ROKAMAT PFM C User manual

1) Rokamat PFM C (22AF0890)
2) 2014/30/EU, 2006/42/EG, 2012/19/EU, 2011/65/EU,
2001/95/EG, EG No. 1907/2006
3) EN 62841-1:2015/AC:2015, EN 62841-2-4:2014/AC:2015,
EN ISO 12100:2010-11
4) Kammerer GmbH, An der B 10, 75196 Remchingen
Remchingen, 20.01.2022
Beate Kammerer
Head of Technical Documentation
EN
Original Instructions
3
PFM C
Art.-Nr. 35000
© Kammerer GmbH. Printed in Germany. Abbildungen unverbindlich.
Technische Änderungen vorbehalten. BA_PFM C_EN_001
ROKAMAT
Kammerer GmbH
An der B 10
75196 Remchingen
Deutschland
www.rokamat.com

PFM C
2
[1]
I
0
[2]
0
[4]
[5]
4-1
4-2
4-3
4-4
6-5
6-1
4-5
[6]
5-1
2-1
6-2
6-6
6-3
6-4
1-2
1-3
1-1
X
[3]
3-1
7-1
[7]
1-4
X
X

PFM C en English
3
1. Symbols ......................................................................... 3
2. Safety Instructions .................................................... 3
3. Intended Use ................................................................4
4. Technical Specifications ..........................................4
5. Device Components...................................................4
6. Commissioning............................................................4
7. Instructions for Use...................................................4
8. Working with the Power Tool ................................4
9. Maintenance and Care.............................................. 5
10. Spare Parts and Accessories.................................. 5
11. Environmental Protection....................................... 5
12. Declaration of Conformity....................................... 5
13. Troubleshooting ......................................................... 5
For your own protection and for the protec-
tion of your power tool, pay attention to all
parts of the text that are marked with this
symbol!
Risk of electric shock!
Read operating instructions and safety no-
tices! *)
Wear protective goggles! *)
Wear ear protection!
Two-hand operation. *)
Do not dispose of as domestic waste! *)
Important advice/information
CAS Li-Ion battery pack *)
Removing battery pack!
Direct Current (DC) *)
Confirms the conformity of the power tool
with the directives of the European Com-
munity. *)
Confirms the conformity of the power tool
with UK legislation. *)
*)These symbols are (also) on the device.
For your safety
Read all safety warnings and instructions.
Failure to follow all safety warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Do not use this power tool before you have
thoroughly read and completely understood
this Instruction Manual, the enclosed “Gen-
eral Safety Instructions”, instructions for bat-
tery packs and chargers.
Keep all safety instructions and information for
future reference. Pass on your power tool only to-
gether with these documents.
Please also observe the relevant national industrial
safety regulations.
Special Safety Instructions
Safety Warnings common for Grinding, Sanding
and Polishing Operations:
a] This power tool is designed to be used as a
sander (with sandpaper) and polisher. Read
all safety warnings, instructions, illustra-
tions and specifications provided with this
power tool. Failure to follow all instructions
listed below may result in electric shock, fire
and/or serious injury.
b] This power tool is not suitable for coarse
sanding, sanding with a wire brush, polishing
and abrasive cutting. Operations for which the
power tool was not designed may create a haz-
ard and cause personal injury.
c] Do not use accessories which are not specifi-
cally designed and recommended by the tool
manufacturer. Just because the accessory can
be attached to your power tool, it does not as-
sure safe operation.
d] The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessories running faster
than their rated speed can break and fly apart.
e] The outside diameter and the thickness of
your accessory must be within the capacity
rating of your power tool. Incorrectly sized
accessories cannot be adequately guarded or
controlled.
f] Threaded mounting of accessories must
match the grinder spindle thread. For acces-
sories mounted by flanges, the arbor hole of
the accessory must fit the locating diameter
of the flange. Accessories that do not match
the mounting hardware of the power tool will
run out of balance, vibrate excessively and may
cause loss of control.
g] Do not use a damaged accessory. Before each
use inspect the accessory such as abrasive
wheels for chips and cracks, backing pad for
cracks, tear or excess wear, wire brush for
loose or cracked wires. If power tool or acces-
sory is dropped, inspect for damage or install
an undamaged accessory. After inspecting
and installing an accessory, position yourself
and bystanders away from the plane of the
rotating accessory and run the power tool at
maximum no-load speed for one minute.
