Rockford Fosgate RFX Series Installation and operating manual

RFX9100
RFX9100R
Páginas de Referencia para la Instalación
Schéma d’Installation
Installations Beiblatt
Istruzioni di Installation
Installation
Reference Sheet

AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Specification
Reference
Sheet
RFX9100
RFX9100RDS
General
• ISO-DIN Mountable – 178mm x 50mm (trim ring removed)
•Fold Down Detachable Faceplate
•Multi-Color LCD Display
•CD Changer Control
•Internal Amplifier –4x25 Watts RMS / 4x40 Watts PEAK
Preamp
•Low Source Impedance –Drive multible amps without
signal loss
•Source Tone Memory –Enables separate Bass and Treble
memory for Tuner/CD Player/Changer modes
•4-Audio Outputs –Front/Rear preamp outputs
Tuner
•MIR –(Multipath Interference Rejection) Improves audio performance
when radio reception is poor
•30 Station Presets –10 AM/20 FM Presets
•Auto Store –Auto programming of all 30 presets
•World Wide Tuner –American/Europe/Australia
•RDS Tuning (RFX9100RDS only) –RDS (Radio Data System) tuners
can automatically tune in radio stations according to the style of
music the station broadcasts. RDS also enables the receiver to display
text messages (usually call letters) and can break in with traffic alerts
or emergency broadcasts when listening to a CD
Compact Disc
•5.0 Hologram Laser –One piece laser accurately tracks CD
•Dual 1-bit D/A Converters w/8x Oversampling
•Digital Servo Control w/Auto Focus –Adjusts to CD manufacturing
tolerances for accurate tracking
FM Tuner
Frequency Response ................................... 30Hz-12kHz
Usable Sensitivity................................... 10dB(S/N 30dB)
IF Rejection............................................................. 90dB
Image Rejection ...................................................... 50dB
Signal-to-Noise Ratio .............................................. 60dB
Channel Separation .................................. ≥25dB@1kHz
CD Player
Usable Discs..................................................... 5" and 3"
Frequency Response........................ 20Hz-20kHz (±3dB)
Signal-to-Noise Ratio ............................................ >90dB
Channel Separation................................................. 86dB
Dynamic Range .................................................... 100dB
AM Tuner
Sensitivity......................... 20dBf max @ 10dB Sensitivity
-6dB Bandwidth ........................... 5kHz min-12kHz max
General
Operating Voltage............................................ +10.8 to +16V DC
Continuous Power Output ........................................... 4x25 Watts
