Rocket Fish RF-ACU12002 User manual

User Guide
Rocketfish Laptop AC Power
Adapter
RF-ACU12002
RF-ACU12002 11-1022_MAN_V1.fm Page 1 Thursday, December 8, 2011 8:05 AM

2
Rocketfish RF-ACU12002
Laptop AC Power Adapter
Contents
Introduction............................................................................2
Safety information................................................................3
Features ....................................................................................3
Using the AC power adapter.............................................4
FAQ for Rocketfish Adapters .............................................5
Specifications .........................................................................7
Legal notices...........................................................................8
Three-year limited warranty........................................... 11
Introduction
Thank you for purchasing a Rocketfish laptop AC power
adapter. This adapter plugs into any AC power outlet anywhere
in the world, and provides a reliable power source to run your
laptop computer and charge its internal battery. Rocketfish
adapters are made using the highest quality components and
feature all of the necessary voltage and heat protection circuits
to ensure maximum levels of safety and efficiency.
NOTE: A physical adapter plug may be necessary to plug into
some AC power outlets outside of the United States.
You can go to the Tip Wizard at www.rocketfishproducts.com
for a complete listing of laptops that are compatible with this
Rocketfish adapter.
CAUTION: This AC power adapter is not compatible with Mac
computers or laptops requiring more than 120 watts of power.
RF-ACU12002 11-1022_MAN_V1.fm Page 2 Thursday, December 8, 2011 8:05 AM

3
RF-ACU12002
Safety information
• Do not expose the power adapter to rain, moisture, or
excessive dust. It may cause shock hazards.
• Do not operate the adapter in direct sunlight.
• Operate the adapter in a well ventilated area. Maximum
ambient temperature around the power adapter must not
exceed 105° Fahrenheit (40° Celsius).
• Do not open the power adapter under any circumstances.
The power adapter is not intended to be repaired in case of
failure or component defect. There are no internal
serviceable parts.
• Discontinue use and contact our toll free help line for
assistance [phone] if any of the following should
occur:
• The adapter shuts down when it is plugged into the
device (LED turns off).
• The adapter's LED light blinks when the adapter is
plugged into an AC power outlet.
• A cord or plug is damaged or frayed.
• Do not use with laptops that require more than 120 watts of
power.
• You can go to the Tip Wizard at
www.rocketfishproducts.com for a complete listing of
compatible models. Do not use a tip that is not listed for
your laptop.
• Keep away from children.
Features
• Provides up to 120 watts of power
• Includes over-voltage, over-temperature, and short circuit
protection
• Powers laptops using a standard AC wall outlet
RF-ACU12002 11-1022_MAN_V1.fm Page 3 Thursday, December 8, 2011 8:05 AM

4
Package contents
• Rocketfish laptop AC power adapter
•ACpowercord
•UserGuide
Using the AC power adapter
To use the AC power adapter:
1Connect the AC power cord to the socket on the AC power
adapter.
2Plug the AC power cord into an AC power outlet or power
strip. The LED on the adapter lights up indicating that the
adapter is powered and ready.
DC input jack
Tip
Output
cable
AC adapter AC cord
AC
power
outlet
LED
RF-ACU12002 11-1022_MAN_V1.fm Page 4 Thursday, December 8, 2011 8:05 AM

5
RF-ACU12002
IMPORTANT: If the adapter's LED does not turn on, or if it
blinks, discontinue use and contact our toll free help line for
assistance [phone].
3Plug the output cable into the DC input jack on the side or
back of your laptop. The LED lights, and the AC power
adapter powers the laptop and charges its battery.
CAUTION: The use of an incorrect tip may damage your laptop.
Do not use this product if you cannot locate your laptop model
in the Tip Wizard at www.rocketfishproducts.com. If you still
have questions, contact our toll-free help line for assistance
[phone]. This AC power adapter is not compatible with
Mac computers.
NOTE: If the compatible tip for your device is not included in the
adapter package, one free tip can be ordered through the Tip
Wizard at www.rocketfishproducts.com. Simply use the Tip
Wizard to locate the manufacturer and model and you can
order your complementary tip. If you are unable to locate your
device on the Tip Wizard or need assistance please contact
Rocketfish customer service at [phone].
FAQ for Rocketfish Adapters
The tip for my laptop is not included, how do I order a
new one?
First go to the Tip Wizard at www.rocketfishproducts.com for a
complete listing of compatible models. If the compatible tip for
your device is not included in the adapter package, one free tip
can be ordered through the Tip Wizard at
www.rocketfishproducts.com. Simply use the Tip Wizard to
locate your device manufacturer and model and you can order
your complimentary tip. If you are unable to locate your device
in the Tip Wizard please contact Rocketfish customer service at
[phone].
RF-ACU12002 11-1022_MAN_V1.fm Page 5 Thursday, December 8, 2011 8:05 AM

