ROOTS RootsScrub RB 800 C User manual

Operator’s Manual
RootsScrub RB 800 C
Ride-On Scrubber Drier
with Cylindrical Brush

TABLE OF CONTENTS
3
RootsScrub RB 800 C
557100057-00, Rev-C, 06/17
Please be advised explicitly that we cannot accept any legal claims out of the contents of this manual. If repair work has to be performed, make sure that only genuine spare parts
are used since genuine spare parts only may guarantee continuous and dependable operation of your machine.
Roots Multiclean Ltd.
RKG Industrial Estate,
Coimbatore - 641 006, India.
Description Page No
Introduction 4
Technical Specification 5
General Safety Instructions 6
Initial Startup 8
Operation Brush 11
Operation Squeegee 12
Procedure for Scrubbing 12
Maintenance 14
Battery System 19
Illustrated Parts List 22

INTRODUCTION
4
RootsScrub RB 800 C
Dear Customer,
We are pleased with your having chosen the RootsScrub
RB 800 C machine for your floor cleaning requirements.
Backed by our industry expertise that spans across
decades, we assure you that the machine comes with our
Roots promise of quality, efficiency and performance.
We advise you to carefully read through the instructions
prior to the operation of the machine. This manual
contains detailed instructions for the proper operation of
the machine, along with important information regarding
its handling, care, maintenance and service needs.
We are sure that you will find the machine and its
performance to your utmost satisfaction. Once again, we
thank you for choosing Roots Multiclean Ltd. (RMCL) as a
trusted partner for your cleaning requirements and
solutions.
Usage, Handling & Modification
Use of the product beyond the specified scope of
functioning is deemed improper and the manufacturer
cannot be held liable for any damages which may arise due
to this.
This machine may be used only by persons who are trained
or are familiar with the machine and are aware of the
possible hazards involved. The appropriate Accident
Prevention Regulations as well as applicable general
regulations pertaining to Safety and Health at the work
place must be adhered to by the user.
M o d i f i ca t i o n s m a d e to m a c h i n e wi th o u t th e
manufacturer's consent will relieve the manufacturer of
responsibility and any possible liability for consequential
damage.
Notes on Domestic Warranty
Please refer to the Limited Warranty card supplied along with
the machine for additional information. This Warranty Policy is
applicable only for the product sold within India. If the product
requires repair or maintenance work to be performed, please
ensure that you get the machine serviced from an authorised
service center or dealer of RMCL to ensure that the warranty is
not void.
Acceptance of the Machine
On arrival of the machine at the shipping address, please check for
any damage that may have occurred as a result of transit. In the
event of any such damage, the purchaser is bound by
responsibility to send a claim letter to the concerned RMCL
branch/dealer with a copy of the invoice. The letter should be sent
within 24 hours of receipt of the machine.
Roots reserves the right to change the product or contents
of this manual without prior information.
For Battery, Motors, Engines and other OEM components
related kindly refer to their manufacturers manual supplied
along with the machine for instructions regarding usage,
maintenance and service.
Note: I llustration s sh own i n th e man ual are for
representative purpose only. Actual product may vary.
All information contained is without obligation. RMCL particularly
reserves the right to modify any equipment, technical
specifications, colours, shapes, materials and the like so as to
adapt t hem to l ocal condi tion s al l wi thou t previous
announcement and without giving reasons. RMCL may stop
manufacturing certain models without previous notice.
The Owner’s Manual corresponds to the latest information
available for this machine at the time it was printed. Minor
deviations resulting from enhancements of the design cannot be
entirely represented.
The Owner’s Manual is an integral part of the machine and must
not be misplaced.
The Manual
Please note down the serial number of your machine
below:
Date of commissioning:
Serial number:
Preface,

TECHNICAL SPECIFICATION
5
RootsScrub RB 800 C
DESCRIPTION UNIT VALUE
Scrubbing width mm 800
Effective suction width mm 1100
Theoretical area coverage m2/h 4800
Working speed, up to km/h 6
Travel speed km/h 6
Battery rating V/Ah 24/320, 24/240
Airflow rate L/sec 33
Vacuum pressure mm of H2O1650
Power supply V 24
Total power W 2300
Brush motor power W 1000
Vacuum motor power W 550
Drive motor power W 750
No. of brushes No. 2
Diameter of brush mm 150
Brush speed rpm 760
Brush pressure Kg 43
Fresh water tank L 120
Dirty water tank L 120
Dimensions (L x W x H) mm 1750 x 1100 x 1410
Weight of machine with battery kg 540 - 320 Ah
Weight of machine with battery kg 490 - 240 Ah
Turning radius m 1.8
Weight of machine (ready to
operate) kg 660 - 320 Ah
Weight of machine (ready to
operate) kg 610 - 240 Ah

