Roberts R9927 User manual

Please read this manual before use

ROBERTS

Sound for Generations

R9927

3 Band Mains Battery

Portable Radio

r9927 Issue 2.PMD 3/20/2007, 1:10 PM1

Contents

Contents ...................................................................................................................................................................................... 1

Controls ....................................................................................................................................................................................2-3

Battery Operation ........................................................................................................................................................................ 4

Mains Operation .......................................................................................................................................................................... 4

Operating your radio - FM .......................................................................................................................................................... 5

Operating your radio - Medium and Long wave ......................................................................................................................... 6

Headphones ................................................................................................................................................................................ 7

General ........................................................................................................................................................................................ 7

Specifications ............................................................................................................................................................................. 8

Notes ........................................................................................................................................................................................... 9

Guarantee.................................................................................................................................................................................. 10

r9927 Issue 2.PMD 3/20/2007, 1:10 PM2

If you need any further advice, please call our Technical Helpline on :-

020 8758 0338 (Mon-Fri) 2

Controls

1. On/Off button

2. Waveband buttons

3. Telescopic aerial

4. Tuning control

(Top)

123

45678

5. Treble control

6. Dial pointer

7. Bass control

8. Volume control

r9927 Issue 2.PMD 3/20/2007, 1:10 PM3

Controls

(Rear)

9. Headphone socket (on side)

10. Battery compartment

11. Mains socket

10 11

r9927 Issue 2.PMD 3/20/2007, 1:10 PM4

If you need any further advice, please call our Technical Helpline on :-

020 8758 0338 (Mon-Fri) 4

Battery operation

1. Remove the Battery cover on the rear of the unit by pushing the

battery door in and downwards.

2. Insert four LR14 (C size) batteries into the spaces in the compart-

ment. Take care to ensure all batteries are inserted with the correct

polarity as shown inside the battery compartment. Replace the

battery cover.

3. Reduced power, distortion and a ‘stuttering’ sound are all signs that

the batteries may need replacing.

4. If the radio is not to be used for any extended period of time it is

recommended that the batteries are removed from the radio.

We would recommend for economy that the R9927 is used on the

mains whenever possible with battery operation for occasional or

stand-by use only.

IMPORTANT: The batteries should not be exposed to excessive

heat such as sunshine, fire or the like. After use, disposable

batteries should if possible be taken to a suitable recycling centre.

On no account should batteries be disposed of by incineration.

Mains operation

1. Place your radio on a flat surface.

2. Plug the mains lead into the Mains socket located on the rear of your

radio ensuring that the plug is pushed fully into the socket.

3. Plug the other end of the mains lead into a wall socket and switch

on the wall socket.

IMPORTANT: The mains plug is used as the means of connecting

the radio to the mains supply. The mains socket used for the radio

must remain accessible during normal use. In order to disconnect the

radio from the mains completely, the mains plug should be removed

from the mains socket outlet completely.

r9927 Issue 2.PMD 3/20/2007, 1:10 PM5

Operating your radio FM

1. Switch on your radio by pressing the On/Off button.

2. Press the FM button to select the FM waveband.

3. Adjust the Volume control until a hissing sound is heard.

4. Rotate the Tuning control to select the desired station. On FM the

Tuning scale is marked in Megahertz (MHz).

5. For FM reception fully extend the Telescopic aerial and then angle

and rotate for best reception

6. Adjust the Volume to the required setting.

7. Adjust the Bass and Treble controls to the required settings.

8. To switch off your radio press the On/Off button.

r9927 Issue 2.PMD 3/20/2007, 1:10 PM6

If you need any further advice, please call our Technical Helpline on :-

020 8758 0338 (Mon-Fri)

Operating your radio (Medium and Long wave)

1. Switch on your radio by pressing the On/Off button.

2. Press either the MW or LW button.

3. Adjust the Volume control until a hissing sound is heard.

4. Rotate the Tuning control to select the desired station. On MW and

LW the Tuning scale is marked in kilohertz (kHz).

