Rodgers 558 User manual

2-Manual Organ

2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING - When using electric products, basic precautions should always be followed, including the following:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in
accordance with the manufacturers instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
WARNING:
IMPORTANT:
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the
letter E or by the safety earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
THIS APPARATUS MUST BE EARTHED
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
GREEN-AND-YELLOW: EARTH, BLUE: NEUTRAL, BROWN: LIVE
For the U.K.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Unplug this apparatus during lightning storms or when
unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Before using this unit, carefully read the sections entitled: “IMPORTANT SAFETY INSTRUCTIONS” (p. 2), “USING THE UNIT SAFELY”
(p. 4), and “IMPORTANT NOTES” (p. 5). These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new unit, Owner’s Manual
should be read in its entirety. The manual should be saved and kept on hand as a convenient reference.

3
Contents
USING THE UNIT SAFELY .................................. 4
IMPORTANT NOTES ....................................... 5
ABOUT THE PERFORMANCE TOUCH KEYBOARDS . . . . . . . . . . . 6
Quick Tour ............................................... 7
About the Display ................................................8
Contents of the Main Screen ................................8
About Pistons ....................................................9
About Toe Pistons .........................................10
Display and Panel ...............................................10
External Connectors .............................................10
Making Settings in the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Menu List .......................................................11
Demo .....................................................11
USB Memory (578 only) ....................................11
Hymn Player (578 only) ....................................12
Song Recorder ............................................12
Pitch/Tuning ..............................................13
Room Modeling ...........................................13
USER/MIDI Coupler ........................................14
Console ...................................................15
Tremulant .................................................16
Exp. Pedal .................................................16
Crescendo ................................................17
Audio .....................................................17
MIDI ......................................................18
Save/Load (USB) ...........................................19
Utility .....................................................19
Storing Your Settings (Customize) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Selecting Stops (Sounds) ................................. 21
Selecting a Sound Variation (Voice Palette) . . . . . . . . . . . . . . . . . . . . . . .21
Storing a Combination of Stops . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Storing or Recalling a Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Storing a Registration .....................................22
Recalling a Registration ....................................22
Resetting the Sound Settings (General Cancel) . . . . . . . . . . . . . . . . . . . 22
Using Memory Banks ............................................23
Storing the Combination of Memory Pistons as a Memory
Bank ......................................................23
Recalling a Registration from a Dierent Memory Bank . . . . .23
Recalling Registrations Successively. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Using Memory Banks with USB Memory (578 Only) . . . . . . . . . . . . . . .24
Preparing USB Flash Drive .................................24
Selecting USB Memory Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Storing the Combination of Memory Pistons as a Memory
Bank to USB Memory ......................................24
Recalling a Registration from a Dierent Memory Bank from
USB Memory ..............................................24
Changing the Settings for FULL ORGAN . . . . . . . . . . . . . . . . . . . 25
Setting the Sound to be Played When the [FULL ORGAN]
Piston is Pressed ...........................................25
Setting Whether Tablet Illumination is On/O When the
[FULL ORGAN] Piston is Pressed . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Changing the Settings for Crescendo . . . . . . . . . . . . . . . . . . . . . 25
Changing ORGAN TYPE (578 Only) . . . . . . . . . . . . . . . . . . . . . . . 25
Practicing Along with a Preset Song or Performance Data . 26
Selecting and Playing Back a Song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Muting a Specic Division During Playback . . . . . . . . . . . . . . . . . 27
Playing Back a Specic Division as a Guide Tone . . . . . . . . . . . . 27
Recording Your Performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Recording a Song ...............................................28
Play Back the Recorded Song ....................................28
Saving a Recorded Song .........................................28
Deleting a Recorded Song .......................................29
Copying a Saved Song ...........................................30
Hymn Player (578 Only) .................................. 31
Selecting Hymn or Prelude ......................................31
Selecting Hymn number ...................................31
Playing Hymn ...................................................31
Playing Prelude .................................................31
Changing Hymn book ...........................................31
Saving and Loading Settings on USB Flash Drive . . . . . . . . . . 32
Formatting USB Flash Drive ......................................32
Saving and Loading Memory Banks (558, 568 only) . . . . . . . . . . . . . . . 32
Saving to USB Flash Drive ..................................32
Loading from USB Flash Drive into Internal Memory . . . . . . . .32
Deleting a Memory Bank from USB Flash Drive . . . . . . . . . . . . . 33
Copying a Memory Bank ........................................33
Saving and Loading Voice Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Saving to USB Flash Drive ..................................33
Loading a Voice Setup .....................................34
Deleting a Voice Setup ....................................34
Backing Up Data/Performing an Initialization . . . . . . . . . . . . . 35
Returning all Settings to the Factory-Set State (Factory Reset). . . . . 35
Backing Up/Loading Data .......................................35
Displaying the Version ...........................................35
List of Shortcuts ......................................... 36
Notice to Users
Information in this document is subject to change without notice. No part of this manual may be translated into any language, stored in a retrieval
system, reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose
without the express written permission of Rodgers Instruments Corporation.
RODGERS INSTRUMENTS CORPORATION
1300 N.E. 25th Avenue
Hillsboro, Oregon 97124
[phone]
http://www.rodgersinstruments.com/
RODGERS IN CANADA
5480 Parkwood Way
Richmond, B.C. V6V 2M4
Toll Free [phone]
Rodgers instruments are manufactured and protected under one or
more of the following U.S. patents: 4,622,878, 5,060,179, 5,087,798,
5,091,613, 5,225,619, 5,262,581, 5,508,472, 6,369,310, 6,399,868
©Copyright 2011. Rodgers Instruments Corporation, a member of the
Roland Group. All rights reserved. Printed in the United States of America.
QuickMenu™, Rodgers®, Rodgers Classic Organs®, Digital Dynamic Wind™,
Dimensional Sound Modeling®, Parallel Digital Imaging®, Voice Palette™,
DVM™, PDI™, TrueChimes™, and Trillium Masterpiece™ are trademarks or
registered trademarks of Rodgers Instruments Corporation , Hillsboro,
Oregon. RSS® is a registered trademark of the Roland Corporation.

