ROOTS RootsScrub B4545 User manual

1
RootsScrub B45 Series
RootsScrub B4545,
B4550 & B4560
Walk-Behind Floor Scrubber Drier
Battery
Read this manual completely and understand the
instructions before operating the machine.
“English Version”
Owner’s Manual
24V

2
RootsScrub B45 Series

3
RootsScrub B45 Series
TABLE OF CONTENTS
557350076-00, Rev-D, 09/17
Prepared by KM, NPM TD Dept.
Description Page No.
Introduction
Know Your Machine
Technical Specification
General Safety Instructions
First Operation
Operation Brush
Operation Squeegee
Procedure for Scrubbing
Maintenance
Battery Instructions
4
5
6
7
9
13
14
15
17
19
Roots Multiclean Ltd (RMCL) is not liable for any legal claims that may arise as a direct or indirect result of the contents of
this manual.
Roots Multiclean Ltd.
RKG Industrial Estate,
Coimbatore - 641 006,
India.

4
RootsScrub B45 Series
INTRODUCTION
Preface
Dear Customer,
We are pleased with your having chosen the RootsScrub
B4545, B4550, B4560, B4545x & B4550x machine for your
floor cleaning requirements. Backed by our industry
expertise that spans across decades, we assure you that the
machine comes with our Roots promise of quality, efficiency
and performance.
We advise you to carefully read through the instructions
prior to the operation of the machine. This manual contains
detailed instructions for the proper operation of the
machine, along with important information regarding its
handling, care, maintenance and service needs.
We are sure that you will find the machine and its
performance to your utmost satisfaction. Once again, we
thank you for choosing Roots Multiclean Ltd. (RMCL) as a
trusted partner for your cleaning requirements and
solutions.
Usage and Handling
Use of the product beyond the specified scope of functioning
is deemed improper and the manufacturer cannot be held
liable for any damages which may arise due to this.
This machine may be used only by persons who are trained or
are familiar with the machine and are aware of the possible
hazards involved. The appropriate Accident Prevention
Regulations as well as applicable general regulations
pertaining to Safety and Health at the work place must be
adhered to by the user.
Modifications made to machine without the manufacturer's
consent will relieve the manufacturer of responsibility and
any possible liability for consequential damage.
Notes on Domestic Warranty
Please refer to the Limited Warranty card supplied along with
the machine for additional information. This Warranty Policy
is applicable only for the product sold within India. If the
product requires repair or maintenance work to be
performed, please ensure that you get the machine serviced
from an authorised service center or dealer of RMCL to
ensure that the warranty is not void.
Acceptance of the Machine
On arrival of the machine at the shipping address, please
check for any damage that may have occurred as a result of
transit. In the event of any such damage, the purchaser is
bound by responsibility to send a claim letter to the
concerned RMCL branch/dealer with a copy of the invoice.
The letter should be sent within 24 hours of receipt of the
machine.
The Manual
All information contained is without obligation. RMCL
particularly reserves the right to modify any equipment,
technical specifications, colours, shapes, materials and the
like so as to adapt them to local conditions all without
previous announcement and without giving reasons. RMCL
may stop manufacturing certain models without previous
notice.
The Owner’s Manual corresponds to the latest information
available for this machine at the time it was printed. Minor
deviations resulting from enhancements of the design
cannot be entirely represented.
The Owner’s Manual is an integral part of the machine and
must not be misplaced.
Roots reserves the right to change the product or contents of
this manual without prior information.
For Battery, Motors, Engines and other OEM components
related kindly refer to their manufacturers manual supplied
along with the machine for instructions regarding usage,
maintenance and service.
Please note down the serial number of your machine
below:
Serial number:
Date of commissioning:
Note:
ŸThis manual includes the Instructions & Spare parts for
B4545, B4550, B4560, B4545x & B4550x models.
ŸWe h ave speci fied the Model No. in s o me
contents/instructions.
ŸIf Model No. has not been specified, the instruction will
be applicable to all models.

