RoboBuilder RBX-BTCONT-01 User manual

1. Introduction
Joypad Remote Controller Board can control RoboBuilder by wireless, which is using Joypad for Games.
2. Part List
① Joypad Remote Controller Board 1 EA
② Bluetooth Module 2 EA
③ Battery Holder 1 EA
④ Screw for fixing board 2 EA
⑤ Nut for fixing battery holder 2 EA
⑥ Bolt for fixing battery holder 2 EA
⑦ two Sockets for the installation of item ②
※ NOTE :
1. Joypad is not included in Part List. Original Sony Playstation 2 Joypad is strongly recommended.
Some other Joypad works, however, we do not gurantee with other Joypad.
2. RoboBuilder does not take any responsibility of physical injuries or damages during assembling.
3. Installation
① Required parts
SONY PlayStation 2 Joypad 1 EA
AAA Battery 4 EA
Bluetooth Kit (RBX-BLTOOTHCOM) 1 EA
② Unscrew the bolt as shown in the below, then fix Joypad Remote Controller Board by using 2 screws for fixing board
Joypad Remote Controller KIT (RBX-BTCONT-01) Manual
August 20th, 2008, RoboBuilder co., Ltd.
①
②③
④
⑤
⑥
⑦

③ Leave Joypad Cable 5~6 cm length and cut the rest parts, then remove each line coating 1~2 mm.
④ In order to make it easy to solder, put some lead on each edge of lines in advance.
⑤ Check out each pin No. and color by using Multi-meter.
※ The color can be different in accordance with parts.
-
Green
8
9
Color
Brown
Orange
Grey or Purple
Black
Red or Pink
Yellow
Blue
4
5
6
7
Pin No.
1
2
3
1
2
3
4
5
6
7
98

⑥ Solder each Joypad line onto the board as shown in the below.
⑦ Insert Battery (Battery is not provided.) into Battery holder, then connect to the board.
You can check the red LED lights after power on. Green LED lights whenever Joypad buttons
are pressed.
※ Unlike the above picture, "×", "○", "△" button is used for combination key, green LED
does not light.
※ If Joypad LED(green) does not light, please check out the followings.
1) Check out PIN No. and Color.
2) Check out Soldering whether it was soldered properly.
⑧ Fix the line and board by using glue-gun, if the operation works properly.
19

⑨ Fix the battery pack as shown in the below by using screw bolt and nut.
⑩ Equip with Battery and Bluetooth module, Completed!

⑪ Unscrew and remove the four screws on the corners of the RBC control box.
Remove the rear plastic cover and separate the battery connector.
⑫ Unscrew and remove the two screws holding the circuit board to the front cover.
⑬ Separate and turn over the circuit board.
Insert the two sockets to prepare for the installation of the bluetooth board.
There are one 3-pin socket and one 4-pin socket included in the kit.
The 3-pin socket is inserted as shown below (be cautious about its position and direction).

⑭ Turn over the circuit board and solder the seven pins of the two sockets.
⑮ Install the bluetooth board on the two sockets as shown below (be cautious about its direction).
Assemble the RBC control box to complete the installation. Follow the steps ⑫ and ⑪ reversely.

4. How To Use Joypad
① Buttons disposition
② Command No. table
Send the command to RoboBuilder through Bluetooth module by wireless when buttons are pressed.
Command No. IR Remocon Button Joypad Button Command No. IR Remocon Button Joypad Button
0x01 A Select 0x21 * + 1 ○ + Up
0x02 B Start 0x22 * + 2 ○ + Right
0x03 L1 0x23 * + 3 ○ + Down
0x04 Up 0x24 * + 4 ○ + Left
0x05 R1 0x25 * + 5 ○ + L1
0x06 Left 0x26 * + 6 ○ + L2
0x07 ■□0x27 * + 7 ○ + R1
0x08 Right 0x28 * + 8 ○ + R2
0x09 L2 0x29 * + 9 ○ + Select
0x0A Down 0x2A * + 0 ○ + Start
0x0B R2 0x2B # + A
0x0C 1 × + Up 0x2C # + B
0x0D 2 × + Right 0x2D # +
0x0E 3 × + Down 0x2E # +
0x0F 4 × + Left 0x2F # +
0x10 5 × + L1 0x30 # +
0x11 6 × + L2 0x31 # + ■
0x12 7 × + R1 0x32 # +
0x13 8 × + R2 0x33 # +
0x14 9 × + Select 0x34 # +
0x15 0 × + Start 0x35 # +
0x16 * + A 0x36 # + 1 △ + Up
0x17 * + B 0x37 # + 2 △ + Right
0x18 * + 0x38 # + 3 △ + Down
0x19 * + 0x39 # + 4 △ + Left
0x1A * + 0x3A # + 5 △ + L1
0x1B * + 0x3B # + 6 △ + L2
0x1C * + ■ 0x3C # + 7 △ + R1
0x1D * + 0x3D # + 8 △ + R2
0x1E * + 0x3E # + 9 △ + Select
0x1F * + 0x3F # + 0 △ + Start
0x20 * +
Up
Down
Left Right
Select Start
Analog
L1
L2
R1
R2
△
○
□
×
L-STICK R-STICK

③ LED Indication
BLUETOOTH : Blue LED lights when Bluetooth communication is connected.
POWER : Power ON Indication (Red LED lighting)
JOYPAD : Joypad communication (Green LED blinks)
5. Circuit Diagram
※ NOTE : U3, CN6 is for acceleration sensor expansion part, and this does not included.
BLUETOOTH
POWER
JOYPAD
