Rockford Fosgate Punch PMX-0R User manual

Installation & Operation
PMX-0R
WIRED
REMOTE
Serial Number: Date of Purchase:

Dear Customer,
Congratulations on your purchase of the world’s finest brand of audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer, as we provide specialized training through Rockford Technical
Training Institute (RTTI). Please read your warranty and retain your
receipt and original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image, order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX [phone]. For all other coun
tries, call +001-480-967-3565 or FAX [phone].
Table of Contents
2 Introduction
3 Features/Mounting
Design Features
Mounting
7 Limited Warranty Information
Introduction
2

If, after reading your manual, you still have questions regarding this product,
we recommend that you see your Rockford Fosgate dealer. If you need further
assistance, you can call us direct at 1-800-669-9899. Be sure to have your serial
number, model number and date of purchase available when you call.
Safety
This symbol with “WARNING” is intended to alert
the user to the presence of important instructions.
Failure to heed the instructions will result in
severe injury or death.
This symbol with “CAUTION” is intended to alert
the user to the presence of important instructions.
Failure to heed the instructions can result in
injury or unit damage.
To prevent injury and damage to the unit, please read and follow the instructions
in this manual. We want you to enjoy this system, not get a headache.
If you feel unsure about installing this system yourself, have it installed by a
qualified Rockford Fosgate technician.
Before installation, disconnect the battery negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
3

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide more reasonable protection against harmful interference in a residential
installation.
Operation is subjected to the following two conditions: (1) This device may
not cause harmful interference, and (2) the device must accept any interference
received, including interference that may cause undesired operation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, you are encouraged to try to correct the
interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
Contents
Wired Remote
Trim Bezel
Mounting Plate
•
•
•
•
•
•
U Bracket
Screws
Installation & Operation Manual
4
©2015 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH® and
associated logos where applicable are registered trademarks of Rockford Corporation in the
United States and/or other countries. All other trademarks are the property of their respective
owners. Specifications subject to change without notice.

Features/Mounting
SRC
PMX-0R
PEQ
Rotary Encoder
This knob is for adjusting main volume, zone volumes,
menu navigation and setting adjustments.
REV / FWD button
Use this button to skip back and forward
through channels or tracks with a short press.
Long pressing will activate manual seek mode.
POWER button
This button allows you to power
the unit ON and OFF by short pressing.
PEQ button
Pressing this button give you
access to change the PEQ level.
Use the rotary encoder to adjust
PEQ levels (0-12).
PLAY / PAUSE button
Press this button to play or pause your music.
This button also acts as a MUTE when the
source is in AUX & TUNER mode.
ISO 8846 / SAE J1171 Certified
Compatible with PMX-8BB, PMX-5
and PMX-2 source units. (3 Remote
Limit,100 ft Total Wired Distance)
SRC Button
This button allows you to switch between
sources by short pressing.
SUB Buttons
These buttons allow you to adjust the
subwoofer output or rear line out UP
or DOWN (0-20).
5

Mounting
To mount the unit, you will need to find a flat surface with adequate clearance
behind that provides enough clearance for the unit and all it’s necessary wiring.
1. Once you have determined a mounting location, you will need to cut a
circular hole 2” (52mm) in diameter.
2. After the hole is cut slide the unit and wiring into through the hole.
3. Take the U bracket and slide over the two studs on the back of the unit.
Tighten down with supplied nuts.
4. Press on the trim bezel on the front side of the unit.
5. Plug in all wiring harnesses and cables. Refer to the wiring diagram for
wire harness connection types.
Panel
Bracket
Wired Remote
Nuts
6

Warranty
7
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
POWER Amplifiers – 2 Years
BMW® Direct Fit Speakers – 2 Years
Source Units – 1 Year
All other products – 1 Year
Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the
United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer
in another country are covered only by that country’s Distributor and not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate
Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt
stating the customer name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be
equivalent) at Rockford’s discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations,water, theft, shipping.
2. Any cost or expense related to the removal or reinstallation of product.
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center.
4. Any product which has had the serial number defaced, altered, or removed.
5. Subsequent damage to other components.
6. Any product purchased outside the U.S.
7. Any product not purchased from an Authorized Rockford Fosgate Dealer.
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of
the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this
limitation may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection with the
sale of the product.
How to Obtain Service
Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call
1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any
product to Rockford Fosgate. You are responsible for shipment of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for details.

Installation assistance available at:
www.rockfordfosgate.com/rftech
ROCKFORDFOSG ATE.CO M
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: [phone] • Toll Free: [phone]
Printed in China060815 1230-59542-01-C
