Robot Coupe Mini MP 170 V.V. User manual

Mini MP 170 V.V.
Mini MP 220 V.V.
Mini MP V.V. - Couv 19/09/03 15:17 Page 1

3
SUMMARY
WARRANTY
IMPORTANT WARNING
YOU HAVE JUST PURCHASED
A MINI POWER MIXER
SWITCHING ON THE APPLIANCE
• Advice on electrical connections
OPERATING THE APPLIANCE
• Starting and stopping the power mixer
• Variable-speed operation
WORKING POSITION
ASSEMBLING / DISMANTLING
USES & EXAMPLES
HYGIENE
CLEANING
• Motor unit
• Foot and bell
• Blades and emulsifying disc
MAINTENANCE
• Blades
• Foot seal
TECHNICAL SPECIFICATIONS
• Weight
• Dimensions
• Working height
• Noise level
• Electrical data
SAFETY
PROBLEMS
STANDARDS
TECHNICAL DATA
• Exploded views
• Electrical and wiring diagrams
Mini MP ANGLAIS 17/11/04 17:26 Page 3

4
ROBOT-COUPE S.N.C., LIMITED WARRANTY
Your new ROBOT-COUPE appliance
is warranted to the original buyer
for a period of one year from the
date of sale if you bought it from
ROBOT-COUPE S.N.C.
If you bought your ROBOT-COUPE
product from a distributor your
product is covered by your distri-
butor’s warranty (Please check
with your distributor terms and
conditions of the warranty).
The ROBOT-COUPE S.N.C.limited
warranty is against defects in
material and/or workmanship.
The ROBOT-COUPE S.N.C.warranty
is given expressly and in lieu of all
other warranties, expressed or
implied, for merchantability and
for fitness toward a particular pur-
pose and constitutes the only war-
ranty made by ROBOT-COUPE
S.N.C.France.
THE FOLLOWING ARE NOT
COVERED BY THE ROBOT-COUPE
S . N . C .WARRANTY:
1 - Damage caused by abuse, misuse,
dropping, or other similar damage caused by
or resulting from failure to follow assembly,
operating, cleaning, user maintenance or
storage instructions.
2 - Labour to sharpen and/ or replacements for
blades which have become blunt, chipped or
worn after a normal or excessive period of use.
3 - Materials or labour to replace or repair
scratched, stained, chipped, pitted, dented or
discoloured surfaces, blades, knives, attachments
or accessories.
4 - Any alteration, addition or repair that has
not been carried out by the company or an
approved service agency.
5 - Transportation of the appliance to or from
an approved service agency.
6 - Labour charges to install or test new attach-
ments or accessories (i.e., bowls, discs, blades,
attachments) which have been arbitrarity replaced.
7 - The cost of changing direction-of-rotation of
electric motors (Installer is responsible).
8 - SHIPPING DAMAGES. Visible and latent
defects are the responsibility of the freight
carrier. The consignee must inform the carrier
and consignor immediately, or upon discovery in
the case of latent defects.
KEEP ALL ORIGINAL CONTAINERS AND
PACKING MATERIALS FOR CARRIER INSPEC-
TION.
Neither ROBOT-COUPE S.N.C. nor its affiliated
companies or any of its distributors, directors,
agents, employees, or insurers will be liable for
indirect damage, losses, or expenses linked to
the appliance or the inability to use it.
Mini MP ANGLAIS 17/11/04 17:26 Page 4

