Room & Board 776074 Adara Collection User manual

WARNING
WARNING
DANGER
WARNING
!
!
!
!
For outdoor use only.
If you smell gas:
• Shut o gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep
away from the appliance and
immediately call your gas
supplier or fire department.
Do not store or use gasoline or other flammable liquids
in the vicinity of this or any other appliance.
An LP-cylinder not connected for use should not be
stored in the vicinity of this or any other appliance.
Improper installation, adjustment, alteration, service, or
maintenance can cause injury or property damage.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
170919FTNG-171130
776074 Adara Collection
1112NG-TGR Rectangle Fire Table Owner’s Manual
DESIGNED AND BUILT BY

2
TABLE OF CONTENTS
DANGER
SPECIFICATIONS
!
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
Verify Page numbers
Product Name
Adara Rectangle Fire Table
Model No.
1112NG
Rated Heat Output
65,000 BTUs/hr
Type of Gas
Natural Gas (NG)
Gas Supply
Professionaly Installed NG system
Important Safety Information
Parts List
Assembly Instructions
Pre-Use Instructions
Lighting Instructions
Care and Cleaning
Spider and Insect Warning
Tips & Troubleshooting
Technical Parts List
Warranty
3
5
6
9
10
11
12
13
14
15

3
IMPORTANT SAFETY INFORMATION
Installation notes
General Warnings
• Minimum Clearance from unit to combustible materials:
48” (121.9 cm) from all sides and back. Do not place this fire table under any overhead structure or
vegetation. Do not place on or above combustible surfaces.
• If stubbing out a natural gas hook-up below the table, the installer must make sure that provision is
made for the hose to not contact any side or base panel of the burner area when the fire table is in its
normal operating position.
• Save these instructions for future reference. If you are assembling this unit for someone else, give this
manual to them to read and save for future reference.
• If the information in this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury, or death.
• Installation and service must be performed by a qualified service agency or gas supplier. Real Flame
recommends using professionals who are certified in the U.S. by the National Fireplace Institute® (NFI)
as NFI Gas Specialists.
• Installation of this fire table must conform with local codes or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1 • NFPA 54; National Fuel Gas Code; Natural Gas and Propane
Installation Code,
• CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable.
• The normal NG inlet pressure for this appliance is 7.0” W.C. (1.74 kPa), maximum inlet pressure is 10.5”
W.C. (2.61 kPa), minimum inlet pressure is 3.5” W.C. (0.87 kPa).
• Do not remove the feet from the fire table.
• Do not place the fire table on anything that blocks or seals the gap between the table and the ground.
• Do not permanently secure the fire table in any way or to any surfaces.
• Do not bury the hose. You must be able to visually inspect the hose for damage before each use.
• Do not coil or hide the hose under the fire table. The hose could be damaged if it touches hot
surfaces.
• Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition.
• Young children should be carefully supervised when in the area of the fire table.
• Clothing or other flammable materials should not be hung from the fire table or placed on or near
the appliance.
• Any guard or other protective device removed for servicing the fire table must be replaced prior to
operating the appliance.
• Installation and repair should be done by a qualified service person. The fire table should be
inspected before use and at least annually by a qualified service person. More frequent cleaning
may be required as necessary. It is imperative that the control compartment, burners, and
circulating air passageways of the appliance are kept clean.
• Do not store or use gasoline or other flammable vapors or liquids within 25 feet ( 7.62 m) of this or
any other appliance.
• Do not store combustible materials in the fire table enclosure. This includes LP tanks.
• Be sure to protect the hose and its components from any hot surfaces. It is dangerous to allow the
hose to come into contact with any hot surface.
• Keep all parts of the fire table clean including the burner and hose assembly. For more information on
cleaning your fire table please refer to the Care and Cleaning section of this manual.