4
Used for instructions intended to alert the
user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic animals
or pets.
Used for instructions intended to alert the
user to the risk of death or severe injury
should the unit be used improperly.
The symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In the
case of the symbol at left, it means that the power-cord
plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or
warnings.The specific meaning of the symbol is
determined by the design contained within the triangle. In
the case of the symbol at left, it is used for general
cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never be
carried out (are forbidden). The specific thing that must
not be done is indicated by the design contained within
the circle. In the case of the symbol at left, it means that
the unit must never be disassembled.
About WARNING and CAUTION Notices About the Symbols
ALWAYS OBSERVE THE FOLLOWING
USING THE UNIT SAFELY
WARNING
Connect mains plug of this model to a
mains socket outlet with a protective
earthing connection.
Do not open or perform any internal
modications on the unit.
• Do not attempt to repair the unit,
or replace parts within it (except
when this manual provides specic
instructions directing you to do so).
Refer all servicing to your retailer, or
Rodgers Instruments Corporation, as
listed on the “Notice to Users” (p. 3).
Never install the unit in any of the
following locations.
• Subject to temperature extremes
(e.g., direct sunlight in an enclosed
vehicle, near a heating duct, on top of
heat-generating equipment); or are
• Damp (e.g., baths, washrooms, on wet
oors); or are
• Exposed to steam or smoke; or are
• Subject to salt exposure; or are
• Humid; or are
• Exposed to rain; or are
• Dusty or sandy; or are
• Subject to high levels of vibration and
shakiness.
The unit should be connected to a power
supply only of the type described as
marked under the keyboard deck.
Do not excessively twist or bend the
power cord, nor place heavy objects
on it. Doing so can damage the cord,
producing severed elements and short
circuits. Damaged cords are re and
shock hazards!
This unit, either alone or in combination
with an amplier and headphones or
speakers, may be capable of producing
sound levels that could cause permanent
hearing loss. Do not operate for a long
period of time at a high volume level, or
at a level that is uncomfortable. If you
experience any hearing loss or ringing
in the ears, you should immediately
stop using the unit, and consult an
audiologist.
WARNING
Do not place containers containing liquid
(e.g., ower vases) on this product. Never
allow foreign objects (e.g., ammable
objects, coins, wires) or liquids (e.g.,
water or juice) to enter this product.
Doing so may cause short circuits, faulty
operation, or other malfunctions.
Immediately turn the power o, remove
the power cord from the outlet, and
request servicing by your retailer, or
Rodgers Instruments Corporation, as
listed on the “Notice to Users” (p. 3) when:
• The power-supply cord or the plug has
been damaged; or
• If smoke or unusual odor occurs
• Objects have fallen into, or liquid has
been spilled onto the unit; or
• The unit has been exposed to rain (or
otherwise has become wet); or
• The unit does not appear to operate
normally or exhibits a marked change
in performance.
An adult should provide supervision until
the child is capable of following all the
rules essential for the safe operation of
the unit.
Protect the unit from strong impact.
(Do not drop it!)
Do not force the unit’s power-supply cord
to share an outlet with an unreasonable
number of other devices. Be especially
careful when using extension cords—the
total power used by all devices you have
connected to the extension cord’s outlet
must never exceed the power rating
(watts/amperes) for the extension cord.
Excessive loads can cause the insulation
on the cord to heat up and eventually
melt through.
Before using the unit in a foreign country,
consult with your retailer, or Rodgers
Instruments Corporation, as listed on the
“Notice to Users” (p. 3).
CAUTION
The unit should be located so that its
location or position does not interfere
with its proper ventilation.
Always grasp only the plug on the
power-supply cord when plugging into,
or unplugging from an outlet.
At regular intervals, you should unplug
the power plug and clean it by using
a dry cloth to wipe all dust and other
accumulations away from its prongs.
Also, disconnect the power plug from
the power outlet whenever the unit is to
remain unused for an extended period of
time. Any accumulation of dust between
the power plug and the power outlet can
result in poor insulation and lead to re.
Try to prevent cords and cables from
becoming entangled. Also, all cords and
cables should be placed so they are out
of the reach of children.
Never climb on top of, nor place heavy
objects on the unit.
Never handle the power cord or its plug
with wet hands when plugging into, or
unplugging from, an outlet.
If you need to move the instrument,
consult with your retailer, or Rodgers
Instruments Corporation, as listed on the
“Notice to Users” (p. 3).
Before cleaning the unit, turn o the
power and unplug the power cord from
the outlet.
Whenever you suspect the possibility of
lightning in your area, pull the plug on
the power cord out of the outlet.
Be careful so you don’t get your ngers
pinched when you handle any moving
parts such as the following. Adult
supervision is recommended whenever
small children use the unit.
• Lid
When using the bench, please observe
the following points:
• Do not allow two or more persons to sit
on the bench.
• Do not adjust the height while sitting
on the bench.
Do not remove the speaker grille and
speaker by any means. Speaker not user
replaceable. Shock hazardous voltages
and currents are present inside the
enclosure.

