..................................................................................................................................................................................................8
Symbol Legend........................................................................................................................................................................................................8
Regulatory Warnings................................................................................................................................................................................................8
Information, Cautions and Warnings ........................................................................................................................................................................9
Before You Head Out ................................................................................................................................................................................................11
Coming Home............................................................................................................................................................................................................12
Interior Living Space..................................................................................................................................................................................................13
Cabinets.................................................................................................................................................................................................................13
Galley Drawers ......................................................................................................................................................................................................15
Lights .....................................................................................................................................................................................................................15
Tables....................................................................................................................................................................................................................16
Rear Table .............................................................................................................................................................................................................16
Front Table ............................................................................................................................................................................................................17
Captain’s Seats......................................................................................................................................................................................................18
Blinds.....................................................................................................................................................................................................................20
Ventilation
..............................................................................................................................................................................................................21
Sleeping Facilities......................................................................................................................................................................................................22
Sofa Bed ................................................................................................................................................................................................................22
Twin Beds..............................................................................................................................................................................................................23
King Bed ................................................................................................................................................................................................................23

Roadtrek Inc.
Bathroom Facilities ....................................................................................................................................................................................................24
Securing Bathroom Door........................................................................................................................................................................................24
Using the Toilet ......................................................................................................................................................................................................24
Shower ..................................................................................................................................................................................................................25
Appliances.................................................................................................................................................................................................................27
TV and Home Theatre System...............................................................................................................................................................................27
Antenna and Cable Connections............................................................................................................................................................................27
Controlling the Rear Speakers ...............................................................................................................................................................................27
Refrigerator............................................................................................................................................................................................................28
Microwave Convection Oven .................................................................................................................................................................................28
Microwave Convection Oven (Big Inverter Version) ...............................................................................................................................................28
Cooktop Stove...............................................................................................................................................................................................29
Hot Water...............................................................................................................................................................................................................29
Outside Your Roadtrek ..............................................................................................................................................................................................30
Awning...................................................................................................................................................................................................................30
Exterior Step ..........................................................................................................................................................................................................31
Sliding Side Door ...................................................................................................................................................................................................32
Rear Door Screen ..................................................................................................................................................................................................33
Outside Shower .....................................................................................................................................................................................................34
Utility Bays .............................................................................................................................................................................................................35
Fuel Fill .............................................................................................................................................................................................................................................. 36
Utilities.......................................................................................................................................................................................................................37
Fresh Water ...........................................................................................................................................................................................................37
City Water ..............................................................................................................................................................................................................37
Wastewater ............................................................................................................................................................................................................39
Heating and Cooling ..................................................................................................................................................................................................40

Roadtrek Inc.
Heating ..................................................................................................................................................................................................................40
Thermostat.............................................................................................................................................................................................................40
Electrical System.......................................................................................................................................................................................................41
Batteries.................................................................................................................................................................................................................41
AGM ......................................................................................................................................................................................................................41
Lithium Batteries .................................................................................................................................................................................................... 42
Turning on the Batteries......................................................................................................................................................................................... 42
If the Batteries Are Depleted ..................................................................................................................................................................................43
Jump Starting Your Engine ....................................................................................................................................................................................44
Battery Disconnect Switch. ....................................................................................................................................................................................44
Standard 3000 Watt Inverter .................................................................................................................................................................................. 45
Engine Generator..................................................................................................................................................................................................46
Solar Panels ..........................................................................................................................................................................................................47
Shore Power ..........................................................................................................................................................................................................48
Electrical Outlets ....................................................................................................................................................................................................49
Monitor Panel ............................................................................................................................................................................................................50
Location .................................................................................................................................................................................................................50
Power Sources.......................................................................................................................................................................................................50
12 Volt DC Power ..................................................................................................................................................................................................51
The EcoTrek Batteries .......................................................................................................................................................................................... 51
Turning on the Batteries........................................................................................................................................................................................ 52
The 12V Main Power Switch .........................................................................................................................................................................................53
Inverter ..................................................................................................................................................................................................................53
Shore Power and Battery Charge Indicator ............................................................................................................................................................53
Other Switches.......................................................................................................................................................................................................54
Patio Light..............................................................................................................................................................................................................54

