Rohnson R-2315 User manual

Contact Grill R-2315
EN
1
Instructions Manual
Contact Grill R-2315
Read this booklet thoroughly before using and save it for
future reference.

Contact Grill R-2315
EN
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
•READ ALL INSTRUCTIONS BEFORE USE
•Do not touch hot surfaces. Use the handle.
•Before using, always check that the electrical rating of the power socket
corresponds to that of the appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
•Do not let cord hang over edge of table or counter, or touch hot surface.
•Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
•Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
adjustment.
•The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
•Do not place the product on or near a hot gas or electric burner, or in a heated
oven.
•Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
•To protect against fire, electric shock and injury to persons, do not immerse
cord, plug, or the grill in water or other liquid.
•Do not plug or unplug the product into/from an electrical outlet

Contact Grill R-2315
EN
3
with a wet hand.
•If the product falls into water, immediately unplug it from the
electrical outlet. Do not touch or reach into the water.
•Use in a well-ventilated area. Keep at least 4-6 inches of space
on all sides to allow adequate air circulation.
•To disconnect, turn off any control, then remove plug from wall outlet.
•Do not use appliance for other than intended use.
•The appliance must not be used by an external timer or remote control
system. Don’t use an accessory not recommended by the manufacturer.
•Don’t wrap food with plastic film, polythene bags or metal foil. You’ll damage
the grill and may cause a fire hazard. Don’t leave food to cool on the grill.
Remove food while hot.
•Don’t use metal or sharp utensils on the grill. They’ll damage the non-stick
cooking surface. Use wooden or plastic spatulas or tongs.
•Children should be supervised to ensure that they do not play with the
appliance.
•WARNING: charcoal or similar combustible fuels must not be used with this
appliance.
•CAUTION-‘hot surface’. The appliance generates heat and escaping steam
during use. Take proper measures to prevent injury, burn or fire.
•Do not leave unattended while in use.
•Close supervision is necessary when any appliance is used by or near
children.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction

Contact Grill R-2315
EN
4
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older than 8 and
supervised.
•Do not use outdoors.
•This appliance is intended to be used in household and similar applications
such as:
-staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments
CAUTION—To reduce the risk of personal injury:
•This product is intended solely for indoor, non-commercial, non-industrial,
household use in cooking/heating food for human consumption. Do not use
the product outdoors or for any other purpose.
•Do not allow the Power Cord to hang where it may be tripped over or
pulled(e.g., over the edge of a table or counter), and do not allow the Cord to
touch hot surfaces.
•Always wear protective oven mitts or heat-resistant gloves when using this
product and use utensils.
•To disconnect from the electrical outlet, pull directly on the Plug; do not pull on
the Power Cord.
•Always use the product on a flat, level, stable, heat-resistant surface.
SPECIAL INSTRUCTIONS:
A short power-supply cord is provided to reduce the risk resulting from becoming

Contact Grill R-2315
EN
5
entangled in or tripping over a longer cord. Extension cords are available and may be
used if care is exercised in their use. If an extension cord is used:
•The marked electrical rating of the extension cord must be at least as great as
that of the product;
•The cord should be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or tripped over unintentionally;
SAVE THESE INSTRUCTIONS
PARTS IDENTIFICATION
1. Aluminum arm
2. Upper plate
3. Bottom plate
4. Release button of lower
cooking plate
5. Handle
6. Upper housing
7. Locking clip
8. Bottom housing
9. Oil tray

Contact Grill R-2315
EN
6
BEFORE FIRST USE
•Read these instructions before use and keep them safe. If you pass the grill
on, pass on the instructions too.
•Remove all packaging, but keep it until you are satisfied that the grill is
working.
•Unpack the package, take out all the accessories and clean them according to
the section of “CLEAN AND MAINTENANCE”.
•Unwind the power cord completely and insert the power plug into a grounded
wall outlet.
•Press the Upper Plate Release Button to remove the upper Grill Plate and
then press the Lower Plate Release Button to remove the lower Grill Plate.
Clean the Grill Plates, the Drip Cups, and the Scraper/Cleaning Tool in warm,
soapy water; rinse and let dry. These parts may also be washed in an
automatic dishwasher. NEVER IMMERSE THE BASE INTO OR EXPOSE IT
TO WATER.
•Reinsert the upper and lower Grill Plates into their respective positions before
use. See the “Inserting/Changing Plates” subsection below for detailed
instructions.
NOTE: When using the Grill Plates for the first time, spray or apply a thin layer of
cooking oil onto the nonstick surfaces of the Plates with a paper towel in order to
season the nonstick surface. As necessary, reapply a thin layer of cooking oil
throughout the life of the Plates to maintain best nonstick performance.
Notice: When your Grill is heated for the first time, it may emit slight smoke or
odor. This is normal with many heating appliances. This does not affect the
safety of your appliance.