5
Power Supply
• Do not connect this unit to same electrical outlet
that is being used by an electrical appliance that
is controlled by an inverter (such as a refrigerator,
washing machine, microwave oven, or air
conditioner), or that contains a motor. Depending
on the way in which the electrical appliance is
used, power supply noise may cause this unit to
malfunction or may produce audible noise. If it
is not practical to use a separate electrical outlet,
connect a power supply noise lter between this
unit and the electrical outlet.
• Before connecting this unit to other devices, turn
o the power to all units. This will help prevent
malfunctions and/or damage to speakers or other
devices.
• Although the LCD and LEDs are switched o
when the POWER switch is switched o, this does
not mean that the unit has been completely
disconnected from the source of power. If you
need to turn o the power completely, rst turn
o the POWER switch, then unplug the power cord
from the power outlet. For this reason, the outlet
into which you choose to connect the power cord’s
plug should be one that is within easy reach and
readily accessible.
• With the factory settings, the power will
automatically be switched o 4 hours after you
stop playing or operating the unit. If you don’t
want the power to turn o automatically, change
the “AUTO OFF” setting to “OFF” as described on
p. 15.
(Note)
The settings you were editing will be lost when
the power is turned o. If you want to keep your
settings, you must save your settings before
turning the power o.
Placement
• Using the unit near power ampliers (or other
equipment containing large power transformers)
may induce hum. To alleviate the problem, change
the orientation of this unit; or move it farther away
from the source of interference.
• This device may interfere with radio and television
reception. Do not use this device in the vicinity of
such receivers.
• Noise may be produced if wireless
communications devices, such as cell phones,
are operated in the vicinity of this unit. Such
noise could occur when receiving or initiating a
call, or while conversing. Should you experience
such problems, you should relocate such wireless
devices so they are at a greater distance from this
unit, or switch them o.
• Do not expose the unit to direct sunlight, place
it near devices that radiate heat, or otherwise
subject it to temperature extremes. Also, do not
allow lighting devices that normally are used while
their light source is very close to the unit (such as a
piano light), or powerful spotlights to shine upon
the same area of the unit for extended periods of
time. Excessive heat can deform or discolor the
unit.
• Do not allow rubber, vinyl, or similar materials to
remain on this unit for long periods of time. Such
objects can discolor or otherwise harmfully aect
the nish.
• Do not allow objects to remain on top of the
keyboard or pedal board. This can be the cause
of malfunction, such as keys ceasing to produce
sound.
• Do not paste stickers, decals, or the like to this
instrument. Peeling such matter o the instrument
may damage the exterior nish.
• Do not put anything that contains water (e.g.,
ower vases) on this unit. Also, avoid the use of
insecticides, perfumes, alcohol, nail polish, spray
cans, etc., near the unit. Swiftly wipe away any
liquid that spills on the unit using a dry, soft cloth.
Maintenance
• To clean the unit, use a dry, soft cloth; or one that
is slightly dampened. Try to wipe the entire surface
using an equal amount of strength, moving the
cloth along with the grain of the wood. Rubbing
too hard in the same area can damage the nish.
• Never use benzine, thinners, alcohol or solvents of
any kind, to avoid the possibility of discoloration
and/or deformation.
Repairs and Data
• Please be aware that all data contained in the
unit’s memory may be lost when the unit is sent
for repairs. Important data should always be
backed up USB ash drive, or written down on
paper (when possible). During repairs, due care is
taken to avoid the loss of data. However, in certain
cases (such as when circuitry related to memory
itself is out of order), we regret that it may not be
possible to restore the data, and Rodgers assumes
no liability concerning such loss of data.
Additional Precautions
• Please be aware that the contents of memory can
be irretrievably lost as a result of a malfunction,
or the improper operation of the unit. To protect
yourself against the risk of loosing important
data, we recommend that you periodically save a
backup copy of important data you have stored in
the USB ash drive.
• Unfortunately, it may be impossible to restore
the contents of data that was stored in the unit’s
memory or USB ash drive once it has been
lost. Rodgers Corporation assumes no liability
concerning such loss of data.
• Use a reasonable amount of care when using the
unit’s buttons, sliders, or other controls; and when
using its jacks and connectors. Rough handling
can lead to malfunctions.
• Never strike or apply strong pressure to the
display.
• When connecting / disconnecting all cables, grasp
the connector itself—never pull on the cable. This
way you will avoid causing shorts, or damage to
the cable’s internal elements.
• A small amount of heat will radiate from the unit
during normal operation.
• To avoid disturbing your neighbors, try to keep the
unit’s volume at reasonable levels. You may prefer
to use headphones, so you do not need to be
concerned about those around you.
• When you need to transport the unit, pack it in
shock-absorbent material. Transporting the unit
without doing so can cause it to become scratched
or damaged, and could lead to malfunction.
• Do not apply undue force to the music stand while
it is in use.
• Some connection cables contain resistors. Do
not use cables that incorporate resistors for
connecting to this unit. The use of such cables
can cause the sound level to be extremely low,
or impossible to hear. For information on cable
specications, contact the manufacturer of the
cable.
• Due to the structural design of this instrument,
small pets or other animals could end up getting
trapped inside it. If such a situation is encountered,
you must immediately switch o the power and
disconnect the power cord from the outlet. You
should then consult with the retailer from whom
the instrument was purchased, or contact Rodgers
Instruments Corporation, as listed on the “Notice
to Users” (p. 3).
• When opening or closing the lid, please be careful
not to get your ngers pinched between the
movable part and the panel. An adult should
provide supervision until the child is capable
of following all the rules essential for the safe
operation of the unit.
• The explanations in this manual include
illustrations that depict what should typically be
shown by the display.
Note, however, that your unit may incorporate
a newer, enhanced version of the system (e.g.,
includes newer sounds), so what you actually see
in the display may not always match what appears
in the manual.
Before Using External Memories
Using External Memories
• Carefully insert the USB ash drive all the way
in—until it is rmly in place.
• Never touch the terminals of the USB ash drive.
Also, avoid getting the terminals dirty.
• USB ash drive is constructed using precision
components; handle the cards carefully, paying
particular note to the following.
• To prevent damage to the cards from static
electricity, be sure to discharge any static
electricity from your own body before handling
the cards.
• Do not touch or allow metal to come into
contact with the contact portion of the cards.
• Do not bend, drop, or subject cards to strong
shock or vibration.
• Do not keep cards in direct sunlight, in closed
vehicles, or other such locations.
• Do not allow cards to become wet.
• Do not disassemble or modify the cards.
IMPORTANT NOTES

6
For generations, organ key tops were made from the best materials – ivory (for white keys) and ebony (for black keys). The Performance Touch keyboards
use the latest technologies to reproduce the touch and feel of these materials.
• Surfaces incorporate stripes of moisture-absorbing material for improved touch and playability.
• Keys feature a subtle gloss and understated coloring, enhancing the look and elegance.
• White keys are nished with a slight yellowish tinge for the look of real ivory.
 Note: — To Ensure Usage in Optimal Conditions —
Handling…
• Do not write on the keyboard with any pen or other implement, and do not stamp or place any marking on the instrument. Ink will seep into the surface
lines and become unremovable.
• Do not ax stickers on the keyboard. You may be unable to remove stickers that use strong adhesives, and the adhesive may cause discoloration.
Care and Maintenance…
Please note the following points. Failure to do so may result in scratches on the surface nish, damaged gloss, or other discoloration or deformation.
• Gently wipe dirt and grime with soft cloth; do not rub the surfaces forcefully.
• To remove more serious grime, use a commercial keyboard cleaner not containing abrasives.
• Do not use benzene, paint thinner, or alcohol on the keys.
ABOUT THE PERFORMANCE TOUCH KEYBOARDS

7
Quick Tour
Music Rest
Tablets
Keyboard Cover
Pistons
Power Switch
Headphone Jack
Organ Bench
Pedalboard
External Connectors
USB Memory
Connector (558, 568)
USB Memory
Connector (578)