Damaged accessories will normally break
apart during this test time.
h] Wear personal protective equipment. De-
pending on application, use face shield,
safety goggles or safety glasses. Where ap-
propriate, wear dust mask, hearing protec-
tors, gloves and workshop apron capable of
stopping small abrasive or workpiece frag-
ments. The eye protection must be capable of
stopping flying debris generated by various op-
erations. The dust mask or respirator must be
capable of filtrating particles generated by
your operation. Prolonged exposure to high in-
tensity noise may cause hearing loss.
i] Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragments of workpiece or of a broken acces-
sory may fly away and cause injury beyond im-
mediate area of operation.
j] Hold the power tool by insulated gripping
surfaces only, when performing an operation
where the cutting accessory may contact hid-
den wiring or its own cord. Cutting accessory
contacting a “live” wire may make exposed
metal parts of the power tool “live” and could
give the operator an electric shock.
k] Position the cord clear of the spinning acces-
sory. If you lose control of the power tool, the
cord may be cut or snagged and your hand or
arm may be pulled into the spinning accessory.
l] Never lay the power tool down until the ac-
cessory has come to a complete stop. The
spinning accessory may grab the surface and
pull the power tool out of your control.
m] Do not run the power tool while carrying it at
your side. Accidental contact with the spinning
accessory could snag your clothing, pulling the
accessory into your body.
n] Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside the
housing and excessive accumulation of pow-
dered metal may cause electrical hazards.
o] Do not operate the power tool near flamma-
ble materials. Sparks could ignite these mate-
rials.
p] Do not use accessories that require liquid
coolants. Using water or other liquid coolants
may result in electrocution or shock.
Kickback and related warnings
Kickback is a sudden reaction to a pinched or
snagged rotating wheel, backing pad, brush or any
other accessory. Pinching or snagging causes rapid
stalling of the rotating accessory which in turn
causes the uncontrolled power tool to be forced in
the direction opposite of the accessory’s rotation at
the point of the binding.
For example, if an abrasive wheel is snagged or
pinched by the workpiece, the edge of the wheel
that is entering into the pinch point can dig into the
surface of the material causing the wheel to climb
out or kick out. The wheel may either jump toward
or away from the operator, depending on direction
of the wheel’s movement at the point of pinching.
Abrasive wheels may also break under these con-
ditions.
Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and
can be avoided by taking proper precautions as
given below.
a] Maintain a firm grip on the power tool and po-
sition your body and arm to allow you to re-
sist kickback forces. Always use auxiliary
handle, if provided, for maximum control over
kickback or torque reaction during start-up.
The operator can control torque reactions or
kickback forces, if proper precautions are
taken.
b] Never place your hand near the rotating ac-
cessory. Accessory may kickback over your
hand.
1. Symbols
2. Safety Instructions
WARNING!
⎓
Contents
X

PFM C en English
4
.c] Do not position your body in the area where
power tool will move if kickback occurs. Kick-
back will propel the tool in direction opposite to
the wheel’s movement at the point of snagging.
d] Use special care when working corners, sharp
edges, etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing
have a tendency to snag the rotating accessory
and cause loss of control or kickback.
e] Do not attach a saw chain woodcarving blade
or toothed saw blade. Such blades create fre-
quent kickback and loss of control over the
power tool.
Additional safety instructions
Never immerse the machine in water or spray it
with water for cleaning, not even the tool holder!
When the safety clutch responds, switch off the
machine immediately!
Do not overload the motor for a long period. Engine
noise should be regular (not wave-like). Unsteady
engine performance can be perceived acoustically.
Take a break when the machine is heated up
strongly and let it cool down again. To that let the
motor idle at top speed for some time.
Keep the carry case out of reach of children. Chil-
dren may suffocate or be strangled when playing
with the carry case.
Emission levels
NOTE! Values for the A-weighted sound pressure
level and for the total vibration values can be found
in the “Technical specifications” table at page 4.
The vibration emission level given in this infor-
mation sheet has been measured in accordance
with a standardized test and may be used to com-
pare one tool with another. It may be used for a
preliminary assessment of exposure.
CAUTION! The indicated measurements refer to
new power tools. Daily use causes the noise and vi-
bration values to change.