5
RootsScrub B45 Series
B 4545
Disc Type with
Parabolic Squeegee &
Solenoid Valve
B 4545
Disc Type with
Parabolic Squeegee &
Solenoid Valve
B 4545
Disc Type with
Straight Squeegee
B 4550
Disc Type with
Straight Squeegee
B 4560
Twin Disc Type with
Straight Squeegee
Disc type
Type of Brush
KNOW YOUR MACHINE

6
RootsScrub B45 Series
TECHNICAL SPECIFICATION
Description Units B 4545 B 4550 B 4560
Scrubbing width mm 450 500 600
Effective Suction Width mm 750 850 850
Theoretical area coverage m2/h 1800 2000 2400
Working Speed, up to km/h 4 4 4
Battery Rating V / Ah 12/96 12/96 12/96
Airflow rate L/sec 28 28 28
Vacuum Pressure mm of H2O1087 1087 1087
Power Supply V 24 24 24
Total Power W 1000 1000 1000
Brush Motor W 720 720 720
Vacuum Motor power W/A 420/18 420/18 420/18
No. of brushes No. 1 1 2
Diameter of brush mm 450 500 330
Brush Speed rpm 180 180 180
Brush load kg 25 26 30
Fresh water tank L 45 45 45
Dirty water tank L 45 45 45
Dimensions (L x W x H) mm 1320 x 500 x 1130 1360 x 545 x 1140 1400 x720 x 1140
Total Weight Empty/with battery kg 82/195 92/205 97/210
Total Weight ready to Operate kg 240 250 255
Description Units B 4545x B 4550x
Scrubbing width mm 450 500
Effective Suction Width mm 750 850
Theoretical area coverage m2/h 1800 2000
Working Speed, up to km/h 4 4
Battery Rating V / Ah - -
Airflow rate L/sec 28 28
Vacuum Pressure mm of H2O1087 1087
Power Supply V 24 24
Total Power W 1000 1000
Brush Motor W 720 720
Vacuum Motor power W/A 420/18 420/18
No. of brushes No. 1 1
Diameter of brush mm 450 500
Brush Speed rpm 180 180
Brush load kg 25 26
Fresh water tank L 45 45
Dirty water tank L 45 45
Dimensions (L x W x H) mm 1320 x 500 x 1130 1360 x 545 x 1140
Total Weight Empty/with battery kg 88/NA 93/NA
Total Weight ready to Operate kg 210 215

7
RootsScrub B45 Series
All paragraphs in this manual referring to you personal safety,
the safety of your machine and the environment protection
are attributed one of the following warning symbols.
Safety & Warning Symbols
General Guidelines
lIn addition to the information contained in this manual,
generally applicable legal provisions for Safety and
Prevention of accidents must be adhered to.
lPlease go through the manual and the instructions
contained herein carefully, even if you possess prior
experience in operating similar ground cleaning
equipment.
lSchedule some time for the careful and thorough perusal
of the manual contents.
lThe responsibility of all persons in the working area fall
upon the operator of the machine.
lNo persons, children included, should be allowed within
the zone of danger.
lThe warning and instruction plates attached to the
machine carry important advice on safe operation of the
machine.
lLost or illegible stickers must be replaced at the earliest.
lPrior to operation of the machine, the operator must
ensure that the machine and its working implements are
in proper and safe operating condition.
lMachines with identified and known defects must not be
used.
lIt is important that operators and all persons likely to use
the machine familiarize themselves with all accessories
and controls, as well as their functions, before
commencing operation.
lAdherence to the above general instructions will help
avoid the operator from having to read the manual while
operating the machine.
Safety during machine operation
lThe machine is applicable for WET scrubbing only.
lGround cleaning machines may be run by qualified
personnel only.
lThe machine may be used for cleaning such surfaces
a p p ro v e d b y t h e o w n e r o r t h i s a u t h o r i z e d
representatives.
lThe machine is only suitable for use on the types of
surfaces specified in the owner’s manual.
lProtect the machine from frost or extremely low
temperatures.
lNever vacuum up explosive liquids, combustible/
explosive dusts as well as acids and solvents! This
includes diesel, petrol, kerosene, paints, paint thinners,
heating oil, etc which can generate explosive fumes on
contact with the suction air. Acetone, undiluted acids and
aggressive solvents must not vacuumed as may cause
damage to the machine components and brooms.
lDo not scrub/vacuum burning or glowing debris.
lDo not scrub/vacuum flooded and slushy areas.
lThis machine must not be operated by persons (including
children) with limited physical ability, sensoric/mental
capabilities or lack of experience, unless such persons are
supervised by the person in charge.
lChildren should be prevented from playing with the
machine.
lThe operator must use the machine properly. The
operator must consider the local conditions and must pay
attention to third parties especially children when
operating the machine.
lNever leave the machine unattended when the motor is
running.
lThe operator must leave the machine only after the
motor has come to a complete standstill.
lPrior to starting work, the operator has to check the
machine’s safety devices are working properly.
lThe operator must wear tight fitting clothes only. The
operator should wear safety shoes only when operating
or while carrying out maintenance work.
lLoose fitting clothes or shoes must not be worn by the
operator or any maintenance personnel who are
intended to work on/with the machine.
lCheck the immediate surrounding prior to starting.
Ensure sufficient visibility!
GENERAL SAFETY INSTRUCTIONS - WALK BEHIND SCRUBBER DRIERS
Symbol
(Hazardous for) Description
Safety Provisions
Caution
Ecological hazard
Read Manual
(persons and goods)
(the machine)
(the environment)
Prior to first operation, read the
manual carefully and strictly comply
with the instructions contained.
D u e t o u s e o f s u b s t a n c e s
representing an inherent danger to
health of environment.
Important information on handling
the machine in order to maintain
operability.
Safety provisions in dangerous
s i t u a t i o n c a u s e d b y m i s u s e
inaccurate adherence of instruction
or prescribed work routine.