8
Quick Tour
About the Display
Contents of the Main Screen
558, 568
17
6
8
2
3
4
5
1. General memory bank number
2. General memory piston number
3. Keyboard transposition status
Range (semitones)
-6–+5
4. Temperament
Available Settings
EQUAL, WERCK., KIRN.1, KIRN.3, VALLO., MEAN.D, MEAN.E, PYTHG., M.BACH
5. Reference pitch (master tuning)
Available Settings (Hz)
392: VERSAILLES
415: BAROQUE
440: MODERN (standard)
465: VENETIAN
MEMO
You can also adjust this tuning within the range of the reference
pitch.
6. Displayed when the V-LINK function is on.
7. Expression pedal status
This indicates the keyboard(s) that are aected by the expression pedal.
Indication Explanation
I PII The expression pedal aects all divisions (MAN I, MAN II, and
PEDAL division)
IP The expression pedal aects the MAN I division and the PEDAL
division
II The expression pedal aects the MAN II division
O The expression pedal will not aect any division
8. Volume of the expression pedal
578
17
6
8
9
2
3
4
5
1. General memory bank number
2. General memory piston number
3. Keyboard transposition status
Range (semitones)
-6–+5
4. Reference pitch (master tuning)
Available Settings (Hz)
392: VERSAIL (VERSAILLES)
415: BAROQUE
440: MODERN (standard)
465: VENETIA (VENETIAN)
MEMO
You can also adjust this tuning within the range of the reference
pitch.
5. Temperament
Available Settings
EQUAL, WERCK., KIRN.1, KIRN.3, VALLO., MEAN.D, MEAN.E, PYTHG., M.BACH
6. Displayed when the MIDI Visual Control function is on.
7. Crescendo pedal status
8. Volume of the MAN-II expression pedal
9. Volume of the MAN-I expression pedal

9
Quick Tour
Piston Explanation
1 [ORGAN TYPE] Piston This piston allows you to select Organ Type.
 This piston is available on limited models.
2 [SET] Piston
This stores a combination of sounds (registration)
to a general memory piston or a division memory
piston.
3General Memory
Pistons
Each of these pistons can store the combination of
sounds (registration) for the entire organ.
4MAN I Division Coupler
Piston
This piston causes the lower manual to play the
sound of the MAN II division (upper manual). It has
the same function as the MAN I division coupler
tablets.
5PEDAL Division
Coupler Piston
This piston causes the pedalboard to play the sound
of the MAN I division (lower manual) or MAN II
division (upper manual). It has the same function as
the PEDAL division coupler tablets.
6MAN II Division
Memory Pistons
Each of these pistons can store the sound
(registration) for the MAN II division (upper manual).
7MAN I Division
Memory Pistons
Each of these pistons can store the sound
(registration) for the MAN I division (lower manual.)
8Memory Bank Select
[M–] Piston/[M+] Piston
Use these pistons when you want to switch memory
banks.
9[PREV] Piston/[NEXT]
Piston
These successively load the registration stored at
the previous or next general memory piston; e.g.,
3 g 2 g 1 ([PREV] piston) or 1 g 2 g 3 ([NEXT]
piston).
10
All Expression Shoe
MAN II Piston
Turn this piston on if you want to assign MAN I, MAN
II and PEDAL divisions to MAN II expression shoe.
 This piston is available on limited models.
MAN I & PEDAL
Enclosed Piston
Turn this piston on if you want to use the expression
pedal to adjust the volume of MAN I division and
PEDAL division.
11
[INT AUDIO OFF] Piston Turn this piston if you want to mute internal
speakers.
[MAIN OFF] Piston
This piston silences the main organ system.
 This is used when an optional board for external
speakers has been installed.
[ANT ON] Piston
This piston activate an antiphonal speaker system.
An antiphonal speaker system is so named because
it is normally installed a substantial distance
from the main organ. This dierence in physical
placement allows for a variety of eects.
 This is used when an optional board for external
speakers has been installed.
12 [CHIMES] Piston This piston allows you to play Chimes voice.
This piston is on upper manual. (558, 568)
Piston Explanation
13
Bass Coupler [BASS]
Piston
This causes the lowest note played on the lower
manual to be sounded by the PEDAL division sound.
Melody Coupler [MEL]
Piston
This causes the highest note played on the lower
manual to be sounded by the MAN II division (upper
manual) sound.
14
[PIPES OFF] Piston
When the [PIPES OFF] piston is engaged, the
wind-blown pipe ranks are silenced.
 This piston is available on limited models.
 This is used when an optional pipe system has
been connected.
[ANC ON] Piston
When an [ANC ON] piston is engaged, digital voices
play from the stops which normally control pipe
voices. These digital voices are often referred to as
the “Ancillary.”
 This piston is available on limited models.
 This is used when an optional pipe system has
been connected.
15 [HYMN PLAYER] Piston This piston allows you to play Hymn.
 This piston is available on limited models.
16
[STOP] Piston This stops playback or recording of a song.
[PLAY/PAUSE] Piston This starts or pauses playback of a song.
[REC] Piston Use this when you want to record your playing.
17 [FULL ORGAN] Piston
FULL ORGAN controls allow you to engage full
organ quickly without canceling the registration
which is set.
18 General Cancel [0]
Piston
This sets the organ to the condition in which all
tablets and couplers are cancelled, so that no
sounds are selected. It’s convenient to use this
piston when you want to specify a combination of
sounds from scratch.
About Pistons
ORGAN
TYPE
ALL
EXPR HYMN
PLAYER
1 3
7 92 13 1612 18
4 5 6 8 10 11 14 15 17