Contact Grill R-2315
EN
7
To Assemble
Place the product on a clean, flat, level, stable, heat-resistant surface with at least 4-6
inches of space on all sides to allow adequate air circulation.
Positioning the Upper Housing:
1. Closed/Heating Position: The Upper Housing is closed and rests on the Base.
Use this position when starting/heating the product and when grilling most
foods.
2. Open Position: The Upper Housing is open. Place the Product in this position
when starting to use the Grill function, and when grilling certain foods in which
the upper Grill Plate is not appropriate, such as pizza or fish. Lift the Handle
until the Upper Housing is at about a 90°angle.
Inserting/Changing Plates:
Slide the notches in the rear of the lower Grill Plate into the retaining hooks, then press
down on the front of the plate to snap it into place. Repeat to attach the upper Grill
Plate.

Contact Grill R-2315
EN
8
HOW TO USE
WARNING: The Grill Plates and metal surfaces of the Upper Housing and Handle will
become very hot during use. To avoid a burn hazard, wear protective oven mitts or
heat-resistant gloves when using and touch only the black portion of the Handle.
NOTICE: Use only heat-resistant wooden, plastic, or silicone utensils to add/remove
food. Do not use a metal utensil as it may scratch the surface of the item.
NOTE: During the initial use this item may emit some light smoke. This is normal and
will subside with further use.
Contact Grill:
Use to cook burgers, boneless or thin pieces of meat and fish, and vegetables. In the
“Closed” position, food will cook quickly since both sides cook at the same time.
Operation panel instruction:
1. Panel interface consists of the power button, start/cancel button, and up and
down two rows of mode selection of key combination, touch-sensitive keys,
meanwhile, there is an indicator light under the button, specific instructions as
below.
•Control panel description (See below):

Contact Grill R-2315
EN
9
Seven cooking modes: BURGER / CHICKEN / SANDWICH/ SAUSAGE /
MEAT / FISH / M
1. Power button:
Pressing the power button, the power light on long time, turn on all the indicator
lights on the interface at the same time (After 1.5s,except
BURGER/CHIKEN/SANDWICH/SAUSAGE/MEAT/FISH/M seven cooking mode
lights on, all other lights go out, the light status is on standby), press the power
button again, turn off the power and all the indicator lights are extinguished. The
gears have no memory function, after power off, the next start interface enters
the initial state, The power button keep bright throughout the cooking process. If
press the power button during cooking, that means the forced shutdown.
1. Power On/Off button
2. Defrost Mode
3. Manual Mode
4. Start/Cancel
5. Preheating mode
6. Progress bar

Contact Grill R-2315
EN
10
2. Power button:
Pressing the power button, the power light on long time, turn on all the indicator
lights on the interface at the same time (After 1.5s,except
BURGER/CHIKEN/SANDWICH/SAUSAGE MEAT/FISH/M seven cooking mode
lights on, all other lights go out, the light status is on standby), press the power
button again, turn off the power and all the indicator lights are extinguished. The
gears have no memory function, after power off, the next start interface enters the
initial state, The power button keep bright throughout the cooking process. If press
the power button during cooking, that means the forced shutdown.
3. Preheating mode:
Power button starts, the power lamp is long time go on and goes into standby
mode. at the same time all the indicator light go on (after 1.5 S, except
BURGER/CHIKEN/SANDWICH/SAUSAGE MEAT/FISH/M seven cooking mode
lights on, all other lights go out, the user select one of the
BURGER/CHIKEN/SANDWICH/SAUSAGE mode (for example BURGER, the
BURGER light long time on, the remaining six kinds of cooking mode selection
button which are not select and will go out, under the white bar, the PREHEATING
button flashing and the start/cancel button flashing)When the user presses the
start/cancel button, BURGER/PREHEATING/ start/cancel three buttons will flash
at the same time, and the machine will start to preheat. After preheating, the
buzzer beeped five times(The frequency is 1Hz. the first 4 sounds are short and
the last one is long and lasts 2 seconds).The BURGER/PREHEATING/ two
buttons lights are on, and the PREHEATING mode is complete.
The user select one of the MEAT /FISH mode (for example MEAT, the MEAT light
long time on, the remaining six kinds of cooking mode selection button which are
not select and will go out, under the white bar, the PREHEATING button flashing
and the start/cancel button flashing)When the user presses the start/cancel button,
MEAT /PREHEATING/ start/cancel three buttons will flash at the same time, and
the machine will start to preheat. After preheating, the buzzer beeped five