GENERAL SAFETY INSTRUCTIONS
6
RootsScrub RB 800 C
Safety & Warning Symbols
All paragraphs in this manual that refer to personal safety,
safety of the machine and environmental protection are
attributed respective warning symbols as indicated.
lThe machine is only suitable for use on the types of
surfaces specified in the owner’s manual.
lProtect the machine from frost or extremely low
temperatures.
lNever scrub or vacuum explosive liquids, combustible /
explosive dusts as well as acids and solvents! This
includes diesel, petrol, kerosene, paints, paint thinners,
heating oil/fuel, etc which can generate explosive fumes
on contact with the suction air. Acetone, undiluted acids
and aggressive solvents must not be vacuumed as it may
cause damage to the machine components and brooms.
lDo not scrub/vacuum burning or glowing debris.
lDo not scrub/vacuum in flooded and slushy areas.
lThis machine must not be operated by persons (including
children) with limited physical ability, sensoric/mental
capabilities or lack of experience, unless such persons
are supervised by the person in charge.
lChildren should be prevented from playing with the
machine.
lThe operator must use the machine properly. The
operator must consider the local conditions and must
pay attention to third parties especially children when
operating the machine.
lNever leave the machine unattended when the motor is
running.
lThe operator must leave the machine only after the
motor has come to a complete standstill, parking brake
applied and the key has been removed.
lPrior to starting work, the operator must check that the
machine’s safety devices are working properly.
lThe operator must wear tight fitting clothes only. The
operator should wear safety shoes only when operating
or while carrying out maintenance work.
lLoose fitting clothes or shoes must not be worn by the
operator or any maintenance personnel who are
intended to work on/with the machine.
General Guidelines
lIn addition to the information contained in this manual,
generally applicable legal provisions for Safety and Prevention
of accidents must be adhered to.
lPlease go through the manual and the instructions contained
herein carefully, even if you have prior experience in
operating similar ground cleaning equipment.
lSchedule some time for the careful and thorough perusal of
the manual contents.
lThe responsibility of all persons in the working area fall upon
the operator of the machine.
lNo individual, including children, should be allowed within
the zone of danger.
lThe warning and instruction plates attached to the machine
carry important information on safe operation of the
machine.
lLost or illegible stickers must be replaced at the earliest.
lPrior to operation of the machine, the operator must ensure
that the machine and its working tools/equipments are in
proper and safe operating condition.
lMachines with identified and known defects must not be
used.
lIt is important that operators and all persons likely to use the
machine familiarize themselves with all accessories and
controls, as well as their functions, before commencing
operation.
lAdherence to the above general instructions will help avoid
the operator from having to read the manual while operating
the machine.
Safety During Machine Operation
lThe machine is applicable for WET scrubbing only.
lGround cleaning machines may be run by qualified personnel
only.
lThe machine may be used for cleaning such surfaces
approved by the owner or the authorized representatives.
Safety regulations in dangerous situation caused by
misuse, improper adherence of instruction or prescribed
work routine.
Safety Regulations
(persons & goods)
Due to use of substances representing an inherent
danger to health of environment.
Ecological hazard
(the environment)
Important information on handling the machine in order
to maintain operability.
Caution
(the machine)
Prior to first operation, read the manual carefully and
comply with the instructions contained herein without
fail.
Read manual