Dynamic Power Output............................................... 4x40 Watts
Pre-Out Voltage (vol. max) .............................................. 2.0 Vrms
Preamp Output Impedance ................................................. 100 Ω
Equalization .................................................Bass: ± 10dB @ 60Hz
Treble: ± 8dB @ 15kHz
Overall Dimensions...... 2-9/32"H x 7-13/32"W x 7-1/4"D
(with trim ring) ................................(58mm x 188mm x 183.7mm)
Nosepiece Dimensions..1-27/32"H x 6-3/4"W x 13/16"D
(without trim ring) .......................(46.5mm x 171.5mm x 20.2mm)
Weight .......................................................... 3.85 lbs. (1.74kg)
IR Remote
Dimensions....................................... 3-3/8"H x 2-1/8"W x 9/32"D
(85.6mm x 54mm x 7mm)
Features
Specifications
Specifications subject to change without notice
®
DISC-INDISC-IN
SCANSCAN RPTRPT RDMRDM EONEON CDXCDX CHCH REGREG
PUNCHPUNCH R.SEAR.SEATV12V12
LOC ST TPTPTP AFAFAF PTYPTY
MP3MP3
DIRDIR SONGSONGROOTROOT
VOLUME
MUTE
PAUSE
PTY
AS
SEL
DISP
BAND
AF/ TP
R.SEAT
PUNCH
123
456
7890
SCAN RPT
TRACK
RDM
ENTER
DISC
DISC-ACC
TRACK-ACC
+
+ROOT
DIR
PWR
MODE
SEEK
VOL
®
DISC-INDISC-IN
SCANSCAN RPTRPT RDMRDM EONEON CDXCDX CHCH REGREG
PUNCHPUNCH R.SEAR.SEATV12V12
LOC ST TPTPTP AFAFAF PTYPTY
MP3MP3
DIRDIR SONGSONGROOTROOT
VOLUME
MUTE
PAUSE
PTY
AS
SEL
DISP
BAND
AF/ TP
R.SEAT
PUNCH
123
456
7890
SCAN RPT
TRACK
RDM
ENTER
DISC
DISC-ACC
TRACK-ACC
+
+ROOT
DIR
PWR
MODE
SEEK
VOL
RFX9100 RFX9100RDS

STANDARD INSTALLATION
ISO-DIN INSTALLATION
Secure factory bracket to at least 2 holes
TOP VIEW
Sleeve Retaining Clip Mounting Sleeve
LEFT SIDE VIEW RIGHT SIDE VIEW
2.90mm to 10.4mm
1.20mm to 11.3mm
2.00mm to 7.00mm
1.20mm to 1.50mm
A
*
Tabs To Bend
B
*
C
*
D
*
E
**
*
*
*
*
***
FGH
5.20mm to 10.4mm
6.30mm to 8.80mm
14.0mm to 19.8mm
18.3mm to 20.8mm
Thickness of
Instrument Panel
C
F
B
A
G
D
H
D
H
G
A
FB
C
EE EE
Standard Installation - Install sleeve retaining clip onto unit.
Install the mounting sleeve in the instrument panel (see chart).
Secure the backstrap to the rear of the radio (use the supplied
M5 x 6mm screws) and tighten the screw. Slide radio into the
mounting sleeve until it "clicks" into position. Replace the
factory trim panel if used.
ISO-DIN Installation - Use the supplied screws (M5 x 6mm)
to secure the factory mounting brackets into at least two holes
on each side of the radio. Install the radio factory trim panel.
INSTALLATION METHODS
1
NO. DESCRIPTION
(R+) CHANNEL
CD ON
BUS
B+
M. GROUND
N/C
(L+) CHANNEL
AUDIO GROUND
2
3
4
5
6
7
8
7
86
5
4
3
2
1
8-PIN CONNECTOR
OPTIONAL CD CHANGER
Antenna
should
have good
connection
to sheetmetal
ANTENNA