Contact Grill R-2315
EN
11
times(The frequency is 1Hz. the first 4 sounds are short and the last one is long
and lasts 2 seconds).The MEAT /PREHEATING/ two buttons lights are on, the
RARE/MEDIUM/DONE/WELL-DONE button start flashing, and the PREHEATING
mode is complete.
4. Selection of cooking mode:
Note that when the user selects one of the BURGER/CHIKEN/ SANDWICH/
SAUSAGE modes, BURGER as an example: after preheating, the buzzer beeped
five times(The frequency is 1Hz. The first 4 sounds are short and the last one is
long and lasts 2 seconds).,The BURGER/PREHEATING two buttons light are long
time on, the start/cancel button flashing, the preheating mode is completed. The
light on the four cooking levels (RARE/MEDIUM/DONE/WELL-DONE) below the
white bar was off and none of the four buttons responded when pressed. The user
put down the food and press start/cancel button, and then the BURGER/DONE/
start/cancel light will be long time on, The middle white bar begins to appear from
left to right, When the cooking is finished, the buzzer beeped five times(The
frequency is 1Hz. the first 4 sounds are short and the last one is long and lasts 2
seconds). When the user selects MEAT /FISH, for example meat, after preheating,
the four cooking levels below the white bar begin to flash, the user selects one of
them, for example DONE, and the other three go out. PREHEATING light turn off,
start/cancel button flashing. After pressing the start/cancel button, and then the
MEAT/DONE/start/cancle three button light long time on .The middle white bar
begins to appear from left to right, When the cooking is finished, the buzzer
beeped five times (The frequency is 1Hz. The first 4 sounds are short and the last
one is long and lasts 2 seconds). The program returns to standby mode, pressing
the start/cancel button during cooking to return the machine to standby mode.
5. Defrost:

Contact Grill R-2315
EN
12
Food is in state of room temperature or in unthawed, the cooking time is different,
so set the DEFROST button. If thawing mode is chosen, the cooking time is
increased by 2 minutes on the basis of the set time. For example, choose the
DEFROST + MEAT + DONE, the cooking time is 7 minutes. The thawing key must
be used in combination with other food selection. After selecting the food button,
the thawing button can be pressed. After selecting the food key, the thawing key
can be pressed. To cancel the thawing, press it again.
6. Manual mode selection key:
In the selection state of mode, if the manual key M is pressed, the top and bottom
two rows of buttons are extinguished. the Manual key M indicator light is on and
the start/cancel button flashing. If the start/cancel button is pressed at this time,
the manual key M and the start/cancel button light will be on, which means start
cooking by hand. Press the start/cancel button again during cooking, and the
machine returns to standby, no pressing buttons for more than 30 minutes, the
machine turn into sleep mode, Interface display all extinguished, only by pressing
the power button again to wake the machine up and it goes into the initialization
state. Manual mode M is used separately, not in combination with the any food
type selection key, defrost and cooking time selection key.
7. Start/Cancel:
After completing the selection of cooking mode, press the start/cancel button to
start cooking. If the cooking state has not been completed in the middle of the
process, press the start/cancel button again to return to the standby state.
8. Cooking finished:

