Robus Vantage Series User manual

TRIPLEACTION/BALLHEAD
RTH-1050
VANTAGE SERIES

Maximum Load 55lb. (25kg)
Material
Aluminum
LateralTilt -45ºto+45º
VerticalTilt 0º to+90º
PanningRange 360º
BaseDiameter 2.75 in.(7 cm)
Height 5in. (12.7cm)
Weight 1.8lb. (0.8kg)
Specifications

Precautions
•Donotexceedtheballhead’smaximumload capacity.
•Ensurethatallappropriatelocksareengaged whennecessary.
•Thisballheadshould be usedonlyin temperaturesranging
between-22°F and140°F.Donot operate insaltwater.Dry the
ballheadifit becomes wet.
•Removethe camerafromtheballheadduring setuportransport.
•Keepthis productawayfromchildren.
•Allimagesare forillustrativepurposes only.

10
1
23
4
5
6
7
8
9
Overview

1. Quick-releaseknob
Turncounterclockwiseto loosenthejawsorremovethequick-release
plate.Turnclockwisetotighten andsecure thequick-releaseplate.
2. Quick-releaseplate
TheArca-stylecompatiblequick-releaseplateattachesto thebaseof
yourcameraviathe 1/4-20mountingscrew.
3. 1/4-20mountingscrew
4. Bubblelevel
Usethebubble levelto ensurethat yourcameraisproperly aligned
withthehorizon.

5. 90°notch
Usethenotch toquickly switchyour camerafromlandscapeto
portraitorientation.
6. Panknob
Turntheknob counterclockwise tounlock the base.Rotatethe base to
thedesired position,andlock thebaseby turning theknobclockwise.
7. Panoramicbase with 360°markings
Usethepan degreesscaleto accuratelysetup panoramicshots.
8. 3/8-16threaded mountingsocket
Tightenalltheknobs onthehead.Then rotatetheballhead clockwise
ontothetripod.

9. Mainlockingknob
Turnclockwisetolock theballhead’sposition. Turncounterclockwise
tounlockand repositionyour camera.
Important!Make sureto supportthecamerawithone hand whileyou
disengagethemain locking knob.
10.Tensiondial
Setsthe minimum amountoffriction ontheball. Thisensuresthere’s
frictiononthe ball,evenif themainlockingknob isdisengaged.This is
usefultoquicklyunlock,reposition,andlockthe ballheadwithout
accidentallylosing controlof thecamera.

Ten-Year Limited Warranty
ThisRobusproductiswarrantedtotheoriginalpurchasertobefreefromdefectsinmaterialsandworkmanshipundernormalconsumeruseforaperiod
often(10)yearsfromthe original purchase dateorthirty(30)daysafterreplacement,whicheveroccurslater. Thewarrantyprovider’sresponsibilitywith
respecttothis limited warranty shall belimited solely torepairor replacement, at theprovider’sdiscretion,ofany product that failsduring normal useof
this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider.
Ifthe product has beendiscontinued, the warrantyproviderreserves the righttoreplace it witha model ofequivalentqualityand function.
Thiswarrantydoes not cover damage or defectcaused by misuse,neglect,accident,alteration,abuse, improper installation or maintenance.EXCEPTAS
PROVIDEDHEREIN,THEWARRANTYPROVIDERMAKESNEITHERANYEXPRESSWARRANTIESNORANYIMPLIEDWARRANTIES, INCLUDING BUT NOTLIMITEDTO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you
mayalsohaveadditional rights thatvaryfromstatetostate.
To obtain warranty coverage, contact the Robus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return
the defective product to Robus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and
expense.
Formoreinformationor to arrangeservice,visitwww.robussupports.comorcall Customer Service at212-594-2353.
GG1
ROBUSTM
A Gradus Group Brand
ProductwarrantyprovidedbytheGradusGroup. www.gradusgroup.com
Robusis a registeredtrademarkoftheGradusGroup.© 2019 GradusGroupLLC.All Rights Reserved.
Imagesarefor illustrativepurposesonly.