10
Quick Tour
About Toe Pistons
1 2
3
Pedal/Piston Explanation
1 Expression Pedal
The volume of MAN-I is adjusted with the left pedal,
and the center pedal is used to adjust the volume of
MAN-II.
 The left pedal is available on limited models.
2 Crescendo Pedal
This shoe gradually adds a predetermined selection of
stops as it is pressed forward.
 This pedal is available on limited models.
3 10 x Toe Pistons
General Memory Piston 1–5
 These pistons are available on limited models.
PEDAL Division Coupler Piston
This piston causes the pedalboard to play the sound of
the MAN I division.
 These pistons are available on limited models.
PEDAL Division Memory Piston 1–4
 These pistons are available on limited models.
Display and Panel
1
3
5
2
4
1. Display
Various information is shown here.
2. [Select/Menu] Knob/[Satellite Volume] Knob
Turn: Adjusts the volume of the satellite speakers. When you’re in a
menu screen for making detailed settings, turn this knob to
select the item you want to operate.
Press: Takes you to a menu screen, or nalizes a setting item.
MEMO
The settings for the volume balance of the organ’s speakers and
the satellite speakers can be stored in memory. For details, refer to
“Storing Your Settings (Customize)” (p. 20).
3. [Value/Exit Menu] Knob
Turn: Adjusts a setting.
Press: Returns you to the previous menu, or cancels an operation.
4. [Master Volume] Knob
This adjusts the volume of the entire organ.
5. [Reverb] Knob
This adjusts the depth of reverberation.
External Connectors
1 2 3 4
1. OUTPUT L/MONO, R (Output) Jacks
You can connect an external amplied speaker system here so that the
sound of the organ is played from the connected speakers.
2. INPUT L/MONO, R (Input) Jacks
You can connect an external sound module or similar device here so
that its sounds are heard from the organ’s speakers.
3. MIDI IN, OUT Connectors
You can connect external MIDI devices here to exchange performance
data with the organ.
4. Connector for Service Use (558, 568)
NOTE
 This connector is for technical service use only. Do not connect anything
to this connector.
 To prevent malfunction and/or damage to speakers or other devices,
always turn down the volume, and turn o the power on all devices
before making any connections.
 Carefully insert the USB ash drive all the way in-until it is rmly in
place.
 This unit is equipped with a protection circuit. A brief interval (a
few seconds) after power up is required before the unit will operate
normally.
 Before switching the power on/o, always be sure to turn the volume
down. Even with the volume turned down, you might hear some
sound when switching the power on/o. However, this is normal and
does not indicate a malfunction.
 If you need to turn o the power completely, rst turn o the POWER
switch, then unplug the power cord from the power outlet. Refer to
“Power Supply” (p. 5).

11
Making Settings in the Menus
Heres how to make settings using the menus. Perform these steps from
the main screen. For a list of the menu items, refer to the next page.
1. Press the [Select/Menu] knob to access the menu.
2. Turn the [Select/Menu] knob to select the item.
3. Press the [Select/Menu] knob to enter the item.
4. Turn the [Value/Exit Menu] knob to change the item’s setting.
To cancel the setting / to return to the previous menu...
Press the [Value/Exit Menu] knob.
5. If a Yes/No conrmation screen appears, press the [SET]
piston to put the setting into eect.
Menu List
The settings shown below will revert to their default values when the organ’s power is turned o; however, with a number of the settings, you can have
their content be stored in memory even after the power is turned o.
Setting items marked with [S] Can be stored in the SYSTEM group. Refer to “Storing Your Settings (Customize)” (p. 20).
Setting items marked with [V] Can be stored in the VOICING group.
Setting items marked with [P] Settings can be stored on an individual piston basis. Refer to “Storing or Recalling a Registration” (p. 22).
Demo
Listen to demo songs
 All rights reserved. Unauthorized use of this material for purposes other than private, personal enjoyment is a violation of applicable laws.
 No data for the music that is played will be output from MIDI OUT connector.
Menu item Value Explanation
Group Demo song group
Song Demo song
Tempo Tempo of the demo song
Satellite Volume 0–127 Volume of the satellite speakers
USB Memory (578 only)
Selecting a USB Memory folder
Menu item Value Explanation
Folder A–Z Selecting a USB Memory folder

12
Making Settings in the Menus
Hymn Player (578 only)
Play back Hymn and Prelude
Menu item Value Explanation
Mode – Select Hymn or Prelude
Hymn number – Select Hymn number
Next Intro, Verse Select to play introduction or verse
Play Mode [S] VAR. Prelude begins at a random selection and plays continuously
FIXED Prelude begins at a predetermined selection and plays continuously
Tempo 20-240 Tempo of the Hymn
Volume [S] 0%-100% The volume of Hymn
Transpose -6 – +5 Change the key of the song in semitone steps
Book [S] – Select Hymn book
Song Recorder
Recording, play back song, saving, deleting, and copying song data
Menu item Value Explanation
Source
USB Play back song data from USB ash drive.
INTERNAL Play back song data from internal memory.
PRESET Play back built-in preset song (demo song).
Song Name of the song
Tempo Refer to “Beat” (p. 12) Tempo of the song
Measure Measure of the song
[Division Mute] Refer to “Muting a Specic Division During Playback” and “Playing Back a Specic Division as a Guide Tone” (p. 27).
MAN-II MUTE, GUIDE, PLAY
Select the division that you want to mute.MAN-I MUTE, GUIDE, PLAY
Pedal MUTE, GUIDE, PLAY
Guide Volume [S] 1–10 Adjust the volume of the guide tone.
Guide Tone [S]
F16, P16, R16, F8, P8,
R8, F4, P4, R4
F: Flute,
P: Principal,
R: Reed,
Number: Footage
Choose the guide tone.
Playback
Transpose
(578 only)
-6 – +5 The transpose function lets you shift the pitch in semitone steps.
Play Mode OFF Play back only the selected song.
CHAIN Consecutively play back all the songs on the selected media.
Metronome
Volume OFF, 1–10 Volume of the metronome. Turn this “OFF” if you don’t want the metronome to sound.
Beat
Beat of the song or metronome
The range within which the tempo can be set will vary depending on the setting for Beat.
Beat Tempo range
2/2 10–120
0/4, 2/4, 3/4, 4/4, 5/4,
6/4, 7/4 20–240
3/8 40–480
6/8, 9/8, 12/8 13–160
[Save Song] Refer to “Saving a Recorded Song” (p. 28).
[Delete Song] Refer to “Deleting a Recorded Song” (p. 29).
[Copy Song] Refer to “Copying a Saved Song” (p. 30).