Contact Grill R-2315
EN
13
At the end of the selected automatic cooking mode, the buzzer will ring 5 times
(The frequency is 1Hz. The first 4 sounds are short and the last one is long and
lasts 2 seconds) and then return to standby mode.
The above described indicator flash frequency is 0.5s once, the color of indicator
is white
9. Sleep mode:
After the machine into standby mode, no pressing buttons for more than 30
minutes, the machine turn into sleep mode, Interface display all extinguished, only
press the power button again to awaken machine and it goes into the initialization
state.
After selecting the cooking mode,no pressing start/cancel button to start
preheating for more than 30 minutes, the machine turn into sleep mode.
10. NTC test:
If there is any contact or damage failure, the machine will stop working
automatically and all the indicator lights will flash at a frequency of 1HZ.
11. Mode switch:
In the cooking process, only switching to manual mode is responsive, it can switch
to manual mode, the manual button M indicator light is on, the start/cancel button
flashing. Press other buttons without response, cannot switch to other cooking
mode. If switch to other cooking modes during manual mode, for example
BURGER, the BURGER light is on, at this moment, the NTC detection
temperature did not reach the preheating temperature, the PREHEATING flash
and the start/cancel button flash, and then press the start/cancel button to start
cooking food. If the NTC test temperature has reached the PREHEATING

Contact Grill R-2315
EN
14
temperature, the PREHEATING light is on, the start/cancel button flashing, press
the start/cancel button to start cooking food.
12. Progress bar instructions:
There is a narrow and long area on the panel interface, with LED lights on at the
bottom as the progress indicator, as shown in the above scheme.
Progress bar display:
The narrow progress bar is divided into four areas, green, yellow, orange and red, and
the corresponding color of LED lights are set at the bottom. In standby mode, all LED
lights are not on, and the progress bar starts to light up in turn when it is cooking. For
example, in MEAT + MEDIUM mode, press the start/cancel button to start cooking.
meanwhile,LED1 begins to flash, after flashing for a period of time,LED1 is long time
on,LED2 is flashing, after the same time as LED1, the LED2 will long time on, and
LED3 will start flashing, thus until the last LED in the red area flashes. When the
expected time arrives (e.g., 5 minutes), before the cooking is finished, the last LED will
keep flashing until the cooking finished and it will be long time on. After finishing
cooking, all the LED lights of the progress bar are lit up, and the buzzer rings 5 times
(The frequency is 1Hz. the first 4 sounds are short and the last one is long and lasts 2
seconds). The program returns to standby mode.
M progress bar display:
Manual, the progress bar is set to flash at 15 minutes, When the last LED flashes, the
cooking continues, the buzzer does not ring, nor does it return to standby, until the
start/cancel button is pressed again, the machine returns to standby mode.
LED1
LED2
LED3
…

Contact Grill R-2315
EN
15
Progress bar LED flash as per frequency 1 second 1 time.
CLEANING AND MAINTENANCE
1. This product contains no user serviceable parts. Refer service to qualified service
personnel.
2. Before cleaning, disconnect the grill and let it cool down completely.
Note: The grill is still very hot. It will take quite a while to cool down.
3. Press down release button and take apart the roasting trays.
4. After disassembling the trays, wash the roasting trays in warm soapy water or in a
dishwasher. Dry the roasting trays before replacing them on the grill.
5. Remove the upper and lower drip trays with gloves, empty the drip tray into a
heat-proof bowl, rinse them in warm soapy water or in the top rack of the dishwasher
and then dry them thoroughly.
Note: before removing the drip box, make sure the temperature of oil or oil residues in
the drip box must be lower than 40℃, otherwise it may burn person for high
temperature.
6. Wipe other surfaces of the grill with a clean damp cloth. Use a paper towel
moistening with a little cooking oil to remove the stubborn stain.
7. Reassemble the roasting trays into grill.
➢Do not immerse the appliance into water or other liquid.
➢Do not use harsh or abrasive cleanser or solvent.
➢Never use scourers, wire wool or soap pads.
STORAGE

Contact Grill R-2315
EN
16
1. Before storing the grill, make sure the grill is clean and dry thoroughly.
2. Close the grill. And rest it flatly.
3. Store the grill in a cool dry area out of the reach of children. The grill can not be
rested vertically.
TECHNICAL SPECIFICATIONS:
Caution: the surfaces are liable to get hot during use
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a
dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health, deriving form inappropriate disposal
and enables the constituent materials to be recovered to obtain significant savings in
energy and resources. As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
Voltage
Frequency
Wattage
Model
220-240VAC
50/60Hz
2000W
R-2315