8
RootsScrub B45 Series
For easy transportation of machine, it is recommended to lift
up the brush head and squeegee as represented, prior to
transportation of the machine .
Transport
lThe operator must always use safety gloves, safety
helmet, shoes while operating/maintaining the machine.
lOn inclined/tilted surfaces, the tilt angle and the driving
direction should not exceed the values given in this
manual.
lDo not place any tools or metallic objects on top the
battery. Risk of short circuit and deflagration!
l Smoking or naked flames are strictly prohibited.
lAlways allow the machine sufficient time to cool before
carrying out any repair or maintenance work.
lEnsure that there is adequate ventilation for diverting the
exhaust gases/dust when operating the machine in a
closed area.
lDo not place hand or any object while the brushes are
running.
lSuitable tools must be used for cleaning and maintenance
work.
lDo not carry out any welding, drilling, sawing or grinding
work on the frame sections. Damaged parts may only be
changed at an authorized service center.
lIt is not permitted to use aggressive and corrosive
cleaning agents.
lUsed batteries with the recycling symbol must not be
disposed of in household waste.
lMaintenance work may be carried out by authorised
dealer only.
lAlways use appropriate tool and equipments while
working on the machine.
lThe cable must not chafe against anything. In the case of
defective insulation, do not use the on-board charger.
lDo not use harsh chemicals to clean the machine.
This machine is not suitable for evacuation of dusts,
which are explosive or dangerous to health.
Do not clean the machine by means of vapour jet
or high pressure cleaning equipment.
lBefore operating the machine kindly use these safety
devices:
a) Shoes
b) Gloves
ûDo not smoke near machine.
ûDo not expose machine to naked flames or
burning debris.
X
lThis machine is not intended for use on public roads and
places. Only qualified personnel must perform
maintenance and repair work.
lTurn the machine off before cleaning and maintaining the
machine, when replacing parts or when changing over to
another function.
GENERAL SAFETY INSTRUCTIONS - WALK BEHIND SCRUBBER DRIERS

9
RootsScrub B45 Series
FIRST OPERATION
After Unpacking
Verify the machine and accessories with the invoice copy.
Check the machine for any transit damage, if found contact
the branch/dealer immediately.
Owner's personnel are not allowed to unpack the
machine.
Identification of Main Parts
Comply with instructions for correct dosage of cleaning
solution. Correct dosage will help optimize costs and also
minimize impact on the environment. Too much foam can
affect the performance of the machine.
Principle of Operation
A squeegee and suitable brushes or pads are required for wet
cleaning of hard floorings. The rotating brush scrubs the floor
thoroughly, removing dirt through suds, thereby cleaning the
floor. The dirty water is drawn during the same cycle through
the squeegee. Thus, the floor can be walked on immediately
after it is dry and clean.
2
3
4
1
Useful Tips:
ŸPrior to wet cleaning, it is necessary to sweep the floor.
ŸThis way, not only is the cleaning efficiency improved, but
wear of the brush is also substantially reduced.
ŸIf floors are particularly dirty or if wax has to be removed
(basic cleaning); the floor must be treated twice.
ŸDuring the first cycle, the floor is scrubbed with the
cleaning agent selected according to the degree of dirt
encountered, the squeegee remaining lifted.
ŸAllow the cleaning agent to act on the floor for approx. 5
or 10 minutes, complying with the manufacturer's
instructions.
ŸScrub the floor once again while the squeegee is lowered.
ŸToo much foam indicates excessive dosage or improper
suitability of cleaning solution for the existing kind of
dirt.
ŸCleaning solution particles contained in the soiled water
that are not used will cause formation of foam.
ŸInstructions for dosage are given on the cleaning solution
tank and must ideally adhere to manufacturer's
recommendations.
ŸThe ideal type of cleaning solution and the perfect dosage
applicable to it will come through sustained use of the
machine.
3b
4a 4b
450
5
2
6
3a
1
1. Fresh water tank
2. Dirty water tank
3. Brush head
a) Disc type
b) Twin Disc type
4. Squeegee
a) Straight
b) Parabolic
5. Handle
6. Fresh water fill port
7. Control panel
8. Fresh water level indicator
9. Squeegee control handle
10. Pedal for lift/lower brush head
810
7
9