(Looking into the Radio Connector)
Power Harness
8
16
43215
121110913
76
1514
BLK (GND)
RED
WHITE
WHITE
RED
BLK (GND) 3
11
12
13
1
2
B
A
LINE OUT
FRONT
B
A
L
R
L
RLINE OUT
REAR
11
15
16
14
12
13
4
6
10
7
8
9
5
1
2
PIN NO
3
FRONT (L-) (WHITE/BLACK)
FRONT (R-) (GRAY/BLACK)
REAR (L-) (GREEN/BLACK)
REAR (R-) (VIOLET/BLACK)
POWER ANTENNA (BLUE/RED)
DIMMER (ORANGE)
TELEPHONE MUTE(PINK)
FRONT (L+) (WHITE)
FRONT (R+) (GRAY)
REAR (L+) (GREEN)
NC
REAR (R+) (VIOLET)
DESCRIPTION
CHASSIS GROUND (BLACK)
POWER REMOTE (BLUE)
BATTERY +12V (YELLOW)
IGNITION +12V (RED)
-
+
-
+
+
2-Speaker System
-
+
-
4-Speaker System
IGNITION (SWITCHED) (INPUT)
POWER REMOTE(400mA MAX)
POWER ANTENNA (175mA MAX)
CHASSIS GROUND
BATTERY +12V
REAR (R+) SPEAKER OUTPUT
REAR (R-) SPEAKER OUTPUT
REAR (L+) SPEAKER OUTPUT
REAR (L-) SPEAKER OUTPUT
FRONT (R+) SPEAKER OUTPUT
DIMMER
TELEPHONE MUTE
FRONT (R-) SPEAKER OUTPUT
FRONT (L+) SPEAKER OUTPUT
FRONT (L-) SPEAKER OUTPUT
CHOKE & FUSE
BOX
BLACK
YELLOW
RED
BLUE/RED
LT. BLUE
VIOLET/BLACK
GREEN/BLACK
GRAY/BLACK
WHITE/BLACK
VIOLET
ORANGE
PINK
GREEN
GRAY
WHITE
Press Button for CD Access
FOLD DOWN FACEPLATE
AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Specification
Reference
Sheet
RFX9100
RFX9100RDS

3
11
12
13
1
2
B
A
B
A
I
D
I
D
INSTALACIÓN ESTANDAR
INSTALACIÓN ISO-DIN
VISTA DE ARRIBA
Presilla de retención de la manga Manga de montaje
VISTA DEL LADO DERECHO
2,90mm to 10,4mm
1,20mm to 11,3mm
2,00mm to 7,00mm
1,20mm to 1,50mm
A
*
Lengüetas para doblar
B
*
C
*
D
*
E
**
*
*
*
*
***
FGH
5,20mm to 10,4mm
6,30mm to 8,80mm
14,0mm to 19,8mm
18,3mm to 20,8mm
Espesor del panel
de instrumentos
C
F
B
A
G
D
H
D
H
G
A
FB
C
EE EE
Instalación estándar - Instale la presilla de retención de la
manga en la unidad. Instale la manga de montaje en el panel de
instrumentos (ver el cuadro). Asegure la cinta trasera a la parte
trasera de la radio (use los tornillos M5 x 6 mm incluidos) y
ajuste el tornillo. Deslice la radio en la manga de montaje hasta
que se trabe en posición. Vuelva a colocar el panel de adorno
de fábrica si lo usa.
Instalación ISO-DIN - Use los tornillos incluidos (M5 x 6 mm)
para asegurar los soportes de montaje de fábrica en por lo
menos dos agujeros en cada lado de la radio. Instale el panel
de adorno de fábrica de la radio.
MÉTODOS DE INSTALACIÓN
1
NO. DESCRIPCIÓN
CANAL (D+)
CD ACTIVADO
BUS
B+
M. A TIERRA
NO CORRESPONDE
CANAL (I+)
AUDIO A TIERRA
2
3
4
5
6
7
8
7
86
5
4
3
2
1
CONECTADOR DE 8 CLAVIJAS
CAMBIADOR DE CD OPCIONAL
La antena
deberátener
una buena
conexión con
el metal.
ANTENA
(Mirando hacia el conectador de la radio)
Arnés de potencia
8
16
43215
121110913
76
1514
NEGRO (TIERRA)