Roadtrek Inc.
Water Pump Switch................................................................................................................................................................................................54
Tank Levels and Battery Charge Indicators............................................................................................................................................................54
Distribution Panel ......................................................................................................................................................................................................55
AC Breaker and 12 Volt Fuse Panel.......................................................................................................................................................................55
Alarms and Warnings ................................................................................................................................................................................................56
CO Monitor ............................................................................................................................................................................................................56
Smoke Detector .....................................................................................................................................................................................................57
Fire Extinguisher............................................................................................................................................................................................................57
Maintenance..............................................................................................................................................................................................................58
Tires.......................................................................................................................................................................................................................58
Cargo Carrying Capacity........................................................................................................................................................................................58
Owner Maintenance Checks ..................................................................................................................................................................................58
When You Stop for Fuel or Weekly...................................................................................................................................................................58
Every Other Week..................................................................................................................................................................................................58
At Least Monthly ....................................................................................................................................................................................................58
At Least Every Three Months.................................................................................................................................................................................59
At Least Twice a Year ............................................................................................................................................................................................59
At Least Once a Year.............................................................................................................................................................................................60
Other Maintenance Checks....................................................................................................................................................................................60
Tire Service Kit ............................................................................................................................................................................................................. 60
Roadtrek Inc. Two (2)-year limited Warranty………………………………………………………………………………………………………………………...61
Roadtrek Limited Warranty…................................................................................................................................................................................... . 64
Obtaining Service...................................................................................................................................................................................................... 64
Contacting Roadtrek Inc .............................................................................................................................................................................................64
Arbitration Provision .................................................................................................................................................................................................. 65

Roadtrek Inc.
Specifications. ............................................................................................................................................................................................................65
Roadside Assistance Program ...................................................................................................................................................................................65
Registration ...............................................................................................................................................................................................................66
Aftermarket Disclaimer ..............................................................................................................................................................................................66
Regulatory Notices ....................................................................................................................................................................................................66
HOWTOs ...........................................................................................................................................................................................................................66

7
Roadtrek Inc.
Disclaimer
This owner’s manual was created to help owners with general use, maintenance and care of their RV. Roadtrek Inc. conducts ongoing product
development and uses photos from multiple brands and vehicles to create these instructions. The included images may not reflect exact makes
and/or models however, the information remains relevant and useful. These instructions are provided as general guidelines only, as certain add-
on or customization to an RV may change the manner these operations are performed.
Introduction to Your SS Agile
Congratulations on the purchase of your Roadtrek and welcome to the family. The information included in this manual is meant to help and
guide you using your vehicle so that you know how to properly use the many functions your Roadtrek has to offer.
Please keep this manual in your vehicle as a reference for when you are travelling. If you have any questions or comments on information found
in this document, please contact us at [email protected].
Copyright
Roadtrek Inc. reserves the right to make changes at any time, without notice in colors, materials, equipment, specifications and models. The
information contained in this manual is intended as a guide only, as continuous improvements are ongoing. Some motorhomes may be shown
with equipment that is optional. Accessories shown in any photographs may not be included.
This manual is released under a Creative Commons Attribution-Non-Commercial-No Derivatives 4.0 International License [1].
In summary, you may:
• Copy any portion of this manual in any form for personal use;
• Distribute this manual complete with all its original unmodified content;
• Modify this manual for your own personal, non-commercial use.
• You may not:
• Use this manual for any commercial use whatsoever;
• Modify this manual except as provided for in the full license and then distribute the resulting
work;
• Charge for this manual other than reasonable media and shipping costs.

Roadtrek Inc.
8
All images used in this manual remain the property of Roadtrek Inc. They are for illustrative purposes only and may or may not be representative
of the upfits in your Roadtrek. Contact Roadtrek Inc. for alternate licensing arrangements if you want to use or distribute this manual
commercially.
References
[1] http://creativecommons.org/licenses/by-nc-nd/4.0/
Do’s and Don’ts
Symbol Legend
Information: Useful information and knowledge.
Warning: Not following this instruction may lead to negative results.
Caution: You should follow this instruction.
Danger: Do NOT perform this action. Doing so may result in injury, severe damage, or death.
Regulatory Warnings
LEVEL
ITEM
INSTRUCTION
Warning
Do not place propane cylinders inside the vehicle.
• Propane cylinders are equipped with safety devices that relieve excessive pressure by discharging propane to
the atmosphere.
• Propane gas is highly flammable. This action can lead to fire or explosion and result in death or serious injury.
Danger
Do not use gas cooking appliances for comfort heating.
• Can lead to carbon monoxide poisoning, which can lead to death or serious injury.
Warning
Gas cooking appliances need fresh air for safe operation.
• Open vents or windows slightly or turn on exhaust fan prior to using cooking appliance.
• Gas flames consume oxygen, which should be replaced to ensure proper operation.
• Improper use can result in death or serious injury.