10
RootsScrub B45 Series
FIRST OPERATION
Operating & Indicator Elements:
Controls - B4545 & B4550
Controls - B4560
A
Before Operation
2. The brush motor is fastened to the connecting arm for
upward and downward movement of brush head and this
can be controlled by the pedal.
This machine is not suitable for evacuation of dusts,
which are explosive or dangerous to health.
1. Tilt the body of the machine to gain access to the inside of
the fresh tank, the tank will stay in its position with a help
of a rope assy.
- Care should be taken while closing the tank.
-Do not drop hardly, which might cause possible
damage to equipment and cause personal injury.
LEGEND DESCRIPTION PURPOSE
AMain Power
Switch
Initiates power supply to the
system
BBrush Motor
Switch For On/Off
C Suction Turbine For On/Off
Shows information - software
version
D
set battery and type
battery charging and status
brush motor & suction turbine
On/Off
total hours run
E LED Glows Green when power is On
Display
LEGEND DESCRIPTION PURPOSE
AMain Power
Switch
Initiates power supply to the
system
BBrush Motor
Switch For On/Off
C Suction Turbine For On/Off
D1 & D2 Brush Release To release the brush
Shows information - software
version
E
set battery and type
battery charging and status
brush motor & suction turbine
On/Off
total hours run
F LED Glows Green when power is On
Display
A
RootsScrub B 4545
B
F
C D2
D1
E
B C
D
E
RootsScrub B 4560

11
RootsScrub B45 Series
V5.4 LA
0016:10
0016:10
0016:10
DISPLAY LAYOUT OF LCD
1 . On Power up- Shows the software version (V5.4) & set
battery type when switched On (while booting)
2 . On Start Up- On start up it displays the total previously
run hours of the machine - Format - hhhh:mm and battery
voltage tower.
3 . Brush Motor ON- A brush symbol is displayed when the
brush motor is switched ON.
4 . Suction Turbine ON- A turbine symbol is displayed when
the suction turbine is switched On.
FIRST OPERATION
Controls - B4545x & B4550x
LEGEND DESCRIPTION PURPOSE
AMain Power
Switch
Solenoid
Initiates power supply to the
To control the water flow
system
B
Brush Motor
Switch For On/Off
C
DSuction Turbine For On/Off
Brush Release
LED
To release the brush
Glows Green when power is On
Shows information - software
version
B & E
F
G
set battery and type
battery charging and status
brush motor & suction turbine
On/Off
total hours run
Display
control
A
RootsScrub B 4545
B
F
C D2
D1
E

12
RootsScrub B45 Series
5a. For B4545 & B4550 - Brush Motor & Suction Turbine
OFF - The brush motor shuts down immediately
when switch “B” is pressed but when switch “C” is
pressed the suction turbine shuts down after a
delay of 15 seconds.
5b . For B4545x & B4550x - Brush Motor & Suction
Turbine OFF- The brush motor shuts down
immediately when switch “C” is pressed but when
switch “D” is pressed the suction turbine shuts
down after a delay of 15 seconds.
0016:10
BATTERY CHARGING
6 . The brush motor & suction turbine icons will start
flashing just before the battery cut off level.
0016:10
8 . Fully discharged condition.
9 . On Battery Charging- Displays that the battery is in
charging mode. After the battery is fully charged a
“BATTERY FULL” icon will be displayed.
10. Sleep Mode - If the machine is left idle for 15
minutes after being switched on the machine will
go into a sleep mode, i.e, the display switches off.
To power up again simply switch off the main
switch and switch it on again. This is a power saving
feature.
0016:10
7 . For B4545x & B4550x - Solenoid valve ON- A tap
symbol is displayed when the solenoid valve is switched
ON.
00 16:10
FIRST OPERATION