ROJO
BLANCO
BLANCO
ROJO
NEGRO (TIERRA)
SALIDA DE LA
LÍNEA DELANTERA
SALIDA DE LA
LÍNEA TRASERA
11
15
16
14
12
13
4
6
10
7
8
9
5
1
2
NO. DE CLAVIJA
3
DELANTERA (I-) (BLANCO/NEGRO)
DELANTERA (D-) (GRIS/NEGRO)
TRASERA (I-) (VERDE/NEGRO)
TRASERA (D-) (VIOLETA/NEGRO)
ANTENA MOTORIZADA (AZUL/ROJO)
ATENUADOR (ANARANJADO)
ENMUDECER EL TELÉFONO (ROSADO)
DELANTERA (I+) (BLANCO)
DELANTERA (D+) (GRIS)
TRASERA (I+) (VERDE)
NO CORRESPONDE
TRASERA (D+) (VIOLETA)
DESCRIPCIÓN
CHASIS A TIERRA (NEGRO)
CONTROL REMOTO MOTORIZADO (AZUL)
BATERÍA +12V (AMARILLO)
ENCENDIDO +12V (ROJO)
-
+
-
+
+
Sistema de
2-altavoces
-
+
-
Sistema de
4-altavoces
ENCENDIDO (CONMUTADO) (ENTRADA)
CONTROL REMOTO MOTORIZADO (400mA MAX)
ANTENA MOTORIZADA (175mA MAX)
CHASIS A TIERRA
BATERÍA +12V
SALIDA DEL ALTAVOZ TRASERO (D+)
SALIDA DEL ALTAVOZ TRASERO (D-)
SALIDA DEL ALTAVOZ TRASERO (I+)
SALIDA DEL ALTAVOZ TRASERO (I-)
SALIDA DEL ALTAVOZ DELANTERO (D+)
ATENUADOR
ENMUDECER EL TELÉFONO
SALIDA DEL ALTAVOZ DELANTERO (D-)
SALIDA DEL ALTAVOZ DELANTERO (I+)
SALIDA DEL ALTAVOZ DELANTERO (I-)
CAJA DE FUSIBLES
Y CEBADOR
NEGRO
AMARILLO
ROJO
AZUL/ROJO
AZUL CLARO
VIOLETA/NEGRO
VERDE/NEGRO
GRIS/NEGRO
BLANCO/NEGRO
VIOLETA
ANARANJADO
ROSADO
VERDE
GRIS
BLANCO
Oprima el botón para acceder al CD
Pliegue la placa hacia abajo
Asegure el soporte de fábrica
en por lo menos 2 agujeros
VISTA DEL LADO IZQUIERDO
AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Hoja de referencia
de las especificaciones
RFX9100
RFX9100RDS

3
11
12
13
1
2
B
A
B
A
S
D
S
D
INSTALLAZIONE STANDARD
INSTALLAZIONE ISO-DIN
VEDUTA DALL’ALTO
Fermaglio di ritenuta a fodero Fodero di montaggio
VEDUTA LATO DESTRO
2.90mm to 10.4mm
1.20mm to 11.3mm
2.00mm to 7.00mm
1.20mm to 1.50mm
A
*
Linguette da piegare
B
*
C
*
D
*
E
**
*
*
*
*
***
FGH
5.20mm to 10.4mm
6.30mm to 8.80mm
14.0mm to 19.8mm
18.3mm to 20.8mm
Spessore del quadretto
porta-strumenti
C
F
B
A
G
D
H
D
H
G
A
FB
C
EE EE
Installazione standard –Installare il fermaglio di ritenuta a fodero
sull’unità. Installare il fodero di montaggio nel quadretto
porta-strumenti (vedere la tabella). Fissare la fascetta posteriore
al retro della radio (utilizzare le viti M5 x 6mm giàfornite) e
stringere la vite. Far slittare la radio dentro il fodero di montaggio
finchénon scatti in posizione. Riattaccare il pannello di rifinitura
di fabbrica, se utilizzato.
Installazione ISO-DIN –Utilizzare le viti fornite (M5 x 6mm) per
fissare i sostegni di montaggio di fabbrica in almeno due fori
su ciascun lato della radio. Installare il pannello di rifinitura di
fabbrica sulla radio.
METODI D’INSTALLAZIONE
1
NO. DESCRIZIONE
CANALE (D+)
CD ACCESO
BUS
B+
MASSA M.
