Rolls PI9 PhonePatch II User manual

PI9 PhonePatch II
Rolls Corporation
Salt Lake City, UT
11/04
- Studio
- Install
- Broadcast
... anywhere you need to connect a telephone
line to your audio system.
PI9 PhonePatch II
The PI9 takes a signal from a standard telephone jack and,via
transformer isolation, connects to a pair of RCA jacks, or a
stereo 1/8" (3.5mm) jack. The isolation keeps the output
signal separate from the telephone line, and will not keep the
line open unless the internal jumper is moved. Applications for
the PI9 include broadcast, conference rooms, phone training,
or wherever a phone conversation needs to be recorded or
heard over a PA system.
PI9 PhonePatch II
PI9 PhonePatch II
PI9 PhonePatch II
SPECIFICATIONS
Input Impedance: 600 Ohms
Output Impedance: 10 K Ohms
Ringer Equivalence: 0.0 A, 0.0 B
Connections: 2; RJ11 phone jack,
2; RCA jacks
1: Tip-Ring-Sleeve 3.5mm jack
Size: 2.7" W x 1.45" H x 2.32" D
Weight: 1 lb.
Thank you for your purchase of the PI9 PhonePatch II. The PI9
takes a signal from a standard telephone jack and,via transformer
isolation, connects to a pair of RCA jacks, or a stereo 1/8"
(3.5mm) jack. The isolation keeps the output signal separate from
the telephone line, and will not keep the line open unless the
internal jumper is moved (see INTERNAL JUMPER section of this
manual). Applications for the PI9 include broadcast, conference
rooms, phone training, or wherever a phone conversation needs
to be recorded or heard over a PA system.
WARRANTY
For complete information on the Rolls 1 Year Warranty, and to
register your warranty on this product; visit our website;
www.rolls.com
DESCRIPTION
INPUTS: 2 ea: Standard RJ11 phone jacks.
AUDIO LINE: 2 ea; RCA jacks, 1 ea; 1/8" (3.5mm) jack
ON/OFF switch: Connects or disconnects the Phone/Line jacks to
the transformer and the Audio output.
CONNECTION: Refer to Figure 1.
Connect a standard telephone cable to an active telephone line,
and to the PI9 Phone Input. To pass the signal on to another
telephone, connect another standard telephone cable from the
PI9 Line jack to a telephone.
Connect either a stereo RCA cable, or stereo 1/8" (3.5mm) cable
to an AUDIO LINE output jack.
INTERNAL JUMPER
An option available in the PI9 is the ability to select whether or not the unit
will hold a line open or not. A line being "held open" acts like a tele-
phone is off the hook.
The PI9 jumper, as set from the factory, will NOT hold the line
open. In order for the unit to operate this way, the
internal jumper must be moved to the position shown
in Figure 2. You must first remove the two
screws on either side of the unit, and
carefully lift off the top. Using either a pair
of needle-nose pliers, or tweezers,
move the jumper to connect the two
pins together as shown.
Carefully replace the cover of the
unit, and secure the screws.
ON/OFF
switch
Move jumper to connect
these two pins.
Figure 2.
ON
OFF
PHONE PATCH II
AUDIO LINE
LINEPHONE
Figure 1.