The declared vibration emission level represents
the main applications of the tool. However, if the
tool is used for different applications, with differ-
ent accessories or poorly maintained, the vibration
emission may differ. This may significantly in-
crease the exposure level over the total working
period. However, if the tool is used for different ap-
plications, with different accessories or poorly
maintained, the vibration emission may differ. This
may significantly decrease the exposure level over
the total working period.
The noise produced during work may damage
your hearing. Wear ear protection!
Environmental conditions
Operation
Temperature range: +5° C to +50° C
Humidity: ≤ 85 %, non-condensing
Climate: dry
Transport and storage
Temperature range: -5° C to +55° C
Humidity: 0 % to 70 %
Climate: dry, roofed, dew protected
Transport and store the power tool only in the car-
rying case. Do not store the power tool and acces-
sories in the case when wet!
The hand-held battery tool ROKAMAT PFM C is in-
tended for finishing and smoothing gypsum plas-
ter, lime-cement plaster, filler, fresh concrete and
similar materials on walls and ceilings in exterior
and interior areas.
The PFM C is intended for use with original ROKA-
MAT machines and accessories only.
Only sufficiently qualified and trained personnel is
allowed to work with the tool. The intended use in-
cludes the observance of the operating instruc-
tions, in particular the safety instructions and the
observance of generally recognized accident pre-
vention regulations.
Plaster Finishing Machine PFM C
Item No. 35000
Rated voltage
18 V DC
No-load speed
230 min-1
Maximum tool diameter
450 mm
Driver disc
Clamping screw
M6
Total weight
2,8 kg
Dimension com-
pact (LxHxW)
1135x160x420 mm
A-weighted sound pressure level (see cap. 2
“Emission levels“):
Sound pressure level LpA
88 dB(A)
Sound power level LWA
99 dB(A)
Uncertainty KpA, KWA
3,0 dB
Total vibration value (see cap. 2 “Emission
levels “):
Emmission value ah
2,0 m/s2
Uncertainty K
1,5 m/s2
The specified illustrations can be found in fig. [1]
on page 2 of the operating instructions.
1-1 Tool disc
1-2 Connection piece (gripping surface)
1-3 Motor (with gripping surface)
1-4 Battery
Before switching on the power tool: Unpack
power tool and accessories and check that no
parts are missing or damaged.
Switching the electric power tool on and off
[2]
Switching on: Push the sliding switch [2-1] for-
ward. For continuous activation, now tilt down-
wards until it engages.
Switching off: Press the rear end of the slide
switch [2-1] and release it.
Risk of injury, electric shock!
Always remove the battery pack before per-
forming any type of work on the machine!
Only use CAS-compatible batteries with a rated
voltage of 18 V DC!
Installing or removing battery pack [3]
To insert: Slide the battery pack [1-4] in until it en-
gages.
To remove: Press the battery pack release button
[3-1] and pull the battery pack downwards and out.
Rotating battery pack [7]
The rear section of the machine can be rotated 270°
in three stages, thus allowing the machine's shape
to be adapted to the working conditions. Only oper-
ate the machine when it is in an engaged position.
Attaching the tool disc with velcro [3]
- Place the tool disc [3-1] in the center of the sup-
porting plate [3-4] and press on.
- Conduct a test run to check that the tool discs are
attached in the center.
Attaching / removing the supporting plates
[3]
- Loosen the clamping screw [3-2] and remove it
together with the rubber washer [3-3].
- The supporting plate [3-4] can be detached/re-
moved.
- Attaching in reverse order. Ensure that both pins
on the driver disc [3-5] mate with the drill holes
in the supporting plate.
Attaching the trowel Ø 450 mm [4]
- The supporting plate [3-4] must be removed be-
fore the trowel [4-1] is mounted (see above).
- Centre trowel directly on the driver disc [3-5]. En-
sure that both pins on the driver disc mate with
the drill holes in trowel.
- Then turn the clamping screw [3-2] clockwise to-
gether with the rubber washer [3-3] to tighten
them.
- Removing in reverse order.
1. Attach tool disc.
2. Insert the battery pack.
3. Hold the plaster finishing machine with both
hands at the gripping surfaces.
4. Switch on the device.
5. Press the tool disc gently against the work sur-
face.
6. Swing the plaster finishing machine with linear
or circular movements.
