Rohnson R-892 User manual

1
R-892
Portable Air Conditioner
User’s Manual

2
Thank you for choosing this mobile air conditioner to provide you and your family with all of the
“Home Comfort”requirements for your home,cottage or office.The appliance can be moved
From room toroom within your home and set-up in just minutes.
It is a multi-functional room air exchanging,air-processing appliance,designed to offer you the
Functions of:Air Conditioning,Dehumidifying,Independent Fan and Heating.The external static
Pressure at which the appliance was tested is 0 Mpa.
This manual will provide you with valuable information necessary for the proper care and maintenance
For your new appliance.Please take a few moments and read the instructions thoroughly.If properly
Maintained,your appliance will give you many years of trouble free operation.
1. All wiring must comply with local and national electrical codes and be installed by a qualified electrician
If you have any questions regarding the following instructions,contact a qualified electrician.
2.Check available power supply and resolve any wiring problems before installation and operation of this unit.
3.For your safety and protection,this unit is grounded through the power cord plug when plugged into
a matching wall outlet.If you are not sure whether the wall outlets in your home are properly grounded,
please consult a electrician.If supply cord is damaged,it must be replaced by the manufacture,its
service agent orsimilarly qualifiedpersons in order toavoid a hazard.
WARNING
To reduce the risk of fire,electrical shock or injury when
using your air conditioner,follow these basic precautions:
1.Plug into a grounded 3 prong outlet.
2. Do not remove ground prong.
3.Do not use an adapter.
4.Do not use an extension cord.
5.Unplug air conditioner before servicing.
6. Use two or more people to move and install air conditioner.
Caution,risk of fire
7. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
8. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
9. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
10. The appliance shall be installed in accordance with national wiring regulations
11. This appliance is not intended for use by persons(including children)with reduced physical,sensory or mental capabilities,
or lack of experience and knowledge,unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.Young children should be supervised to ensure that they do not play with the appliance.
12. Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes throughout
The EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,
Recycle it responsibly to promote the sustainable reuse of material resources.To return your used device,
Please use the return and collection , systems or contact the retailer where the product was purchased.They
Can take this product for environmental safe recycling.
13. Do not use means to accelerate the defrosting process or to clean,other than those recommended by the manufacturer.
Recommended by the manufacturer.
The appliance shall be stored in a room without continuously operating ignition sources for
example: open flames, an operating.
Gas appliance or an operating electric heater.
Be aware that refrigerants.
May not contain an odour.
Do not pierce or burn.
the maximum refrigerant charge amount: 260g

3
1
Identification of parts
5
Control panel
Cold air outlet
Signal receptor
Remote controller
Transport handle
Air outlet hose
Evaporator air intake
Primary drain port
Back
7
6
8
The figures in this manual are based on the external view of a standard model.
Consequently, the shape may differ from that of the air conditioner you have selected.
Identification of parts
Front
1
2
3
4
2
3
4
6
5
7
8

3
“
”
E
mobile
SWING/UV FAN
On/Off button
Timer button
Swing / uv button
Speed button
Mode button
low 、middle 、 high Fan speed
and Fan Model operation.
Timer/Temperature up button
Timer/Temperature down button
Aatomatic 、 Cool 、
Dehumidify and Fan mode
Full water alarm
a) Plug in,then the unit beeps once.
Power
6.
Swing
Press this button to set swing .
“
”
“”
E
“
”
C by 1

4
* mode
：
1. Once the Operation is selected, the indoor temperature sensor operates
automatically to select the desired operation mode with or .
2. When the room temperature ≥ 24 ℃ ,the unit will automatically select mode .
3.
When the room temperature
＜
24
℃
,the unit will automatically select mode .
* mode
：
1 . The up centrifugal fan will run at low speed ,and the speed can’t be adjusted.
2 . The compressor and the down centrifugal fan will stop after running 8 mins, then
run again after 6mins.
3 . The unit adopts constant temperature dehumidifying mode,and the adjustment
of temperature is no effective.
* mode
：
1.When the room temperature is higher than set temperature ,the compressor starts to run.
2.When the room temperature is lower than set temperature ,the compressor stop and
operate at original set speed.
* mode :
1.The up centrifugal fan runs at set speed , and the compressor does not run .
2.
The adjustment of temperature is no effective.
operation
1.Press “Timer” button to set Automatic Off time while the unit is running.
2.Press “Timer” button to set Automatic On time while the unit is ready.
3.The time can be adjusted within a range of 1 hour to 24 hour. Press the temp up( ) or
temp down( ) button to increase or decrease the time 1 hour by pressing once .
operation
1. The operation is effective when the unit is under mode.
2.
Press the button in mode,then the unit will work under sleep mode and
the up centrifugal fan will turn to low speed automatically. The set temperature
will increase 1 ℃ after one hour, and increase 2 ℃
the unit will stop running.
after two hours. After six hours,
Swing / uv button
1. Press button, the swing function is effective and swing blade swings up and down automatically.
2. Press and hold button for 3seconds, the UV indciator is on and UV function is effectived.
3. Press and hold button for 3seconds again, the UV indciator is off and UV function is cancelled.
Notice:
Except the AUTO mode, the appliance has the memory function: when the appliance is turned
on it will return to the working mode before it is turned off in case the appliance has never been
unplug from the main source.