9
Roadtrek Inc.
Warning
Do not fill propane containers to more than 80% of their capacity.
• A properly filled container contains approximately 80 percent of its volume as liquid propane.
• Overfilling propane container(s) can result in uncontrolled propane flow, which could lead to a fire or explosion
and result in death or serious injury.
Danger
If you smell propane:
1. Extinguish any open flames and all smoking materials.
2. Shut off propane supply at the container valve(s) or propane supply connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating openings.
5. Leave the area until the odor clears.
6. Have the propane system checked and leakage source corrected before using again.
7. Ignition of flammable vapors could lead to a fire or explosion and result in death or serious injury.
Danger
Vehicles and equipment powered by internal combustion engines and placed in recreational vehicles can cause
carbon monoxide poisoning or asphyxiation, which could result in death or serious injury.
• Do not store, transport, or dispense fuel inside this vehicle.
Information, Cautions and Warnings
LEVEL
ITEM
COMMENT
Seat Belts
Use only forward-facing seats equipped with factory installed seat belts while the vehicle is in motion. All
passengers must be seated in these seats only, with the seat belts fastened while the vehicle is in motion.
TV
Turn the TV off and stow it while the vehicle is in motion.
TV
The flat screen TV should not be stored inside the Roadtrek in cold temperatures. Remove it to reduce the chance
of damage from the cold. Check the Owner's Manual for the TV for storage and operating temperatures.
TV
To remove the TV, release the bracket on the back of the TV mounting bracket and remove the RCA cables,
power supply cable and antenna cable.
Propane
Do not store propane tanks inside your vehicle. Propane tanks are equipped with safety devices which relieve
excessive pressure by discharging gas to the atmosphere.
Propane
Do not refuel the propane tank to more than 80% of its capacity.
Propane
The propane tank valve must be closed and all pilot lights, appliances and their igniters must be turned off during
refueling of the motor fuel tank and/or the propane fuel tank. Only qualified personnel should refuel your propane
tank.

Roadtrek Inc.
10
Propane
Purchase propane from a reputable propane facility. Contaminated propane is a common cause of system failure
and is not covered under any warranty.
Propane
The BBQ quick disconnect is regulated to 10 P.S.I. Please ensure that all devices connected to this are either
rated for high "pressure" or have their own regulator. Many grills sold in the United States are "low pressure" (1/2
P.S.I.) and will require an additional regulator to step the pressure down to a useable level. If hooked directly to
the BBQ quick disconnect they will be a severe fire hazard.
Propane Leak
Detector
Do not block the air circulation in the area where the Propane Leak Detector is located.
Propane Leak
Detector
Battery disconnect switch must be in the "ON" position for the propane detector to function.
Flammable
Liquids and
Gasses
Do not store gasoline or other flammable liquids inside your vehicle.
Heating
Never use cooking appliances or unvented propane heaters for space heating purposes. They need fresh air for
safe operation.
Heating
The heating furnace provides its own outside combustion air and exhausts to the outside.
Heating
Portable fuel burning equipment, including wood, charcoal, and liquid fuel grills and stoves, should not be used
inside your vehicle. Use of this type of equipment inside your vehicle may cause a fire or asphyxiation.
Carbon
Monoxide Leak
Detector
Do not block the air circulation in the area where the Carbon Monoxide Leak Detector is located.
Carbon
Monoxide Leak
Detector
Battery disconnect switch must be in the "ON" position for the Carbon Monoxide Leak Detector to function.
110 V Electrical
Servicing
Prior to servicing any 110 V, unplug the output lead from the power inverter.
Exterior Access
Doors
Ensure the shore power cord and city water supply lines are disconnected and in their stored positions before the
vehicle is put in motion.
Awning
Close the sliding side door prior to opening or closing the awning.
Dining Table
When storing the dining table, secure in place using the snap-on strap.
Extra Counter
Space
Make sure the stove is off and has cooled prior to lowering the stove cover.