5
UNPACKING
•WARNING - some of the tools are very sharp e.g.
blades, etc..
INSTALLATION
•We recommend that you install your appliance on
its wall frame.
CONNECTION
•Always check that your mains supply corresponds
to that indicated on the identification plate on the
motor unit and that it can withstand the amperage.
•Never plug your appliance into the mains supply
before placing it inside the preparation bowl.
HANDLING
•Always take care when handling the blades, as
they are extremely sharp.
ASSEMBLY PROCEDURES
•Follow the various assembly procedures carefully
(see page 7) and make sure that all the attach-
ments are correctly positioned.
USE
• Never try to override the safety systems
• Never insert an object into the preparation.
• Never switch the appliance on unless it has been
placed in the preparation bowl.
• Before dismantling the foot, bell or whisk always
check that the power mixer is unplugged.
• We recommend that you tilt the appliance at
a slight angle to prevent the bell from touching the
bottom of the container.
CLEANING
• As a precaution, always unplug your appliance
before cleaning it.
IMPORTANT WARNING
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
WARNING
WARNING : In order to limit accidents such as electric shocks or personal injury, and in order to limit material damage due to misuse
of the appliance, please read these instructions carefully and follow them strictly. Reading the operating instructions will help you get to
know your appliance and enable you to use the equipment correctly. Please read these instructions in their entirety and make sure that
anyone else who may use the appliance also reads them beforehand.
WARNING
Procedure to follow if the stick blender is accidentally
immersed during use.
1) Do not touch either the power mixer, the bowl or the
work surface.
2) Unplug the mixer’s power cord from the wall socket.
3) Remove the power mixer from the preparation.
4) Tilt the power mixer to drain off as much liquid as
possible.
5) Do not switch the power mixer back on, as there is
still a risk of electrocution.
6) Send the power mixer to a Robot-Coupe approved
after-sales service to have the electrical components
cleaned and dried.
• Always clean the appliance and its attachments at
the end of each cycle.
• Never immerse the motor unit in water.
• For parts made from aluminum, use cleaning
fluids intended for aluminum.
• For plastic parts , do not use detergents that are
too alkaline (e.g., containing too much caustic soda
or ammonia).
• Robot-Coupe can in no way be held responsible for
the user’s failure to follow the basic rules of cleaning
and hygiene.
MAINTENANCE
• Before opening the motor housing, it is absolutely
vital to unplug the appliance.
• Check the seals and washers regularly and ensu-
re that the safety devices are in good working order.
• It is particularly important to maintain and check
the attachments since certain ingredients contain
corrosive agents, e.g. citric acid.
• Never operate the appliance if the power cord
or plug has been damaged or if the appliance fails
to work properly or has been damaged in any way.
• Do not hesitate to contact your local Maintenance
Service if something appears to be wrong.
Mini MP ANGLAIS 17/11/04 17:26 Page 5

6
YOU HAVE JUST PURCHASED
A MINI POWER MIXER
The new Mini MP 170 V.V. and Mini MP 220 V.V.
models are the latest additions to Robot-Coupe’s
range of power mixer. They have been specially
designed for processing smaller quantities. They are
fitted with a foot, blades and an emulsifying disc
which can be entirely dismantled, and their tubes
measure 170 and 220 mm long respectively.
These power mixer are tools which are totally adapted
to the needs of professionals. They will enable you
to make soups, vegetables purées and cereal
preparations without any effort.
The variable-speed function will enable you to
adjust the speed to suit each preparation and to
start the processing at a lower speed in order to
reduce splashing.
The simple design of these appliances allows the
assembly and dismantling of the moving parts in no
time at all, to ease maintenance and cleaning.
These instructions contain important information
that will enable you to extract the greatest return on
your investment.
We therefore strongly advise you to read these
instructions carefully before using the appliance.
SWITCHING ON
THE APPLIANCE
•ADVICE ON ELECTRICAL CONNECTIONS
This class II appliance (double insulation) requires
a single-phase alternating current but does not
need an earthed socket. The universal-type motor
is fitted with an interference suppressor.
The power supply must be protected by a
differential circuit breaker and a 10 A fuse.
Check that you have a standard 10/16 A
single-phase socket.
Make sure that the voltage of your power supply
matches that shown on the identification plate of
your appliance.
Robot-Coupe supplies these models with different
types of motors:
230 V / 50 Hz for power supplies
of : 220 à 240 V.
120 V / 60 Hz
220 V / 60 Hz
The power mixer is supplied with a single-phase
plug connected to a power cord.
OPERATING THE APPLIANCE
• STARTING AND STOPPING
1. Plug your appliance
into the mains, making
sure you do not press
the button (BC).
2. Insert the foot into
the preparation.
3. Press the control
button (BC), and the
power mixer will start
up.
4. To stop the power
mixer, release the
control button (BC).
• VARIABLE-SPEED OPERATION
Follow steps 1 to 4 above, then:
5. Change the speed of the motor by turning the
variable speed button (MV) towards the maximum
or minimum as required.
Variable-speed : Speed between 2000 and
12500 rpm.
With the self-regulating speed system, once you
have selected a speed, it will remain constant, even
if the consistency of your mixture changes.
WORKING POSITION
For a more ergonomic
approach, we recom-
mend that you hold the
handle of the appliance in
one hand and the contai-
ner in the other. It is a
good idea to lean forward
slightly, making sure that
the bell does not touch the
bottom of the container.
Always make sure that the
bell is sufficiently immersed to avoid splashing and
that the air vents of the motor unit does not come into
contact with any liquid.
For optimum efficiency, two thirds of the foot should
be immersed in the preparation.
Mini MP ANGLAIS 17/11/04 17:26 Page 6

