T-Track Tape Measure Kit Instructions
Effective February 2021

2BP1219
GENERAL SAFETY WARNINGS
This product is designed only for specific applications as defined in the instructions and should not be modified or used for any
manner not described in these instructions. Use only recommended accessories. Before using the T-Track Tape Measure Kit:
READ, UNDERSTAND and FOLLOW ALL INSTRUCTIONS AND SAFETY WARNINGS. KEEP THESE INSTRUCTIONS
READILY AVAILABLE FOR FUTURE REFERENCE.
>Always confirm that you are using the most recent version of
the Instructions and safety warnings for your product (see the
Instructions link on the product page at Rockler.com).
>Before using another tool with this product, always read,
understand and follow the instructions and safety warnings
in the owner’s manual for that tool. If you do not have the
owner’s manual, obtain one from the tool’s manufacturer
before using it with this product.
>Before using any chemical with this product, always read,
understand and follow all safety warnings and guidelines in
the manufacturer’s Safety Data Sheet (SDS; formerly called
“MSDS”), especially regarding:
• How to safely use the chemical, including potential hazards
and recommended first aid measures;
• Personal safety equipment required to safely use the
chemical (e.g. gloves, eye protection, mask/respirator, etc.);
• Proper and safe handling, storage and disposal of
the chemical.
>Before using this product, review and verify that all tools to be
used with it have safety equipment installed and are in proper
working order as defined by the tool’s owner’s manual.
>Do not use this product until you have read and are
confident you understand:
• Installation (pp. 3 - 4).
>The user assumes all risk and responsibility for the proper and
safe use of this product and for ensuring product suitability for
the intended application.
>It is the sole responsibility of the purchaser of this product to
ensure that any anyone you allow to use this product reads
and complies with all instructions and safety precautions
outlined in this manual prior to use.
>Follow all standard shop safety practices, including:
• Keep children and bystanders away from the tool
operating area;
• Do NOT use power tools in explosive environments, or in
the presence of flammable liquids, fumes or dust;
• TURN OFF AND UNPLUG all power tools BEFORE
making any adjustments or changing accessories;
• Remain alert and use good judgment. Do not use this
product if you are in any way impaired by medications,
alcohol, drugs or fatigue;
• Keep your work area well lit and clean;
• Dress appropriately. Secure loose clothing, remove all
jewelry and tie up long hair before using this product;
• ALWAYS wear safety glasses, hearing protection
and respiratory protection that complies with
NIOSH/OSHA/ANSI safety standards;
• Use dust collection tools and dust face masks to
reduce exposure to dust;
• Use safety equipment such as featherboards, push
sticks and push blocks, etc., when appropriate;
• Maintain proper footing at all times and do not overreach;
• Do NOT force woodworking tools.
>These warnings and instructions do NOT represent the total
of all information available regarding tool safety, use and
technique. Always seek out opportunities to learn more
and improve your skills and knowledge.
Drilling, sawing, sanding or machining wood
products can expose you to wood dust, a substance known
to the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for
personal protection. For more information go to
www.P65Warnings.ca.gov/wood.
Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury
or property damage.
Notice indicates important or helpful information and/or user tips.

3
Installation
1. Determine how many of the 16" Interlocking Inserts (1)
you will need for your application and snap the Inserts
together. (The included Inserts and Tape Measure work for
applications up to 48" long.) The Inserts have a tab at one end
and a recess at the other. Fit the tab of one Insert into the
recess of another and press until you feel a snap. Fig. 1.
2. Slide the joined 16" Interlocking Inserts (1) into the T-track
where you will use them. Make sure the Inserts remain locked
together, and position them as they will be in use.
3. On each end, mark where the Insert assembly will need
to be cut to fit (if necessary). Only the tab should need to
be removed at one end. Fig. 2.
4. If necessary, slide the Insert assembly so the cut marks are
clear of the T-track ends. Then carefully cut the assembly to
length at the marks. We recommend using a utility knife to cut
the tab, and a handsaw to cut the thicker parts of the Insert.
Ease any rough edges with sandpaper. Fig. 2 and Fig. 3.
5. Using the included Hex Key (3), thread as many #8-32
Nylon Set Screws (2) as needed for your application into
the threaded holes in the 16" Interlocking Inserts (1), but
don’t tighten them.
6. The #8-32 Nylon Set Screws (2) allow you to secure the
Insert assembly permanently in position or set it so that it
won’t shift during use but can be repositioned if desired. You
must decide which setup you want now because the 48" Steel
Tape Measure (5) will eventually cover the Set Screws, making
them inaccessible. Fig. 3
Fig. 2
Fig. 1

4Distributed by Rockler Companies, Inc.
4365 Willow Dr. Medina, MN 55340
64842 69017
Rev 02/21
1-800-279-4441
www.rockler.com
To set it permanently: Make sure the Insert assembly is
positioned as desired and fully tighten the #8-32 Nylon Set
Screws (2) with the Hex Key (3). Fig. 4.
To allow it to be repositioned: Tighten the #8-32 Nylon Set
Screws (2) with the Hex Key (3) and then back off each screw
a quarter-turn. Fig. 4.
7. If necessary for your application, cut the 48" Steel Tape
Measure (5) to length with tin snips or heavy-duty scissors.
Sand away any burr.
8. Peel the backing off the adhesive on the 48" Steel Tape
Measure (5) and apply the Steel Tape Measure to the
Insert assembly, taking care to position it correctly so
that your measurements will be accurate.
9. The Acrylic Hairline Indicator (5) has an adhesive backing and
is provided so you can attach it to Flip Stops (26991 and 31214,
sold separately) or to shop-made jigs to help you achieve
greater accuracy.
Check Rockler.com for updates. If you have further questions, please