7
RootsScrub RB 800 C
This machine is not suitable for evacuation of dusts, which
are explosive or dangerous to health.
lDo not clean the machine by means of
vapour jet or high pressure cleaning
equipment.
lDo not direct water into the electrical
components. Risk of injury and equipment
damage.
lCheck the immediate surrounding prior to starting.
Ensure sufficient visibility!
lThe operator must always use safety gloves, safety
helmet, shoes while operating /maintaining the
machine.
lOn inclined/tilted surfaces, the tilt angle and the driving
direction should not exceed the values given in this
manual.
lDo not place any tools or metallic objects on top the
battery. Risk of short circuit and deflagration!
l Smoking or open fires are strictly prohibited.
lAlways allow the machine sufficient time to cool down
before carrying out any repair or maintenance work.
lEnsure that there is adequate ventilation for diverting
the exhaust gases/dust when operating the machine in
a closed area.
lDo not place hand or any object while the brushes are
running.
lAppropriate tools must be used for cleaning and
maintenance work.
lDo not carry out any welding, drilling, sawing or grinding
work on the frame sections. Damaged parts may only be
changed at an authorized service center.
lIt is not permitted to use aggressive and corrosive
cleaning agents.
lUsed batteries with the recycling symbol must not be
disposed of in household waste.
lMaintenance work may be carried out by authorised
dealer only.
lAlways use appropriate tool and equipments while
working on the machine.
lDisconnect the battery when working on electrical
system.
lBattery may only be handled and changed by properly
skilled maintenance personnel.
lPay attention that the insulation of the charger cable is
not damaged and cannot be damaged during the
charging process.
lThe cable must not chafe against anything. In the case of
defective insulation, do not use the on-board charger.
lWhen charging the batteries, there must be sufficient
ventilation in the charging area. Otherwise, there is a risk of
explosion!
lBatteries must not be connected or disconnected when
conducting electricity.
lDo not use harsh chemicals to clean the machine.
- Do not smoke near the machine.
- Do not expose machine to open fires or burning
debris.
ŸBefore operating the machine kindly use
these safety devices:
i) Shoes
ii) Helmet
iii) Gloves
The machine may be used only on indoor hard floorings
and for operation on level grounds with a maximum
inclination of up to 10° .
- The machine is splash-water proof (IPX3).
- This machine is not intended for use on public roads and
place s. Only qualif ied personnel mu st pe rform
maintenance and repair work .
- Turn the machine off and disconnect the mains plug before
cleaning and maintaining the machine, when replacing
parts or when changing over to another function.
X
GENERAL SAFETY INSTRUCTIONS

Upon unpacking
Verify the machine and accessories with the invoice copy.
Check the machine for any transit damage, if found contact
the branch/dealer immediately.
INITIAL STARTUP
8
RootsScrub RB 800 C
Owner’s personnel are not allowed to unpack the
machine.
Steering Wheel
Debris Tray Squeegee Control Panel Traction Battery Electronics Bay Drive Motor
Cylindrical Brush Head Working Lamp
Accelerator Pedal Brake Pedal Operator Seat Fresh Water Tank Dirty Water Tank
KNOW YOUR MACHINE
Identification of main parts

Decals on the machine Principle of operation
Useful tips
9
RootsScrub RB 800 C
6
7
1. Roots - Silvergrey
2. Roots - Dome
3. Fresh water filling
4. Remove key/Read instruction manual
5. Do not wash with high pressure/Max inclination
6. Read battery instruction
7. Pinch warning
8. Control panel
A squeegee and suitable brushes or pads are required for wet
cleaning of hard floorings. The rotating brushes (1) scrubs the
floor thoroughly, removing dirt, by cleaning agent supplied from
the fresh water tank (2) thereby cleaning the floor. The soiled
water is drawn during the same cycle through the squeegee (3)
and fed into the dirty water tank (4). Thus, the floor can be
accessible immediately after it is dry and clean.
·Detergent particles contained in the soiled water that
are not used will cause formation of foam.
·Instructions for dosage are given on the detergent
container and must ideally adhere to manufacturer's
recommendations.
·The ideal type of detergent and the perfect dosage
applicable to it will come through sustained use of the
machine.
·Prior to wet cleaning, it is necessary to clean the floor. This
way, not only is the cleaning efficiency improved, but wear of
the brush is also substantially reduced.
·If floors are particularly dirty or if wax has to be removed
(basic cleaning); the floor must be treated twice.
·During the first cycle, the floor is scrubbed with the cleaning
agent selected according to the degree of dirt encountered,
the squeegee remaining lifted.
·Allow the cleaning agent to act on the floor for approx. 5 or 10
minutes, complying with the manufacturer's instructions.
·Scrub the floor once again while the squeegee is lowered.
·Too much foam indicates excessive dosage or improper
suitability of detergent for the existing kind of dirt.
Comply with instructions for correct dosage of
detergent. Correct dosage will help optimize costs
and also minimize impact on the environment. Too
much foam can affect the performance of the
machine.
1
2
3
4
1
2
3
4
5
8
13 4
5
67
8
2
INITIAL STARTUP