7
ASSEMBLING/
DISMANTLING
• BLADE FUNCTION
Attaching the tube to the motor unit.
- Check that the appliance is not plugged in.
- Insert the threaded section right into the
housing of the motor unit.
- Turn the tube in the direction of the arrow
(see figure) until it is locked into place moderately
tightly.
B
A
Removing the tube from the motor unit
- Check that the appliance is unplugged.
- Turn the tube in the opposite direction to when you
assembled it until it is completely unscrewed.
Attaching the bell to the tube
- Check that the machine is not plugged in.
- Insert the threaded section into the housing
of the bell. Turn the bell in the direction of the
arrow (see drawing) until it starts to tighten.
B
A
Removing the bell from the foot
- Check that the machine is not plugged in.
- Turn the bell in the direction of the arrow (see
drawing) to detach it from the tube.
Removing the blade
- To remove the blade safely, hold them with the tool
provided or an oven glove or a thick cloth.
- Using the removal tool, unscrew the drive
coupling.
- As soon as the drive coupling has been unscrewed,
the blade can be removed for cleaning.
A
B
A
B
TURN TO REMOVE BELL
TURN TO ATTACH BELL
Installing the emulsifying disc
-In order to install it safely, introduce the disc into
the bell, then hold it in place using the locking
tool.
- Next, turn the drive coupling with this tool until it
starts to tighten.
Removing the emulsifying disc
- The disc can be removed in exactly the same way
as the blades.
B LADE LOCKING
B LADE LOCKING
B LADES WITH WATERTIGHT SEALS
B ELL
D RIVE COUPLING
BLADE REMOVAL
REMOVAL DIRECTION
S OLID EMULSIFYING DISC
B ELL
D RIVE COUPLING
BLADE REMOVAL
REMOVAL DIRECTION
Mini MP ANGLAIS 17/11/04 17:26 Page 7