4
IMPORTANT SAFETY INFORMATION
General Warnings (Cont.)
Set-Up Warnings
In-Use Warnings
• Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
that has been under water.
• Do not use this fire table for cooking.
• Do not pour water into the fire table.
• Do not attempt to move or store this fire table until all parts are cool.
• Always shut o the gas supply at the source and disconnect the hose when the fire table is not in use.
• Any alteration of this outdoor fire table that is not specifically directed in the owner’s manual will void
the manufacturer’s warranty. This includes the use of unapproved filler materials.
• Prior to each operation, check the hose assembly for evidence of excessive abrasion, wear or damage.
Use a hand-held mirror, if necessary, to see hose sections located below the unit.
• If the hose assembly is damaged, cracked, or cut, it must be replaced before using the fire table.
The hose assembly must be replaced with a hose assembly specified by Real Flame. Please call us at
1-800-654-1704 for assistance.
• Place the hose out of the pathways where people may trip over it. Do not place the hose in areas
where it may be accidentally damaged.
• Before each use, examine the burner and its components for dirt and debris. If cleaning is required,
use a pipe brush and soapy water solution. Also examine the area around the burner. Any dirt or
foreign material such as spider webs, nests, leaves, etc., should be removed. If it is evident that the
burner is damaged, the fire table must not be used, and the burner assembly must be replaced. Please
contact Real Flame at 1-800-654-1704 for support.
• Do not burn solid fuels such as wood, charcoal briquettes, lump charcoal, manufactured logs, drift
wood, trash, leaves, paper, cardboard, plywood, painted, stained or pressure-treated wood and other
materials in this fire table.
• NEVER LEAVE this fire table unattended when in use.
• The use of alcohol, prescription or non-prescription drugs may impair your ability to safely operate
this fire table.
• Always use in accordance with all applicable local, state and national codes. Contact your local fire
department for details on outdoor burning.
• Do not use in windy conditions. Winds above 10 mph may cause the flame to extinguish.
• Some surfaces of this fire table may become hot during use. Be careful and do not touch surfaces
until the unit has cooled.
• Do not attempt to disconnect the gas supply from the fire table when the unit is in use.
• Do not sit on the fire table.

5
PARTS LIST
1
2
3
4
5
6
ITEM R&B Number JCo NUMBER QUANTITY
Fire Table Body N/A N/A 1
Lid N/A 11122005 1
NG Hose and N/A 056NG010 1
Quick Connect Socket
Black Lava Rock 970274 100240120J 1
Protective Cover 869214 11120002 1
Valve Key 711797 11110004 1
1
2
3
4
5
6

7
ASSEMBLY INSTRUCTIONS
3.) Connecting your fire table to the natural gas source:
A professionally installed shut-o valve between the supply piping and the socket is
recomended by the National Fuel Gas Code, and must be used for this fire table. A
professional gas technicial or plumber must make sure that your house’s gas system
is capable of providing the correct amount of gas at the correct pressure for your ire
table to operate safely and correctly.
The socket connection must be made outdoors. The diagram below shows the main
components of a standard natural gas connection.
If the socket connection is below the fire table, no part of the hose may contact the
side panels or base panel of the burner area when the table is in its normal operating
position.
House Natural Gas Piping
Shut-O Valve
Quick Connect Socket
Gas Hose

8
ASSEMBLY INSTRUCTIONS
4.) Connecting the Socket
Coat the gas supply pipe nipple with gas approved pipe compound or tape. Screw
the quick connect socket included with your fire table onto the gas supply pipe.
The quick disconnect should not be permanently attached to the gas hose on the fire
table. The direction of the gas flow is indicated on the socket.
5.) Using the Quick Connect Socket
Using one hand, pull back the sleeve on the quick connect socket and, with the other
hand, insert the unattached end of the fire table gas hose into the socket. Release the
sleeve and continue pushing the hose into the socket until the sleeve snaps into the
locked position.
After making the connection, perform a leak check as described on the next page.
Apply gas approved, pipe
compound or tape
Professionally installed shut-o
valve on the gas supply line
Screw the provided quick connect
socket onto the gas supply pipe
From Fire
Table