OPERATING AND INDICATOR ELEMENTS
1. Steering Wheel-
4. Control Panel-
2. Operator’s seat
3. Accelerator Pedal
5. Brake Pedal
Used to propel the machine forward
or backwards.
Used to slow/stop the machine.
Used to steer the machine.
Houses all the controls of the
machine.
Control panel switches in detail -
10
RootsScrub RB 800 C
Adjust the driver's seat longitudinally
as follows:
- Push lever to the side and displace
the seat as required, then let the
lever catch into place again.
E. Suction Turbine (On/Off)-
Turns the Suction Turbine On/Off.
Lowers & Raises the squeegee
according to the operation.
G. Soiled water tank full indicator
lamp-
Glows when the soiled water tank
is full.
D. Brush Motor (On/Off)-
Turns the Brush motor On/off
Lowers & Raises the brush head
according to the operation.
F. Extra Pressure-
Increases the brush pressure
to 50 kg max for heavy soiling.
A B C
D
J
G
E F
I
K
L
M
H
A. Key Switch-
Turns the electrical system On/Off.
C. Direction Selector-
Selects the direction of travel.
0
I
B. Horn Button-
Actuates the electric horn.
H. Working Lamp
(On/Off)-
Toggles the working lamp On or Off
INITIAL STARTUP

11
RootsScrub RB 800 C
BRUSH
Cylindrical Brush Head
Clean the cylindrical brushes on the brush head daily or as
necessary.
1. Raise the brush head.
2. Remove the rubber deflector stip assembly (a) by unscrewing
the knobs.
3. Unscrew the idler plate securing pin (b).
4. Raise the idler plate assemble (c) upwards to access the
brushes.
5. Pull out the brushes (d) to clean or to rotate them end-to-end.
Cleaning the cylindrical brushes
Do not use harsh acids or chemicals to
clean the brushes.
1. Slide the brush (d) in the cylindrical brush head and allow
to snap into place on the oppositely facing catches.
2. Clock the idler plate assembly (c) and secure it with the pin
(b) provided.
3. Mount the rubber deflector stip assembly (a).
1. Lift the debris tray upwards a little to facilitate easy
removal of the tray from its retaining position.
2. Empty the debris in an approved manner.
3. Clean the debris tray and place it back on the brush head.
Installation of cylindrical brushes
Cleaning the debris tray
I. Drive Motor Malfunction
warning lamp-
Glows when there is an error
in the drive motor or controller.
M
J. Battery Charge status
indicator lamp-
Shows the status of the
battery.
K. Hour meter & Error Code
Display-
Displays the total hours of machine
use and any error in the electronic
module.
L. Water level indicator-
Displays the level of water
selected.
M. Water level controls-
Used to On/Off,
Increase/Decrease the amount
of water to clean the floor.
a
c
d
b
Switch off machine before changing brushes.
Care should be taken while mounting brushes.
Do not stand on the brush head.
Do not empty the debris into the
environment.
Switch off machine before removing the debris
tray.
Care should be taken while removing the debris
tray, may injure your hands.

