Ronda QM1 User manual

PROFESSIONAL INSTALLATION REQUIRED
Installation, Use & Care
Guide
Double Drawer/Cooler Units QM1

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 2 / 6
PROFESSIONAL INSTALLATION REQUIRED
Welcome & congratulations
Congratulations on your purchase of this double drawer.
We at Ronda are very proud of our product and we hope you consider us for fu-
ture purchases.
This product is made in our factory in Italy with components all made in Italy.
For any questions contact us at : [email protected]
PLEASE READ CAREFULLY AND SAVE THESE INSTRUCTIONS
Packaging contents:
# 1 SMC Cabinet
# 2 Drawers

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 3 / 6
PROFESSIONAL INSTALLATION REQUIRED
Notes and Installation Tips
ALWAYS USE PROTECTION GLOVES AND EYE SAFETY GOGGLES:
Use care and always use protection gloves and safety goggles during in-
stallation and care. Because the drawers may have sharp edges, if not
handled with care they can cause cuts and abrasions.
Tools you will need : Power screw driver, manual screw driver, level, tape
measure.
Carefully unpack cabinets making sure not to scratch stainless steel fronts
and not to loose or misplace any components.
DO NOT remove polyethylene protective coating until installation is com-
plete.
Remove all drawers before installation. This will make cabinet easier to lift
and install and give access to installation hardware.
This product is made only for application on a subframe, which can be
made in different materials (wood, plastic, alluminium) into a wall structure
(Fig. 1)
Do not use the drawers as ladder. This would be dangerous for you and can
cause the item to break.
Fig. 1
a
b
Subframe

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 4 / 6
PROFESSIONAL INSTALLATION REQUIRED
Before Installation
Verify model number on the box label.
Verify the counter hole measure refering to the following table :
The maximum deviation permitted is : 0.04’’ (1 mm). Otherwise the SMC
panels get deformed and drawers don’t work properly. Use spacers to get
the right counter hole dimensions.
Checkwith a level that
Verify with a level the horizontal and vertical level of the counter hole and
correct if not accurate.
Counter Hole
Model a b
+0,04 + 0,04
inch 14.96
0
24.44
0
+1 +1
QM11
mm 380
0
621
0

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 5 / 6
PROFESSIONAL INSTALLATION REQUIRED
Assembly and Installation
1. Carefully unpack cabinet making sure not to scratch stainless steel fronts.
Stainless is protected by a plastic coating that must be removed after
setup.
2. Remove drawers and store in a safe place.
3. Put the cabinet inside the counter
hole.
ATTENTION:
To correctly insert the cabinet , the slots
on the guides must be turned upward.
( see the foto down side )

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 6 / 6
PROFESSIONAL INSTALLATION REQUIRED
4. Be sure that the cabinet fits well in
the wall.
No clearanceshould be left be-
tween the edges of the cabinet and
the wall.
If not, use spacers to fit.
5. Secure the cabinet to the wall with
screws in the dedicated matching
holes in the cabinet.
Use # 12 mushroom head screws.
6. Insert the drawer rear wheels into the guide slots.

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 7 / 6
PROFESSIONAL INSTALLATION REQUIRED
7. Put the drawer forward,
than lift a bit to insert the
second wheel and put in-
side.
Close completely the
drawer.
8.
Repeatfor the second drawer
the operationfrom 6 to 7.

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 8 / 6
PROFESSIONAL INSTALLATION REQUIRED
Care and cleaning
It is imperative that the owner realizes that he/she is required to perform
reasonable maintenance and care of the drawers in order to maintain the
manufacturers warranty. Failure to perform reasonable maintenance and
care may void the warranty.
The following is a list of maintenance steps and things to avoid. This is not
intended to be a complete list, but is to be used as a guideline for general
care.
Carefully remove protective plastic peel coat from each stainless steel surface.
External Surfaces:
Clean stainless with stainless steel cleaner in direction of grain. Rubbing across
the grain direction may produce minor scratches. Recommended cleaners are
Weiman © , Stainless Steel Magic © and Sheila Shine © .
In a salty air environment, a slightly more oily cleaner like Sheila Shine © will pro-
tect better against oxidation, pitting or slight surface rust. Cleaning the surfaces
periodically will protect the finish for many years. In a heavily salty area, you will
have to clean more frequently as salt breaks down into highly corrosive chlorine
that will attack the metal. Surface corrosion will not affect performance of the
product, but will affect the look.
DO NOT USE scratchy pads, scouring pads, or stiff sponges for cleaning. Do not
use abrasive detergents, powdered cleansers or detergents containing acid sub-
stances or bleach.

