Robin Robin Cyclone User manual

1
Version 1.3

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Fixture exterior view ...................................................................................................... 5
3. Installation....................................................................................................................... 6
3.1 Connection to the mains ............................................................................................ 6
3.2 Rigging the xture ...................................................................................................... 7
3.3 Operating the Robin Cyclone with smoke machines.................................................. 9
3.4 DMX-512 connection................................................................................................ 10
3.5 Ethernet connection ................................................................................................. 11
4. Control menu map........................................................................................................ 13
5. Robin Cyclone - DMX chart ......................................................................................... 16
5.1 Virtual colour wheel - colour mixing chart ................................................................ 23
5.2 Pixels order .............................................................................................................. 24
6. Control menu ............................................................................................................... 28
6.1 Tab " Address" ......................................................................................................... 29
6.2 Tab "Information"...................................................................................................... 30
6.3 Tab "Personality"...................................................................................................... 31
6.4 Tab "Manual Control" ............................................................................................... 33
6.5 Tab "Stand-alone" ................................................................................................... 33
6.6 Tab "Service"............................................................................................................ 34
7. RDM ............................................................................................................................... 36
8. Wireless DMX operation .............................................................................................. 36
9. Error and information messages ................................................................................ 38
10. Technical Specications............................................................................................ 38
11. Maintenance and cleaning......................................................................................... 41
11.1 Replacing fuse ....................................................................................................... 41
12. ChangeLog ................................................................................................................. 41
13. Photometric diagrams................................................................................................ 42
Robin Cyclone

3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR ROBIN Cyclone !
Save it for future reference.
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning
notes written in this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
The Robin Cyclone was designed for indoor use and it is intended for
professional application only. It is not for household use.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS
UNIT!
Make sure that the available voltage is not higher than stated on the rear panel of the xture.
This xture should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the xture from AC power before cleaning, removing or installing the fuses, or any part.
The power plug has to be accessible after installing the xture. Do not overload wall outlets and extension cords
as this can result in re or electric shock.
Do not allow anything to rest on the power cord. Do not locate this xture where the cord may be damaged by
persons walking on it.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the xture and the power
cord from time to time.
Refer servicing to qualied service personnel.
This xture falls under protection class I. Therefore this xture has to be connected to
a mains socket outlet with a protective earthing connection.
Do not connect this xture to a dimmer pack.
LED light emission. Risk of eye injury. Do not look into the beam at a distance of less
than 1 meter from the front surface of the product. Do not view the light output with
optical instruments or any device that may conncentrate the beam
Warning.
With respect to the high frequency interference, this product falls into class A, there-
fore can cause the high frequency interference at home environment. In this case, the
user has to make appropriate steps.
If the xture has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until
it has reached room temperature.

4
Do not shake the xture. Avoid brute force when installing or operating the xture.
This xture was designed for indoor use only, do not expose this unit to rain or use near water.
When choosing the installation spot, please make sure that the xture is not exposed to extreme heat, moisture
or dust.
Secure the blowed objects so that they cannot slide or fall, even if air pressure
during full speed operation of the Robin Cyclone is present.
The openings for xture cooling should never be covered with cloth or other materials, and never must be
blocked.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly faste-
ned.
Always use a secondary safety wire for over head installation of this xture.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the xtu-
re.
Do not block the front objective LEDs with any object when the xture is under operation.
The xture becomes hot during operation. Allow the xture to cool approximately 10 minutes prior to manipulate
with it.
Operate the xture only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the xture. Most damages are the result of unprofessional operation!
Please use the original packaging if the xture is to be transported.
Please consider that unauthorized modications on the xture are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
Never allow any object or part of your body to enter the path of the fan
blades, and ensure that clothing, cables or other items cannot be
sucked into the fan. Position the fan well out of reach of members of the
public.

5
2. Fixture exterior view
The head should be locked for transportation- the tilt lock latch (6) has to be in the locked positions. To unlock
the head, move this latch to unlock position before operating the xture.
The ENTER/DISPLAY ON button also serves for switching the display on when the xture is disconnected
from the mains.
1 - Moving head
2 - Arm
3 - QVGA touch screen
4 - Control buttons
5- Base
6 - Tilt lock
7 - Fan
Rear panel of the base
1 - 5-pin DMX IN
2 - 3-pin DMX IN
3 - Fuse holder
4 - Ethernet input
5 - 5-pin DMX OUT
6 - 3-pin DMX OUT
7 - Power cord

6
3. Installation
Fixtures must be installed by a Qualied electrician in accordance with all
national and local electrical and construction codes and regulation.
3.1 Connection to the mains
For protection from electric shock, the xture must be earthed!
The Robin Cyclone is equipped with auto-switching power supply that automatically adjusts to any 50/60Hz AC
power source from 100-240 Volts.
Install a suitable plug on the power cord, note that the cores in the power cord are coloured according to the
following table. The earth has to be connected!
If you have any doubts about proper installation, consult a qualied electrician.
Core (EU) Core (US) Connection Plug Terminal Marking
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth

7
3.2 Rigging the xture
The installation of the xture has to be built and constructed in a way that it can hold 10 times the weight for 1
hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down if
the main attachment fails.
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the rst time and after changes before taking into operation another time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
The xture should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all installation
material and the projector. If you lack these qualications, do not attempt the installation yourself, but instead
use a professional structural rigger. Improper installation can result in bodily injury or damage to property.
The xture has to be installed out of the reach of people.
If the xture shall be lowered from the ceiling or high joists, professional trussing systems have to be used. The
xture must never be xed swinging freely in the room.
Caution: Fixture may cause severe injuries when crashing down! If you have doubts concerning the safety of
a possible installation, do not install the moving head!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the xture’s
weight.
When installing the device, make sure there is no highly inammable
material (decoration articles, etc.) in a distance of min. 1 m.
CAUTION!
Use an appropriate clamp to rig the xture on the truss.
Make sure that the device is xed properly! Ensure that the
structure (truss) to which you are attaching the xtures is secure.
The xture can be placed only directly on the stage oor or rigged upside down on a truss without altering its
operation characteristics.
Never rig the xture in the side position!
.
.
.

8
For securing a xture to the truss install a safety wire that can hold at least 10 times the weight of the xture.
Use only safety wire with screw-on carabine. Pull the safety wire through the carrying handles and around the
truss as shown on the pictures below.
Note: If the safety wire is too long, whip it several times around the trusss in order to attach the xture tight.
In case of an accident, the way of the falling xture will be short.
Rigging via two Omega holders
Securing the xture using one safety wire Securing the xture using two safety wires
1-Fixture
2-Omega holder
3-Clamp
4-Trust
5-Safety chain

9
3.3 Operating the Robin Cyclone with smoke machines
When using the Robin Cyclone in combination with a smoke machine, fog machine or hazer, place the xture
behind the machine or aside the direct output from the machine , as shown on the pictures below. Do
not place the xture in front of the machine and direct the output from the machine into the xture, as this will
cause undesirable moisture and residue build-up.

10
3.4 DMX-512 connection
The xture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired
in parallel.
Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in
order to connect the controller with the xture or one xture with another.
DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):
If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with the
DMX input of the rst xture in the DMX chain. If you wish to connect DMX controllers with other XLR-outputs,
you need to use adapter cables.
Building a serial DMX-chain:
Connect the DMX-output of the rst xture in the DMX-chain with the DMX-input of the next xture. Always
connect one output with the input of the next xture until all xtures are connected.
Caution: At the last xture, the DMX-cable has to be terminated with a terminator. Solder a 120 Ω resistor be-
tween Signal (–) and Signal (+) into a 3-pin (5-pin) XLR-plug and plug it in the DMX-output of the last xture.
1 - Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1 - Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected

11
3.5 Ethernet connection
The xtures on a data link are connected to the Ethernet with ArtNet communication protocol.The control soft-
ware running on your PC (or light console) has to support Art-Net protocol.
Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP.Its purpose is to allow
transfer of large amounts of DMX 512 data over a wide area using standard network technology.
IP address is the Internet protocol address.The IP uniquely identies any node (xture) on a network.
The Universe is a single DMX 512 frame of 512 channels.
The Robin 300E Wash is equipped with 8-pin RJ- 45 socket for Ethernet input.Use a network cable category 5
(with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect xtures to the hubs or LAN sockets are wired 1:1,that is,pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
If only the xture and the computer are to be interconnected,no hubs or other active components are needed.
A cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
If the xture is connected with active Ethernet socket (e.g. switch) the network icon will appear at the
bottom right corner of the screen:
Direct Ethernet operation
Connect the Ethernet inputs of all xtures with the Ethernet network.
Option “ Artnet (gMaI or gMA2)" has to be selected from “Ethernet Mode” menu on the xture.
Set IP address (002.xxx.xxx.xxx / 010.xxx.xxx.xxx) and the Universe.
(DMX address=46) (DMX address=17) (DMX address=1)
IP addres=002.168.002.004 IP addres=002.168.002.003 IP addres=002.168.002.002
Universe=1 Universe=1 Universe=1
An advised PC setting: IP address: 002.xxx.xxx.xxx / 010.xxx.xxx.xxx (Different from xture IP addresses)
NET mask: 255.0.0.0

12
Ethernet / DMX operation
Option “Art2DMX” has to be selected from the “Ethernet Mode” menu on the rst xture (connected to the
Ethernet) in the xture chain,next xtures have standard DMX setting.
Connect the Ethernet-input of the rst xture in the data chain with the network. Connect the DMX output of
this xture with the input of the next xture until all xtures are connected to the DMX chain.
Caution: At the last xture, the DMX chain has to be terminated with a terminator. Solder a 120 Ω resistor
between Signal (–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last xture.
Example:
DMX address=1 DMX address=17 DMX address=46
IP addres=002.168.002.002
Universe=0
DMX address=1 DMX address=17 DMX address=46
IP addres=002.168.002.003
Universe=1

13
4. Control menu map
Default settings=Bold print
Tab Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Addressing Settings DMX Address 001-255
Ethernet Settings Ethernet Mode Disable
ArtNet
gMAI
gMA2
Art2DMX
IP Address/NetMask Default IP Address
Custom IP Address
Net Mask
ArtNet Universe 0-255
MANet settings MANet I/IIUniverse 1-256
MANet Session ID 1-32
Information Fixture Times Power On Time Total Hours
Resetable Hours
Air Filters Elapsed Time
Alert Period 10-300
Fixture Temperatures LEDs Temperature Current
Maximum NonRes.
Maximum Res.
AmbientTemperature Current
Maximum NonRes.
Maximum Res.
Base Temperature Current
Maximum NonRes.
Maximum Res.
DMX Values Pan
:
Dimmer Fine
Wireless State* Signal Qualityr
Unlink Wireless
Adapter
Software Versions Display System
Module M
Module DR
Module L
Wireless
Product IDs Mac Address
RDM UID
RDM Label
View Logs Fixture Errors
Fixture Status Power On
Power Off
Fixture Position
Fixture Temperatures LEDs Temperature
Ambient Temperature
Base Temperature
Personality User Mode User A Settings
User B Settings
User C Settings
DMX Presets Mode 1
Mode 2

14
Tab Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Mode 3
View Selected Preset
DMX Input Wired
Wireless
Wireless In/XLR Out
Pan/Tilt Settings Pan Reverse Off, On
Tilt Reverse Off, On
Pan/Tilt Feedback Off, On
Pan/Tilt mode Time
Speed
Microphone Sen-
sitivity
1-10-20
Blackout Settings Blackout During M.C. Off, On
Blackout while: Pan/Tilt moving Off, On
Colour Mixing
mode
RGBW, CMY
Dimmer Curve Linear
Theatrical
Zoom Mode Beam
Wash
Colour Calibration
Mode
Off, On
Init Effect Positions Pan 0-255
:
Dimmer Fine 0-255
Screen Settings Display Intensity 1-10
Screen Saver Delay Off-10min.
Touchscreen Lock Off-10min.
Recalibrate Touch-
screen
Display Orientation Normal
Inverted
Auto
Temperature Unit °C,°F
Fan Mode Auto
High
Date & Time Settings
Default Settings
Manual Control Reset Functions Total System Reset
Pan/Tilt reset
Zoom Reset.
Preset Effect Con-
trol
Pan Position 1-Position 5
:
Dimmer Position 1- Position 5
Manual Effect Con-
trol
Pan 0-255
:
Dimmer Fine 0-255
Stand -Alone Test Sequences Dynamic Mode
Static Mode Pan 0-255
Tilt 0-255
Zoom 0-255
MusicTrigger Off, On
Preset Playback None
Test

15
Tab Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
:
Prog. 3
Play Program Play Program 1
Play Program 2
Play Program 3
Edit Program Edit Program 1 Start Step 1-100
End Step 1-100
Edit Program Steps Step 1 Pan (0-255)
: :
:Dimmer Fine
(0-255)
:Step Time
(0-25.5s)
Step 100 Pan (0-255)
:
Dimmer Fine
(0-255)
Fade Time
(0-25.5s)
Service Adjust DMX Values Pan 0-255
:
Dimmer Fine 0-255
Calibrations Calibrate Effects Pan 0-255
Tilt 0-255
Calibrate colours Red 0-255
Green 0-255
Blue 0-255
White 0-255
Temperarure
Calibration
Load Default Calibra-
tions
Update Software

16
5. Robin Cyclone - DMX chart
Version 1.1
Mode/Channel Value Function Type of control
1 2 3
1 1 1 0-255
Pan (8 bit)
Pan movement by 450° proportional
- 2 2 0-255
Pan Fine (16 bit)
Fine control of pan movement proportional
2 3 3 0-255
Tilt (8bit)
Tilt movement by 300° proportional
- 4 4 0-255
Tilt ne (16 bit)
Fine control of tilt movement proportional
3 5 5
0
1
2 - 255
2 - 255
Pan/Tilt speed, Pan/Tilt time
Standard Mode
Max. Speed mode
Pan/Tilt speed
Speed from max. to min.
Pan/Tilt time
Time from 0.2 s to 25.5 s.
step
proportional
proportional
4 6 6
0 - 9
10 - 14
15 - 19
20 - 49
50 - 59
60 - 69
70 - 79
80 - 89
90 - 139
140 - 149
150 - 179
180 - 189
190 - 199
200 - 209
210 - 255
Special functions
Reserved
To activate following functions , stop in DMX value for
at least 3sec. and shutter must be closed at least 3sec.
(Shutter channel 15/22 must be at range of 0-31DMX).
Corresponding menu items are temporily overrided
except DMX Input.
DMX input: Wired DMX *
DMX input: Wireless DMX*
* function is active only10 seconds after switching the xture on
Reserved
Pan/Tilt speed mode
Pan/Tilt time mode
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Reserved
To activate following reset function, stop in DMX value
for at least 3 sec.
Pan/Tilt reset
Reserved
Zoom reset
Reserved
Total reset
Reserved
step
step
step
step
step
step
step
step
step
5 7 7 0
1-255
Fan speed
Rotation=off
Fan speed min.->max..
step
proportional
6 8 8 0-255
Red (8 bit) - all pixels
Red LEDs saturation control (0-100%) proportional
- 9 9 0-255
Red ne(16 bit) - all pixels
Fine red LEDs saturation control proportional
7 10 10 0-255
Green (8 bit) - all pixels
Green LEDs saturation control (0-100%) proportional
- 11 11 0-255
Green ne (16 bit) - all pixels
Fine green LEDs saturation control proportional
8 12 12 0-255
Blue (8 bit) - all pixels
Blue LEDs saturation control (0-100%) proportional
- 13 13 0-255
Blue ne (16 bit) - all pixels
Fine blue LEDs saturation control proportional

17
Mode/Channel Value Function Type of control
1 2 3
9 14 14 0-255
White (8 bit) - all pixels
White LEDs saturation control (0-100%) proportional
- 15 15 0-255
White ne (16 bit) - pixels
Fine white LEDs saturation control proportional
10 16 16 0
1-255
CTO
No function
Colour temperature correction from 15500K to 2700K
step
proportional
11 17 17
0
1-2
3
4-5
6
7-9
10-12
13-15
16
17-55
56
57 - 95
96
97 – 134
135
136 - 174
175
176 -214
215
216 - 246
247
248-251
252-255
Virtual Colour Wheel
For detailed description see " Virtual colour wheel- colour mixing chart
No function
White 2700 K
White 2700 K (tungsten emulation**)
White 3200 K
White 3200 K (tungsten emulation**)
White 4200 K
White 5600 K
White 8000 K
Blue (Blue=full, Red+Green+White=0)
Red=0, Green->up,Blue =full, White=0
Light Blue (Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue->down, White=0
Green (Red=0, Green=full, Blue =0, White=0)
Red->up, Green=full, Blue=0, White=0
Yellow (Red=full, Green=full, Blue=0, White=0)
Red=full, Green->down, Blue=0, White=0
Red(Red=full, Green=0, Blue=0, White=0)
Red=full, Green=0, Blue->up, White=0
Magenta (Red=full, Green=0, Blue=full, White=0)
Red -> down, Green=0, Blue=full, White=0
Blue (Red=0, Green=0, Blue=full, White=0)
Rainbow effect( with fade time) from min.->max. speed
Rainbow effect (without fade time) from min.->max.
step
step
step
step
step
step
step
step
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
proportional
12 18 18 Pixel effects
See table below
13 19 19
0-63
64-127
128-191
192-255
Pixel effects speed
Speed from min. —>max. without fade time
Speed from max. —>min. without fade time (op. direc.)
Speed from min. —>max. with fade time
Speed from max. —>min. with fade time (op. direc.)
proportional
proportional
proportional
proportional
14 20 20 0 - 255
Zoom (8 bit)
Zoom from min. to max. beam angle
proportional
proportional
- 21 21 0 - 255
Zoom ne (16 bit)
Fine zooming from min. to max. proportional
15 22 22
0-31
32-63
64-95
96-127
128-143
144-159
160-191
192-223
224-255
Shutter/Strobe
Shutter closed
Shutter open
Strobe effect from slow--> fast
Shutter open
Opening pulses in sequences from slow--> fast
Closing pulses in sequences from fast--> slow
Shutter open
Random strobe effect from slow--> fast
Shutter open
step
step
proportional
step
proportional
proportional
step
proportional
step

18
Mode/Channel Value Function Type of control
1 2 3
16 23 23 0-255
Dimmer (8 bit)
Dimmer intensity from 0% to 100% proportional
- 24 24 0-255
Dimmer ne (16 bit)
Fine dimming proportional
- - 25 0-255
Red pixel 1
Red LEDs saturation control (0-100%) proportional
- - 26 0-255
Green pixel 1
Green LEDs saturation control (0-100%) proportional
- - 27 0-255
Blue pixel 1
Blue LEDs saturation control (0-100%) proportional
- - 28 0-255
Red pixel 2
Red LEDs saturation control (0-100%) proportional
- - 29 0-255
Green pixel 2
Green LEDs saturation control (0-100%) proportional
- - 30 0-255
Blue pixel 2
Blue LEDs saturation control (0-100%) proportional
- - 31 0-255
Red pixel 3
Red LEDs saturation control (0-100%) proportional
- - 32 0-255
Green pixel 3
Green LEDs saturation control (0-100%) proportional
- - 33 0-255
Blue pixel 3
Blue LEDs saturation control (0-100%) proportional
- - 34 0-255
Red pixel 4
Red LEDs saturation control (0-100%) proportional
- - 35 0-255
Green pixel 4
Green LEDs saturation control (0-100%) proportional
- - 36 0-255
Blue pixel 4
Blue LEDs saturation control (0-100%) proportional
- - 37 0-255
Red pixel 5
Red LEDs saturation control (0-100%) proportional
- - 38 0-255
Green pixel 5
Green LEDs saturation control (0-100%) proportional
- - 39 0-255
Blue pixel 5
Blue LEDs saturation control (0-100%) proportional
- - 40 0-255
Red pixel 6
Red LEDs saturation control (0-100%) proportional
- - 41 0-255
Green pixel 6
Green LEDs saturation control (0-100%) proportional
- - 42 0-255
Blue pixel 6
Blue LEDs saturation control (0-100%) proportional
- - 43 0-255
Red pixel 7
Red LEDs saturation control (0-100%) proportional
- - 44 0-255
Green pixel 7
Green LEDs saturation control (0-100%) proportional
- - 45 0-255
Blue pixel 7
Blue LEDs saturation control (0-100%) proportional
- - 46 0-255
Red pixel 8
Red LEDs saturation control (0-100%) proportional
- - 47 0-255
Green pixel 8
Green LEDs saturation control (0-100%) proportional
- - 48 0-255
Blue pixel 8
Blue LEDs saturation control (0-100%) proportional

19
Mode/Channel Value Function Type of control
1 2 3
- - 49 0-255
Red pixel 9
Red LEDs saturation control (0-100%) proportional
- - 50 0-255
Green pixel 9
Green LEDs saturation control (0-100%) proportional
- - 51 0-255
Blue pixel 9
Blue LEDs saturation control (0-100%) proportional
- - 52 0-255
Red pixel 10
Red LEDs saturation control (0-100%) proportional
- - 53 0-255
Green pixel 10
Green LEDs saturation control (0-100%) proportional
- - 54 0-255
Blue pixel 10
Blue LEDs saturation control (0-100%) proportional
- - 55 0-255
Red pixel 11
Red LEDs saturation control (0-100%) proportional
- - 56 0-255
Green pixel 11
Green LEDs saturation control (0-100%) proportional
- - 57 0-255
Blue pixel 11
Blue LEDs saturation control (0-100%) proportional
- - 58 0-255
Red pixel 12
Red LEDs saturation control (0-100%) proportional
- - 59 0-255
Green pixel 12
Green LEDs saturation control (0-100%) proportional
- - 60 0-255
Blue pixel 12
Blue LEDs saturation control (0-100%) proportional
- - 61 0-255
Red pixel 13
Red LEDs saturation control (0-100%) proportional
- - 62 0-255
Green pixel 13
Green LEDs saturation control (0-100%) proportional
- - 63 0-255
Blue pixel 13
Blue LEDs saturation control (0-100%) proportional
- - 64 0-255
Red pixel 14
Red LEDs saturation control (0-100%) proportional
- - 65 0-255
Green pixel 14
Green LEDs saturation control (0-100%) proportional
- - 66 0-255
Blue pixel 14
Blue LEDs saturation control (0-100%) proportional
- - 67 0-255
Red pixel 15
Red LEDs saturation control (0-100%) proportional
- - 68 0-255
Green pixel 15
Green LEDs saturation control (0-100%) proportional
- - 69 0-255
Blue pixel 15
Blue LEDs saturation control (0-100%) proportional
- - 70 0-255
Red pixel 16
Red LEDs saturation control (0-100%) proportional
- - 71 0-255
Green pixel 16
Green LEDs saturation control (0-100%) proportional
- - 72 0-255
Blue pixel 16
Blue LEDs saturation control (0-100%) proportional
- - 73 0-255
Red pixel 17
Red LEDs saturation control (0-100%) proportional
- - 74 0-255
Green pixel 17
Green LEDs saturation control (0-100%) proportional

20
Mode/Channel Value Function Type of control
1 2 3
- - 75 0-255
Blue pixel 17
Blue LEDs saturation control (0-100%) proportional
- - 76 0-255
Red pixel 18
Red LEDs saturation control (0-100%) proportional
- - 77 0-255
Green pixel 18
Green LEDs saturation control (0-100%) proportional
- - 78 0-255
Blue pixel 18
Blue LEDs saturation control (0-100%) proportional
- - 79 0-255
Red pixel 19
Red LEDs saturation control (0-100%) proportional
- - 80 0-255
Green pixel 19
Green LEDs saturation control (0-100%) proportional
- - 81 0-255
Blue pixel 19
Blue LEDs saturation control (0-100%) proportional
- - 82 0-255
Red pixel 20
Red LEDs saturation control (0-100%) proportional
- - 83 0-255
Green pixel 20
Green LEDs saturation control (0-100%) proportional
- - 84 0-255
Blue pixel 20
Blue LEDs saturation control (0-100%) proportional
- - 85 0-255
Red pixel 21
Red LEDs saturation control (0-100%) proportional
- - 86 0-255
Green pixel 21
Green LEDs saturation control (0-100%) proportional
- - 87 0-255
Blue pixel 21
Blue LEDs saturation control (0-100%) proportional
- - 88 0-255
Red pixel 22
Red LEDs saturation control (0-100%) proportional
- - 89 0-255
Green pixel 22
Green LEDs saturation control (0-100%) proportional
- - 90 0-255
Blue pixel 22
Blue LEDs saturation control (0-100%) proportional
- - 91 0-255
Red pixel 23
Red LEDs saturation control (0-100%) proportional
- - 92 0-255
Green pixel 23
Green LEDs saturation control (0-100%) proportional
- - 93 0-255
Blue pixel 23
Blue LEDs saturation control (0-100%) proportional
- - 94 0-255
Red pixel 24
Red LEDs saturation control (0-100%) proportional
- - 95 0-255
Green pixel 24
Green LEDs saturation control (0-100%) proportional
- - 96 0-255
Blue pixel 24
Blue LEDs saturation control (0-100%) proportional
**In the Halogen lamp mode the Dimmer channel imitates behaviour of the halogen lamp during dimming.