N/C
CANALE (S+)
MASSA AUDIO
2
3
4
5
6
7
8
7
86
5
4
3
2
1
CONNETTORE A 8 POLI
CD CHANGER (CAMBIATORE DI CD) OPZIONALE
L’antenna
dovrebbe
essere
collegata in
modo adeguato
alla lamiera
ANTENNA
(Guardando all’interno del connettore radio)
Cablaggio preassemblato di potenza
8
16
43215
121110913
76
1514
NERO (MASSA)
ROSSO
BIANCO
BIANCO
ROSSO
NERO (MASSA)
USCITA LINEA
ANTERIORE
USCITA LINEA
POSTERIORE
11
15
16
14
12
13
4
6
10
7
8
9
5
1
2
N. POLO
3
ANTERIORE (S-) (BIANCO/NERO)
ANTERIORE (D-) (GRIGIO/NERO)
POSTERIORE (S-) (VERDE/NERO)
POSTERIORE (D-) (VIOLA/NERO)
ANTENNA DI POTENZA (BLU/ROSSO)
OSCURATORE (ARANCIONE)
SILENZIAMENTO TELEFONICO (ROSA)
ANTERIORE (S+) (BIANCO)
ANTERIORE (D+) (GRIGIO)
POSTERIORE (S+) (VERDE)
NC
POSTERIORE (D+) (VIOLA)
DESCRIZIONE
MASSA TELAIO (NERO)
TELECOMANDO DI POTENZA (BLU)
BATTERIA +12V (GIALLO)
ACCENSIONE +12V (ROSSO)
-
+
-
+
+
Sistema a 2
altoparlanti
-
+
-
Sistema a 4
altoparlanti
ACCENSIONE (COMMUTATA) (INGRESSO)
TELECOMANDO DI POTENZA (400mA MAX)
ANTENNA DI POTENZA (175mA MAX)
MASSA TELAIO
BATTERIA +12V
USCITA ALTOPARLANTE POSTERIORE (D+)
USCITA ALTOPARLANTE POSTERIORE (D-)
USCITA ALTOPARLANTE POSTERIORE (S+)
USCITA ALTOPARLANTE POSTERIORE (S-)
USCITA ALTOPARLANTE ANTERIORE (D+)
OSCURATORE
SILENZIAMENTO TELEFONICO
USCITA ALTOPARLANTE ANTERIORE (D-)
USCITA ALTOPARLANTE ANTERIORE (S+)
USCITA ALTOPARLANTE ANTERIORE (S-)
INDUTTORE
D’ARRESTO
E PORTAFUSIBILI
NERO
GIALLO
ROSSO
BLU/ROSSO
BLU
VIOLA/NERO
VERDE/NERO
GRIGIO/NERO
BIANCO/NERO
VIOLA
ARANCIONE
ROSA
VERDE
GRIGIO
BIANCO
Premere il pulsante per accedere al CD
Piegare il quadrante verso il basso
Fissare il sostegno di fabbrica in almeno 2 fori
VEDUTA LATO SINISTRO
AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Scheda tecnica
di riferimento
RFX9100
RFX9100RDS

3
11
12
13
1
2
B
A
B
A
L
R
L
R
STANDARDINSTALLIERUNG
ISO-DIN INSTALLIERUNG
DRAUFSICHT
Halteklemmen für Manschette Halterungsmanschette
LINKE SEITENANSICHT RECHTE SEITENANSICHT
2.90mm to 10.4mm
1.20mm to 11.3mm
2.00mm to 7.00mm
1.20mm to 1.50mm
A
*
zu biegende Riegel
B
*
C
*
D
*
E
**
*
*
*
*
***
FGH
5.20mm to 10.4mm
6.30mm to 8.80mm
14.0mm to 19.8mm
18.3mm to 20.8mm
Stärke des
Armaturenbretts
C
F
B
A
G
D
H
D
H
G
A
FB
C
EE EE
Standardinstallierung –Halteklemmen für die Manschette am
Gerät anbringen. Die Halterungsmanschette im Armaturenbrett
installieren (siehe Abbildung). Den Halteriemen an der Rückseite
des Radios befestigen (die beiliegenden M5 x 6 mm Schrauben
verwenden) und die Schrauben anziehen. Das Radio in die
Halterungsmanschette schieben, bis es einklickt. Die
Originalabdeckung ggfs. wieder anbringen.
ISO-DIN Installierung –Die beiliegenden Schrauben (M5 x 6 mm)
verwenden, um die Originalbefestigungsbügel in wenigstens zwei
Löchern auf jeder Seite des Radios zu befestigen. Die
Originalradioabdeckung anbringen.
INSTALLIERUNGSMETHODEN
1
NO. BESCHREIBUNG
(R+) KANAL
CD EIN
BUS
B+
M. ERDUNG
N/C
(L+) KANAL
AUDIO ERDUNG
2
3
4
5
6
7
8
7
86
5
4
3
2
1
8-STIFT STECKER
WAHLWEISER CD-WECHSLER
Die Antenne
sollte eine gute
Verbindung
zum Blech
haben.