9
PRE-USE INSTRUCTIONS
WARNING
!
Before using this fire table, make sure you have read, understand, and are following all information
provided in this manual. Failure to follow these instructions could cause property damage, serious
injury or death.
Make a leak check solution by mixing one part dish-washing soap with three parts water in a spray
bottle.
Make sure that the control knob on the fire table is in the OFF position, then connect your fire
table to the gas supply line.
Spray leak solution on the valve connections, paying particular attention to the areas indicated in
the diagrams below by arrows.
If bubbles appear, shut o the gas supply, disconnect the hose, and inspect all connections making
sure threads are clear of debris. Reconnect the hose, turn the gas supply on and re-test. If you
continue to see bubbles, turn the gas supply o, disconnect the hose and call Real Flame at 1-800-
654-1704 for assistance.
If no bubbles appear after one minute, wipe away excess leak solution and proceed to the next
step.
Checking for Leaks
Pay close attention to the areas indicated by the arrows

10
LIGHTING INSTRUCTIONS
Lighting the Fire Table
1. Read and understand all operating instructions before lighting.
2. Before beginning, make sure the key valve is in the OFF position.
3. Connect the fire table to the gas supply and make sure the gas is on (see previous pages).
4. Position a burning long match or long burning butane lighter near the side of the burner.
5. Insert the valve key and slowly turn the valve counterclockwise towards the ON position.
6. Once the burner has been lit, remove the long match/ long butane lighter. Observe the flame
and make sure that all the burn ports are lit.
7. Adjust the flame to the desired height using the key valve.
8. WARNING: If ignition does not occur in 15 seconds, turn the key valve to the “OFF” position
and turn the gas o at the tank. Make sure there is no source of ignition around the fire table
and wait at least five minutes until the gas has cleared to repeat the lighting procedure. Failure
to do so could result in a large flashback of pooled gas, causing property damage or injury.
1. Using the key, turn the valve to the OFF position.
2. Once the flame is out, remove the key, and turn the gas o at its source.
3. Store the key in a safe location.
Shut-o Instructions
Flame Height
8-14”
20.3-35.5 cm
OFF
ON
KEY VALVE

11
CARE AND CLEANING
Inspecting Your Fire Table
General Care and Cleaning
Storage
Your fire table should be inspected regularly to ensure that it is safe to use and to extend the life
of its parts.
To inspect your fire table follow these steps.
1. Make sure all parts are securely fastened in place. If a part moves when touched, check its
connection points to see if they are loose.
2. Check all connections for leaks using the leak check method described in the “Check for Leaks”
section of this manual.
3. Check the ignition system by pushing the igniter button and verifying that a spark is being
generated in the igniter housing.
4. Visually check all components for any signs of damage, rust, or excessive wear.
5. If damage or leaks of any kind are found, DO NOT operate the fire table until the proper repairs
have been made.
After repeated use, a slight discoloration or weathering of the fire table finish may occur. Your fire
table should be cleaned regularly to ensure safe use and extend its life.
General Cleaning
Make a cleaning solution using a mild soap mixed with water. Use a soft cloth to wipe down
exterior surfaces and rinse with clean water. Never use oven cleaners or abrasive solvents as these
will damage the fire table.
Burner
The burner should be kept clean to ensure proper operation. Clogged burn ports may be cleared
with a paper clip or pin. Debris in the burner can be cleaned using compressed air or a pipe brush.
Soot
After use it is possible for soot to develop on some surfaces, this soot deposit will usually come o
with water and mild soap.
1. Turn the gas supply o at shut-o valve. Disconnect the quick connect socket and secure the
hose in a way that it will not be damaged.
2. Secure all loose filler material or parts.
3. Cover your fire table when it will not be in use. Covering the table will help to protect the
internal components from dirt and debris, prevent water from pooling on the surfaces and
prevent the finish from fading and discoloring.
4. Store the fire table in a cool, dry location away from children and pets.
WARNING
WARNING
!
!
DO NOT inspect, clean, move or store your fire table until the flames are COMPLETELY out and all
parts are cool to the touch.
DO NOT tamper with this appliance. This is dangerous and will void the warranty.
Repairs and modifications must be approved by Real Flame and completed by a professional gas
technician.
This fire table has been tested and certified by a third party certification agency based on its
specific and unique parts. Installing any other parts will void both the certification and the
warranty. For approved replacement parts, contact Real Flame at: 1-800-654-1704

