INSTRUCTIONS MANUAL
STEAM IRON
MODEL: R-335
Please read these instructions for use and have a good look at the illustration before using the appliance
Main features:
The product has many functions such as temperature regulating, Spraying, Dry Ironing, Normal Steam,
Burst Steam, Self-Cleaning, etc. and is with characteristics: luxury shape, high heat efficiency, easy using,
good ironing result work and time saving, and so on.
A: Steam regulating Knob G: Water tank
B: Burst steam button H:Stainless Steel Soleplate
C: Spraying button I: Spraying mouth
D: Indicator bulb J: Cover of water filling mouth
E: Movable wire K: Self-clean
F: Temperature regulating knob
Main features:
1. High precision temperature adjuster (Thermostat): high precision temperature adjuster was used; it
is called Thermostat. We fixed the temperature range according to the kind of materials.
2. Heat protecting: when the working temperature pass its normal one. The fuse will melt automatically,
and cut off the power supply. When the failure happens, it must be sent to its service agent in order to
avoid a hazard.
Usage
Steam ironing:
1. Before ironing, please make sure the goods can be iron.
2. Pull up the cover of water filling mouth, fill water into water tank, until it reaches the “max” position. Water
capacity is 270g.
3. Push the cover back to its original position.
4. Turn the temperature adjusting knob to the “0” position, ensure the iron is on the smooth and stable
place vertically. Then put the plug into the socket.
5. After about 1.5 to 3 minutes, the indicator will turn off, when the indicator turn on again, your can start
ironing with steam.
6. Adjust Steam regulating Knob, the steam will spurt continuously (you can use it when iron the clothes)
7. Press the Burst steam button, the steam will spurt out from Stainless Steel soleplate (you can use it in
vertical or flat position )
8. Vertical steam ironing: convenience to iron clothes which was hung on.
9. During ironing clothes, if you need some water on the clothes for easy iron, you could press Spray button,
and some water will come out from spraying mouth
10. If no steam goes out, it means no water in the water tank now. At this moment, you must turn off the

steam button. If you want it to work on, pull out the plug first, then fill in water, push the cover of water filling
mouth back. Put the plug into the socket. Then you can continue to use it.
11. After ironing is complete, turn the temperature adjusting knob to “0” position, pull the plug out of the
socket. Then pour the water out and turn the temperature adjusting knob to the “MAX” position. Put the plug
into the socket again and press the burst steam button again and again, till no water inside. This method is
used to prevent remained water into damager box, and damage the steam function.
Function
Powerful Burst steam spurting:
Strong and High-pressure steam helps to smooth the firm gruffer
1. Dry cleaning function:
Strong and powerful steam will give you a wonderful effect no less then dry cleaning shop.
2. Sterilization function:
100high temperature steam, more than once spurt, all kinds of germs will be killed. It can be used in your
kitchen, toy, mattress, sofa and so on
Take off bad smell
With High-pressure steam spurting, no bad smell clear away.
3. Convenience:
Very easy to use without stokehold hanging
Over speed steam spurting
Powerful steam jet
Easier heat up, you can iron clothes in minute.
Accident avoidance
Inspection part
Failure
Water tank Temperature
adjusting knob
Steam bore power supply Heating body
power
No steam
Little steam
Can not heat up
Cloth burnt and
shrink
Water drop from the
steam bore
water tank
without
water
Temperature
adjusting knob
in the correct
position or not,
choose a right
temperature,
Clear scale
away
check the
indicate light
can work or
not, power
supply
correctly fixed
Check if the
indicate light is
on

Correct fiber ironing
Attention: 1. Heat sensitive clothes ironing, please cover a piece of cloth on the clothes first, then ironing, or
the clothes will be burnt.
1. Cotton material ironing, please adjusting temperature according the heat resistant of the material.
Cloth material Temperature
setting
Marks in
clothes
Preferable ironing method
Man-made
cotton
Ironing the back of clothes without any water or
cover a piece of cloth on the goods you want to
iron
synthetic fibre Dry ironing the back of the clothes
silk Dry ironing the back of the clothes
wool
cotton According to the thickness and gruffer to iron with
steam. For some fuscous clothes, we’d better
adopt to back ironing.
Linen
Correct ironing with steam
Electric iron is a common home appliance, to be used very frequent. Before using, please read the items as
follow:
1. Fill in cold boiled water or purity water.
2. According to different material, adjusting proper temperature. If you are not familiar with the material of
the cloth, you may choose a piece
3. When the soleplate reaches its adjusted temperature, then you can start ironing. Or the water will leak
form the soleplate. Please notice, it’s a normal phenomenon.
4. Using steam spurt to recover the elasticity of the fiber. Rub and press the polished cloth, then it will come
back. If spurt steam, at the same time brush the cloth to its opposite side. The effect will be better.
5. Do not put the ironed clothes into wardrobe immediately. Hanging the clothes to clothes rack till it is code.
And the clothes will not go moldy causing decompose.
6. When soleplate calcified, you can use Self-cleaning function to clean soleplate. Ensure the water tank
with water, adjust the steam regulating knob to SELF CLEAN place, Then the big strong steam will come
out with some water, it will cleaning the soleplate
7. After ironing, pour out the rest water. If some water left in the water tank, put the plug into the socket,
make sure no water in it, you can pull the plug out. Keep the iron upright. And the life of the iron can be
longer.

Attentions:
1. Please read the owner’s manual before using the product.
2. Before using, please check the voltage of the product if it is the same with the one in your home.
3. When using steam ironing, you are recommended to use distilled water.
4. During the iron is electrified, operator must not leave, must not let children touch the iron.
5. When filling water or pouring out remaining water. Please pull out the plug first.
6. After using, turn the temperature regulating knob to “0”, pull out the plug, put the iron on the smooth and
stable place vertically.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
8. The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
9. The iron must not be left unattended while it is connected to the supply mains
10. The plug must be removed from the socket-outlet before the water reservoir is filled with water
11. The iron must be used and rested on a stable surface.
12. When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
13. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety
14. Children should be supervised to ensure that they do not play with the appliance.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH
EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible negative consequences for the environment
and health, deriving form inappropriate disposal and enables the constituent materials to be recovered to
obtain significant savings in energy and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out wheeled dustbin.