12
RootsScrub RB 800 C
SQUEEGEE
Clean the squeegee before starting the work
cycle every time.
Do not stand on the squeegee.
Cleaning the squeegee
Check the squeegee everyday and clean as necessary.
To clean the squeegee, raise it, disconnect it from the
suction hose, loosen the knobs and remove the squeegee.
Wash the squeegee under clean running water.
PROCEDURE FOR SCRUBBING
MAX
5.0 mm
Water Level
Max. 10°
Driving the machine
Do not park the machine on slopes or ramps.
Maximum inclination of 10°
is only allowed.
Maximum water wading of
5.0 mm is allowed.
The machine is powered by a powerful traction motor.
Starting-
To propel the machine press the accelerator pedal in downward
direction.
Stopping-
To stop or slow the machine release the accelerator pedal
(Pedal returns to its initial position). Press the brake pedal to
slow or stop the machine.
Proceed to the first driving trails on a clear training ground until
the driver is acquainted with the elements and their functions.
lBefore leaving the machine make sure to remove the
key.
lBecause of skidding hazard drive at reduced speed
on wet grounds and when turning.
lDrive slowly on downhill, turning, wet grounds,
ramps and on uneven surfaces.
lDo not drive the machine in flooded areas. Risk of
damaging the traction motor.
lNever make sharp maneuvers while driving.
lDo not adjust the seat while driving the machine.
Do not modify the machine to transport people or
goods.
Do not drive fast with the tanks full of water.
Start of cleaning
ŸTo fill clean water in the fresh water tank insert the
water hose into the fill port.
ŸAdd required amount of recommended cleaning agents
to the water.
ŸMove the machine to the area to be cleaned.
ŸSwitch on key “A”.
ŸOperate switch “M” to select the desired amount of
water flow.
ŸPress “D” to lower the brush head - brush head lowers
and brushes rotate.
ŸPress “E” to start suction turbine - suction turbine starts
and squeegee lowers.
ŸOperate “C” to forward position.
ŸDrive immediately or the brushes will leave traces on
the floor.
ŸCommence cleaning operation of the area.
MALFUNCTION
OR
EMERGENCY
XDo not tamper the traction motor
controller. Risk of damaging the motor.
In case of an emergency or malfunction - switch of key and
disconnect battery plug.
Squeegee
The parabolic squeegee is used to extract the dirty water
from the floor.
The sealing strips can be removed without the need for any
tools, as follows:
ŸRemove the squeegee.
ŸRemove the squeegee knobs.(1)
ŸRelease the Inner(3) and Outer clamps(4).
ŸPull the sealing strips (2).
ŸMount the new sealing strips through inverse sequence
of operation.
Replacement of Sealing Strips
13
4
2

PROCEDURE FOR SCRUBBING
13
RootsScrub RB 800 C
DIRTY AND FRESH WATER TANKS
Fresh water tank
The fresh water tank has a
capacity of 120 liters.
Place the water hose into the fill
port to filter and fill the tank.
Do not fill water beyond a
temperature of 50°C.
Fresh water tank indicator hose.
Dirty water tank
The dirty water tank has a
capacity of 120 liters.
Float
Collection
Tray
Suction
Hose
Drain
Hose
End of cleaning
ŸPress “D” to switch off brush head.
ŸClose the water flow.
ŸRun the machine to collect the remaining water.
ŸPress “E” to switch off suction turbine and raise squeegee.
ŸDrive the machine to the waste disposal area.
ŸUnhook the drain hose and dump the dirty water to the drain.
Do not drain the soiled
water into the environment.
- Remove the collection tray and clean with fresh water.
- Clean the dirty water tank with clean water.
Remove the squeegee from the machine and clean the lips
before the next operation.
- Do not direct the water jet into any opening, slots,
on electronic modules, control panels or sealing.
- Do not use harsh chemicals to clean the machine.
- Wipe the machine with a damp cloth after usage.
- Do not clean the machine by means of a vapor jet or
a high pressure cleaning equipment. Clean the
brush head with a water hose (pressure: 5 to 6 bar
max.) and from the bottom only.

14
RootsScrub RB 800 C
MAINTENANCE
Electrical System
Main control module
& Traction motor controller
Cover electrical module
The electrical system houses the main control module
and the traction motor controller.
- Do not open the cover of the electrical module.
- Remove key before carrying out any electrical
work.
- During battery top up ensure that the cover
electrical module is closed securely.
- Never open the cover electrical module in dusty
areas.
- DO NOT TAMPER WITH THE ELECTRICAL MODULE
OR THE CONTROLLER.
- Do not dispose the replaced electrical/electronic
components in to the environment.
Service Display
Fuse Error Codes
- software version
is displayed
- battery type
is displayed
- total operated hours
is displayed
V 02 LA 0000
The hour meter holds the service display. Upon turning on the
following are successively displayed:-
Error Code Description What to do ?
EF 01 F1 Fuse blown
Brush motor 1 is overloaded.
Rectify the cause and replace
the fuse.
EF 02 F2 Fuse blown
Brush motor 2 is overloaded.
Rectify the cause and replace
the fuse.
EF 03 F3 Fuse blown
Suction turbine is
overloaded. Rectify the cause
and replace the fuse.
If a malfunction occurs during operation, e.g. a defective fuse, a 4-
digit number appears in the hour meter display with 4 dots
flashing and a buzzer sounding. This 4- digit number advises the
technician in detail on the last error found.