13
Making Settings in the Menus
Pitch/Tuning
Settings for pitch, Temperament, Tuning, and Transpose
Menu item Value Explanation
Pitch
The reference pitch can be changed from “A=440.0 Hz” to “A=415.0 Hz” (Baroque pitch) or “A=392.0 Hz” (Versailles pitch).
VERSAILLES 392 (Hz)
BAROQUE 415 (Hz)
MODERN 440 (Hz)
VENETIAN 465 (Hz)
Temperament
Historical styles of music such as baroque can be played in the tunings that were used during that time.
EQUAL
(Equal temperament)
This temperament divides the octave into twelve equal intervals. Modulating to a dierent key will not aect the sonority of
the chords.
WERCK.
(Werckmeister)
This temperament combines the meantone temperament and the Pythagorean temperament. It allows playing in all keys
(method 1, number 3).
KIRN.1
(Kirnberger 1)
This is an improvement of meantone temperament and just intonation to allow greater freedom of modulation. It allows
playing in all keys (method 1).
KIRN.3
(Kirnberger 3) This is a variation of Kirnberger 1 (method 3).
VALLO.
(Vallotti)
This is a relatively recent temperament. It is close to equal temperament but has a certain amount of just intonation, making
it easier to stay in tune with other instruments, and is thus frequently used for ensembles.
MEAN.D (Meantone
temperament)
This temperament is a partial compromise from just intonation in order to allow a certain degree of modulation. Preference
is given to the sonority in D#.
MEAN.E (Meantone
temperament)
This temperament is a partial compromise from just intonation in order to allow a certain degree of modulation. Preference
is given to the sonority in Eb.
PYTHG.
(Pythagorean tuning)
This is a system of tuning attributed to the philosopher Pythagoras, in which the fourth and fth are pure. Chords including
the third will not sound smooth, but the melody will sound good.
M.BACH
(Modern Bach) This is one of the recently researched temperaments from the era of Bach. It allows playing in all keys.
Tuning ±100 cents You can adjust this in a range of ±100 cents (a semitone) centered on the selected pitch.
Transpose -6–+5
The transpose function lets you shift the pitch in semitone steps without changing the keys you play on the keyboard.
MEMO
From the main screen, while holding the [SET] piston, turn the [Value/Exit Menu] knob to change the transpose. From the main
screen, press [0] piston, transpose will also be turned o.
Room Modeling
Reverb settings
Menu item Value Explanation
Room Type [S]
By changing the type of reverberation you can experience the sensation of performing in a variety of locations.
CHAMBER The reverberation of a pipe chamber
HALL The reverberation of a hall
CHURCH The reverberation of a church
CATHEDRAL The reverberation of a cathedral
Wall Type [S]
You can make additional changes to the reverberation by changing the wall type (the material out of which the wall is constructed).
DRAPERY Pleated curtains
WOOD Wood
BRICK Brick
MARBLE Marble

14
Making Settings in the Menus
USER/MIDI Coupler
• Selecting sounds that are not available via the sound tablets and stops
• MIDI coupler settings
• Adjusting sounds
Menu item Value
Division MAN-I A, MAN-I B, MAN-II A, MAN-II B, PEDAL A, PEDAL B
 Details of the available items will depend on the Source/MIDI CH setting.
Menu item Value Explanation
Source/MIDI CH
[V] [P]
USER Internal sound generator
CH1–16 MIDI transmit channel
The range will depend on the division that is selected.
Source/MIDI CH = USER
Menu item Value Explanation
Name [V] [P] Name of sound Select by sound name
Volume [V] [P] OFF, 0–127 Species the volume of the sound assigned to the [USER/MIDI] coupler.
Octave [V] [P] -2–+2, NORMAL Species the octave of the sound assigned to the [USER/MIDI] coupler.
Coarse Tune [V]
[P] (578 only) -12–+12 Adjusts the pitch in semitone steps.
Fine Tune [V] [P]
(578 only) -50–+50 Adjusts the pitch in a range of ±50 cents
Reverb [V] [P]
(558, 568 only) OFF, 0–127 Species the reverb depth for the sound assigned to the [USER/MIDI] coupler. For organ sounds, set this “OFF.”
Warmth [V] [P] -10–10 Adjusts the low-frequency tone for the sound assigned to the [USER/MIDI] coupler.
Presence [V] [P] -10–10 Adjust the mid-frequency tone for the sound assigned to the [USER/MIDI] coupler.
Brilliance [V] [P] -10–10 Adjusts the high-frequency tone for the sound assigned to the [USER/MIDI] coupler.
Velocity [V] [P]
KBD The keyboard’s velocity will be used
EXP The expression pedal’s position will be used
2–127 The specied value will be used as the velocity
 Velocity can be applied only to orchestral sounds
Source/MIDI CH = CH1–16
Menu item Value Explanation
Name [V] [P] Name of sound Select by sound name (refer to “Tone Name [S]” (p. 18))
PC Number
[V] [P] OFF, 001–128 Program change number
Bank MSB [V] [P] OFF, 000–127 Bank select MSB
Bank LSB [V] [P] OFF, 000–127 Bank select LSB
Volume [V] [P] OFF, 0–127 Species the volume
Octave [V] [P] -2–+2, NORMAL Species the octave (pitch)
Reverb [V] [P] OFF, 0–127 Species the depth of reverb
Chorus [V] [P] OFF, 0–127 Species the depth of chorus
Velocity [V] [P]
KBD The keyboard’s velocity will be used
EXP The expression pedal’s position will be used
2–127 The specied value will be used as the velocity
Expression [V] [P] OFF, ON Expression Pedal

