TENNANT S7
PEDESTRIAN SWEEPER
OPERATOR MANUAL
Clemas & Co. Unit 16 Ashchurch Business Centre, Alexandra Way, Tewkesbury,
Gloucestershire, GL20 8NB.
Tel: [phone] Fax: [phone]
Email: [email protected]o.uk Web: www.clemas.co.uk

EN TRANSLATION OF ORIGINAL INSTRUCTIONS
TECHNICAL DATA AND CHARACTERISTICS ......................................................................................................2
WARNINGS..............................................................................................................................................................3
SAFETY MEASURES..............................................................................................................................................3
SAFETY LABELS....................................................................................................................................................4
SERIAL NUMBER LABEL LOCATION...................................................................................................................5
INTRODUCTION......................................................................................................................................................5
UNPACKING............................................................................................................................................................5
PREPARING THE MACHINE ..................................................................................................................................5
Fitting the side brush...................................................................................................................................5
Fitting the handle..........................................................................................................................................5
Preparation, installation and replacement of the battery .........................................................................6
ADJUSTMENT CONTROLS....................................................................................................................................6
START-UP................................................................................................................................................................6
INSTRUCTIONS FOR CORRECT OPERATION.....................................................................................................7
TAKING OUT THE DEBRIS HOPPER FOR CLEANING .......................................................................................7
)URQWELQ¿J ............................................................................................................................................7
5HDUELQ)LJ.............................................................................................................................................7
ROUTINE MAINTENANCE......................................................................................................................................7
BATTERY MAINTENANCE .....................................................................................................................................8
Recharging the battery.................................................................................................................................8
BATTERY CHARGER SETTINGS...........................................................................................................................8
BATTERY CHARGER ANOMALIES .......................................................................................................................8
FILTER MAINTENANCE..........................................................................................................................................9
&OHDQLQJWKHSUH¿OWHU...................................................................................................................................9
&OHDQLQJWKH¿OWHU .........................................................................................................................................9
5HSODFLQJWKH¿OWHU .......................................................................................................................................9
REPLACING AND ADJUSTING THE SIDE BRUSH...............................................................................................9
REPLACING AND ADJUSTING THE CENTRE BRUSH........................................................................................9
REPLACING AND ADJUSTING THE BELT............................................................................................................10
Replacing the side brush belt......................................................................................................................10
Replacing the drive belt...............................................................................................................................10
REPLACING THE FLAPS .......................................................................................................................................10
2XWHUVLGHÀDSV.............................................................................................................................................10
,QQHUVLGHÀDSV .............................................................................................................................................10
&HQWUHÀDS.....................................................................................................................................................10
REPLACING AND ADJUSTING THE CABLES......................................................................................................11
Replacing the drive cable ............................................................................................................................11
Replacing the side brush lifting cable........................................................................................................11
TROUBLESHOOTING TABLE................................................................................................................................11
SCRAPPING THE MACHINE..................................................................................................................................11
RECOMMENDED SPARE PARTS LIST..................................................................................................................12
TABLE OF CONTENTS
Copyright © 2019 Tennant Company. All rights reserved.
Tennant N.V.
Industrielaan 6 5405 AB
P.O. Box 6 5400 AA, Uden - The Netherlands
[email protected]
http://www.tennantco.com
- 1 -

EN TRANSLATION OF ORIGINAL INSTRUCTIONS
TECHNICAL DATA AND CHARACTERISTICS
DESCRIPTION
Maximum width mm 740
inches 29
Maximum length mm 1245
inches 49
Maximum height clearance with handle mm 960
inches 37,75
Cleaning width with centre brush mm 500
inches 19,68
Cleaning width with centre brush and side brush mm 700
inches 28
Weight with battery kg 121
lbs 266,76
Front debris bin capacity l45
ft31.6
Operating autonomy h<3
Filtering area m² 1,03
ft211.08
Filtration   HႈFLHQW IRU SDUWLFOHV XS WR 
microns
Productivity (for Hour) Theoretically Max. m2/h 2601
ft2/h 28000
Productivity (for Hour) Estimate Coverage m2/h 2508
ft2/h 27000
Installed power / current 710W / 59A
Battery type (maintenance-free) 12V 140Ah (C20)
12V 105Ah (C5)
Sound pressure, LpA 70 dBA
Measurement uncertainty, kpA 3.0 dBA
Sound power, LwA,g 80 dB
Vibration level (hand), ahv 1.1 m/sec2
Measurement uncertainty, k 0.5 m/sec2
- 2 -

