rontec 8110/8185 User manual

Assembly instructions Coat rack 8110/8185
24
3
Hook support
Umbrella storage prole
Umbrella tray with grooved rubber insert
Stand
Standpipe
1
1
22
3
3
3
3
Lower connection crossbar
8110/8111
8180/8181
8112/8113
8182/8183
8114/8115
8184/8185
Online-Kongurator: www.rontec.de
Expertentelefon: [phone]
Schnellantwort: [e-mail]
Montageanleitung Umkleidebank 8546/47 + 8540/41
Stand 01/2012
Online-Konfigurator: www.rontec.de
Expertentelefon: [phone]
Schnellantwort: [e-mail]
DIE AVANTGARDEROBE
Montageanleitung Reihengarderobenständer 8110-8115
Anzahl:
1Schraube DIN 912 mit ISK M8 x 30 mm verz.
inkl. Abdeckkappen
2Schraube DIN 7991 mit ISK M8 x 40 mm verz.
3Schraube DIN 912 mit ISK M6 x 16 mm verz.
Erforderliches Werkzeug: Imbusschlüssel 3 und 5 und 6
Online-Kongurator: www.rontec.de
Expertentelefon: [phone]
Schnellantwort: [e-mail]
24
3
Hakenträger
Schirmhalterprol
Schirmschalenprol mit Rillengummimatte
Standfuß
Standrohr
1
1
22
3
3
3
3
untere Verbindungstraverse
8110/8111 8112/8113 8114/8115
Stand 07/2012
Wir haben für Sie folgendes Montagematerial beigelegt:
We have included the following assembly material for you to assemble the coat racks:
Quantity:
(1) Screw DIN 912 with ISK M8 x 30 galvanized
with back cover cap
(2) Screw DIN 7991 with ISK M8 x 40 galvanized
(3) Screw DIN 912 with ISK M6 x 16 galvanized
Required tools:
Allen wrench 3 and 5 and 6
Date 03.2021
rontec GmbH Metallwerke
Gottlieb-Wolfer-Str. 8
73770 Denkendorf
Germany
Expert telephone: [phone]
Fax: [phone]
Fast answer: [e-mail]
www.rontec.de

Assembly instructions Coat rack 8110/8185
Description:
Coat racks made of aluminum system proles. Surface in aluminum natural anodized E6/
EV1 or on customer request aluminum RAL powder-coated. Height-adjustable gliders or
swivel casters are used to protect the oor.
Use:
The coat racks are suitable for normal checkroom operations. An improper use by one
or more persons standing on the coat racks or umbrella storage proles is not intended.
Damage caused by improper use is not a reason for complaint and therefore not part of
the warranty.
Improper use:
In case of improper use, the warranty and the manufacturer´s warranty obligation expire.
This includes gymnastics and climbing on the coat racks as well as the use as a vehicle.
The hooks of the coat rack are to be used exclusively for hanging up clothes and must not
be used for heavy objects.
Maintenance:
The coat racks must be checked for safety at least once a year. The aluminum frames must
be checked for damage and tight t.
Hazard notice:
•oor mounting is only possible if stability is ensured and no underoor heating is
installed in the mounting area.
•care should be taken to ensure that damaged coat racks are blocked from use and
repaired immediately by our professional tters.
•broken coat hooks must be replaced to prevent injury from the breakage.
Technical data:
See front page. Further information is available in the download area at www.rontec.de
Notice:
These assembly instructions represent a service, but not the content of the performance
claim. If the defect consists of faulty assembly instructions, rontec GmbH Metallwerke
shall only be obligated to subsequently deliver error-free assembly instructions.