Other Error Codes
(For RMCL service engineers reference only)
15
RootsScrub RB 800 C
Error
Code
No.of Alarm
LED Blinks Description What to do ?
A 1 1 FNR switch(-S3) at forward
position when power-on
Put the accelerator pedal to zero and set
the FNR switch in neutral at power-on.
A2 2 FNR switch(-S3) at reverse
position when power-on
Put the accelerator pedal to zero and set
the FNR switch in neutral at power-on.
A3 3 Potentiometer(-S6) in the
accelerator pedal fault. Check the potentiometer (-S6) wires
A4 4 Potentiometer(-S6) out of
neutral position at power on
Move the potentiometer to neutral
position or,if it is in neutral position
already, calibrate the speed reference.
A5 5 Thermal protection
Wait few minutes and check the motor
current. If it is high rectify the cause and
then use.
A6 6 Controller power stage
damaged Change the drive controller.
A7 7 Over current 1: short circuit Check the motor wires: if OK, and the
controller repeats this alarm, change it
A8 8 Over current 2: short circuit Check the motor wires: if OK, and the
controller repeats this alarm, change it
A9 9 Under voltage Check the battery's charge
A10 10 Over voltage Battery voltage upper than 45V : Check the
battery
A11 11 Overload protection
Check whether the traction motor brake
functions properly. If not replace brake
immediately and use. Check the motor
working current.
A12 12 Disable switch on
Check the parking brake limit switch ( if
used). This alarm will reset by resetting the
keyswitch (-S1).
A13 13 Key-off sequence detected Check the key switch(-S1) connections
A14 14 E2 prom fail Check your settings: if the controller
repeats this alarm, change it
MAINTENANCE

16
RootsScrub RB 800 C
Compliance with our recommendations concerning
maintenance work will give you the certitude always having
a machine at your disposal, which is ready to work and in
good operating condition. Please contact your local
distributor; the people there will be glad to perform that
work for you.
- Well trained personnel and genuine spare parts are at your
disposal.
- In case of any inquiries or orders for spare parts, please
always quote the machine's serial number mentioned on
the nameplate.
- The name plate is fixed in the rear side of the machine.
- When cleaning or servicing the machine, and when
replacing any parts, shut off the machine and on principle
disconnect the power plug from the power supply.
- For reasons of safety during cleaning and/or maintenance
work in or on the tank, the tank lid - when lifted - must be
secured so as to prevent accidental closing or tilting down.
- The machine may be taken into operation only if all
guarding devices are fitted and in protective position. As
far as possible, cleaning should not be done by hand, but
using appropriate tools or equipment.
- Maintenance and repair work may be carried out only by
means of suitable tools and by the people trained in the
factory - for reasons of safety, only genuine spare parts may
be used.
Maintenance Work Maintenance Schedule
daily every 50 every 200 every 500
Recharge batteries according to charger unit
instructions
Empty and clean dirty water tank
Check condition of squeegee lips
Check squeegee for foreign particles taken
and clean if required
Clean filter in fresh water tank
Check battery poles and apply grease if
required
Check tight fitting and condition of suction
hose between squeegee and dirty water tank
Check squeegee lips for wear and turn or
replace if required
Check brushes and water retaining ring for
tight fitting and condition and replace if
required
Check function of float
Check rotational direction of the brushes
Check function of brake
Check squeegee holder and castor roller, re-
adjust if required
Check fresh water supply to the brushes
Clean traction motor from carbon dust and
check the accessible carbon brushes for
smooth running and condition, replace if
required
Clean electro-motor from carbon dust and
check the accessible carbon brushes for
smooth running and condition, replace if
required
Grease steering pinion and gear ring
Check joints at squeegee holder and grease if
required
Service Hours
Maintenance Table
Greasing Points
Greasing point
MAINTENANCE