EN TRANSLATION OF ORIGINAL INSTRUCTIONS
WARNINGS
This machine is intended for commercial use only. Its intended
purpose is to collect dirt, dry waste and dust from dry, paved or
carpeted surfaces.
Itmustnotbe used for any other purposes. Do not use the machine
to pick up liquids, hazardous or toxic materials.
Operators are required to read, understand and comply with the
following warnings.
In this manual, the warning symbol shown below and the term
“SAFETY WARNING” are used with the following meanings:
WARNING: warns of dangers or dangerous proce-
dures that may cause serious injuries or death.
SAFETY WARNING: indicates the procedures to be followed
for the safe use of the machine.
Failure to comply with these warnings may be the cause of injuries,
HOHFWULFVKRFN¿UHRUH[SORVLRQV
WARNING: Do not operate the machine in the pres-
HQFHRIÀDPPDEOHOLTXLGVRUYDSRXUVRUFRPEXV-
tible dusts.
The machine is not equipped with explosion-proof motors. The
sparks generated in the electric motors when starting and during
RSHUDWLRQPD\FDXVH¿UHRUH[SORVLRQLIWKHPDFKLQHLVXVHGLQWKH
SUHVHQFHRIÀDPPDEOHOLTXLGVYDSRXUVRUFRPEXVWLEOHGXVWV
:$51,1*'RQRWSLFNXSWR[LFRUÀDPPDEOHPDWH-
rials, burning or smouldering waste.
WARNING: The batteries emit hydrogen.
.HHS DZD\ IURP VSDUNV DQG RSHQ ÀDPHV /HDYH
the battery compartment open while charging.
WARNING: Do not charge the batteries if the char-
ger’s power cable appears damaged. Do not mod-
ify the plug.
If the battery charger cable is damaged or broken, have it replaced
E\WKHPDQXIDFWXUHUDQDXWKRULVHGVHUYLFH FHQWUHRUDTXDOL¿HG
technician.
WARNING: Before carrying out any work on the
machine, disconnect the battery cables and unplug
the charger’s power cable.
SAFETY WARNINGS: Do not use the machine on wet surfac-
es. Do not expose the machine to rain.
The machine must be kept indoors at all times
The following information indicates potentially dangerous
conditions for the operator or the machine.
SAFETY MEASURES
Do not use the machine:
• ,QWKHSUHVHQFHRIÀDPPDEOHRUH[SORVLYHVXEVWDQFHV
• Unless trained and authorised.
• Without having read the operator manual carefully.
• If the machine is not in perfect conditions.
• ,QWKHDEVHQFHRIDELQDQGRU¿OWHUV
Battery charger;
• Make sure that the power socket used for the battery charger
is connected to a suitable earth system and protected by
thermal overload and residual current circuit breakers.
• Make sure the electrical characteristics of the battery charger
(voltage, frequency, absorbed power) given on the rating
plate are the same as those of the mains power supply.
Before starting the machine:
• Make sure the safety devices are present and are functioning
correctly.
When the machine is running:
• Do not pick up burning or smouldering waste, such as
cigarettes, matches or embers.
• Do not use the machine to pick up liquids.
• Report any damage or faults immediately.
• Proceed slowly on sloping and slippery surfaces.
• Do not leave the machine unattended or on sloping surfaces.
• Do not use the machine to pick up wires, ropes, straps or
similar materials.
• Make sure the work area is well lit.
• Keep the machine out of the reach of children.
• Do not use the machine to transport people or things.
• In dusty environments, wear protective glasses and gloves.
Before leaving the machine or before carrying out maintenance:
• 6WRSWKHPDFKLQHRQÀDWDQGGU\ÀRRULQJ
• 7XUQWKHPDFKLQHRႇ
During maintenance and repair work:
• Keep away from moving parts. Do not wear jackets, shirts
or clothes with sleeves that may get caught in parts of the
machine.
• Before working on the machine, disconnect the battery and
the charger plug.
• Use original or approved spare parts.
• 5HSDLUVPXVWEHSHUIRUPHGE\DTXDOL¿HGWHFKQLFLDQ
• Do not modify the machine in any way.
• When handling the battery or battery cables, wear protective
gloves and goggles.
• Avoid contact with battery acid.
• Do not operate the machine on slopes greater than 2%
When transporting the machine:
• 7XUQWKHPDFKLQHRႇ
• Request assistance to lift the machine.
• )RU ORDGLQJXQORDGLQJ RQWRRႇ RI D WUXFN RU WUDLOHU XVH D
suitable ramp.
• Secure the machine to the truck or trailer using straps.
- 3 -

EN TRANSLATION OF ORIGINAL INSTRUCTIONS
SAFETY LABELS
6DIHW\ODEHOVDUHDႈ[HGWRWKHPDFKLQH,IGDPDJHGWKHVHPXVWEHUHSODFHG
WARNING! RISK OF ENTANGLEMENT
WARNING! RISK OF ACID BURNS
WARNING! RISK OF BURNS
MAXIMUM SLOPE
OPERATOR MANUAL, INSTRUCTIONS FOR USE
READ THE OPERATOR'S MANUAL
DIRECT CURRENT SYMBOL
CLASS III APPLIANCE. AN APPLIANCE IS IDENTIFIED AS CLASS III WHEN
ITS EXPLOSION-PROOF PROTECTION IS BASED ON THE FACT THAT
THERE ARE NO VOLTAGES HIGHER THAN THE ULTRA-LOW SAFETY
EXTRA-LOW VOLTAGE (SELV). THIS MEANS IN PRACTICE THAT THE
APPLIANCE IS POWERED BY A BATTERY OR A SELV TRANSFORMER.
SPECIAL WASTE. DO NOT DISPOSE OFAS NORMAL WASTE.
WARNING! RISK OF ABRASION OR ENTANGLEMENT BY TOUCHING THE
BRUSH IN ROTATION