13
RootsScrub B45 Series
Twin Disc Type Brush
Installation of brush
ŸThe tank should be empty.
ŸRaise the brush head.
ŸHold the brush in hand - press while rotating the brush
onto the catch till a click sound.
Removal of brush
ŸEmpty the tanks.
ŸLift the squeegee and the brush head.
ŸRotate the brush with a sudden jerk to remove them.
The brush must snap in immediately. A rattling noise
indicates that the brush head is not correctly
centered. Turn off switch ”A”, correct position of
brush head and turn on switch “C” for locking. Now
the brush is locked. Repeat locking operation.
Installation of brush
ŸThe tank should be empty.
ŸLift the squeegee.
ŸPlace the brush in front of the machine.
ŸRaise the brush head.
ŸMove the brush to center of the brush head.
ŸLower the brush head so that the catch is centered in the
brush.
ŸFor B4545 & B4550 - Turn on switch “B” for a short time in
order to allow locking.
ŸFor B4545x & B4550x - Turn on switch “C” for a short time
in order to allow locking.
When lowering the machine pay attention to
prevent the pedal for lifting of the brush head from
being pressed down.
Disc Type Brush
Removal of brush
ŸEmpty the tanks.
ŸLift the squeegee and the brush head.
ŸFor B4545 & B4550 - Press “D1 & D2” simultaneously to
release the brush.
ŸFor B4545x & B4550x - Press “D1 & D2” simultaneously to
release the brush.
ŸRaise the brush head and move machine backwards.
ŸBrush is now lying in front of the machine.
Brush Lifting
ŸPedal is used to lift and lower the brush.
ŸFor lowering, first press the pedal a little to outside
(unlock) and then allow it to move slowly upwards.
ŸFor lifting, press the pedal slowly downwards and make it
lock.
Pedal to raise/lower
the brush head.
Brushes / Pads
The machine must be equipped with brushes from the
accessories kit, as required by the degree of dirtiness and
kind of ground.
OPERATION BRUSH

14
RootsScrub B45 Series
The squeegee bracket group fixed to the machine, allowing
swiveling and the oscillating movements. The squeegee,
protruding at the side, evades obstacles in the machines path
and is made swivel backwards.
Straight Squeegee
Before staring to work, check the squeegee for
possible collection of foreign matter and for proper
condition.
Mounting of Squeegee (first time)
ŸLift squeegee bracket group (3)
ŸMount squeegee (1) to squeegee bracket group (3) and
screw the knobs (2) as shown in figure.
ŸAttach suction hose to the tubular socket of the
squeegee.
The supporting wheel under the squeegee bracket
group has been adjusted by the factory.
ŸLift squeegee.
ŸUnscrew the squeegee knob (1).
ŸRemove the squeegee towards the bottom side.
ŸDetach the suction hose from the tubular socket of the
squeegee.
Replacement of Sealing Strips
The sealing strips can be removed without any need of tools,
as follows:
ŸRemove the squeegee.
ŸRemove the knob at the deflector area.(1)
ŸPull the sealing strips (2).
ŸMount the new sealing strips by inverse sequence of
operation.
Removal of Squeegee
1. Squeegee
2. Squeegee Knob
3. Squeegee Bracket group
Mounting of Squeegee (first time)
ŸLift squeegee bracket group (3)
ŸMount squeegee (1) to squeegee bracket group (3) and
screw the knobs (2) as shown in figure.
ŸAttach suction hose to the tubular socket of the
squeegee.
The supporting wheel under the squeegee bracket
group has been adjusted by the factory.
ŸLift squeegee.
ŸUnscrew the squeegee knob (2).
ŸRemove the squeegee towards the bottom side.
ŸDetach the suction hose from the tubular socket of the
squeegee.
Removal of Squeegee
Parabolic Squeegee
1
2
3
1. Squeegee
2. Squeegee Knob
3. Squeegee Bracket group
13
4
2
The sealing strips can be remove without any need of tools,
as follows:
ŸRemove the squeegee.
ŸRemove the squeegee knobs.(1)
ŸRelease the Inner(3) and Outer clamps(4).
ŸPull the sealing strips (2).
ŸMount the new sealing strips by inverse sequence of
operation.
Replacement of Sealing Strips
OPERATION SQUEEGEE
ŸIf worn, the rear sealing strip can be turned at the
front side edge.
ŸThe supporting strip may modify the sealing strip
effect, hard-soft, and thus be adapted to different
floor conditions.
2
1
2
1
3