5

6
How to install batteries
Inserting batteries
Slide the cover to open
Be sure the direction
is correct
1. Open the back cover, and take off the isolating film on the batteries ;
2.
Put the batteries inside the slot, with anode and cathode in right directions;
3. Put on the back cover.
Notices:
1). The anode and cathode of the batteries must be corresponding to the signs of
“+” and “-”on the remote control;
2). Do not use new battery cells together with run-down cells;
3). For long time no use, take out the batteries;
4 ). To prevent environmental pollution ,
take out the used batteries and dispose
safely and appropriately.
distance of up to 5m (16.4 feet) when pointing
at singal receptor of the air conditioner

7
Special reminder: there is condensing water recycling hidden within this unit. The
condensing water is partly kept recycling between the condenser and the water plate.
When the water level rises to the upper level, the float switch
and water full indicator (E4) lights on to remind draining water. Please cut off the
power supply, move the appliance to a suitable place, remove the drain plug, drain water
completely. after the drain, re-install the plug, or the appliance may leak and make your room wet.
Notice:
1. When the machine is temporarily
unused, drain from the bottom
drain hole.
Pull out the water plug Internal diameter 10mm pipe connect the drain pipe
2. When use dehumidifying function
a long time, please use the drain pipe
to dran the water continousely.
Pull out the
upper water
plug
Internal diametere
10mm
connect the drain pipe
Cooling
Dehumidifying
5
5

8

9
“E4”

10
Before claiming repair, check the machine as follows:
Failures
Causes
Solutions
Machine fails to start up.
Power supply failure:
1. Not plugged;
2. Plug or socket damaged;
3. Fuse broken.
1. Plug in;
2. Replace the power cord or
socket;
3. Replace the fuse by service
provider (Specification:
3.15A/250VAC).
Machine automatically
stops.
TIMING shut down or set
temperature reached.
Restart or wait for auto-switch.
No cold air under
COOLING mode.
1.Room temperature lower
than set temperature;
2. Machine enters into
anti-frost protection.
1. This is a normal
phenomenon, the machine will
auto-switch while the room
temperature is higher than the
set temperature;
2. The machine will auto switch
after anti-frost protection is
over.
LED displays failure
code “E2”
Room temperature sensor
fails or damaged.
Replace the room temperature
sensor.
LED displays failure
code “E3”
The evaporator oil pipe sensor
fails or damaged.
Replace the evaporator coil pipe
sensor.
LED displays failure
code “E4”
Water-full warning.
Drain out the water.

11
Installation accessories
1
2
3
Air exhaust duct 2 Connector of air exhaustduct
Window exhaust adapter 4 Remote control
Baffle Plate
6 Remote control
6
5
4
Installation
1
3
5

12
How to connect the connectors to the Air exhaust duct
1. Extend the air exhaust duct by drawing out the two ends of the duct.
2.
Screw the air exhaust duct into the connector of air exhaust duct.
3.
Screw the connector of window into the plastic connector.
4. Connect the connector of air exhaust duct to the unit .

13
Warranty Information
The manufacturer provides warranty in accordance with the legislation of the
customer's own country of residence, with a minimum of 1 year, start from the
date on which the appliance is sold to the end user. .
The repairs under warranty may only be carried out by an authorized service
centre. When making a claim under the warranty, the original bill of purchase
(with purchase date) must be submitted.
The warranty will not apply in cases of:
-Normal ware and tear
-Incorrect use, e.g. overloading of the appliance, use of non-approved
accessories
-Use of force, damage caused by external influences
-Damage caused by non-observance of the user manual, e.g.connection to
an unsuitable mains supply or non-compliance with the installation instructions
-Partially or completely dismantled appliances
Cautions
Keep the unit at least 1 meter away from TV or radios to avoid electromagnetic
interference.
Do not expose the unit under direct sun light to avoid surface color fading.
Do not tilt the unit for more than 35°or upside-down while transporting.
Place the unit on a flat surface with less than 5°inclination.
The unit operates more efficiently in certain room locations (see Technical
Specifications).
Empty the condensed drainage pan before putting the unit in storage to
prolong the unit lifetime at the end of the season.
Do not use chemical solvents (e.g. Benzene, alcohog-glazer) to clean the unit
surface to avoid scratching, damaging the surface.
Make sure to cut off the power before disassembing or installing the air-inlet
fence.
Please empty the water from the water tank, if you want to move the machine.
The battery must be removed from the appliance before it is scrapped
The battery is to be disposed of safely
The plug must be removed before cleaning, maintaining or filling the appliance
Using Information

14
Model
R-896
RatedVoltage /Frequenc(V/Hz)
220-240V~/50Hz
EER
rated Class
A
Dimensions
WXDXH
Body (mm)
440 X335 X710mm
Package (mm)
470X380X880mm
Refrigerant
R290
Miniature Fuse
3.15A 250VAC
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a
dealer providing this service.
Disposing of a household appliance separately avoids possible negative consequences
for the environment and health, deriving form inappropriate disposal and enables the
constituent materials to be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household appliances separately, the
product is marked with a crossed-out wheeled dustbin.
Technical specifications