Roadtrek Inc.
11
Battery
Battery acid can burn your skin and damage clothing. Protective eye wear and gloves should be worn while
handling batteries. Effective June 2010 all Roadtrek Inc. installed batteries are sealed AGM batteries that do
not require the addition of water.
Battery
Disconnect the inverter/charger prior to disconnecting the auxiliary battery.
Generator
The Roadtrek is supplied with an DC generator located in the engine. Never submerge the generator. Use a
spotter when launching a boat or crossing streams.
Wastewater
Storage and
Dumping
System
Close the gray & black water gate valve before using the wastewater system.
Freezing
Under moderate subfreezing conditions, antifreeze is required in the exterior freshwater tank, toilet cassette and
gray wastewater tank. Use RV antifreeze in accordance with the manufacturer's instructions.
Electrical
Servicing
This unit has a 12VDC, 110VAC and potentially 36-volt solar system. These systems need to be disconnected
before working on them.
Before You Head Out
Your new Roadtrek is ready to go with just a little bit of preparation. To prepare for your first trip, you should:
•Read this manual.
•Contact your dealer with any questions.
•Plan your trip.
Then use this quick checklist:
•The day before your trip:
oCharge your batteries by plugging in overnight.
oCool your refrigerator by turning it on.
oChill any beverages in your home refrigerator.
oFill your freshwater tank with clean tap water.
•The day of the trip:
oLoad the refrigerator with cold food (from your home refrigerator).

Roadtrek Inc.
12
Coming Home
When you come home, there are a few maintenance tasks you should do to get your Roadtrek ready to go for next time. Refer to other sections in
this manual for the procedures listed here.
•On your way home, dump the gray and black tanks at a convenient facility. See the HOWTO: Wastewater Dumping section for a concise
description of the procedure to do this. Some RV parks and gas stations will let you dump for a fee, some city wastewater plants will let you
dump for free but there is no real pattern, so local knowledge is vital in locating dump stations. The website
http://www.sanidumps.com is a good resource. The maps for each state and province are
Especially helpful: http://www.sanidumps.com/maps/help.php
•At home, flush the water tank and fill it with fresh chlorinated water if you will be using it in the next few days. Otherwise, drain the tank. Don't
let water you are planning to use sit in your tank for more than a week or so, and don't let any water sit in your tank for more than two weeks,
whether you plan on using it or not. Over time, the chlorine goes away, and the microbes come out to play.
•To flush the tank, fill it using the fill port in the driver's side rear panel and open the freshwater tank drain under the tank at the side of the
vehicle.
•Plug in overnight to fully charge batteries.
•Turn off and clean out the refrigerator and prop the door open to let it air out.
•Turn off two important switches on your monitor panel to keep from draining your batteries:
oThe battery disconnect switch.
oThe inverter switch
•

Roadtrek Inc.
13
Interior Living Space
Cabinets
Your Roadtrek is equipped with cabinet latches that are rated for 50 lbs, which prevent the door from
opening while the vehicle is in motion. The pushbuttons on the cabinet latches toggle from latched
(button in) to openable (button out) by pressing the button. (Pictures 13.1, 13.2)
To open a cabinet, press the button to pop the latch, pull gently on the latch, and the cabinet door will
open.
To close a cabinet, make sure the latch is still open (button out), then close the door. Once the
cabinet door is closed, press the latch button in to lock the cabinet.
Do not attempt to close the cabinet doors while the latch button is pressed in. This will
break the latch. Always make sure the button is out before attempting to close a cabinet
door.
It is not recommended to keep large, round, and/or heavy objects in a cabinet unsecured as
they may roll around and apply excessive pressure to the inside of the cabinet doors as you
drive. The objects may shift position with vehicle motion and cause injury when the cabinets
are opened. For this reason, Roadtrek Inc. recommends that you are aware of the objects
that you store in overhead cabinets.
If you load a large amount of weight into a cabinet, experience large swings in temperature or
humidity, ride on bumpy roads at high speeds frequently, or sometimes as part of normal wear and
tear, the cabinet hinges may go out of adjustment. You will know the cabinet is out of adjustment
when it will not open with the button out, or not latch with the button in.
Picture 13.1
Picture 13.2

14
Roadtrek Inc.
Cabinets (Continued)
Picture 14.1 Picture 14.2
Apply moderate upward pressure and GENTLE
outward pressure with both thumbs on the bottom
corners of the door to open a stuck cabinet
Turn screw clockwise to lower cabinet
face (if it won’t latch), counterclockwise
to raise it up (if it won’t open)
To open a cabinet stuck shut with the button out, apply pressure UPWARD with your thumbs on both bottom corners of the cabinet door while
simultaneously applying gentle pressure to open it, as shown above left. (Picture 14.1)
DO NOT FORCE THE DOOR OPEN BY PULLING OR PRYING ON IT - you will break the latch.
The screw in the top part of the hinge nearest the pivot point adjusts the vertical location of the door. Screw out to raise the door and fix stuck doors;
screw in to lower the door and fix doors that won't stay shut when latched. (Picture 14.2)

