Robus VANTAGE RTH-1030 User manual

TRIPLEACTION/BALLHEAD
RTH-1030/RTH-1050
VANTAGE SERIES

Precautions
•Donotexceedtheballhead’smaximum load
capacity.
•Ensurethat all appropriatelocks areengaged
whennecessary.
•Thisballhead should be used only in
temperaturesranging between-22°F and 140°F.
Donot operatein salt water.Drythe ballhead if it
becomeswet.
•Removethe camerafrom the ballhead during
setupor transport.
•Keepthis productawayfromchildren.
•Allimages are forillustrativepurposesonly.
Onrare occasions,dueto the
strengthof the lockingmechanism,
thehead may not unlock.
Ifthis happens, turn the tension
dialto its minimumsetting.Tighten
thelocking knob by turning it
clockwiseto itsmaximum
tightness.Then turn it
counterclockwisetoloosen it. The
ballheadshould move freely.
Troubleshooting

10
1
23
4
5
6
7
8
9
Overview
ModelRTH-1050 shown

1. Quick-releaseknob
Turncounterclockwisetoloosen the jaws or removethe quick-release
plate.Turnclockwisetotightenand secure the quick-releaseplate.
2. Quick-releaseplate
TheArca-stylecompatible quick-releaseplateattachestothebaseof
yourcameravia the 1/4-20mounting screw.
3. 1/4-20mountingscrew
4. Bubblelevel
Usethebubbleleveltoensure that yourcamerais properly aligned
withthehorizon.

5. 90°notch
Usethenotchto quickly switchyourcamerafrom landscape to
portraitorientation.
6. Panknob
Turnthe knobcounterclockwisetounlockthebase.Rotatethe base to
thedesiredposition, and lock the base byturningtheknobclockwise.
7. Panoramicbase with 360° markings
Usethepandegreesscaletoaccuratelyset up panoramic shots.
8. 3/8-16threaded mounting socket
Tightenallthe knobs on the head. Then rotatethe ballhead clockwise
ontothe tripod.

9. Mainlockingknob
Turnclockwise to lock the ballhead’sposition.Turncounterclockwise
tounlock andrepositionyour camera.
Important!Make suretosupportthe camerawith one hand while you
disengagethemainlocking knob.
10.Tensiondial
Setsthe minimum amount of friction on the ball. This ensures there’s
frictionontheball,evenif the mainlockingknobisdisengaged. This is
usefultoquickly unlock, reposition, and lock the ballhead without
accidentallylosing control of the camera.

Maximum Load
Material
LateralTilt
VerticalTilt
PanningRange
BaseDiameter
Height
Weight
Specifications
55lb. (25 kg)
Aluminum
-45ºto +45º
0º to +90º
360º
2.75in. (7 cm)
5in. (12.7 cm)
1.8lb. (0.8 kg)
RTH-1050
35lb. (15.9 kg)
Aluminum
-45ºto +45º
0º to +90º
360º
2in. (5.1 cm)
3.9in. (9.9 cm)
0.9lb. (0.4 kg)
RTH-1030

Ten-Year Limited Warranty
ThisRobusproductiswarrantedtotheoriginalpurchasertobefreefromdefectsinmaterialsandworkmanshipundernormalconsumeruseforaperiod
often(10) yearsfromthe original purchasedateorthirty(30) daysafterreplacement,whicheveroccurslater.Thewarrantyprovider’sresponsibilitywith
respecttothis limited warranty shall be limited solely torepair or replacement,atthe provider’sdiscretion, of any productthat fails during normaluse of
this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider.
Ifthe product has beendiscontinued, the warrantyproviderreservestherightto replace it witha model ofequivalent quality and function.
Thiswarrantydoes not cover damageor defect caused bymisuse, neglect, accident, alteration, abuse, improper installationormaintenance. EXCEPT AS
PROVIDEDHEREIN,THEWARRANTYPROVIDERMAKESNEITHERANYEXPRESSWARRANTIES NOR ANY IMPLIED WARRANTIES,INCLUDINGBUTNOTLIMITEDTO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you
mayalso haveadditional rights thatvaryfromstatetostate.
To obtain warranty coverage, contact the Robus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return
the defective product to Robus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and
expense.
Formoreinformationor to arrangeservice,visit www.robussupports.comor call CustomerServiceat212-594-2353.
GG4
Productwarrantyprovidedbythe Gradus Group. www.gradusgroup.com
Robusis a registeredtrademarkoftheGradusGroup. © 2022GradusGroupLLC.All Rights Reserved.
Imagesarefor illustrativepurposesonly.
