Introduction
If you have never experienced the wonders of an Auto
Wah pedal, jump on board now with Rocktron’s VII
Deadly Sins! Seven deadly sins will be washed away
with this intriguing effect that will offer up bliss lled
wah sounds with incredibly easy control.
Part of the Rocktron Boutique Series of stomp boxes
this pedal design comes in a rugged metal chassis with
eye popping retro custom design laser etched artwork.
This is a TRUE BYPASS pedal: when you turn it
off…it is out of your signal path!
Control knobs for the VII Deadly Sins Auto Wah
include MODE which controls the A.D.S.R. (Attack,
Decay, Sustain, Release) response curve applied to the
wah lter. Q SHAPE determines how wide you set
the wah lter sweep. DEADLY SIN provides Trigger
Threshold Detection for wah actuation.
With the VII Deadly Sins, you shape the wah
you desire, you set the wah sweep you want, you
determine the attack, decay, sustain and release
responses you need. One click of the footswitch
sends you to wah heaven with an auto wah that uses

Introduction
a minimum of real estate on your pedalboard, yet
provides years of solid performance in a rugged
chassis.
The VII Deadly Sins is sure to inspire your next
composition and your stage performances. Wah
effects are at the heart of so many great songs and
solos, and Rocktron’s stomp box will be no exception.
The footswitch on the VII Deadly Sins Auto Wah
controls On/Off status (indicated by the LED). This
stomp box runs on a 9V Alkaline battery. You may
also use the Rocktron DC OnTap Universal Power
Adaptor.

Descriptions
1
8
7
6
5
432

Descriptions continued.........
MODE Control - This control allows you to
select DOWN, MIDDLE or UP of the response
curve applied to the wah lter.
Q-SHAPE Control -The control determines the
width of the wah lter boost.
9VDC Input - This input jack provides 9VDC
power to the pedal from the Rocktron DC
OnTap 9V power supply (sold seperately).
DEADLY SIN Control - This control
determines the threshold point at which the
wah will activate.
ON/OFF Led - This LED shows if the pedal is
on or off. When the LED is light the pedal is
on. When the LED is not light the pedal is off.
FOOTSWITCH - Use this switch to turn on or
off the pedal. The On/Off Led will show you
if the pedal is on or off.
1
2
3
4
5
6

Descriptions continued.........
INPUT Jack - Using a standard 1/4” guitar
cable, plug your guitar into this jack.
OUTPUT Jack - Using a standard 1/4” guitar
cable you can plug in another pedal from this
jack or plug directly into your amplier.
7
8

Typical Connection

Specications
Maximum Input
Maximum Output
Imput Impedance
Output Impedance
Current Consumption
Power Requirements
Dimensions
Weight
3dBu
8dBu
1MΩ
10k
15mA
9V Alkaline Battery or
Rocktron DC OnTap
Univeral Power Supply
(sold seperately). Nega-
tive tip.
95mm x 122mm x 56mm
3.75” x 4.75” x 2.25”
410g
14.46 oz

How to change the battery:
To change the battery, turn the pedal over and
remove the 4 screws on the bottom. Remove the
back cover. Carefully remove the old battery and
replace it with a new 9V Alkaline battery. Replace
battery in the same area as the old battery was
located. Place the back cover on the pedal and re-
insert the screws.
Save yourself tons of money in batteries by using
the Rocktron DC OnTap Universal Power Supply
to power this pedal (sold seperately). The Rock-
tron DC OnTap provides a constant ow of power
to the pedal, unlike a battery that will degrade over
time. The Rocktron DC OnTap Univeral Power
Supply can also power up to 20 pedals and can be
used with both 110V and 220V power sources.
Check, www.rocktron.com for more information
on the DC OnTap and where to purchase.