6. Commissioning
7. Instructions for Use
4. Technical Specifications
5. Device Components
3. Intended Use
WARNING!
8. Working with the Power Tool
CAUTION!
CAUTION!
X

PFM C en English
5
After finishing work
Once you have finished the grinding work, set the
power tool down.
Risk of damage to the device!
Do not set the power tool down with the tool
disc facing downwards!
Risk of injury, electric shock!
Always be sure that the tool is switched off and
the battery pack is removed before performing
maintenance work on the machine!
Risk of damage to the device!
Never immerse the tool holder in water or spray
it with water to clean it!
Repairs may be carried out by an authorized cus-
tomer service center only.
Repairs to electrical tools must be carried out by
qualified electricians only!
During the warranty period do not loosen the
screws on the housing. Non-compliance will deem
the guarantee obligations of the manufacturer null
and void.
Remove dust from the motor regularly
It is possible that particles deposit inside the power
tool during operation. This impairs the cooling of
the power tool. Conductive build-up can impair the
protective insulation of the power tool and cause
electrical hazards.
The power tool should be cleaned regularly, often
and thoroughly through all front and rear air vents
using a vacuum cleaner or by blowing in dry air.
Prior to this operation, remove the battery pack and
wear protective glasses and dust mask.
Replacement of the flexible drive shaft [6]
Disassembling: First loosen the nut [6-2] on the
clamping ring [6-1]. Then press in the press button
[6-3] in the borehole [6-6] with a tool (e.g. screw-
driver) and pull out the protective hose [6-4]. Now
the shaft core [6-5] can be replaced.
Mounting: In reverse order. Make sure that the
shaft core [6-4] is threaded into the square in each
case.
Other accessories, in particular insertion tools, can
be found in the manufacturer’s catalogues. Ex-
ploded drawings and spare-part lists can be found
on our homepage: www.rokamat.com.
Use only original ROKAMAT spare parts and work
tools!
Observe national regulations on environmentally
compatible disposal and on the recycling of dis-
used machines, packaging and accessories.
For Great Britain and EU countries: Do not
dispose of electric equipment or battery
pack together with household waste mate-
rial! In observance of the European Direc-
tives, on Waste Electric and Electronic-
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators and
their implementation in accordance with
national laws, electric equipment and bat-
teries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
It is expressly declared that the cordless grinder
and polisher listed on the first page under 1) from
the serial number indicated onwards complies with
all relevant provisions of the directives or regula-
tions listed in 2) and that the harmonized stand-
ards listed in 3) have been applied. The technical
documentation is available from the authorized
documentation agent named in 4).
Risk of damage to the device!
The two boreholes for the push button at the
drive shaft serve as length adjustment between
shaft core and protective hose. The shaft core
should be freely movable in length and must not
get compressed!
Check all wearing parts once a month.
Please ask your dealer about disposal options!
Problem
Possible causes
Remedy
Motor runs, but the sup-
porting plate does not ro-
tate.
Shaft core broken.
Exchange shaft core.
Mitre-gear of the tool holder is
defective.
Replace the mitre-gear with case top.
The electronic signal dis-
play [7-1] lights up and
the load speed decreases.
There is too much load on the
machine.
Run the machine in idling until the
electronics signal indicator switches
off.
The machine does not
start. The electronic sig-
nal display [7-1] flashes.
The restart protection is active.
The machine will not start if the
battery pack is inserted while the
machine is on.
Switch the machine off and on again.
Motor power fluctuates.
Carbon brushes worn.
Replace carbon brushes.
PFM C not working.
Battery discharged.
Charge battery.
PFM C does not run
smoothly over the sur-
face.
Tool discs are not mounted cor-
rectly.
Check the correct fit of the tool discs.
Surface quality not per-
fect.
Incorrect or worn tool discs.
Select correct tool discs and check
for good condition.
Material to be processed is too
moist.
Allow material to dry longer.
Material to be processed is too
dry.
Moisten material with water.
Machine may not be suitable due
to constant speed.
Use machine with speed control.
9. Maintenance and Care
WARNING!
CAUTION!
10. Spare Parts and Accessories
11. Environmental Protection
13. Troubleshooting
CAUTION!
ADVICE!
12. Declaration of Conformity
If problems other than those listed occur, please contact your ROKAMAT service workshop or your local
specialist.
Li-Ion
CAUTION!
X
ADVICE!