15
RootsScrub B45 Series
Raising / Lowering the Squeegee
ŸTo lower the squeegee pull the handle up from the slot
and lower squeegee.
ŸTo raise the squeegee pull the handle up and place in slot
provided.
Squeegee handle
movement
PROCEDURE FOR SCRUBBING
OPERATION SQUEEGEE
Dirty and Fresh Water Tanks
The machine has a Dirty Water Tank and a Fresh Water Tank.
The filling capacity is 45 liters. Please do not fill beyond that
mark; water temperature must not exceed 50°C. Dirty water
is fed via the suction hose into the dirty water tank.
- Do not collect any external water.
- When work is finished both the dirty and the fresh
water tanks on principle must be drained and
rinsed in order to preclude formation of residues.
For disposal of dirty water and lye, the legal provisions
have to be compiled with.
Check the in-feed filter in the tank regularly and clean
it if required.
Filling of Water
ŸFill fresh water and cleaning solution as described below
before start of operation.
ŸFill the fresh water tank with water (50° max) as required
by the work to be done through the filter which is present
in front of the machine and add detergent as specified by
the manufacturer.
ŸFilling amount : 45 (45 series)/60 (60 series) liters Max.
max 50°C
Max water
level
1
1
1
2
Use cleaning solution suitable for automatic
machines (low foaming) in order to preclude
damages at the suction turbine. We recommend our
agents for cleaning and care, which are perfectly
adopted to the machine.
How to operate the machine:
ŸTurn on Switch “B” the brush is rotating.
ŸTo discharge the cleaning solution , position the lever
suitably to achieve the desired flow of cleaning solution.
ŸLower the brush head.
ŸLower the squeegee.
ŸTurn on switch “C” the suction turbine is running.
ŸAs soon as the suction turbine is switched on operate the
lever to start water flow.
ŸThe water flow can be adjusted to suite the floor.
ŸThe water flow is maximum when the lever is in top
position.
ŸThe water flow is minimum or to stop when the lever is in
bottom position.
ŸWater flow is controlled by mechanical stopper.
ŸTurn on Switch “C” the brush is rotating.
ŸTo discharge the cleaning solution , position the lever
suitably to achieve the desired flow of cleaning solution.
ŸLower the brush head.
ŸLower the squeegee.
ŸTurn on switch “D” the suction turbine is running.
ŸAs soon as the suction turbine is switched on operate the
lever to start water flow.
ŸThe water flow can be adjusted to suite the floor.
ŸThe water flow is maximum when the lever is in top
position.
ŸThe water flow is minimum or to stop when the lever is in
bottom position.
ŸWater flow is controlled by solenoid valve.
For B 4545, B4550 & B4560:
(Refer Controls section of B4545 & B4550, B4560 in First
Operation)
For B 4545x & B4550x:
(Refer Controls section of B4545x & B4550x in First
Operation)
Lever to adjust
flow of water

16
RootsScrub B45 Series
PROCEDURE FOR SCRUBBING
At the end of cleaning
ŸStop the machine and lift the brush head.
ŸLift the squeegee.
ŸDrain and rinse the dirty water tank (refer to section
"Dirty and Fresh Water Tanks" )
ŸClean the sealing strips at the squeegee.
The machine must not be cleaned by water jet or high
pressure cleaning equipment, as this will endanger its
proper working function.
Remove the drain hose
from this clamp to drain
the water.
Draining of Dirty water tank
When work is completed, the dirty water tank has to
be drained and rinsed.
ŸThe hose used to drain the dirty water.
Draining of Fresh water tank
The tank requires rinsing at regular intervals.
ŸThe water level hose is used to drain the fresh water.
Procedure for draining tanks
ŸUnclamp the drain hose from the hose clamp.
ŸLower the tip of the drain hose to the floor level
ŸAfter draining the water completely, clamp the hose in
the hose clamp.
After lowering the brush move the machine
immediately; otherwise the brush might leave
traces on the floor. Lift the squeegee during reverse
travel. When passing over dormers with a height of
more than 0.7° in =10 mm, the brush drive must be
turned off and the brush must be lifted up.
ŸCleaning of floor areas starts from the wall corner and is
effected stripe by stripe.
ŸIn case of unoccupied areas it will be useful to clean at
first the border areas, passing with the machine along
those areas in counterclockwise sense.
ŸCleaning of the remaining areas then should be effected
stripe by stripe, starting from the outlet socket.
ŸCheck the strainer upstream of the intake opening in the
fresh water tank; clean if required, as otherwise the
suction efficiency will be affected.