ANTENNE
(Blick in den Radiostecker)
Stromverteiler
8
16
43215
121110913
76
1514
SCHWARZ (ERDUNG)
ROT
WEISS
WEISS
ROT
SCHWARZ (ERDUNG)
LEITUNG
AUS VORN
LEITUNG
AUS HINTEN
11
15
16
14
12
13
4
6
10
7
8
9
5
1
2
STIFT-NR.
3
VORN (L-) (WEISS/SCHWARZ)
VORN (R-) (GRAU/SCHWARZ)
HINTEN (L-) (GRÜN/SCHWARZ)
HINTEN (R-) (VIOLETT/SCHWARZ)
STROM ANTENNE (BLAU/ROT)
DIMMER (ORANGE)
TELEFON-STUMMSCHALTER (ROSA)
VORN (L+) (WEISS)
VORN (R+) (GRAU)
HINTEN (L+) (GRÜN)
NC
HINTEN (R+) (VIOLETT)
BESCHREIBUNG
ERDUNG DES GEHÄUSES (SCHWARZ)
STROM FERNBEDIENUNG (BLAU)
BATTERIE +12V (GELB)
ZÜNDUNG +12V (ROT)
-
+
-
+
+
System mit 2
Lautsprechern
-
+
-
System mit 4
Lautsprechern
ZÜNDUNG (GESCHALTET) (INPUT)
STROM FERNBEDIENUNG (400mA MAX)
STROM ANTENNE (175mA MAX)
ERDUNG DES GEHÄUSES
BATTERIE +12V
HINTEN (R+) LAUTSPRECHERAUSGANG
HINTEN (R-) LAUTSPRECHERAUSGANG
HINTEN (L+) LAUTSPRECHERAUSGANG
HINTEN (L-) LAUTSPRECHERAUSGANG
VORN (R+) LAUTSPRECHERAUSGANG
DIMMER
TELEFON-STUMMSCHALTER
VORN (R-) LAUTSPRECHERAUSGANG
VORN (L+) LAUTSPRECHERAUSGANG
VORN (L-) LAUTSPRECHERAUSGANG
CHOKE &
SICHERUNGSKASTEN
SCHWARZ
GELB
ROT
BLAU/ROT
BLAU
VIOLETT/SCHWARZ
GRÜN/SCHWARZ
GRAU/SCHWARZ
WEISS/SCHWARZ
VIOLETT
ORANGE
ROSA
GRÜN
GRAU
WEISS
Zum CD-Zugriff Knopf drücken
Das Bedienpanel nach unten klappen
Originalbügel in wenigstens
zwei Löchern befestigen
AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Technische
Daten
RFX9100
RFX9100RDS

3
11
12
13
1
2
B
A
B
A
G
D
G
D
INSTALLATION STANDARD
INSTALLATION ISO-DIN
VUE DE HAUT
Fixation de retenue de manchon Manchon de montage
VUE LATÉRALE DROITE
2.90mm to 10.4mm
1.20mm to 11.3mm
2.00mm to 7.00mm
1.20mm to 1.50mm
A
*
Languettes àrecourber
B
*
C
*
D
*
E
**
*
*
*
*
***
FGH
5.20mm to 10.4mm
6.30mm to 8.80mm
14.0mm to 19.8mm
18.3mm to 20.8mm
Épaisseur du
tableau de bord
C
F
B
A
G
D
H
D
H
G
A
FB
C
EE EE
Installation standard - Installez la fixation de retenue du manchon
sur l’appareil.Installez le manchon de montage dans le tableau de
bord (voir tableau). Fixez la bride arrière àl’arrière de la radio
(àl’aide d’une des vis M5 x 6 mm fournies) et serrez la vis.
Glissez la radio dans le manchon de montage jusqu’à ce qu’elle
s’enclenche d’un déclic. Replacez le panneau de garnissage le
cas échéant.
