Rohnson R-397 User manual

MODEL: R-397 Smart Temp
INSTRUCTION MANUAL

Parts description
1. Handle
2. Spray button and burst button
3. Water inlet
4. Soleplate
5. Cord Guard
6. Water tank
7．Head decoration Piece
8．Steam adjusting knob
9．pilot light
10. Top cover
11. Left ang right decoration Piece
Instruction Manual
Make yourself familiar with the your new dry steam iron according to the description. Pay attention to the sale guards; they shall assist you to
avoid accidents and damages.
Important Safeguards
◼Connect steam iron whit a correctly installed power point (220-240V). Make sure that the voltage of your steam iron is in accordance
with the voltage of your power supply.
◼This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
◼Children should be supervised to ensure that they do not play with the appliance.
◼Do not allow children use it.
◼Unplug the appliance even during short-term absence.
◼The iron must not left unattended while it is connected to the supply.
◼The plug must be removed from the socket-outlet before the water reservoir is filled with water.
◼If the supply cord is damaged, it must be replaced by the manufacturer , its service agent or similarly qualified persons in order
to avoid a hazard.
◼Do not use the dry steam iron if the appliance itself cable or the plug are damaged.
◼Do not immerse the dry steam iron into water.
◼Keep the cable away from hot steam plate.
◼Let the steam iron completely cool down storing.
◼Always keep the instruction manual. In case the steam iron is given away to a third person instruction manual must be handed over,
too.
◼Note: Before first use test with an old tissue whether the steam plate and water tank are clean. Some parts have been slightly greased,
thus smoke can raise during first use. This should stop after some moments.
◼the iron must be used and rested on a stable surface;
◼when placing the iron on its stand, ensure that the surface on which the stand is placed is stable;
The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
1
8
2
7
3
9
6
5
4
11
1
10

Use
Remove the protection film from the steam plate before first use.
You can use your steam iron with usual tap -water. Should the water harder than 17℃dH, destilled or demineralized water has to be used to
increase the steam iron’s life span.
Fill in water tank (for steam ironing)
Unplug the appliance and screw the steam adjusting knob (8) to position “0”(off).
Fill so much water into the tank until the water-level is visible with horizontal by hold tank in the middle of the transparent window.
Now connect the steam iron with a correctly installed power point.
DO not need Temperature control (Smart Temp )
The SMART TEMP technology enables the use to iron all types of clothes and fabrics, in any order, without adjusting temperature of the iron.
Also, there is no need sorting your garments. It is safe to just rest the hot soleplate directly on the ironing board without putting back to the iron
platform.
Do not need temperature control,when heating is complete (the pilot light switches out). you can choose also dry or steam ironing.
Suitable for ironing all kinds of cloth (Chemical fibred /synthetic, Nature fibred/silk/wool, Nature fibred/cotton/linen )
Functions
Water spray
To moist the steam laundry press the button “water spray”(2)
Dry / Steam
You can fix the steam intensity directly by urning turning the steam function “0”=steam dry
aximum steam outflow
Burst of steam
To reach a burst of steam, press the button “short burst of steam”(8).
Attention: Only, use the steam push button when the steam iron has reached the steam or
maximum temperature.
Do not press this button more than 3 times at once.
Keeping/Cleaning/Care
Switch the steam adjusting iron off and unplug. Put the steam iron upright and let it completely cool down, empty the water tank.
Remove residues from steam sole with a vinegar-water solution. Rub the cabinet with a moisted cloth and finally rub it dry.
Automatic electricity interruption for security

In case the installed thermostat gets out of order the power supply will stop automatically to avoid the steam iron to overheat. In this case the
steam iron has to be repaired by the service point.
Self Clean
The function of self clean is to clean the soleplate when you use this iron about half of year.
You must be:
1. Fill the iron and plug in;
2. When the temperature attaches “MAX”, press the self clean-Button for about 1 minute;
3. Plug into power in order to dry the water in soleplate off
4. Conduct self cleaning only with a basin to collect all water. Otherwise the hot water will be spilled maybe over the
user.
Cleaning / Care
According to frequency of use it is recommended that you should monthly clean the steam iron-this will increase the steam iron’s life span.
⚫Fill the water tank half with water.
⚫Put the steam iron upright.
⚫Put the steam function (8) to the “off”-position and connect the steam iron with the mains.
⚫Water until the steam iron is completely hot (the pilot light switches out).
⚫Unplug the steam iron.
⚫Hold the steam iron horizontally over the wash - basin.
⚫Put the steam function (8) to the maximum –position (cleaning). In this position it can be pulled a bit upwards.
⚫Now hot water and steam are coming out of the apparatus. Residues like e.g. chalk depositions (if available) should be washed away
with the water coming out.
⚫Simulate the ironing move until the water tank is almost empty.
⚫let the steam iron become hot again. The remaining tank water vaporizes and comes out through the apparatus.
⚫We recommend moving the steam iron over an old tissue during this process.
Technical data
Steam Iron R-397
Power supply 220-240V 50/60Hz
Power 2800 W
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the environment and
health, deriving form inappropriate disposal and enables the constituent materials to be recovered to obtain
significant savings in energy and resources. As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