8
IMPORTANT
MAINTENANCE
• BLADES
The performance of the cut essentially depends on
the state of your blades and their wear. The blades
are subject to wear and as such need to be replaced
from time to time to ensure the consistent quality of
the end product.
You are also advised to change, at the same time,
the washer and the watertight seals.
•FOOT SEAL
In order to maintain a perfect watertight seal between
the foot and the bell it is necessary to check the wear
of the seal regularly and replace it if necessary.
HYGIENE
The equipment must be clean at all stages of
production.
It is vital to clean the power mixer thoroughly between
each job using a detergent or disinfectant.
•N.B. NEVER USE PURE BLEACH
-Dilute the detergent/disinfectant following the
manufacturer’s instructions on the label.
-Scrub well if necessary.
-Leave the disinfectant/detergent to take effect if
necessary.
-Rinse thoroughly.
-Dry properly using a clean cloth.
CLEANING
WARNING
After using the power mixer in a hot preparation,
cool the bottom of the foot in cold water before
dismantling the bell from the foot.
After completion of preparation, clean immediately
to prevent food from sticking to surfaces.
•MOTOR UNIT
Never put the motor unit and its handle in water,
clean them with a damp cloth or a sponge.
•FOOT AND BELL
It is possible to proceed in two ways:
• Simple cleaning procedure
-Place the foot and bell into a suitable container
with water and switch on for a few seconds to
clean the bell and the foot.
-After unplugging the appliance – essential –,
making sure that no water finds its way into the foot.
-Detach the bell from the foot to avoid a build-up
of condensation.
• Complete cleaning procedure
-Unplug the power mixer.
-Rinse the bell under the tap.
-Remove the bell from the foot, then remove the
blades. Be careful to avoid damaging the surface
of the blade shaft and the watertight seals. Do not
use too strong a detergent when cleaning the parts.
-Ensure that all the different parts are thoroughly
dried before reassembly.
• BLADES AND EMULSIFYING DISC
In order to clean the appliance thoroughly, the
blades and the disc must be removed from the bell
beforehand.
After they have been cleaned, make sure you always
dry the disc or blades properly to avoid oxidation.
CATERING AND RESTAURANT WORK
•Soups, creamed soups
•Vegetable purees : carrots, spinach, celery,
turnips, French beans, etc.
•Mousses : vegetable, fish
•Fruit compotes
•Sauces : green, rouille, remoulade, cream
emulsions, tomato or parsley
•Bisques : langoustines and shellfish
•Pancake batter
The foot, the blades, Emulsifying disc can be
entirely dismantled, (Robot-Coupe’s exclusive
patented system), thereby ensuring easy cleaning,
perfect hygiene and simple maintenance.
USES &
EXAMPLES
The Mini MP 170 V.V. and Mini MP 220 V.V. make
it possible to process smaller quantities in any
number of ways. As this takes very little time, we
advise you to keep a close eye on the preparation,
in order to obtain the desired result.
Check that your detergent is suitable for cleaning plastic
parts. Some washing agents are too alkaline (e.g.
high levels of caustic soda or ammonia) and totally
incompatible with certain types of plastic, causing
them to deteriorate rapidly.
As a precaution, always unplug your appliance
before cleaning it (risk of electrocution).
Mini MP ANGLAIS 17/11/04 17:26 Page 8

9
TECHNICAL
SPECIFICATIONS
• WEIGHT
Net weight Gross weight
Mini MP 170 V.V. 1,51 kg 1,85 kg
Mini MP 220 V.V. 1,56 kg 1,99 kg
• DIMENSIONS (in mm)
•Safety control button
This safety mechanism prevents any unintentional
starting of the power mixer. In fact, it is necessary to
press down two buttons to start the power mixer.
In order to start the machine, read the paragraph
entitled OPERATING THE APPLIANCE (page 14).
• Thermal and overload protection
If there is an obstruction in the container (a spoon
or utensil) or the machine is exposed to over
use/overload, the thermal safety mechanism
automatically stop the motor. In this case, wait for
the power mixer to cool down completely before
restarting, see paragraph entitled OPERATING THE
APPLIANCE (page 14).
ROBOT-COUPE power mixers are equipped with a
safety system comprising of a :
-safety control button,
-safeties on motor: thermal and overload protection.
Mini MP
220 V.V.
A = 078
B = 515
C = 065
D = 220
Mini MP
170 V.V.
A = 078
B = 465
C = 065
D = 170
A
C
D
B
Single-phase machine Mini MP 170 V.V.
Motor Mixer Speed Power Intensity
(rpm) (watts) (Amp.)
230 V/50 Hz 2000 to 12500 220 1.1
120 V/60 Hz 2000 to 12500 215 1.9
220 V/60 Hz 2000 to 12500 200 1
Single-phase machine Mini MP 220 V.V.
Motor Mixer Speed Power Intensity
(rpm) (watts) (Amp.)
230 V/50 Hz 2000 to 12500 250 1.3
120 V/60 Hz 2000 to 12500 245 2.4
220 V/60 Hz 2000 to 12500 230 1.2
WARNING
SAFETY
REMEMBER
PROBLEMS
At first, try to identify precisely what has caused the
power mixer to stop.
•If it is due to a powercut if the appliance has
been unplugged.
-Release the control button (BC).
-Check the power supply.
Never try to override the locking and safety mechanisms.
Never insert an object into the preparation.
Never switch the appliance on unless it has been placed
in the preparation bowl.
Before dismantling the foot or bell, always check that
the power mixer is unplugged.
We recommend that you tilt the power mixer at
a slight angle to prevent the bell from touching the
bottom of the container.
The blades are extremely sharp. Handle with care.
•WORKING HEIGHT
We recommend that you ensure that the container is
placed on a stable and solid work surface.
•NOISE LEVEL
The equivalent continuous sound level when the foot
is not immersed in anything is less than 70 dB (A).
•ELECTRICAL DATA
WARNING
From time to time, check:
- The state of the button’s watertight membrane. Even
the tiniest cracks will allow liquid to seep in.
- The state of the blender housing. This, should not show
any signs of cracking or any abnormal openings which
could allow access to the live components.
Mini MP ANGLAIS 17/11/04 17:26 Page 9