TROUBLESHOOTING
17
RootsScrub RB 800 C
Problem Cause Remedy
Poor water recovery Tank gasket faulty Contact service
Drain hose leak Hook up drain hose and close
Suction turbine faulty Contact service
Battery charge low Recharge battery
Tires noisy Bearing dry Grease bearings
Faulty hubs Contact service
Poor traction Excessive brush pressure Reduce pressure
Worn traction tire Replace tire
Heavy soap concentration Contact service
Short run time Battery run down Charge battery twice
Battery still down Contact service
Battery low on water Refill with distilled water
Battery over cycled Contact service
Problem Cause Remedy
No power - nothing works Faulty power switch Contact service
Battery need to be recharged Recharge battery
Faulty battery Replace battery
Loose battery cable Tighten loose cable
Main fuse blown Rectify the cause & Replace the
fuse
Brush motor does not work Accelerator pedal is not depressed Depress accelerator pedal
Main fuse blown Rectify the cause & Replace the
fuse
Faulty brush motor or loose cable Contact Roots service
Suction turbine does not
work Faulty suction turbine switch Replace switch
Suction turbine fuse blown Replace the fuse
Faulty suction turbine Contact Roots service
Carbon brushes worn Contact Roots service
Insufficient water flow Water tank low Refill fresh water
Water pump not On Switch On water pump
Water line clogged Remove and blow with
compressed air
Water pump clogged Remove and clean
Poor water recovery Dirty water tank is full Empty dirty water tank
Suction hose is clogged Remove debris
Squeegee is clogged Remove debris
Squeegee lip is worn Rotate or replace lips
Faulty vacuum hose Contact service

DO’S & DON'T’S
Do’s Don't’s
1. Charge the batteries after it has been completely discharged.
2. Charge the batteries only in a well ventilated area.
3. Use only clean water to fill the fresh tank.
4. Fill fresh water till the marked level only.
5. Clean the fresh water filter after each cleaning cycle.
6. Empty the dirty water at a specified draining area.
7. Clean the dirty water tank and collection tray after each cleaning cycle.
8. Clean the suction float assembly if any dirt is noticed.
9. Clean the squeegee after every cleaning cycle.
10. Use only recommend cleaning solutions.
11. Wipe the machine at the end of the day.
12. Drive at a slow speed on ramps and uneven surfaces.
13. Use only recommended brushes for the specified floors.
14. Park the machine in a covered dry place.
15. Clean the debris tray at the end of each work routine.
1. Do not charge the batteries between cleaning cycle.
2. Do not use the machine for transporting goods or persons.
3. Do not modify the machine.
4. Do not fill water beyond 50°C.
5. Do not use harsh or acidic solutions.
6. Do not empty the dirty water in a habitable area.
7. Do not drive with the fresh water tank open.
8. Do not stand on the brush head and squeegee.
9. Do not park the machine on ramps or slopes.
10. Do not place any objects on the battery while charging.
11. DO NOT TAMPER WITH THE ELECTRICAL CIRCUITS.
12. Do not open the electrical module cover.
13. Do not adjust the drive motor controller.
14. Do not clean the machine with a high pressure cleaning system.
15. Do not abuse the machine beyond its operable limit.
16. Do not mix brushes and use.
17. Do not park the machine by exposing it to the natural elements.
18. Do not use the machine to tow or push other equipments.
19. Do not over fill the distilled water in the battery.
18
RootsScrub RB 800 C