12
SPIDER AND INSECT WARNING
Example of pipe
cleaning brush available
at local hardware stores.
Spiders or other insects may build webs or nests in your fire table burner which can obstruct or block the
flow of gas.
Some of the gas may back up in the burn tube and cause a flashback (a fire in the burn tube or
underneath the fire table) which could result in personal injury or property damage. Check and clean the
burn tube periodically using a pipe cleaner brush (as shown below) available at any hardware store and
compressed air.
Insect Nest
Possible Spider Nest
or Debris

13
TIPS & TROUBLESHOOTING
If the fire table will not ignite or stay lit
Make sure that the gas shut-o valve is fully open and that the connection between the
hose and the quick connect socket is correct. Verify that the valve key is not stripped out
and that the valve is opening/ closing. Make sure that the hose does not have any kinks or
sharp bends.
Other Common Problems
Clogged or Obstructed Burner
It is common for bugs, especially spiders, to make webs or nests inside of burner tubes. If it seems
like you are getting low or no gas flow, visually check all openings in the burner for signs of clogs. If
you see anything clogging the burner try using compressed air to remove the debris.
High Winds
High winds may cause the flame to blow out. Do not operate your fire table in high wind conditions.
If you continue to have problems with your fire table please
contact Real Flame customer service at : 1-800-654-1704

14
TECHNICAL PARTS LIST
NG Hose and Quick Connect
056NG010
Burner Kit
Key
11110004
Rectangle Lid
11122005
Thumb Screw
11110006
Foot x 4
115010003
Protective Cover
11120002
Lava Rock
100240120J

15
WARRANTY & RETURN POLICIES
Warranty
Real Flame® Company warrants the body and internal components of this Real Flame gas fireplace
to be free from defects under normal use with a limited 2 year warranty from the date of purchase.
The burn tube and nozzels carry a lifetime warranty. In the event of defects Real Flame will, at its
option, replace the defective product or refund the purchase price. The foregoing is the exclusive
remedy and Real Flame disclaims all other warranties, including any implied warranty of merchantability
or fitness for a particular purpose. In addition, Real Flame will not be responsible for consequential
damages in excess of the purchase price of the product on which such liability is based.
Return Policy
Contact Room & Board customer service at 1-800-301-9720 for complete return policy.
Replacement Parts
In the event that an item has been lost or damaged, either by the manufacturer or in shipping,
you may request a replacement within 30 days of receipt. Replacement parts are not available for
all units and only given at Real Flame’s discretion. We will assess any damage and find a solution,
which could include shipping you a replacement. No replacements are available for discontinued
items or repackaged (open box) products. Please call Real Flame Customer Service at 800-654-1704
for replacement parts before returning the damaged item. Please have the following information
(which can be found in your instruction manual) ready before you call Customer Service.
• Model Number of Item
• 4-8 digit Part Number
• Shipping Address
• A picture of the damaged item may be requested. Pictures should be sent to custserv@realflame.com
If a part has been lost or damaged after 30 days, please contact Room & Board for replacement
options. 1-800-301-9720
Incorrect Order Received
If you received something other than what you ordered, please contact Room & Board Customer
Service at 1-800-301-9720 within 48 hours of receiving the item.
Version1. 10/25/17
Room & Board Customer Service
Customer Service: 1-800-301-9720
Real Flame Customer Service
Customer Service: 1-800-654-1704 in USA
Service à la clientèle: 1-800-363-6443 in Canada
custserv@realflame.com

16
ADVERTENCIA
ADVERTENCIA
PELIGRO
ADVERTENCIA
!
!
!
!
Para uso sólo en exteriores.
Si siente olor a gas:
• Desconecte el gas del artefacto.
• Extinguir cualquier llama abierta.
•
Si el olor continúa, manténgase
alejado del artefacto y llame
inmediatamente a su proveedor de
gas o al departamento de bomberos.
No almacene ni use gasolina u otros líquidos inflamables
en las cercanías de este o de cualquier otro artefacto.
Un cilindro de LP no conectado para el uso no debe ser
almacenado cerca de este o de cualquier otro artefacto.
La instalación, ajuste, alteración, servicio o mantenimiento
incorrectos pueden causar lesiones o daños a la propiedad.
Lea atentamente las instrucciones de instalación, operación
y mantenimiento antes de instalar o reparar este equipo.
Manual del propietario del fogón rectangulo 1112NG-TGR
DISEÑADO Y CONSTRUIDO
170919FTNG-171130
776074 Adara Collection