Installation ISO-DIN –Fixez les supports de montage en insérant
les vis fournies (M5 x 6 mm) de chaque côtéde la radio (utilisez
deux trous au moins). Installez le panneau de garnissage.
MÉTHODES D’INSTALLATION
1
NO. DESCRIPTION
CANAL (D+)
ALLUMAGE CD
BUS
B+
MASSE PRINCIPALE
SANS CONNEXION
CANAL (G+)
MASSE AUDIO
2
3
4
5
6
7
8
7
86
5
4
3
2
1
CONNECTEUR À8 BROCHES
CHANGEUR DE CD, EN OPTION
L’antenne doit
être bien
connectée à
la tôle
ANTENNE
(Vue en direction du connecteur radio)
Harnais d’alimentation
8
16
43215
121110913
76
1514
NOIR (MASSE)
ROUGE
BLANC
BLANC
ROUGE
NOIR (MASSE)
LIGNE DE
SORTIE AVANT
LIGNE DE
SORTIE ARRIÈRE
11
15
16
14
12
13
4
6
10
7
8
9
5
1
2
No DE BROCHE
3
AVANT (G-) (BLANC/NOIR)
AVANT (D-) (GRIS/NOIR)
ARRIÈRE (G-) (VERT/NOIR)
ARRIÈRE (D-) (VIOLET/NOIR)
ANTENNE TÉLÉCOMMANDÉE (BLEU/ROUGE)
GRADATEUR (ORANGE)
SOURDINE, TÉLÉPHONE (ROSE)
AVANT (G+) (BLANC)
AVANT (D+) (GRIS)
ARRIÈRE (G+) (VERT)
SANS CONNEXION
ARRIÈRE (D+) (VIOLET)
DESCRIPTION
MASSE DU CHSSIS (NOIR)
COMMANDE ÀDISTANCE (BLEU)
BATTERIE +12 V (JAUNE)
CONTACT +12 V (ROUGE)
-
+
-
+
+
Système à2
haut-parleurs
-
+
-
Système à4
haut-parleurs
CONTACT (COMMUTÉ) (ENTRÉE)
COMMANDE ÀDISTANCE (400 mA MAX)
ANTENNE TÉLÉCOMMANDÉE (175 mA MAX)
MASSE DU CHSSIS
BATTERIE +12 V
SORTIE HAUT-PARLEUR ARRIÈRE (D+)
SORTIE HAUT-PARLEUR ARRIÈRE (D-)
SORTIE HAUT-PARLEUR ARRIÈRE (G+)
SORTIE HAUT-PARLEUR ARRIÈRE (G-)
SORTIE HAUT-PARLEUR AVANT (D+)
GRADATEUR
SOURDINE, TÉLÉPHONE
SORTIE HAUT-PARLEUR AVANT (D-)
SORTIE HAUT-PARLEUR AVANT (G+)
SORTIE HAUT-PARLEUR AVANT (G-)
ÉTRANGLEUR ET
BOÎTE DE FUSIBLES
NOIR
JAUNE
ROUGE
BLEU/ROUGE
BLEU
VIOLET/NOIR
VERT/NOIR
GRIS/NOIR
BLANC/NOIR
VIOLET
ORANGE
ROSE
VERT
GRIS
BLANC
Appuyez sur le bouton pour accéder au lecteur CD
Rabattez la plaque
Fixez les supports de montage
àdeux trous au moins
VUE LATÉRALE GAUCHE
AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
RDS/AF/FM ST/CD Player/Changer Control/IR Remote/Audio Switcher
Fiche de
référence
technique
RFX9100
RFX9100RDS

PRINTED IN KOREA
Rockford Fosgate
Rockford Corporation
546 South Rockford Drive
Tempe, Arizona 85281 U.S.A.
In U.S.A., [phone]
In Europe, Fax [phone]
In Japan, Fax [phone]
www.rockfordfosgate.com
03/01 B.M.
MAN-3575-A
