ROBINHOOD RIWC9PLUS User manual

ARCO PLUS WALL
APPROVED Page 1 of 8
ISSUE: B
ECN 07 033
CANOPY RANGE HOOD
MODEL
RIWC9PLUS

ARCO PLUS WALL
APPROVED Page 2 of 8
ISSUE: B
ECN 07 033
ITEM
DESCRIPTION PART
NUMBER
1 METAL FILTER ARCO CURVO 1142 3
6 LOWER CHIMNEY PLUS UAP74 1142 4
7 LEFT DIRECTIONAL GRID 114188
8 RIGHT DIRECTIONAL GRID 114187
9 UPPER CHIMNEY PLUS H21 1142
12 PLUG S8 114190
18 SPACER RICICLING CONNECTION 114193
19 RICICLING CONNECT. PARTICULAR 11419
22 ARCO PLUS WALL GLASS 1142 7
27 SPOT LIGHT SUPPORT 1142 8
28 SPOT LIGHT SUPPORT X DIRECT 114006
29 FEMALE PLUG BOX 2 WAYS 114017
30 MALE PLUG BOX 2 WAYS 114009
31 LAMP HOLDER 114007
32 HALOGEN LAMP 12V 20W 11400
100 SWITCH ASSEMBLY 1142 9
102 PUSH BUTTON PANEL BOX COVER 114041
103 M8 PUSH BUTTON PANEL (220V) 114042
104 PUSH BUTTON BOX 114043
10 PILOT LAMP 114260
106 BUTTON 0-1 CR SAT D8 114261
107 PLUG 2-3V CR SAT D8 114262
110 PUSH BUTTON FRAME 114263
300 MOTOR ASSEMBLY 114264
304 CONDENSER 4MF 400V 11426
310 SX D140 M8 ROTOR 114266

ARCO PLUS WALL
APPROVED Page 3 of 8
ISSUE: B
ECN 07 033
ITEM
DESCRIPTION PART
NUMBER
314 DX D140 M8 ROTOR 114267
316 AIR ENTRY RIGHT FLANGE 114268
320 AIR ENTRY LEFT FLANGE 114269
600 POWER PACK STILO/2 PRO/HI-LO 114270
606 FIXING KIT 114211
626 TRANSFORMER 40VA (40W) 114228
SOME COMPONENTS ARE NOT AVAILABLE OUTSIDE PRODUCTION.