17
ÍNDICE
Información importante de seguridad
Lista de partes
Instrucciones de montaje
Instrucciones de pre-uso
Instrucciones de iluminación
Cuidado y limpieza
Advertencias relativas a insectos y arañas
Consejos y solución de problemas
Lista técnica de partes
Garantía
PELIGRO
ESPECIFICACIONES
!
PELIGRO DE MONÓXIDO DE CARBONO
Este artefacto puede producir monóxido de carbono
que no tiene olor.
Usarlo en un espacio cerrado puede poner la vida
en peligro.
Nunca utilice este artefacto en un espacio cerrado,
como un campamento, tienda, automóvil o el hogar.
Verify Page numbers
Nombre del producto
Fogón Adara
Nro de modelo
1112NG
Salida de calor nominal
65,000 btu/hr.
Tipo de gas
Gas natural (GN)
Alimentación a gas
Sistema de GN instalado profesionalmente
18
20
21
24
25
26
27
28
29
30

18
INFORMACIÓN IMPORTANTE DE SEGURIDAD
Notas de instalación
Advertencias Generales
• Distancia mínima de la unidad a los materiales combustibles:
48” (121,9 cm) de todos lados y parte trasera. No coloque el fogón debajo de ninguna estructura o
vegetación. No lo coloque sobre ningún material combustible.
• Si el conector de gas natural está desconectado debajo del fogón, el instalador debe asegurarse de
que la manguera no toque ningún panel lateral o base del área del quemador cuando el fogón esté en
su posición normal de operación.
• Guarde estas instrucciones para referencia futura. Si está instalando esta unidad para otra persona,
entréguele este manual para que lo lea y lo guarde como referencia futura.
• Si la información contenida en este manual no se observa estrictamente, puede producirse un
incendio o una explosión, causando daños materiales, lesiones personales o pérdida de vidas.
• La instalación y el servicio deben ser realizados por un instalador, una agencia de servicios o un
proveedor de gas certificados. Real Flame recomienda el uso de profesionales certificados por el
National Fireplace Institute® (NFI) como Especialistas en Gas NFI.
• La instalación de este fogón debe cumplir con los códigos locales o, en ausencia de códigos locales,
con el Código Nacional de Gas Combustible, ANSI Z223.1 • NFPA 54; Código Nacional de Gas
Combustible; Código de Instalación de Gas Natural y Propano,
• CSA B149.1; o el Código de Almacenamiento y Manejo de Propano, CSA B149.2, según corresponda.
• La presión normal de entrada del GN de este artefacto es de 7,0” W.C. (1,74 kPa), la presión máxima
de entrada es de 10,5” W.C. (2,61 kPa), la presión mínima de entrada es de 3,5” W.C. (0,87 kPa).
• No remueva los pies del fogón.
• No coloque el fogón sobre nada que bloquee o obstruya el espacio entre el fogón y el suelo.
• No fije de forma permanente el fogón de ninguna manera ni a ninguna superficie.
• No entierre la manguera. Debe ser capaz de inspeccionar visualmente la manguera para verificar la
existencia de daños antes de cada uso.
• No enrolle ni oculte la manguera debajo del fogón. La manguera podría dañarse si toca superficies calientes.
• Niños y adultos deben ser alertados en relación a los peligros de altas temperaturas superficiales y
deben permanecer alejados para evitar quemaduras o que la ropa se encienda.
• Los niños pequeños deben ser vigilados cuidadosamente cuando están en la zona de influencia.
• Ropa u otros materiales inflamables no deben colgarse del artefacto ni colocados en o cerca del
artefacto.
• Deberá reponerse cualquier protector o dispositivo de protección que haya sido retirado del
artefacto para su del mismo.
• La instalación y reparación deben ser realizadas por parte del personal de servicio cualificado.
El fogón deber ser inspeccionado antes de su uso y al menos una vez por año por un técnico
cualificado. Una limpieza más frecuente puede ser requerida según sea necesario. Es imperativo
que el compartimento de control, los quemadores y conductos de circulación de aire del artefacto
se mantengan limpios.
• No almacene ni utilice gasolina ni otros vapores o líquidos inflamables dentro de una distancia de 25
pies (7,62 m) de este o de cualquier otro artefacto.
• No almacene materiales combustibles en el compartimiento del fogón. Esto incluye los tanques de PL.
• Asegúrese de proteger la manguera y sus componentes fuera del alcance de cualquier superficie
caliente. Es peligroso permitir que la manguera entre en contacto con cualquier superficie caliente.
• Mantenga limpias todas las partes del fogón incluyendo el conjunto de quemador y manguera. Para obtener
más información sobre la limpieza del fogón, consulte la sección “Cuidado y limpieza” de este manual.

