Roline 12.04.1102 User manual

USB 2.0 Cat. Extender 50m
Power Over Cable
12.04.1102
User Manual
INTRODUCTION
Congratulations on your purchase of this USB 2.0 Extender. This USB.2.0
Extender is capable of sending data across a Cat.5/5e/6 cable up to 50 meters at
data rate of Hi-Speed (480Mb/s), Full Speed (12Mb/s) and Low Speed (1.5Mb/s).
Setting up the USB 2.0 Extender is quite simple. Plug the RJ-45 connectors into
the ports. It takes only minutes to setup, and there is no configuration necessary.
The Extender is USB 2.0 compliant and is backward compatible with USB 1.1/1.0.
PACKAGE CONTENT
Before installation, please check if following items are included in the package:
 Transmitter Unit X1
 Receiver Unit X1
 USB AM-BM cable X1
 User Manual X1
 Power Adapter (24V/0.5A) X1

FEATURES
 Supports date transfer rates of 1.5Mb/s, 12Mb/s, 480Mb/s
 Product consists of two electronic modules, a "Transmitter unit" and a
"Receiver unit".
 Receiver unit can connect 1 USB 2.0 device.
 Units can be connected by a standard Cat. 5 cable or higher, which extends
USB devices up to 50m.
 Wall mounting is integrated in the metal housing
 Supports Hot Plug & no software driver is required.
 Power supply for Transmitter unit is included.
Transmitter Unit

Receiver Unit
ITEM TYPE DESCRIPTION
1 PWR LED (Red) LED turns on when power supply is from
Transmitter unit.
Off when no power is supplied.
2 LINK LED (Green) Indicates that a valid interconnection between
Transmitter Unit and Receiver Unit is
established via LAN cable
3 ACT. LED (Amber) The LED flash mean that this Extender links to
PC/NB properly & a device is plugged in to the
downstream port.
INSTALLATION
1. Connect the Transmitter Unit to the Host System (or PC) via USB Cable (A
Male to B Male).
2. Plug the 24V/0.5A DC Power Supply into the USB 2.0 Extender Transmitter
Unit. Plug the AC power cord of power supply into an available electrical outlet.

3. Connect the USB 2.0 Extender Transmitter Unit and Receiver Unit together with
a LAN Cable (supplied by user).
4. Connect USB Device(s) to the Receiver Unit.
5. Check the LED on the USB 2.0 Extender Receiver Unit. Make sure that the
ACT. LED flashes, which means that the extenders are powered and are
communicating.
System Requirements
 Windows XP/7/Vista/8/8.1/10
 Mac OS
Specifications
Transmitter
Unit
Upstream Port USB Type B Female
Downstream Port RJ45 Jack
Power Bus-Powered (Transmitter)
Self-Powered 24V/0.5A (Receiver)
Dimensions 66 x 60 x 24 mm
Receiver Unit
Upstream Port RJ45 Jack
Downstream Port USB Type A Female
Dimensions 66 x 60 x 23 mm (1-port)
Interconnect Cable Standard LAN Cables
Max Cable Length 50m