15
Making Settings in the Menus
About MIDI transmit channels
When the [USER/MIDI] coupler is on
To avoid a conict between the MIDI transmit channels of the various
[USER/MIDI] couplers, the MIDI transmit channels are xed as follows.
Division (keyboard) Tablet name MIDI transmit channel
MAN-I (lower) USER MIDI A CH1–CH16
USER MIDI B CH5 (xed)
MAN-II (upper) USER MIDI A CH2 (xed)
USER MIDI B CH6 (xed)
PEDAL (pedalboard) USER MIDI A CH3 (xed)
USER MIDI B CH7 (xed)
When the [USER/MIDI] coupler is o
Even when the [USER/MIDI] coupler is o, the performance data from
each division is transmitted on the following MIDI channels.
As appropriate, you’ll need to change the MIDI reception settings on
the MIDI device that’s connected.
Division (keyboard) MIDI transmit channel
MAN-I (lower) CH12 (xed)
MAN-II (upper) CH13 (xed)
PEDAL (pedalboard) CH14 (xed)
 When using a [USER/MIDI] coupler to control an external MIDI sound
module, we recommend that you set your external MIDI device to not
receive messages on channels 12–14.
Console
• Screen contrast
• MEL and BASS coupler settings, and other settings
Menu item Value Explanation
Display Contrast
[S] 0–30
Adjust the Display Contrast
 This setting will return to the default value when you turn o the power, but you can store the setting so that it will be
remembered even after the power is turned o. For details, refer to “Storing Your Settings (Customize)” (p. 20).
Bass Split [S]
You are free to change the range in which the bass coupler will operate. The specied note and those below it will use the bass coupler.
Top key of the Bass coupler range
Bass coupler
Mel Split [S]
You are free to change the range in which the melody coupler will operate. The specied note and those above it will use the melody coupler, and
notes below it will not.
Melody coupler
Bottom key of the Melody coupler range
Blind [S]
BLIND When the [FULL ORGAN] piston is pressed or Crescendo pedal is activated, tablet illumination is turned o.
VISIBLE When the [FULL ORGAN] piston is pressed or Crescendo pedal is activated, tablet illumination is turned on.
OPERATE (578 only) When the [FULL ORGAN] piston is pressed or Crescendo pedal is activated, tablet illumination is turned on. Also you can
operate the tablets.
Auto O [S] OFF–240 min
If this is set to “240 min,” the power will automatically turn o 240 minutes after the Organ was last operated.
NOTE
After Auto O shut down, turn the power switch o. Wait at least ve seconds, then turn the power switch on again.
Music Rest Lamp
[S] (578 only) OFF, ON Setting Music Rest and Pedalboard Lamp.

16
Making Settings in the Menus
Tremulant
The tremulant eect adds vibrato (cyclic modulation) to the sound.
Menu item Value Explanation
Division MAN-I Sets the tremulant for MAN-I.
MAN-II Sets the tremulant for MAN-II.
Depth [V] (558, 568)
Depth [S] (578) 0–127 With a setting of “0,” no tremulant will be applied. Increasing this value will make the tremulant deeper.
Rate [V] (558, 568)
Rate [S] (578) 0–127 A slow tremulant will be applied with a setting of “0,” and this will become faster as you increase the value.
Exp. Pedal
Expression pedal settings
Menu item Value Explanation
Pedal Asgn [S]
(558, 568 Only)
EXPRESSION Expression pedal has Expression function
CRESCENDO Expression pedal has Crescendo function
MAN-I/Pedal [S]
[P] (*) (558, 568)
MAN-I/Pedal [P]
(578)
MAN I division and PEDAL division
OFF Not aected by the expression pedal
ON Aected by the expression pedal
MAN-II
[S] [P] (*)
(558,568)
MAN-II [P] (578)
MAN II division
OFF Not aected by the expression pedal
ON Aected by the expression pedal
* When Exp. Mode has been set to PISTON, settings can be stored on an individual general memory piston basis.
Shutter [V] (558,
568)
Shutter [S] (578)
You can adjust the minimum volume that will be in eect when the expression pedal is at the minimum position.
PPPP Least volume
PPP Low volume
PP Somewhat higher volume
UNENCL (578) Not aected by the expression pedal
Kick SW [S]
The kick switch is located on the side of the expression pedal. You can assign a function to the kick switch.
OFF The kick switch will be o.
NEXT This has the same function as the [NEXT] piston. It will switch to the adjacent general memory piston. Each time you press
the kick switch, the general memory piston will switch to the next higher number.
PREV This has the same function as the [PREV] piston. It will switch to the adjacent general memory piston. Each time you press
the kick switch, the general memory piston will switch to the next lower number.
SUSTAIN
Sustain will be applied while you are pressing the switch.
 Sustain can be applied only to some of the [USER/MIDI] coupler sounds and to the sounds of an external MIDI sound module.
 Sustain will not be applied to the sounds of the organ.
Exp. Mode [S]
(558, 568 only)
SYSTEM Only one set of settings for MAN-I/Pedal, MAN-II can be stored.
PISTON The settings for MAN-I/Pedal, MAN-II can be stored individually for each general memory piston.
[Crescendo
Setup]
(558, 568 only)
Refer to “Changing the Settings for Crescendo” (p. 25).

17
Making Settings in the Menus
Crescendo
Crescendo settings
Menu item Value Explanation
Crescendo Step 0–63 Refer to “Changing the Settings for Crescendo” (p. 25).
Audio
External device settings
Menu item Value Explanation
Aux In Volume [S] 0–127 Adjusts the volume of the external audio device.
Aux In Reverb [S] 0–127 Adjusts the reverb depth for the external audio device.
Line Out Gain [S] 0–127
Adjusts the volume that is output from the OUTPUT jacks.
 The volume balance for Master Volume and Line Out can be stored. For this reason, the value of the setting for Line Out Gain
can change depending on the value of Master Volume.
Master Volume [S] KNOB, 1–127
Adjusts the overall volume of the organ.
When set to KNOB, the Master Volume knob can be used to perform the adjustment.
When set to a value from 1 through 127, the Master Volume knob and Line Out Gain will be disabled.
[Division Audio]
(558, 568)
Adjusts the volume of the main and antiphonal speaker system.
Four dierent types of settings can be established depending on whether the [MAIN OFF] and [ANT ON] pistons have been pressed or not.
MAN-I/PD to Main1 [S] 0–127 The volume of MAN-I/Pedal to Main 1
MAN-I/PD to Ant [S] 0–127 The volume of MAN-I/Pedal to Antiphonal
MAN-II to Main2 [S] 0–127 The volume of MAN-II to Main 2
MAN-II to Ant [S] 0–127 The volume of MAN-II to Antiphonal
Orch to Main1&2 [S] 0–127 The volume of Orchestra to Main 1&2
Orch to Ant [S] 0–127 The volume of Orchestra to Antiphonal
Aux In to Main1&2 [S] 0–127 The volume of Aux in to Main 1&2
Aux In to Ant [S] 0–127 The volume of Aux in to Antiphonal
Reverb to Main1&2 [S] 0–127 The volume of Reverb to Main 1&2
Reverb to Ant [S] 0–127 The volume of Reverb to Antiphonal
[Division Audio]
(578)
Adjusts the volume of the main and antiphonal speaker system.
Four dierent types of settings can be established depending on whether the [MAIN OFF] and [ANT ON] pistons have been pressed or not.
MAN-I to Main [S] 0–127 The volume of MAN-I to Main
MAN-I to Ant [S] 0–127 The volume of MAN-I to Antiphonal
MAN-II to Main [S] 0–127 The volume of MAN-II to Main
MAN-II to Ant [S] 0–127 The volume of MAN-II to Antiphonal
PEDAL to Main [S] 0–127 The volume of Pedal to Main
PEDAL to Ant [S] 0–127 The volume of Pedal to Antiphonal
ORCH to Main [S] 0–127 The volume of Orchestra to Main
ORCH to Ant [S] 0–127 The volume of Orchestra to Antiphonal
AUX-IN to Main [S] 0–127 The volume of Aux in to Main
AUX-IN to Ant [S] 0–127 The volume of Aux in to Antiphonal
Reverb to Main [S] 0–127 The volume of Reverb to Main
Reverb to Ant [S] 0–127 The volume of Reverb to Antiphonal

