Robus RCTT-200 User manual

CARBONFIBER/WITHBALLHEAD
RCTT-200
TABLETOP TRIPOD

Precautions
•Donotexceedthe ballhead’smaximumloadcapacity.
•Ensurethat all appropriatelocksare engaged when necessary.
•Thisballheadshouldbeusedonlyintemperaturesranging
between-22°F and 140°F.Do notoperate in salt water.Drythe
ballheadifitbecomeswet.
•Removethe camerafromtheballheadduringsetupor transport.
•Keepthis productaway fromchildren.
•Allimagesarefor illustrativepurposesonly.

Specifications
Base Mount 1/4-20
Quick-Release
Plate Type
Arca-type
Controls Quick-releaseknob
Mainratchet-stylelocking knob
Material Tripod:10Xcarbon fiber
Ballhead:CNCmachined aluminum
Weight 8.5oz.(241 g)
Maximum Load 11lb.(5 kg)
Maximum Height 8in.(20.3 cm)
Minimum Height 3.5in.(8.9 cm)
Folded Length 8.7in.(22.1 cm)
Leg Sections 1
Leg Positions 3positions(30°, 60°, 85°)
Vertical Tilt 0°to90°
Panning Range 360°
Head Type Ballhead

4
2
1
3
Overview

1. Quick-releaseknob
Turncounterclockwise toloosenthejawsto removethe
quick-releaseplate.Turnclockwisetotightenand secure the
quick-releaseplate.
2. Quick-releaseplate
TheArca-stylecompatible quick-release platehasa1/4-20mounting
screw.Use a flat screwdriveror coin to tightenthescrewto the base
ofyourcamera.
3. 90°notch
Usethenotchto switchyourcamera fromlandscapetoportrait
orientation.

4. Ratchet-stylelockingknob
Slowlyloosenthe knob to repositionthe
headandpanoramicbase.
Forabetter grip, pull the knob out to
repositionit, and letgotoreengagethe
lockingknob.
Important!Alwayssupportyour camerawithonehandwhen
looseningthelockingknob.
Mounting the Ballhead
Mounttheballheadbyscrewingit ontothetripod’s1/4-20mounting
screw.Make suretheballheadisflushwiththemountingplate.

Adjusting the Leg Angle
TheRCTT-200offers threelegangles.
Slidetheanglelockdowntoextendtheleg
toits widest position.Closetheleguntilit
clicksinto the twootherlockingangles.
Oncetheballheadissecurelyattachedto
thetripod,tightenthe setscrewwiththe
includedhexkeytoensurethe ballhead
doesn’tcomeloosedue to handling.
60°
85°
30°

Ten-Year Limited Warranty
ThisRobusproductiswarrantedtotheoriginalpurchasertobefreefromdefectsinmaterialsandworkmanshipundernormalconsumeruseforaperiod
often(10)yearsfromthe original purchase date or thirty(30)daysafterreplacement,whicheveroccurslater. The warrantyprovider’sresponsibilitywith
respecttothis limited warranty shall belimited solely torepairor replacement, at the provider’sdiscretion,ofany product that failsduring normal useof
this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider.
Ifthe product has beendiscontinued, the warrantyproviderreservestherighttoreplaceit with amodel of equivalentqualityand function.
Thiswarrantydoes not cover damage or defectcaused by misuse,neglect,accident,alteration,abuse, improper installation or maintenance.EXCEPTAS
PROVIDEDHEREIN,THEWARRANTYPROVIDER MAKES NEITHER ANY EXPRESS WARRANTIESNORANYIMPLIEDWARRANTIES,INCLUDINGBUTNOTLIMITEDTO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you
mayalsohaveadditional rights that varyfromstatetostate.
To obtain warranty coverage, contact the Robus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return
the defective product to Robus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and
expense.
Formoreinformationor to arrange service, visitwww.robussupports.comor call CustomerServiceat212-594-2353.
GG1
ProductwarrantyprovidedbytheGradusGroup. www.gradusgroup.com
Robusis a registeredtrademarkoftheGradusGroup.© 2022 Gradus Group LLC.AllRights Reserved.
Imagesarefor illustrativepurposesonly.