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 9 / 6
PROFESSIONAL INSTALLATION REQUIRED
Internal surfaces:
Clean the internal surface of the cabinet use warm water and soap.
Wash after each use and dry to avoid formation of molds and staining.
The cabinet’s working surface are constructed from Sheet Moulding Coumpound
(SMC), a glass rinforced polyester resin resistent to corrosion.
Removing and cleaning the magnetic gasket :
•Carefullyinsertascrewdriverinto acornerof
thegasket(1).
•Liftthegasket untilitexitsfromtheseat(2).
•Removethegasketbyhand (3).
•Cleanwithwater andneutraldetergent.
•Insert the gasket inits seat andstrongly
pressitonalltheperimeter.Youcanlubri-
catethegasketseattodothiseasly.
Drawer Guides
Drawer load capacity should not exceed 50 lbs per drawer. Never use an ex-
tended drawer for a ladder or a work platform.
1
2
3

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 10 / 6
PROFESSIONAL INSTALLATION REQUIRED
WARNINGS
•Surfaces can be very hot when exposed to direct sunlight.
•Molds can form if not properly dried.
•Do not use as a ladder.
•Avoid any contact with electrical outlets or wires.
•This is only a food container. It is not a refrigerated space,
and will not prevent food spoilage.
•If exposed to temperatures below – 4 °F and above + 120 °F
deformation and malfunction of the drawers can occur.
•If installed adjacent to the heating elements of a barbeque,
insulation can be less effective.
•If installed near to the sea, damage from salty water can oc-
cur.
•Keep drawers closed when not in use.

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 11 / 6
PROFESSIONAL INSTALLATION REQUIRED
LIMITED WARRANTY:
1. Limited Warranty.
RONDA warrants for a period of one (1) year from the date of purchase that each new RONDA
product shall be free, under normal use and maintenance, from any defect in material and
workmanship, subject to the exclusions and limitations set forth below.
2. Exclusions:
The limited warranty offered by RONDA is not applicable:
a. to products subject to wear and tear as part of their normal function (rubber parts);
b. to defects resulting from oxidation, damages from salty environment or the action of at-
mospheric agents;
c. to defects resulting from incorrect use, misuse, neglect or abuse of the product or failure
to carry out the maintenance recommended by RONDA;
d. removal of drawers from their original location.
e. “remodeling” after original installation.
f. defects caused by failure to provide suitable installation environments for the product,
including without limitation the frame ; and
g. to defects resulting from faulty installation, modifications or adjustments not recom-
mended or authorized by RONDA in writing, or repairs carried out improperly.
3. Coverage.
RONDA will remedy any material or workmanship found to be defective within the one (1) year
limited warranty term as follows:
Any RONDA product which is found defective in material or workmanship within the one (1) year
limited warranty term shall be repaired or replaced, at the option of RONDA, at the RONDA fa-
cilities located at ,
UTi, United States, Inc.
3717 Wilson Road SE, Suite 100
Atlanta
GA 30354
without charge. Any defective RONDA product replaced under this warranty shall become the
property of RONDA.
4. Limitation.
The liability of RONDA under this limited warranty is limited solely to the repair or replacement
of defective product at the RONDA location during normal business hours, without charge for
you. Defects and delays in repair do not give you a right to compensation. This limited warranty
does not include any expense of or related to transportation of the RONDA product to or from
the RONDA location or compensation for inconvenience or loss of use of the product while the
RONDA product is being repaired or replaced. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, RONDA SHALL NOT BE LIABLE FOR ANY OTHER EXPENSE, LOSS OR
DAMAGE, WHETHER DIRECT, INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY ARISING

IL-MO-044 Rev. 1 04/2010
Double Drawer Unit – QM1
Insulated
Pag. 12 / 6
PROFESSIONAL INSTALLATION REQUIRED
IN CONNECTION WITH THE SALE OR USE OF OR INABILITY TO USE THE RONDA
PRODUCT FOR ANY PURPOSE.
This limited warranty shall constitute your sole remedy and the sole liability of RONDA, whether
on warranty, contract or negligence grounds, with regard to any actual or alleged defect in the
condition or performance of any RONDA product. TO MAXIMUM EXTENT ALLOWED BY AP-
PLICABLE LAW, THE FOREGOING STATEMENTS OF WARRANTY ARE EXCLUSIVE AND
IN LIEU OF ALL OTHER REMEDIES.
RONDA’S LIABILITY ON ANY CLAIM OF ANY KIND RELATING TO THESE TERMS OR THE
MANUFACTURE, SALE, DELIVERY, RESALE OR USE OF ANY RONDA PRODUCT, SHALL
IN NO EVENT EXCEED THE PRICE OF THE RONDA PRODUCT WHICH GAVE RISE TO
ANY SUCH CLAIM.
Some States do not allow the exclusion or limitation of incidental or consequential dam-
ages, so the above limitation or exclusion may not apply to you.
5. Disclaimer.
RONDA is not responsible for any accidents which may occur while the RONDA product is be-
ing used or as a result of, or causes arising from, its installation or use and shall not be liable for
any loss, damages or harm to persons or things derived from the same. RONDA is not respon-
sible for any damage to the drawers or to the outer casing caused by failure to properly maintain
the product.
This warranty gives you specific legal rights, and you may also have other rights which
vary from State to State.
6. Force Majeure.
RONDA shall not be responsible for any loss, damage or delay caused by industrial distur-
bances or disputes, strikes, fire, acts of nature, acts of God, casualty, embargoes, currency re-
strictions, labor, conflicts or shortages, war, radiation, civil riot, import or export restrictions,
shortage of materials or labor, or any other cause beyond RONDA’s reasonable control, even if
RONDA knew, had reason to believe, or was advised of the possibility or probability of any such
cause.
Ronda S.p.A.
Via Vegri, 83
36010 Zanè (VI) ITALY
Tel. [phone] – Fax [phone]
Email: [e-mail]
www.ronda.it