6
How do I connect the tip to the adapter cable?
The correct tip should already be attached to the adapter cable.
However, if you verified that your laptop requires a different tip,
you must remove the tip that is currently attached and connect
the new tip. After you have selected the correct tip for your
laptop, connect the tip to the output cable, making sure that
the ridge on the inside of the tip aligns properly with the
groove in the output cable connector. Additionally, the pins on
the inside of the tip should be in line with the holes in the
output cable. The tip should be pushed firmly onto the cable
until the tip and cable meet and there is no gap.
What other laptops can I use this adapter for?
The Rocketfish Laptop AC Power Adapter is compatible with
thousands of laptop models. A complete list of compatible
laptops can be viewed through the Tip Wizard at
www.rocketfishproducts.com.
Why doesn't the tip fit into my laptop?
The tip should fit snugly inside the DC input jack on the side or
back of your laptop. If the tip does not fit into the jack, do not
force the tip. Confirm you have selected the correct tip for your
laptop by visiting the Tip Wizard at
www.rocketfishproducts.com. If you need additional assistance
please contact Rocketfish customer service at [phone].
Will using an incorrect tip damage my laptop?
The tips are designed to be used with specific laptops and so
you should only use the tip that is designated specifically for
your laptop. The correct tip can be identified by using the
online Tip Wizard at www.rocketfishproducts.com.
The use of an incorrect tip may cause performance issues,
including the inability to charge the internal battery or power
the laptop, or the display of an error message on the laptop
screen. It is also possible that the use of an incorrect tip could
damage your laptop. For these reasons, it is necessary to use the
tip designed specifically for your laptop.
RF-ACU12002 11-1022_MAN_V1.fm Page 6 Thursday, December 8, 2011 8:05 AM

7
RF-ACU12002
My laptop is less than 120 watts (e.g., 90 watts or
75 watts). Will this adapter damage my laptop?
No, using this power adapter will not damage your laptop. This
adapter only supplies as much power as required by the laptop,
up to a maximum of 120 watts.
My laptop is more than 120 watts (e.g., 150 watts).
Will this adapter damage my laptop?
This is a 120 watt adapter and it should NOT be used with
laptops that require more than 120 watts of power.
I notice that the adapter is warm when I use it. Is this a
problem?
During standard operation the adapter body may feel warm,
and this is normal. The adapter should always be placed in a
ventilated area in order to prevent over-heating.
How long is the cord from the wall to the laptop?
The AC input cord is 6 feet (172 cm) and the DC output cord is
3.8 feet (116 cm).
Specifications
AC wall socket input cable 6’ (172 cm)
DC power output cable 3.8’ (116 cm)
AC input voltage 100~240V AC, 50-60Hz ~2.5 A
DC output voltage 19.5 Volts
Output current 6.2 Amps
Output power 120 W maximum (AC)
RF-ACU12002 11-1022_MAN_V1.fm Page 7 Thursday, December 8, 2011 8:05 AM

8
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within
the limits for a class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
Weight (adapter w/cable) 12.7 oz. (360 g)
Adapter dimensions
(LxWxH)
6.23 x 2.95 x 1.02 inches
(158 x 75 x 26 mm)
RF-ACU12002 11-1022_MAN_V1.fm Page 8 Thursday, December 8, 2011 8:05 AM

9
RF-ACU12002
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
Copyright
© 2011 Rocketfish. Rocketfish and the Rocketfish logo are
trademarks of BBY Solutions, Inc. Other brands and product
names are trademarks or registered trademarks of their
respective holders. Specifications and features are subject to
change without notice or obligation.
For service and support call [phone].