17
RootsScrub B45 Series
ŸFor reasons of safety during cleaning and/or maintenance
work in or on the tank, the tank lid - when lifted - must be
secured so as to prevent accidental closing or tilting down.
ŸThe machine may be taken into operation only if all guarding
devices are fitted and in protective position. As far as
possible, cleaning should not be done by hand, but using
appropriate tools or equipment.
ŸMaintenance and repair work may be carried out only by
means of suitable tools and by the people trained in the
factory - for reasons of safety, only genuine Roots spare parts
may be used.
The electrical equipment of this machine uses a mains
voltage of 24 DC. Easy access to brush motor and vacuum
motor is possible after the upper part of the unit has been
titled to upside.
The suction turbine has been provided with a fuse having a
rating of 25A. It must be replaced by a fuse of same rating.
The brush motor is protected by a fuse having a rating of 35A.
When brush motor trips identify the cause and correct it
before trying to run the machine.
The fuses can be changed by removing the rear panel
assembly.
MAINTENANCE
- If there should be repeated cases of failure, look for
the reason.
- Any work at the electrical system has to be carried
out by specialized electricians only.
Maintenance Work
Compliance with our recommendations concerning
maintenance work will give you the certitude always having a
machine at your disposal, which is ready to work and in good
operating condition.
Please contact your local Roots Multiclean distributor; the
people there will be glad to perform that work for you. There
well trained personnel and genuine Roots spare parts are at
your disposal.
ŸWell trained personnel and genuine Roots spare parts
are at your disposal.
ŸIn case of any inquiries or orders for spare parts, please
always quote the machine's serial number mentioned on
the nameplate.
ŸThe name plate is fixed in the rear side of the machine.
ŸWhen cleaning or servicing the machine, and when
replacing any parts, shut off the machine and on principle
disconnect the power plug from the power supply.
Electrical System
Maintenance Schedule
Daily Every
50
Every
100
Every
200
Service Hours
Maintenance Schedule
Check connection - extension
cables and plugs for good
condition; discard Defective
cables immediately
Empty and clean the dirty water
tank
Check the sealing strips of
squeegee for good condition
Check the float for proper
operation
Check the squeegee for possibly
collected foreign matter and
clean it, if required
C h e c k t h e s u c t i o n h o s e
between squeegee and Dirty
water tank
Check the caps of both Fresh
and dirty water drain hose;
c h e c k t h e m f o r s m o o t h
operation
Remove carbon dust from the
suction motor, check the carbon
brush for smooth operation and
wear; renew as required
Check the squeegee sealing
strips for wear; renew them if
required
Check the brush for tight fit and
wear; renew them if required
Check the tank lid seal; renew if
it is required
Check the fresh water infeed to
the brush

18
RootsScrub B45 Series
ŸPrior to cleaning, sweep the floor before using the
machine.
ŸUse the machine in an even surface.
ŸUse only Non foaming chemical for cleaning.
ŸAlways check the condition of Battery.
ŸInspect the condition of float for any deposit of dirt.
ŸDirty water to be drained if it reaches the cut-off stage.
ŸAfter usage, fresh & dirty water has to be drained.
ŸAfter usage of machine, squeegee lips, float assembly
and dirty water tank to be cleaned with fresh water.
ŸDon’t use inflammable liquids (thinner / kerosene) in
fresh water tank for cleaning operation.
ŸAfter usage during cleaning the machine don’t allow
water on the panel board.
ŸDon’t clean the machine with high water pressure jet
equipments.
Do’s
Do’s & Don’t’s
Don’t’s
MAINTENANCE - Troubleshooting
Problem Cause Remedy
No power - nothing works Faulty power switch Contact service
Battery need to be recharged Recharge battery
Faulty battery Replace battery
Loose battery cable Tighten loose cable
Main fuse blown Replace the fuse
Main fuse blown Replace the fuse
Faulty brush motor or loose cable Contact service
Suction turbine does not
work Faulty suction turbine switch Replace switch
Suction turbine fuse blown Replace the fuse
Faulty suction turbine Contact service
Carbon brushes worn Contact service
Insufficient water flow Water tank low Refill fresh water
Flow lever turned to stop Turn lever more to open
Water line clogged Remove and blow with
compressed air
Water valve clogged Remove and clean
Poor water recovery Dirty water tank is full Empty dirty water tank
Suction hose is clogged Remove debris
Squeegee is clogged Remove debris
Squeegee lip is worn Rotate or replace lips
Faulty vacuum hose Contact service
Drain hose leak Hook up drain hose and close
Suction turbine faulty Contact service
Battery charge low Recharge battery
Short run time Battery run down Charge battery twice
Battery still down Contact service
Battery low on water Refill with distilled water
Battery over cycled Contact service

