ROBLON RobLight Ara 2 Series User manual

RobLight accepts no responsibility for possible errors in catalogues, brochures and other printed m aterial.
RobLight reserves the right to alter or discontinue its products w ithout notice. © 2019 RobLight A/S
RobLight A/S, Nordhavnsvej 1A, DK-9900 Frederikshavn
T: [phone], E: info@ rob-lig h t.c o m
www.rob-lig h t.c o m
99082093, 15-06-2021, Rev. 1.2
Troubleshooting
Problem Trace the problem Solution
No light
Check the pow er Connect the pow er cord properly and
tu rn o n th e d e vice
Check the w iring
Unplug the m ain. Check connectors on
th e co n n e ctio n s tre e is a tta ch e d to a
product or a jum per.
Turn on the pow er
Check the dim m ing
Unplug the m ain. Unplug the dim m er
syste m from th e d rive r.
Turn on the pow er
Light output has
dim inished
Check if the light has
been dim m ed via a
dim m er?
In c re a s e b rig h tn e ss t o t h e n o rm a l le v e l
Check the operating
conditions of the
lig h t e n g in e
If t h e lig h t e n g in e h a s b e e n ru n n in g a t
elevated tem peratures for an extended
tim e , a d e cre ase in th e o u tp u t w ill b e
observed
User m anual
Ara 2 Series

Product overview /unboxing
1 Ara 2
1 U ser m anual
In s ta lla t io n in s tr u c t io n s
Follow the installation instructions to ensure
· Safe operation
· Full functionality
· Stated expected lifetim e
· Uninterrupted illum ination
Applies to :
1143 3210 Ara 2 70 3000K-G1 black
1143 3220 Ara 2 70 3000K-G1 grey
1143 3230 Ara 2 70 3000K-G1 white
1143 3211 Ara 2 70 3000K-G2 black
1143 3221 Ara 2 70 3000K-G2 grey
1143 3231 Ara 2 70 3000K-G2 white
Application notes
The light generator is an electronic device and m ust be handled accordingly. The
different com ponents w ill have different factors influencing the practical lifetim e.
The m ost im portant factor for this system is the condition of the surrounding air
(te m p e ra tu re a n d cle a n lin e ss). T h e d a ta w e h a v e sta te d a b o u t o r a n d th e e xp e c te d
life tim e o f th e k e y c o m p o n e n ts, a re a t th e t e m p e ra tu re s th a t th e su p p lie rs h a v e
perform ed during their standardized tests in clean environm ents.
The light generator is designed to run at m ax am bient tem perature, but the longest
usable operation is achieved w ith low er tem peratures.
Although there is therm al protection built into this device, it is only a safety device
and should not be used as a m easurem ent device to test if the light generator is
ru n n in g a t a to le ra b le su rro u n d in g te m p e ra tu re .
The polyconnector is the m ost stressed part of this system .
Care should be taken to ensure that the fibre ends are 100% clean and free from
dust and grease (fingerprint w ill do dam age.). See w w w .rob-lig h t .c o m fo r re c o m -
mendations to clean fibre ends.
Running the light generator at too high tem peratures w ill not only risk dam age to
th e ligh t so u rce b u t a lso to th e fib re h a rn e ss.
CLEAN AIR
KEEP COOL
Maintenance, spare parts & repairs
The cooling for this device is dependant that the m etal surface is clean and free
fro m d u st. T h e p ro d u c t c a n b e cle a n e d w ith a so ft b ru sh o r lo w p re ssu re c le a n e d
and dry com pressed air. If a vacuum cleaner is applied arrangem ents to rem ove
sta tic e le ctricity m u st b e d o n e .
The lens can be changed as show n in this m anual. Take care not to dam age or soil
th e le n se s w h e n h a n d lin g / cle a n in g. T a ke ca re n o t to to u ch th e LED w h e n th e p rod -
uct is open.
This product is not supposed to be otherw ise serviced, if it is used as recom m end-
ed.
If t h e p ro d u c t is n ’t p e rfo rm in g a s sp e cifie d , u se th e tro u b le sh o o tin g g u id e . If yo u
need further assistance please contact our office.
If n e e d e d t h e L e d m o d u le c a n b e c h a n g e d b y a tra in e d t e c h n ic ia n .
Phone: [phone]
E-mail: info@rob-lig h t.c o m