15
Roadtrek Inc.
Galley Drawers
Beneath the galley countertop there are drawers to the left and right of the food preparation surface.
The center panel is fixed and is not a drawer. (Picture 15.1)
All these drawers have conventional non-locking knobs, and a friction closure mechanism to secure
them while the Roadtrek is in motion. Make sure they are completely closed before driving.
Lights
Your Roadtrek is equipped with interior LED lighting designed to give you control based on your
requirements. There are three lights down the length of the aisle, and one more over the galley.
Before attempting to turn on any interior lights, you MUST ensure the battery disconnect switch is
turned on. The battery disconnect switch can be located on the bottom left corner of the control panel,
which is above the vehicle's sliding door.
To use the tap lights, press the fixture lens. (Picture 15.2)
Picture 15.2
Picture 15.1

16
Roadtrek Inc.
Tables
Your Roadtrek is equipped with two tables for your use, one for the front and one for the rear of the vehicle. (Picture 16.2)
Rear Table
The rear table is stored under the bench seat on the driver’s side. The table leg is stored behind the driver's seat. (Picture 16.1)
To install the table, place the leg into the existing floor socket. Rotate the leg to ensure it is securely in place and then place the tabletop on top of
the table leg. Make sure the table leg is seated firmly in the tabletop socket. (Picture 16.3)
Picture 16.1 Picture 16.2
Rear table leg Rear table in position
Picture 16.3
Table leg floor socket

Roadtrek Inc.
17
Front Table
Pull the table out from its drawer-like storage in the galley cabinet. Flip the support bracket (Picture 17.1) out from behind the driver's seat. Fold the
tabletop leaf over so it rests on the support bracket. (Pictures 17.2, 17.3)
Picture 17.1
Picture 17.2
Picture 17.3
Front table support
Front table being set up
Fully extended

Roadtrek Inc.
18
Captain’s Seats
To move the front seats to their desired fore and aft position, pull up on the bar located under the front of the seat. Release the bar to lock the seat
in place.
To swivel the front seats, locate the swivel lever on the back of the seat and move it sideways against its spring to release the lock and
swivel the chair.
Always return the seats to the forward-facing position when the vehicle is in motion - the seats will lock in place as you swivel them to face
forward.
There are three adjustments on the outboard side of each front seat: the knob in front raises and lowers the front of the seat, the lever where the
back and base of the seat join raises and lowers the back of the seat, and the knob above that on the seat back reclines the seat back. The lumbar
support adjustment is on the inboard side of the seat. For the full range of adjustments on the front seats, please refer to the Mercedes Sprinter
manual.
To create a front lounge area, first bring the backs of the seats to their upright position. Do not attempt to pivot a reclined seat. Use the fore-and-aft
adjustment while pivoting the seats to allow the sides of the chairs to clear the armrests on the vehicle doors and other obstructions. Do not force
the seats around. Swiveling the seats is easier if you open the doors and loosen the tilt steering wheel adjustment and move the steering wheel as
far forward and up as possible.

Roadtrek Inc.
19
Captain’s Seats (Continued)
The rear seat fore and aft adjustment is a lever extending forward at the front right corner of the seat base. Push this lever to the left (driver's) side
of vehicle and slide the seat. (Picture 19.1) The swivel lever for the rear seat is on the right (passenger) side of the base. (Picture 19.2) Push it
backward to release the lock and swivel the seat. (Picture 19.3)
Picture 19.1 Picture 19.2 Picture 19.3
Seat swivel adjustment Outboard front seat
adjustments
Lumbar support adjustment
on inboard side seat

20
Roadtrek Inc.
Blinds
The nightshade curtain blocks airflow. If you leave the window open,
then close the nightshade, close all other windows, and then close the
side door, it is possible for the curtain to get blown out of the track.
Always close the window prior to closing the nightshade.
The window curtains slide to the right and left. The plastic clip is not a pull
tab; it is a locking tab. Always pull on the aluminum bar. The curtains are
configured so that the nightshade side covers the window opening for
additional privacy.
The curtains on the sliding door and the rear door slide on tracks.
It is best to use both hands, one near each track, to move the curtains.