19
INFORMACIÓN IMPORTANTE DE SEGURIDAD
Advertencias generales (Cont.)
Advertencias de instalación
Advertencias durante el uso
• No use este artefacto si alguna de sus partes estuvo debajo del agua. Llame inmediatamente a un
técnico de servicio calificado para inspeccionar el fogón y substituir cualquier parte o sistema de
control y cualquier control de gas que haya estado debajo del agua.
• NO use este fogón para cocinar.
• NO vierta agua en el fogón.
• NO intente mover ni guardar el fogón hasta que todas las partes estén frías.
• Siempre cierre el suministro de gas y desconecte la manguera cuando el fogón no esté en uso.
• Cualquier alteración de este fogón de exteriores que no esté específicamente detallada en el manual de
operaciones anulará la garantía del fabricante. Esto incluye el uso de materiales de relleno no aprobados.
• Antes de cada operación, compruebe que no haya evidencias de abrasión o desgaste excesivo de la
manguera. Utilice un espejo de mano para ver las secciones de la manguera ubicadas debajo de la unidad.
• Si la manguera está dañada, agrietada o con cortes, debe ser reemplazada antes de usar el fogón. El
conjunto de la manguera sólo puede ser reemplazado por un conjunto de manguera especificado por
Real Flame. Llame al 1-800-654-1704 para obtener ayuda.
• Coloque la manguera fuera del camino donde la gente pueda tropezar con ella. No coloque la
manguera en áreas donde pueda sufrir daños accidentales.
• Antes de cada uso, examine el quemador y sus componentes para comprobar la existencia de
suciedad y residuos. Si se requiere limpieza, utilice un cepillo de tuberías y una solución de agua y
jabón. Examine también el área alrededor del quemador. Cualquier suciedad o material extraño, como
por ejemplo telas de araña, nidos u hojas debe ser removido. Si es evidente que el quemador está
dañado, no debe utilizarse el fogón, y el conjunto del quemador debe ser reemplazado. Comuníquese
con Real Flame llamando al 1-800-654-1704 para obtener soporte técnico.
• No queme combustibles sólidos tales como: madera, briquetas de carbón, carbón vegetal, troncos
manufacturados, madera balsa, basura, hojas, papel, cartón, madera enchapada, madera pintada o
manchada o tratada a presión en este fogón de exteriores.
• NUNCA DEJE este fogón desatendido cuando esté en uso.
• El abuso de alcohol, medicamentos recetados o no recetados, puede perjudicar la capacidad de un
individuo para operar con seguridad este fogón.
• Utilice siempre de acuerdo con todos los códigos locales, estatales y nacionales aplicables. Póngase
en contacto con su departamento local de bomberos para obtener detalles sobre fuegos al aire libre.
• NO USE en condiciones de viento. Los vientos de más de 10 mph pueden hacer que la llama se extinga.
• Algunas superficies de este fogón pueden calentarse durante el uso. Tenga cuidado y no toque las
superficies hasta que la unidad se haya enfriado.
• No intente desconectar el suministro de gas del fogón cuando la unidad esté en uso.
• No se siente sobre el fogón.

20
LISTA DE PIEZAS
1
2
3
4
5
6
PRODUCTO NUMÉRO R&B NUMÉRO JCo CANTIDAD
Cuerpo del fogón N/D N/D 1
Tapa N/D 11122005 1
Manguera de GN y N/D 056NG010 1
conector de conexión
Roca de lava negra 970274 100240120J 1
Cobertura de protección 869214 11120002 1
Llave de válvula 711797 11110004 1
1
2
3
4
5
6