5. For MW or LW reception rotate your radio to the position giving best

reception.

6. Adjust the Volume to the required setting.

7. Adjust the Bass and Treble controls to the required settings.

Rotating the controls clockwise increases the bass or treble.

8. To switch off your radio press the On/Off button.

Note : The telescopic aerial is inoperative on MW and LW.

Trouble shooting

In case of malfunction due to electrostatic discharge, it may be neces-

sary to reset the product to resume normal operation. This may generally

be performed by turning the unit off and on. In some cases a more

complete reset may be needed, either by removing all sources of power

(battery and mains) when turned off.

r9927 Issue 2.PMD 3/20/2007, 1:10 PM7

Headphones

1. A Headphone Socket (3.5mm) located on the right hand end of

your radio is provided for use with either headphones or an

earpiece. Inserting the headphone plug automatically mutes the

internal loudspeaker.

IMPORTANT: Excessive sound pressure from earphones and

headphones can cause hearing loss.

General

Do not allow this unit to be exposed to dripping or splashing. Do not leave

your radio where excessive heat could cause damage such as in a

parked car where the heat from the sun can build up even though the

outside temperature may not seem too high. It is recommended that the

FM band be used where ever possible as better results in terms of quality

and freedom from interference will usually be obtained than on the MW

or LW bands.

• No objects filled with liquids such as vases, shall be placed on

the radio.

• It is recommended to operate the product such that there is a minimum

distance (10cm recommended) to adjacent objects in order to

ensure good ventilation.

• The ventilation of the product should not be restricted by covering

it or its ventilation openings with items such as newspapers, table-

cloths, curtains etc.

• No naked flame sources such as lighted candles should be placed

on the product.

• It is recommended to avoid using or storing the product at extremes

of temperature. Avoid leaving the unit in cars, on window sills in

direct sunlight etc.

• The name plate is located on the bottom panel.

r9927 Issue 2.PMD 3/20/2007, 1:10 PM8

If you need any further advice, please call our Technical Helpline on :-

020 8758 0338 (Mon-Fri) 8

Specifications

Power Requirements

Mains AC 230 volts, 50Hz only

Batteries 4 x LR14 (C size)

Battery Life

Approx. 80hrs of listening for 4 hours a day at

normal volume using alkaline cells.

Frequency Coverage

FM 87.5-108MHz

MW 522- 1620kHz

LW 144- 281kHz

Circuit Features

Loudspeaker 92mm 4ohms

Output Power 1W into 4ohms

Headphone socket 3.5mm dia

Aerial System FM Telescopic aerial

MW Built-in Ferrite aerial

LW Built-in Ferrite aerial

ROBERTS RADIO LIMITED

PO BOX 130

MEXBOROUGH

SOUTH YORKSHIRE

S64 8YT

The Company reserves the right to amend the specification without notice.

r9927 Issue 2.PMD 3/20/2007, 1:10 PM9

Notes:

r9927 Issue 2.PMD 3/20/2007, 1:10 PM10

If you need any further advice, please call our Technical Helpline on :-

020 8758 0338 (Mon-Fri)

Guarantee

This instrument is guaranteed for twelve months from the date of delivery to the original owner against failure due to faulty workmanship or component

breakdown, subject to the procedure stated below. Should any component or part fail during this guarantee period it will be repaired or replaced free

of charge.

The guarantee does not cover:

1. Damage resulting from incorrect use.

2. Consequential damage.

3. Receivers with removed or defaced serial numbers.

N.B. Damaged or broken telescopic aerials will not be replaced under guarantee.

Procedure:

Any claim under this guarantee should be made through the dealer from whom the instrument was purchased. It is likely that your Roberts' dealer

will be able to attend to any defect quickly and efficiently but should it be necessary the dealer will return the instrument to the Company’s service

department for attention. In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact
