ROBINHOOD Rangehood User manual

WARNING
•This appliance is not intended for use by young children or infirm persons
without supervision.
•Young children should be supervised to ensure that they do not play with the
appliance.
•There shall be adequate ventilation of the room when the rangehood is used at
the same time as appliances burning gas or other fuels.
•You must read the details concerning the method and frequency of cleaning.
(Refer to Maintenance Instruction)
•There is a fire risk if cleaning is not carried out in accordance with the
instructions. (Refer to Maintenance Instruction)
•Do not flambé under the rangehood.
•Exhaust air must not be discharged into an existing flue which is used for
exhausting fumes from appliances burning gas or other fuels.
•The minimum distance between the hob surface and the lowest part of the
range hood is 600mm. This distance shall be at least 650mm if the range
hood is installed over a gas hob.
•Attention should be given to ensure that any applicable regulations concerning
the discharge of exhaust air are fulfilled.
•If the supply cord of this equipment is damaged, it must only be replaced by
the manufacturer or its service agent or similarly qualified person in order to
avoid a hazard.
IMPORTANT:
THESE RANGEHOODS ARE NOT SUITABLE
FOR BARBEQUES, OPEN ROTISSERIES,
OR IN A COMMERCIAL APPLICATION
4
INSTALLATION INSTRUCTION
RANGEHOOD
Note: Generic model is shown.
Actual product may differ.
All dimensions are in millimeters
PRODUCT DIMENSIONS
274 (600 Model)
449 (900 Model)
72
239
10
73
488 (600 Model)
663 (900 Model) 258
80
285
520 (600 Model)
696 (900 Model)
Ducting Adaptor
provided to connect
Ø150mm Ducting System
103805 Issue E
ECN: 07 007
1
Ø150mm to
Ø125mm
Reducer
Visit our Website at:
Electrical Rating:
240W (1.00A) Max. at 240V 50Hz
YEARS
WARRANTY
2
distributed by
ROBINHOOD Ltd
P.O. Box 51 201, Pakuranga
Auckland, New Zealand
TEL: [phone]
FAX: [phone]
ISO9001 Certified
email: [email protected]
for service of advice in Australia contact
Robinhood Pty Ltd A.C.N 079 616 550
P.O. Box 3065, Syndal 3149
Victoria, Austrailia
TEL: [phone]
FAX: [phone]
email: [email protected]
RECOMMENDS UNIDUCT DUCTING SYSTEMS
FOR RANGEHOODS
www.robinhood.co.nz

INSTALLATION OF UNIT
Please read the entire instruction before installing the rangehood.
The following steps will help you to easily install your
rangehood in the manner most suited to your kitchen.
Plan your ducting method and mounting arrangements,
choose your electrical connection, then simply follow
these instructions.
When installing the rangehood, the lower edge of the unit
must be a minimum of 600mm (650mm for gas cooker)
above the cooking range.
The recommended position for the hood is 650mm
above the hotplates.
STEP 1. PRELIMINARY INSTRUCTIONS
STEP 2. MOUNTING THE RANGEHOOD
Fit the exhaust adaptor to the rangehood using
the short screws suppllied.
Provide an opening on the underside of the cupboard
to suit models. Provide 489mm x 259mm for 600
Model or 664mm x 259mm for 900 Model.
Remove the face plate by undoing the
two visible screws to access the
mounting holes. Note: there are
eight mounting holes.
Lift the rangehood and fit
through the opening. Secure
using long screws supplied.
Refit face plate.
600-800
For Gas 650-800
Panel
Cupboard
Opening to
suit models
Face Plate
Mounting holes
Additional fixing maybe done by installing a panel
into the cupboard above the rangehood. In the top
of the rangehood, drill two holes on either side of
the motor. Locate holes to suit panel. Ensure
clearance is made for the exhaust adaptor. Secure
the rangehood into the top panel.
2103805 Issue D
ECN: 07 007
MAINTENANCE
USE & CARE GUIDE
Thank you for choosing our product. These instructions will help you derive the greatest benefit from it.
Please remember to fill out the details on the warranty certificate.
LIGHT
The light is controlled by an ON/OFF switch in accordance with the graphics printed on the control panel.
FAN
The fan is controlled by a switch in accordance with the graphics printed on the control panel.
REPLACEMENT OF LIGHT GLOBE
To replace the globe, disconnect rangehood from power supply, remove the filter, reach inside the rangehood
and remove light bulb. Replace with 40 Watt light bulbs.
GENERAL MAINTENANCE
The rangehood should be cleaned regularly using warm water with soap or mild liquid detergents, so that no
build-up of grease occurs as these deposits are corrosive. Do not use abrasives or harsh detergents/cleaning
fluids.
FILTER MAINTENANCE
To maintain efficiency, the Aluminium Filter P/N 103818 (600 Model) or P/N 103824 (900 Model) should be
removed regularly (approximately monthly), and washed using soap or mild detergents or dishwasher powders.
Badly smoked filters may be cleaned with “cookware cleaners”.
Rangehoods fitted with Charcoal Filter Disc P/N 103819 are designed to remove grease and odours from cooking
vapours, prior to the cleansed air re-entering the kitchen (when the Rangehood is in recirculating mode). Fully
saturated charcoal filters can become a barrier to air movement therefore impeding Rangehood performance.
Alsoin theevent offire, fullygrease ladenfilters couldbe flammableand thereforeregular replacementis recommended.
Under normal conditions a period of about three months. In ducted installations, conventional aluminium filters are
recommended.
DUCTING OPTIONS
STEP 3. DUCTING METHODS
Some authorities require rangehoods to be vented outside. DUCTED models comply with this requirement in
every respect.
TOP DUCTING THROUGH ROOF SIDE DUCTING RECIRCULATING
(use Charcoal Filter Discs mounted
either side onto the Motor)
3
It is recommended that Ø150mm ducting is to be used, however a reducer from Ø150mm to Ø125mm is
supplied should Ø125mm be required.