19
RootsScrub B45 Series
BATTERY INSTRUCTIONS
Safety Symbols
Before using the machine
Battery charging procedure
The above instructions have been established for
your safety and have to be strictly observed.
ŸObserve the instruction which must be
mounted clearly at the charging point!
ŸNo Smoking!
ŸNo naked lights, embers or sparks in the
vicinity, risk of fire and explosion!
ŸWear protective goggles and protective
clothing when working on the batteries!
ŸDo not tilt the battery!
ŸOnly use certified hoisting and transport
equipment.
ŸKeep children away from batteries.
ŸAny splashes of acid in the eyes or on the
skin must be rinsed throughly with plenty of
clear pure water.
ŸThen consult a doctor immediately!
ŸRisk of fire explosion, avoid short circuits!
ŸCaution! Metal components in the battery
cells are always under voltage, never place
any foreign items or tools on the battery!
ŸEnsure the battery is in fully charged condition.
ŸCheck the battery electrolyte level, if required refill it.
- Drain both the tanks
- Move machine near charger location
- Switch Off Machine
- Tilt fresh tank.
- Connect charger to power supply.
Charge the batteries in a well ventilated area.
- Make sure to connect the charger to the specified
voltage and frequency.
- Ensure that the seat cover is completely open.
- Do not place any objects on the battery.
ŸElectrolyte is highly corrosive!
ŸKeep children away from batteries
ŸDo not throw in garbage!
Traction Batteries (AGM/LA)
1. Initial Checking
Check the battery to ensure that it is in perfect mechanical
condition. All screwed unions within the circuit must be
tightened to ensure reliable contacts. Machine cables and
charging cable are to be connected to the correct poles of
the battery otherwise battery and charger can be
damaged.
2. Discharging
Ventilation openings may not be covered or closed. Electric
connections (e.g-plugs) may be connected or disconnected
only when the machine is in off condition. Discharge
batteries must be recharged immediately and may not
remain in discharged condition. this also applies to only
partially discharged batteries.
The battery may only be connected up to the allocated
battery charger certified for the particular battery size, to
avoid overload on the electric current Maintenance Free
Batteries have low gassing properties but are not completely
free of gassing. The battery is to be connected with the
correct poles (plus to plus and minus to minus) to the
disconnected battery charger. The battery charger should
then be switched on.

20
RootsScrub B45 Series
BATTERY INSTRUCTIONS
1. Kindly ensure that the Warranty certificate of the battery is
available at your end.
ŸKindly read the Do’s & Don't’s of the battery, understand
and follow.
ŸCheck the electrolyte level before charging and top it up
with battery grade distilled water if required.
ŸMatch the battery to the correct charger.
ŸKeep the battery well ventilated while charging.
ŸCharge the battery immediately after it is discharged.
ŸKeep all inter cell connections and bolted terminals tight
and covered with petroleum jelly.
ŸKeep the machine tank opened while charging to
improve ventilation.
Battery and Charger
Batteries connecting diagram
ŸThe batteries and charger are located in the fresh water
tank.
ŸThe on board charger is located in the fresh water tank,
mounted on to a special bracket.
Do not tamper with the charger connections
AGM LA
Lead Acid (LA) Battery Instructions:
3. Temperature
The battery temperature of 30 °C is rated temperature.
Higher temperatures shorten the service life and lower
temperatures reduce available capacity. 45 °C is the limit
temperature and is not tolerable as operating temperature.
4. Electrolyte
The electrolyte is sulphuric acid (LA) stored in liquid form.
The specific gravity of the electrolyte and quantity shall be
checked weekly.
If the quantity is low, refill with battery grade distilled water.
5. Maintenance
Daily maintenance- Recharge the battery every time it has
been discharged.
Weekly maintenance- Visual inspection after recharging for
signs of dirt and mechanical damage.
Maintenance to be carried out every three months
After fully recharging and following a standing period of at
least 5 hours, the following must be measured and Recorded:
– total voltage / – individual voltage
If noticeable changes are detected compared to previous
measurements, or differences between the cells or block
batteries, the customer service should be called for testing or
repair.
6. Care
The battery must be kept clean and dry to prevent creeping
current. Any liquid in the battery container must be extracted
and disposed of according to regulations.
Distilled water level shall be maintained at safe level.
( refer battery manual )
7. Storage
If batteries are out of operation for longer periods, they
should be stored in fully charged state in a dry, frost free
room.
In order to ensure that the battery is ready for operation at
any time, full recharge every three months. When a
consumer is connected up (e.g. measuring or controlling
devices), it may be necessary to recharge the battery every
two weeks.
8. Faults
The customer service should be called immediately when
any faults are discovered in battery or battery charger.
B1 B2