10
-Restart the power mixer following the paragraph
entitled OPERATING THE APPLIANCE (page 14).
•If you cannot locate the cause of the problem
-Release the control button (BC).
-Unplug the power mixer.
-Check :
- the plug,
- that the blades are free to rotate in the bell,
- the state of the power cord,
-that the drive shaft is free to rotate. To do this,
remove the bell and test the rotation of the end of
the drive shaft manually.
If a malfunction occurs which is not on our list of
possible faults, consult your retailer or return the
appliance to the after-sales service.
STANDARDS
MACHINES IN COMPLIANCE WITH:
• The following European directives and related
national legislation:
- Modified "machinery" directive 98/37/EEC,
- "Low voltage" directive 73/23/EEC,
- "EMC" directive 89/336/EEC,
- "Materials and parts in food contact" directive
89/109/EEC,
- "Plastic materials and parts in food contact"
directive 90/128/EEC.
• The following European harmonized standards
and standards setting out health and safety rules:
- We certify that the Mini MP 170 V.V. and Mini
MP 220 V.V. comply with the essential require-
ments of the standard EN 292 – 1 and 2:
machine safety – general design principles,
- EN 60204 -1 (1998).
- For hand-held blenders and whisk : EN 12853.
(Procedure to follow if the stick blender is acci-
dentally immersed during use).
Mini MP ANGLAIS 17/11/04 17:26 Page 10

12
Mini MP ANGLAIS 17/11/04 17:26 Page 12

13
Mini MP ANGLAIS 17/11/04 17:26 Page 13

15
Mini MP ANGLAIS 17/11/04 17:26 Page 15

16
Mini MP ANGLAIS 17/11/04 17:26 Page 16

17
Mini MP ANGLAIS 17/11/04 17:26 Page 17

19
Mini MP ANGLAIS 17/11/04 17:26 Page 19

21
Mini MP ANGLAIS 17/11/04 17:26 Pge 21

Administration Commerciale France
& Service Après-Vente
Tél. : [phone] - Fax : [phone]
12, avenue du Maréchal Leclerc - BP 134
71305 Montceau-en-Bourgogne Cedex
email : [email protected]
Agence de Service Après-Vente
pour la Région Parisienne
Tél. : [phone] - Fax : [phone]
13, rue Clément Viénot
94305 Vincennes Cedex
FABRIQUÉ EN FRANCE PAR ROBOT-COUPE S.N.C.
Export Department
Tel. : + 33 1 43 98 88 33 - Fax : + 33 1 43 74 36 26
18, rue Clément Viénot - BP 157
94305 Vincennes Cedex - France
http://www.robot-coupe.com - email : [email protected]
Mini MP V.V. - Couv 19/09/03 15:17 Page 3
We reserve the right to alter at any time without notice the technical specifications of this appliance.
© All rights reserved for all countries by: ROBOT-COUPE
S . N . C .
We reserve the right to alter at any time without notice the technical specifications of this appliance.
© All rights reserved for all countries by: ROBOT-COUPE
S . N . C .
Réf. : 404 021 - 07/2004 - Mini MP 170 V.V. • Mini MP 220 V.V.