18
Making Settings in the Menus
MIDI
MIDI settings
Menu item Value Explanation
Local
When the organ is connected to a MIDI sequencer, change this setting to Local O.
OFF Local O: the keyboard is disconnected from the internal sound generator. No sound will be heard when you play the
keyboard.
ON Local On: the keyboard is connected to the internal sound generator.
Tone Name [S]
When using an [USER/MIDI] coupler with an MX-200 or GM2-compatible external MIDI sound module, you can make the sound names of your MX-200
or GM2-compatible sound module appear in the “USER/MIDI” screen.
OFF Tone name will not show.
MX200 The screen will show the name of the MX-200’s sound if an MX-200 is connected as an external MIDI sound module.
GM2 The screen will show the name of the GM2 sound if a GM2-compatible sound module is connected as an external MIDI
sound module.
TX Piston [S]
When transmitting performance data via MIDI, you can specify the type of MIDI data that will be transmitted when you press a general memory piston
and division memory piston.
OFF MIDI data will not be transmitted.
STOP MAP
Data describing the details of the sounds that should be produced when that piston is pressed will be transmitted. If you’re
recording your performance into a MIDI sequencer, this will ensure that the sounds are reproduced accurately. However,
since a large amount of data is transmitted when you press the piston, the sounding of the rst note-on after you press the
piston may be delayed in some cases.
PC
Only program changes indicating the current memory bank and the memory piston that was pressed will be transmitted.
If you’re recording your performance into a MIDI sequencer, the performance will not be accurately reproduced unless the
contents of the memory bank used during the performance match the contents during recording. However, since a large
amount of data will not be transmitted when you press the piston, there will be no signicant delay in the rst note-on after
you press the piston.
Visual Control
When external, MVC/V-LINK-compatible, audiovisual presentation equipment is connected, you’ll be able to control the imagery presented by such
equipment at the same time as you play the organ. When you press a general memory piston, messages used for video control will be transmitted from
the MIDI OUT connector. This allows you to control the imagery presented by the audiovisual equipment.
OFF The MIDI Visual Control function is o.
MVC MVC is on
V-LINK V-LINK is on
Selecting sounds on your external MIDI
device
How sound names are displayed
If an MX-200 or a GM2 compatible sound module is connected, you
can set “Tone Name [S]” (p. 18) to the model of sound module you’re
using, so that the “USER/MIDI Coupler” screen’s “Name” eld will show
the names of the sounds, allowing you to choose sounds by name.
Using the keyboard to select
You can use the following method to select sounds on your external
MIDI device.
1. Turn on the desired [USER/MIDI] coupler.
2. Set it like this: Source/MIDI CH = CH 1–16.
3. Hold down the [SET] piston and play a note on the
keyboard and the pedalboard. The [USER/MIDI] coupler
will blink.
The program change corresponding to the note you played will
be transmitted, and the sound selection on your MIDI device will
change.
Each note of the keyboards corresponds to the following program
changes.
Keyboard Tone name Program change
Lower keyboard C2–C7 1–61
Upper keyboard C2–C7 62–122
Pedalboard C2–F2 123–128

19
Making Settings in the Menus
Save/Load (USB)
Save/load the contents of the general memory pistons and voice setup, and format the USB ash drive
Menu item Explanation
Save Memory Bank (558, 568 only) Refer to “Saving and Loading Memory Banks (558, 568 only)” (p. 32).
Load Memory Bank (558, 568 only)
Copy Memory Bank Refer to “Copying a Memory Bank” (p. 33).
Delete Memory Bank Refer to “Deleting a Memory Bank from USB Flash Drive” (p. 33).
Save Voice Setup Refer to “Saving and Loading Voice Setup” (p. 33).
Load Voice Setup Refer to “Loading a Voice Setup” (p. 34).
Delete Voice Setup Refer to “Deleting a Voice Setup” (p. 34).
Format USB Memory Refer to “Formatting USB Flash Drive” (p. 32).
Utility
Backing Up Data/Performing an Initialization
Menu item Explanation
Version Refer to “Displaying the Version” (p. 35).
Back up/Restore Refer to “Backing Up/Loading Data” (p. 35).
Factory Reset Refer to “Returning all Settings to the Factory-Set State (Factory Reset)” (p. 35).

20
Making Settings in the Menus
Storing Your Settings (Customize)
The following settings will return to their default state when you switch o the organ’s power, but you can use the procedure described below to store
these settings.
Setting Group
Default Voice Palettes (*)
VOICING
“User/MIDI coupler” screen settings
“Tremulant” screen settings (558, 568)
Loaded Voice Setup (p. 34)
“Room Modeling” screen settings
SYSTEM
“Console” screen settings
“Tremulant” screen settings (578)
“Exp. Pedal” screen settings
“Audio” screen settings
Satellite Volume settings
“MIDI” screen settings
“Guide Tone” and “Guide Volume” settings in “Song
Recorder” screen
Hymn book (578)
* What is the Default Voice Palette?
The “Default Voice Palettes” species which variation sound will be heard when you turn on a specic tablet.
If you specify the variation sounds that you frequently use, you’ll be able to play those variation sounds simply by selecting those tablets, without
needing to select the variation sounds.
1. Hold down the [SET] piston and press the [0] piston.
Conrmation screen will appear
2. Turn the [Value/Exit Menu] knob to choose the group.
• If you choose “VOICING,” the VOICING group settings will be saved.
• If you choose “SYSTEM,” the SYSTEM group settings will be saved.
3. Press the [SET] piston to store the settings.
If you decide to cancel, press the [Value/Exit Menu] knob.
NOTE
 Never turn o the power before the storage has been completed. (Wait until the “Executing” indication is no longer shown.)