Part nam e Description Ordering
CCT Filter A –500KWill make the light warmer.
Will not fade.
No tools needed
+0126 1000
CCT Filter A –900KWill make the light warmer.
Will not fade.
No tools needed
+0126 1002
CCT Filter A –1200KWill make the light warmer.
Will not fade.
No tools needed
+0126 1001
Colour Filter, FL1000,
yellow
Yellow colour filter. G lass.
Will not fade. No tools needed
+0126 1004
Colour Filter, FL1000,
green
Green colour filter. Glass. W ill
not fade. No tools needed
+0126 1005
Colour Filter, FL1000,
blue
Blue colour filter. G lass. W ill
not fade. No tools needed
+0126 1006
Colour Filter, FL1000,
re d
Red colour filter. Glass. W ill
not fade. No tools needed.
+0126 1007
Colour W heel kit User attachable kit for m ake
your fibres light in sparkling
colours.
+0126 6105
Dim m er 1-10V
(p o te n tio m e te r)
Attach it to the driver and the
product can be dim m ed
+0126 5110
Tw inkling W heel kit User attachable kit to m ake
your fibres tw inkle.
+0126 6205
Accessories
Part nam e Description Ordering
Lens A 10° black
Lens A 10° grey
Lens A 10° w ihte
Spot 10
1148 0100
1148 0105
1148 0106
Lens A 20° black
Lens A 20° grey
Lens A 20° w ihte
Narrow 20
1148 0300
1148 0305
1148 0306
Lens A 30° black
Lens A 30° grey
Lens A 30° w ihte
Medium 30
1148 0500
1148 0505
1148 0506
Lens A 48°/8° black
Lens A 48°/8° grey
Lens A 48°/8° w hite
Oval 48/8
1148 0400
1148 0405
1148 0406
Lens tool A For m ounting/rem oving lenses 1148 0007
Filter clip A black Mounting ring for colour filters 1148 0006
Driver set 2A 3W
700 m A. Plug-and-play LED
driver
1-2 connections
1148 0001
Driver set 2A 15W
700 m A. Plug-and-play LED
driver
4-8 connections
1-10 V dim m ing
1148 0002
Ara snoot 50 m m black 1148 8016
Filter
Colour filter
Ø28*0,4 m m On request
Barn doors Ara black 1148 8012
General
Material Alum inium
Dim ensions (L x H x W ) Ø50 x 33 m m
Dist. betw een driver and LED 2m standard, other lengths on request
Weight (total) 80 g
Safety CE, RoHS, W EEE
Eletrical topology Serial connection
Environm ental
Protection rating IP 2 0
Cooling Natural convection
Am bient tem perature 40°C
Driver/electrical
Driver LED driver constant current
Driver size (L x H x W ) Depends on driver solution (see accessories)
Supply voltage (m ains) 100–240V 50-60 H z
Driver expected lifetim e >50000h
Dim m er system s applicable 1-10V, PU SH (m ains)
LED current
Total pow er consum ption 2.4W
Light source
Applied LED Cree
LED expected lifetim e >50000h @ Ta=25°C
Typical CCT 3000K, other CCT on
re q u e st
Typical Ra (CRI
1-8
) 90
500 m a DC (±5%)
Technical data

Surface m ounting
Ø 40 mm
Make a Ø40 mm hole Install Ara using the springs
Connect main power
(100-240V)
Connect driver.
Driver with multiple
connections use
jumper if not in use
Min 15 mm
The Ara 1 requires some free space for
installation, between the light source and
ceiling.
In s ta llin g a c c e s s o r ie s
Lens m ounting
When adjusting the 48°/8° lens use the narrow
end of lens tool A (accessories)
You can mount a film filter using filter clip A (accessories).
Dimension : Ø28*0.4 mm (Max thickness 1.5 mm)
To ensure the most durable solution only use filters from recognized suppliers. (Lee,
Rosco, etc)
Place the filter in the holder
and press the holder onto the
lens
Press
Easily mount the lens by screwing it into the fitting
NB. The film technology is not a du-
rable solution and will fade.
Dont touch the lens surface.
