REQ215
OWNER’S MANUAL
Who reads manuals?
Scan the QR code or go to rockvillesupport.com/req215 to access
how-to video(s), the owner’s manual, and other important information
you may need to get the most out of your item.
If you prefer written instructions, please read ahead!
With Rockville you get many options.
ATTENTION: WATCH THIS VIDEO BEFORE FIRST USE!

2

3
Thank you for purchasing this Rockville REQ215 Dual Channel 15 Band Rack Mountable EQ. Please read this owner’s manual
carefully for proper use of your REQ215. Should you need technical assistance, please call our technical help line at 1-646-
758-0144, 24 hours a day/7 days a week.
IMPORTANT SAFETY INSTRUCTIONS
•To reduce risk of electric shock, never open the unit. There are no user serviceable parts, refer service to the Rockville service center.
• Do not expose this unit to any kind of moisture.
• Please ensure that the unit is situated in a properly ventilated area.
• Make sure the unit is placed on a level and stable surface.

4
1. Rack ears: allows for unit rack mount using four attaching screws and washers (not included).
2. Power switch
3. Power-on LED indicator
4. Equalization sliders: cut or boost corresponding frequencies by ±12dB.
5. Level meter LEDs: indicate the input/output levels from –12dB to +17dB.
6. Level control: The level control can attenuate or boost the signal by up to 12dB. 0dB is normalized at 12 o’clock. Turn the
knob counter-clockwise for up to 12dB of attenutation or clockwise for up to 12dB of gain.
7. Bypass switch: engage this switch and the input signal will bypass all features except the LOW-CUT FILTER (see item 8).
The signal is routed from INPUT though the low-cut lter to the channel’s output. Bypass is indicated by the LED located
above the switch.
8. Low-Cut Filter switch: use this switch to activate the low-cut lter which will attenuate frequencies below 80Hz. Frequency
roll-off is 24dB per octave. Low-cut lter is indicated by the LED located above the switch.
Functions
21 3 4 5 6
7 8
BYPASS

5
1. Balanced XLR input
2. Balanced ¼˝TRS input
3. Balanced XLR output
4. Balanced ¼˝TRS input
5. XLR Passive subwoofer output
6. Crossover Frequency control: 30Hz – 200Hz: Set this to the desired frequency and it will play everything below that frequency.
7. DC 12V power input
1 3
2 4
5 6 7

6
• Dual channel (15 bands per channel)
• 80Hz 24dB/Octave
• octave lter sets
• 25Hz to 16kHz effective equalization range
• Constant Q lters
• Output level LEDs (-12 to +17dB)
• Low cut lter switch with status LED
• XLR inputs and outputs for balanced operation
• Bypass switch with status LED
• Subwoofer out
• Subwoofer X-Over Freq (30Hz – 200Hz)
• Connectors: balanced XLR & TRS inputs and outputs
• Frequency Centers: 31.5Hz, 40Hz, 63Hz,100Hz,160Hz, 250Hz, 400Hz, 500Hz, 630Hz, 800Hz,1kHz, 2kHz, 4kHz, 8kHz,16kHz
• Input Impedance: 20k ohms
• Output Impedance: 1.5k ohms
• Maximum Output Level: 11 VAC
• Level Control: ±12dB
• Signal to Noise: 90dB
• Distortion: 0.03%
• 100-240V worldwide voltage power adaptor
Features/Specifications