36 V
24 V
80 V
24 V
No m i n a l p lu g v o l t ag e i s
indicated on each side of the
hexagon (letters upside down)
I n d i c a t i o n f o r
n o m i n a l s o c k e t
voltage accordingly
Replace the coding plugs by pressing the ends together
with pliers.
All battery plugs at machines, batteries and battery
charger units have to be coded with the colored coding
pins according to the battery type and the charger unit
plugs are/will be seteristic curve such that a modification
of the curve (in relation to the battery type) requires
changing of the plug coding nominal voltage.
Press together for removal
Insert coding plug such that the nominal voltage
inscription is visible through the case window. Socket and
p l u g o n l y w i t h t h e s a m e n o m i n a l v o l t a g e .
The following three conditions have to be met:
1) Voltage coding must be the same for all sockets and
plugs.
2) Coding pin colour in the machine = yellow
3) Coding pin colour in the charger unit = the same as for
the battery plug according to battery type.
Before first operation of the machine, fully charge the
battery with an initial charging procedure and comply
with the operating instructions of the charger
as well as with those of the battery manufacturer. Roots
cannot be held liable for damages resulting from the fact
that the initial charging has not or insufficiently been
done.
Before using the machine
Battery plug coding
BATTERY SYSTEM
Plug case of charger units :
Grey for fluid-filled batteries, Green for maintenance-
free Gel batteries
Plug case of machine :
Yellow for both battery types
Socket case of battery: Grey for fluid-filled batteries :
Green for maintenance-free
Open the seat console of the machine
before performing charging operations.
Coding system in the charger unit for fluid-filled batteries
Example 24V Battery System
Charging procedure for traction block batteries
- Drain both the tanks
- Move machine near charger location
- Switch Off Key
- Remove key
- Tilt operator seat forward completely
- Disconnect the battery plugs and connect them to the
charger supplied with the machine.
- Make sure to connect the charger to the
specified voltage and frequency.
- Ensure that the seat cover is completely open.
- Do not place any objects on the battery.
Charge the batteries in a well ventilated area.
Do not tamper with the charger settings.
19
RootsScrub RB 800 C

BATTERY SYSTEM
20
RootsScrub RB 800 C
Safety symbols for traction battery system
-Observe the instruction which
must be mounted clearly at the
charging point!
-No Smoking!
-No naked lights, embers or sparks
in the vicinity, risk of fire and explosion!
- Risk of fire explosion, avoid short circuits!
- Caution! Metal components in the battery
cells are always under voltage, never
place any foreign items or tools on the
battery!
-Wear protective goggles and protective
clothing when working on the batteries!
-Do not tilt the battery!
-Only use certified hoisting and
transport equipment.
-Do not throw in garbage!
-Keep children away from batteries
-Charge in a well-ventilated area
-Electrolyte is highly corrosive!
-Any splashes of acid in the eyes or
on the skin must be rinsed throughly
with plenty of clear pure water.
-Then consult a doctor immediately!
Traction Batteries (LA)
The above instructions have been
established for your safety and
have to be strictly observed.
1. Initial Checking-
Check the battery to ensure that it is in perfect mechanical
condition. All screwed unions within the circuit must be tightened
to ensure reliable contacts. Machine cables and charging cable
are to be connected to the correct poles of the battery otherwise
battery and charger can be damaged.
2. Discharging-
Ventilation openings may not be covered or closed. Electric
connections (e.g-plugs) may be connected or disconnected only
when the machine is in off condition. Discharge batteries must be
recharged immediately and may not remain in discharged
condition. This also applies to only partially discharged batteries.
The battery may only be connected up to the allocated battery
charger certified for the particular battery size, to avoid overload
on the electric current Maintenance Free Batteries have low
gassing properties but are not completely free of gassing. The
battery is to be connected with the correct poles (plus to plus and
minus to minus) to the disconnected battery charger. The battery
charger should then be switched on.
During the recharging procedure, the temperature in the
battery increases by approx. 10 °C. For this reason, the
recharging procedure may not be started unless the
temperature is below 35 °C.
Before recharging the battery, the temperature should be at
least 15 °C, otherwise the battery will not be correctly.
If the temperatures are constantly greater than 40 °C or
lower than 15 °C, temperature-dependent constant voltage
regulation of the battery charger will be necessary.
3. Temperature-
The battery temperature of 30 °C is rated temperature.
Higher temperatures shorten the service life and lower
temperatures reduce available capacity. 45 °C (51 °C for
AGM) is the limit temperature and is not tolerable as
operating temperature.
4. Electrolyte-
The electrolyte is sulphuric acid. The density of the
electrolyte cannot be measured. Use the recommended
electrolyte to top up.
5. Maintenance-
Daily maintenance- Recharge the battery every time it has
been discharged.
Weekly maintenance- Visual inspection after recharging for
signs of dirt and mechanical damage.
Maintenance to be carried out every three months
After fully recharging and following a standing period of at
least 5 hours, the following must be measured and
Recorded: – total voltage / – individual voltage
If noticeable changes are detected compared to previous
measurements, or differences between the cells or block
batteries, the customer service should be called for testing
or repair.
6. Care-
The battery must be kept clean and dry to prevent creeping
current. Any liquid in the battery container must be
extracted and disposed of according to regulations.
